  • Page 1 LED BossFx-2 Pro Bundle LED Lighting Set...
  • Page 2 Thomann GmbH Hans-Thomann-Straße 1 96138 Burgebrach Germany Telephone: +49 (0) 9546 9223-0 Internet: www.thomann.de 04.12.2023, ID: 466569 (V5)
  • Page 3: Table Of Contents

    Table of contents Table of contents General information......................5 1.1 Symbols and signal words................... 5 Safety instructions......................... 6 Features............................8 Installation..........................9 Starting up..........................12 Connections and controls....................13 Operating..........................15 7.1 Starting and stopping operation................15 7.2 Main menu........................15 7.3 Menu overview......................
  • Page 4 LED BossFx-2 Pro Bundle LED Lighting Set...
  • Page 5: General Information

    Our products and documentation are subject to a process of continuous develop‐ ment. They are therefore subject to change. Please refer to the latest version of the documentation, which is ready for download under www.thomann.de. 1.1 Symbols and signal words In this section you will find an overview of the meaning of symbols and signal words that are used in this document.
  • Page 6: Safety Instructions

    Safety instructions Safety instructions Intended use This device is intended for use as an electronic lighting effect by means of LED tech‐ nology. The device is designed for professional use only and is not suitable for use in households. Use the device only as described in this user manual. Any other use or use under other operating conditions is considered to be improper and may result in personal injury or property damage.
  • Page 7 Safety instructions CAUTION! Risk of injury due to tipping of the stand during loaded transport! If the stand is moved without having removed the installed devices, the stand may tip over and cause injuries and property damage. Remove the installed devices before transporting the stand. NOTICE! Risk of fire due to covered vents and neighbouring heat sources! If the vents of the device are covered or the device is operated in the immediate vicinity of other heat sources, the device can...
  • Page 8: Features

    Features Features Special features of the device: 2 LED spots each with 6 tricolour LEDs, 9 W each Derby effect each with 6 tricolour LEDs, 3 W each Stroboscope with 4 LEDs, 2 W each (white and ultra-violet) Control via DMX (4 different modes), buttons and display on the unit, the sup‐ plied wireless foot switch and the supplied infrared remote control Preprogrammed automatic shows Sound control...
  • Page 9: Installation

    Installation Installation Unpack and check carefully there is no transportation damage before using the unit. Keep the equipment packaging. To fully protect the product against vibration, dust and moisture during transportation or storage use the original packaging or your own packaging material suitable for transport or storage, respectively. WARNING! Risk of injury from falling devices that were inadequately secured! If devices are not properly secured during assembly, they can cause...
  • Page 10 Installation NOTICE! Potential property damage due to unsuitable stands! If the device is mounted on an unsuitable stand, there is a risk that the stand will fall over and cause damage. Only use stands whose maximum bearing capacity is at least as high as the weight of the device.
  • Page 11 Installation Inserting the battery into the remote Push the lock of the battery holder towards the centre of the housing and pull out control the battery holder like a drawer. Insert the batteries. The battery is correct if the posi‐ tive pole points to the housing base of the remote control.
  • Page 12: Starting Up

    This equipment uses a frequency range that is free of charge and registration within the European Union. For more information, please visit: http://www.thomann.de. Make sure that no metal objects are located between transmitter and receiver. Avoid interference by other radio and in-ear systems.
  • Page 13: Connections And Controls

    Connections and controls Connections and controls Front ö ö ö ö DMX OUT DMX IN MICROPHONE SENSITIVITY FUNCTION SETTING POWER INPUT: 100-240V~50/60Hz/130W MENU DOWN ENTER FUSE: T3.15AL250V %& 1 Strobe LEDs 2 Microphone for sound control 3 [IR] | Infrared sensor for the remote control signals 4 [POWER OUTPUT] | Rubber panel socket for the power supply of further devices 5 Rubber panel plug for the power supply with fuse holder 6 [DMX IN] / [DMX OUT] | DMX input and output...
  • Page 14 Connections and controls Wireless foot switch POWER TRANSMITTER AUTO MUSIC COLOR BLACKOUT 9 [AUTO] | Activates “Automatic” mode (playback of pre-programmed automatic shows). 10 [MUSIC] | Activates “Sound control” mode (playback of sound-controlled automatic shows). 11 [COLOUR] | Starts the automatic colour change or stops it again. 12 [BLACKOUT] | Blacks out all LEDs or turns them back on again.
  • Page 15: Operating

    Operating Operating 7.1 Starting and stopping operation Starting Complete the following steps to start operation: Connect the device to the power grid. After a few seconds, the fan and the motors start to work. The display shows the current operation mode. The device is now operational. Turn the foot switch on.
  • Page 16 Operating Main menu Menu level 2 Menu level 3 Meaning ‘SouN’ Selecting a sound-controlled automatic show for all compo‐ nents ( ‘SM01’ … ‘SM03’ ) ‘CoL’ Manual colour selection for the LED spots ‘r.xxx’ Setting intensity red ( ‘r.000’ … ‘r.255’ ) ‘G.xxx’...
  • Page 17: Menu Overview

    Operating 7.3 Menu overview AutP AP01 S.01 N.01 SouP SP01 COLO d001 SLAV LEdS AP18 S.99 N.99 SP18 04CH d001 r.000 tESt AutF AF01 S.01 SouF SF01 r.255 d509 rESt AF12 S.99 SF11 05CH d001 G.000 W-EN AutN AN01 S.01 SouN SN01 d508...
  • Page 18: Functions In 5-Channel Dmx Mode

    Operating Channel Value Function 188…190 AP15 / SP15 191…203 AP16 / SP16 204…216 AP17 / SP17 217…255 AP18 / SP18 Strobe LEDs 0...5 Blackout 6...24 AF01 / SF01 25...43 AF02 / SF02 44...62 AF03 / SF03 63...81 AF04 / SF04 82...100 AF05 / SF05 101...119...
  • Page 19: Functions In 7-Channel Dmx Mode

    Operating Channel Value Function 5…127 Clockwise rotation, speed increasing 128…133 Stopped 134…255 Counter-clockwise rotation, speed increasing 7.6 Functions in 7-channel DMX mode Channel Value Function LED spots and derby effects 0…255 Intensity Red (0 % to 100 %) 0…255 Intensity Green (0 % to 100 %) 0…255 Intensity Blue (0 % to 100 %) 0…191...
  • Page 20 Operating Channel Value Function 0…255 Intensity Blue (0 % to 100 %) 0…9 No function 10…255 Strobe effect with increasing speed, 30 Hz at max Motor control 0…4 Stopped 5…127 Clockwise rotation, speed increasing 128…133 Stopped 134…255 Counter-clockwise rotation, speed increasing LED spot 1 0…255 Intensity Red (0 % to 100 %)
  • Page 21 Operating Channel Value Function 5…9 LED on 10…255 Strobe effect with increasing speed LED 2, white 0…4 Blackout 5…9 LED on 10…255 Strobe effect with increasing speed LED 3, white 0…4 Blackout 5…9 LED on 10…255 Strobe effect with increasing speed LED 4, white 0…4 Blackout...
  • Page 22: Technical Specifications

    Technical specifications Technical specifications Light source LED spots: 12 × 9 W RGB LEDs 1500 mm Derby effects: 12 × 3 W RGB LEDs Strobe LEDs: 4 × 2 W LEDs (white and ultraviolet) Control DMX, infrared remote control, wireless foot switch, buttons and display on the device Number of DMX channels 4, 5, 7 or 25...
  • Page 23: Plug And Connection Assignment

    Plug and connection assignment Plug and connection assignment Introduction This chapter will help you select the right cables and plugs to connect your valuable equipment so that a perfect light experience is guaranteed. Please take our tips, because especially in ‘Sound & Light’ caution is indicated: Even if a plug fits into a socket, the result of an incorrect connection may be a destroyed DMX controller, a short circuit or ‘just’...
  • Page 24: Troubleshooting

    Troubleshooting Troubleshooting In the following we list a few common problems that may occur during operation. We give you some suggestions for easy troubleshooting: Symptom Remedy The unit does not work, no light, the fan does 1. Check the power connection and main fuse. not run No response to the DMX controller 1.
  • Page 25: Cleaning

    Cleaning Cleaning Optical lenses Clean the optical lenses, that are accessible from the outside, regularly in order to optimize the light output. The frequency of cleaning depends on the operating envi‐ ronment: wet, smoky or particularly dirty surroundings can cause more accumulation of dirt on the optics of the device.
  • Page 26: Protecting The Environment

    Repairing a device or passing it on to another user is an ecologically valuable alternative to disposal. You can return your old device to Thomann GmbH at no charge. Check the current conditions on www.thomann.de. If your old device contains personal data, delete those data before disposing of it.
  • Page 28 Musikhaus Thomann · Hans-Thomann-Straße 1 · 96138 Burgebrach · Germany · www.thomann.de...
