5. Specifications
Input/Output Connectors
Input
Output
Resolutions
HDMI
VGA
Operating Frequency
HDMI Video Amplifier
Bandwidth
Environmental
Operating
Temperature
Operating Humidity
Storage Temperature
Storage Humidity
Power Requirement
External Power Supply
(Optional)
Regulatory Approvals
Converter Unit
© Copyright 2016, 2024. Black Box Corporation. All rights reserved. Black Box
logo are registered trademarks of BB Technologies, Inc. Any third-party trademarks appearing in this
manual are acknowledged to be the property of their respective owners.
EN_CABL_Datasheet_VA-HDMI-VGA-R2_Rev1_2403
HDMI Male, Micro USB Female (optional
power)
VGA DB15HD Female, 3.5 mm Female audio
(analog)
Up to 1080p @60 Hz
Downstream up to 1080p @ 60 Hz
720p@60Hz
1.65 Gbps /165 MHz
32 to 113° F (0 to +45° C)
10 to 85% RH (no condensation)
-14 to +176° F (-10 to +80° C)
5 to 95% RH (no condensation)
Micro USB: Min 5V/500ma
FCC,CE
877-877-2269 | blackbox.com
and the Double Diamond
®
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Black Box VA-HDMI-VGA-R2
Summary of Contents for Black Box VA-HDMI-VGA-R2
- Page 1 (Optional) Regulatory Approvals Converter Unit FCC,CE © Copyright 2016, 2024. Black Box Corporation. All rights reserved. Black Box and the Double Diamond ® logo are registered trademarks of BB Technologies, Inc. Any third-party trademarks appearing in this manual are acknowledged to be the property of their respective owners.
- Page 2 Before installation, make sure all the devices you wish to connect are powered off. 1. Connect the VA-HDMI-VGA-R2 unit’s HDMI A input to an HDMI source display. 2. Attach the VA-HDMI-VGA-R2 unit’s VGA output to a VGA display with a VGA cable.
