Black Box VA-HDMI-VGA Quick Start Manual

HDMI Male to VGA Female Adapter Dongle

1. Introduction

The HDMI Male to VGA Female Adapter Dongle (VA-HDMI-VGA) enables you to
convert a digital HDMI signal into an analog VGA signal and extract the audio signal
from an HDMI signal through the 3.5-mm audio port. If the HDMI source can't
supply enough power, you can connect a power adapter or computer to the
Micro USB female port to supply power for the adapter.

2. Features

• Supports HDMI A and Micro USB input, VGA, and R/L audio output.
• Provides HDMI resolutions up to 1080p @ 60 Hz, with HDMI bandwidth
up to 165 MHz / 1.65 Gbps per channel (6.75 Gbps for all channels combined).
• Enables analog audio format.
• Supplies USB bus power up to 2 W.
• Uses HDCP.

3. Package Includes

• One Dongle
• This manual

4. Connecting the VA-HDMI-VGA

Before installation, make sure all the devices you wish to connect are powered off.
1. Connect the VA-HDMI-VGA unit's HDMI A input to an HDMI source display.
2. Attach the VA-HDMI-VGA unit's VGA output to a VGA display with a VGA cable.
3. Link a headset and stereo video speakers to the VA-HDMI-VGA unit's output jack.
4. If the HDMI source can't supply enough power, you can connect the Micro USB
port to a computer or power adapter.
