Troubleshooting

Problem
Motor not running. Power supply not connected.
Motor protection tripped.
The engine stops Incorrect fuse.
immediately after
Motor protection tripped.
starting.
Motor runs, but no Suction hose not connected.
suction.
Hose blocked.
The container is not properly fitted.
Motor runs, but Suction hose perforated.
poor suction.
Blocked filter.
Suction hose too long or narrow.
Hose partially blocked.
Top of machine poorly fitted.
Dust trapped in cyclone.
Abnormal sound
from machine.
*) The motor protection must never be readjusted as it is set from the factory to protect against overheating.
The middle picture shows tripped motor protection.
DC 5800 H Turbo EX
Cause
Connect power supply.
Investigate why the motor has overloaded and rectify. Note that if the machine
has been operating with too much throttle, the motor protection has tripped
to protect against overheating. Wait for 5 minutes. Reset by first turning to 0
position and then to start position. See picture below the table.*)
Replace with correct fuse.
Investigate why the motor has overloaded and rectify. Note that if the machine
has been operating with too much throttle, the motor protection has tripped
to protect against overheating. Wait for 5 minutes. Reset by first turning to 0
position and then to start position. See picture below the table.*)
Connect hose.
Reverse or clean hose.
Fit the container.
Replace hose.
Clean or replace.
Replace hose.
Reverse or clean hose.
Adjust fitting.
Remove top and clean cyclone.
Book service.
38
Action
