Fig.3. Example of the basic supply–exhaust unit (FPV) with additional coils section (HC):
1 – filters, 2 – counter–flow heat exchanger, 3 – fans, 4 – heater, 5 – cooler, 6 – droplet eliminator
VVS005s–030s AHUs
configurable sections. One can find recovery
section with very high efficiency counter–flow
plate heat exchanger, filters (M5 and F7) and
fans with EC motors. For that main unit is
possible to choose additional section with
Table 2 Functionality and length of the sections
Function
F Filter
H Water heater
HE Electric heater
C Cooler (water or freon)
C_de Cooler with droplet eliminator
HC Water heater and cooler
HC_de Water heater and cooler with droplet eliminator
HEC Electric heater and cooler
HEC_de Electric heater and cooler with droplet eliminator
FPV Plate heat exchanger, filters and fans
V Fan
FV Filter and fan
FHV Filter, water heater and fan
FHEV Filter, electrc heater and fan
FCV Filter, cooler and fan
FCV_de Filter, cooler with droplet eliminator and fan
FHCV Filter, water heater, cooler and fan
FHCV_de Filter, water heater, cooler with droplet eliminator and fan
FHECV Filter, electric heater, cooler and fan
Filter, electric heater, cooler with droplet eliminator and
FHECV_de
fan
S Silencer L=370
S Silencer L=740
E Empty section L=370
E Empty section L=740
*for section with cooling coils bigger than 4 rows
OMM–VTS–ver.2.4 (01.2020)
consist of freely
Name
heater (water and electric, cooler (water and
Freon), secondary filter and silencer. The
functions like filtration, heating and cooling are
also available installed in one section with a
fan (tab.2, fig.4).
VVS VVS VVS
005s 010s 015s
L [mm]
1500
1230
370
460
460
740 1030 1030
740 860/1030*
860 1030
860 1030
1030
1030 1230
1230 1380
VVS VVS
020s 030s
180
180
370
370
460
460
600
740
860
1828
460
740
740
1100
1110
1110
1100
1230
1380
1450
370
740
370
740
