TRENDnet TE100-S1616V Specifications

TE100-S1616V
16-port 10/100Mbps N-way VLAN Switch
TRENDnet's unique 16-port 10/100Mbps N-way VLAN Switch has
an optional fiber optic and BNC (10Base-2) module that makes this
switch flexible enough for mid-sized companies and branch offices
to meet their high bandwidth requirements. The TE100-S1616V
supports both 10/100Mbps speed and half-/full-duplex modes on
the same port. Additionally, it features programmable
reconfiguration for half-duplex and full-duplex modes. By using
standard auto-negotiation, it provides a cost-effective way of
integrating 10Mbps segments with 100Mbps Fast Ethernet
networks, ideal for extending the distance between two 100Mbps
network segments. Supporting Virtual Local Area Net-working
(VLAN), the TE100-S1616V is powerful and easy-to-use in
reducing unnecessary broadcast traffic, segment the network, and
enhance network security.
FEATURES
Complies with IEEE 802.3 10Base-T, IEEE 802.3µ
100Base-TX/FX standards
16 10/100Mbps auto-negotiation and auto-sensing ports
Supports four Port-based VLAN
Programmable reconfiguration for half- and full-duplex
modes
Store-and-forward packet switching
Half- and full-duplex operation for all UTP and fiber ports
Supports 1,024 MAC address
Auto-learning of network configuration
Push button uplink port (shared) for easy expansion
Optional fiber module port (multi-mode SC-type) or
10Base-2 BNC module
Plug and Play
Front panel port status LEDs
EIA-19 rack mountable
5 Year Warranty
TRENDnet
TRENDware, USA
What's Next in Networking
BENEFITS
Easy Upgrade:
Ethernet workgroups are able to
upgrade to Fast Ethernet by changing
adapters and a hub without changing
switches.
Expandability:
Expand the connection up to 2km with
optional fiber module or optional BNC
module (10Mbps thin coax cable).
Flexibility:
Port-based VLAN reduces broadcast
traffic and enhance network security.
Cost Effective:
Provides non-blocking high
performance with internal switch
controller.
Performance:
The TE100-S1616V presents
10/100Mbps of Fast Ethernet at an
affordable rate.
TE100-S1616V (11-17-2002)
