- Page 1 User manual Evolux 100-45 This product is not suitable for primary heating purposes Version number: 01-350342 Serial number: Date: 26-05-2021 Production date:...
- Page 2 Barbas Bellfires BV. This document could contain technical inaccuracies or typographical errors. Barbas Bellfires BV reserves the right to revise this document from time to time in the contents thereof.
-
Page 3: Table Of Contents
7.3.2 Reload with fuel.......................20 7.3.3 Control the burn process ....................20 7.3.4 General firing tips......................22 Firing the appliance with the optional Barbas Opti-Air system...........22 7.4.1 Installation of the Opti-Air app ..................22 7.4.2 First load and ignition with Opti-Air................. 22 7.4.3 Reload with fuel with Opti-Air..................24 7.4.4 General firing tips...................... - Page 4 Clean the glass.......................... 26 8.3.1 Access to inside of door ....................27 Opti-Air system ......................... 29 Troubleshooting..................30 Information on disposal of the appliance ..........32 Technical data ..................33 Product information according regulation (EU) 2015/1185....34 Warranty Terms..................36 Evolux 100-45...
-
Page 5: Declaration Of Performance
Name, registered trade name or registered trade Barbas Bellfires BV; Hallenstraat 17; 5531 AB Bladel; The Netherlands mark and contact address of the manufacturer as required pursuant to Article 11(5) -
Page 6: Evolux 100-45 Opti-Air
Name, registered trade name or registered trade Barbas Bellfires BV; Hallenstraat 17; 5531 AB Bladel; The Netherlands mark and contact address of the manufacturer as required pursuant to Article 11(5) -
Page 7: The Clean Air Act 1993 And Smoke Control Areas
21 of the Clean Air Act 1993 and can be used in accordance with the intended use as described in this manual in smoke control areas in the UK. The Barbas Evolux 100-45 incorporates a factory-fitted modified air control Under the Clean Air Act local authorities may declare the whole or part of the district of the authority to be a smoke control area. -
Page 8: About This Document
About this document About this document This document shows the necessary information to do these tasks on the Evolux 100-45: • Operate the appliance • Do basic maintenance This document refers to the Evolux 100-45 as 'the appliance'. This document is an essential part of your appliance.Read it carefully before you do work on the appliance. -
Page 9: Description
This helps you to achieve an efficient and clean combustion at all times. You can operate the Opti-Air device with the Barbas Opti-Air app on your mobile device. With this app you have the possibility to choose different combustion levels or the possibility to control the room temperature. -
Page 10: Overview Of The Barbas Opti-Air App
• With the Barbas Opti-Air system it is not possible to manually control the amount of combustion air into the appliance. 4.2.2 Overview of the Barbas Opti-Air app... -
Page 11: Combustion Levels
Room temperature Statistics • Combustion chamber temperature • Chimney draught 4.2.3 Combustion levels The Opti-Air system has 3 combustion levels to choose from. Each combustion level is a pre-defined thermal output. Combustion level Thermal output Minimum Nominal Maximum Evolux 100-45... -
Page 12: Combustion Modes
Description The Barbas Opti-Air app indicates when the Burning or Refill combustion mode starts. This is dependent on the gas temperature and the chosen combustion level. Combustion level Burning Refill Gas temperature must be higher Gas temperature must be lower than... - Page 13 Description The appliance is intended for intermittent use and is not intended for continuous use. The appliance is intended to heat the room by direct heating. It is not allowed to connect the appliance to a central-heating installation. Evolux 100-45...
-
Page 14: Safety
Note: • Do inspect and clean the appliance, the chimney and the external combustion air supply by a Barbas dealer minimum every year. • Do not use the appliance continuously. The intended use is as intermittent appliance. - Page 15 Dispose of ceramic heat-resistant glass as household waste. Do not dispose of ceramic heat-resistant glass in a glass recycling container. • Dispose of an obsolete appliance according to instructions of the authorities or the fitter. • Obey the local regulations. Evolux 100-45...
-
Page 16: Fuel
Approximately 25 cm The above listed amount burns for approximately 45 minutes. This time can be different, dependent on the chimney draught and the position of the combustion air valve or the chosen combustion level (for Opti-Air system). Evolux 100-45... - Page 17 Fuel Attention: The amount of fuel specified here should not be exceeded, overloadingcan cause excess smoke. Evolux 100-45...
-
Page 18: Operation
Make sure that all package material, stickers, etc, has been removed from the vicinity of the appliance after installation. 7.4.1 10. If applicable, download and install the Barbas Opti-Air app. Refer to chapter detailed instructions. First use of the appliance Caution: •... -
Page 19: Firing The Appliance (Without Opti-Air)
When present, open the chimney valve completely. Open the door of the appliance. Put 8 wood logs crosswise on the floor of the combustion chamber. Put a layer of small wood logs and 2 firestarter cubes on top of the wood logs. Evolux 100-45... -
Page 20: Reload With Fuel
If desired and applicable, close the safety screen. If desired and applicable, start the convection ventilator. 7.3.3 Control the burn process Note: If the appliance has the Opti-Air option refer to chapter instructions on the control of the burn process. Evolux 100-45... - Page 21 Continuous firing with the primary air inlet fully open (control lever in the far right position) causes a white-hot fire that can damage the appliance. Use the primary air only during the first fuel load and for ignition of a new fuel load. Evolux 100-45...
-
Page 22: General Firing Tips
If the appliance has the optional Opti-Air system, the appliance automatically controls the amount of combustion air. With the Barbas Opti-Air app for Android and iOS it is possible to select from 3 different combustion levels or to select room temperature control. - Page 23 After approximately 20 minutes the wood logs burn. Dependent on the quality of the chimney the wood logs burn for approximately 1 to 1.5 hours. Do not open the door of the appliance before the last flames have almost disappeared. Evolux 100-45...
-
Page 24: Reload With Fuel With Opti-Air
If thereare too few embers in the fire bed, add suitable kindling to prevent excessive smoke. Note: The procedure hereunder is a general description. The Barbas Opti-Air app indicates when a reload with wood logs is neccesary. The Opti-Air system works best with closed door during operation. - Page 25 Start the convection ventilator by turning the dimmer knob clockwise in the ON position. • Set the desired ventilator speed by turning the dimmer knob. • Stop the convection ventilator by turning the dimmer knob counterclockwise into the OFF position Evolux 100-45...
-
Page 26: Maintenance
To access the inner side of the glass, refer to chapter Make sure that the glass is dry. Water droplets can leave a mark on the glass. Note: Damaged or broken glass must be replaced before the appliance can be used again. Evolux 100-45... -
Page 27: Access To Inside Of Door
Maintenance 8.3.1 Access to inside of door Make sure the door is closed. Rotate the frame forward. Evolux 100-45... - Page 28 Rotate the door forward. The inside of the door and the glass is now accessible for inspection and cleaning. To close the door and frame do steps 2 to 4 in reverse order. Make sure the door lock is is locked. Evolux 100-45...
-
Page 29: Opti-Air System
Replace the 9 V battery and close the battery holder. Put the battery holder and ventilation air inlet grate back. Post requirements • Change the 9 V back-up battery every year. Evolux 100-45... -
Page 30: Troubleshooting
The chimney draught is too Contact your installer. high • Do the recommended ignition Excessive smoke escapes procedure. Refer to section The chimney draught is too when the door of the combus- 7.3.1 tion chamber is open • Contact your installer. Evolux 100-45... - Page 31 The residual cient ventilated black particles flow via the • Avoid as much as possible the convection air outlet to the presence of household parti- room. cles. It is recommended to use a vacuum cleaner every day. Evolux 100-45...
-
Page 32: Information On Disposal Of The Appliance
Insulating plates used Calcium silicate Remove from appli- Dispose as building for the fireplace ance . construction waste (stone) Gaskets Glass fibre cord or Remove from appli- Dispose as glass fibre plates ance and components (non-flammable waste) Evolux 100-45... -
Page 33: Technical Data
Technical data Technical data Name Barbas Barbas Model Evolux 100-45 Evolux 100-45 Opti-Air EPREL registration number 257907 1257233 EN 13229:2001-A2:2004 EN 13229:2001-A2:2004 Tested in accordance with EN 16510-1 annex D, E, F EN 16510-1 annex D, E, F Energy efficiency index (ac-... -
Page 34: Product Information According Regulation (Eu) 2015/1185
Product information according regulation (EU) 2015/1185 Product information according regulation (EU) 2015/1185 Model identifier Evolux 100-45 Equivalent models N.A. Indirect heating function Direct heat output 19.6 kW Indirect heat output - kW Emissions at nominal heat Emissions at minimum heat... - Page 35 Product information according regulation (EU) 2015/1185 Model identifier Evolux 100-45 Opti-Air Equivalent models N.A. Indirect heating function Direct heat output 21.9 kW Indirect heat output - kW Emissions at nominal heat Emissions at minimum heat output (*) output (*)(**) Preferred...
-
Page 36: Warranty Terms
Warranty Terms Warranty Terms To make a claim under the warranty, it is important to register the Barbas appliance after pur- chase via www.barbasbellfires.com. Barbas Bellfires Warranty Terms Barbas Bellfires B.V. guarantees the quality of the supplied Barbas appliance and the quality of the materials used. - Page 37 Article 5: Warranty period This warranty will only be granted during the warranty period. The body of the Barbas appliance is guaranteed for a period of 10 years against construction and/or material faults, starting from the moment of purchase. For other parts of the Barbas appliance, a similar warranty applies from the moment of purchase for a period of two years.
