INSTALLATION INSTRUCTIONS &

MANUAL FOR ANNUAL MAINTENANCE

EVO 80-65

Wood-burning built-in appliance

Barbas wishes you many cosy evenings with your new appliance

This document is an essential part of your ﬁ re. Read it carefully before

installation and maintenance of the gas ﬁ re and keep it in a safe place!

Version number: 01 - 334801

Date: 15-10-2013

Serial number:

Production date:

Table of Contents

Need help?

Do you have a question about the EVO 80-65 and is the answer not in the manual?

Questions and answers

Summary of Contents for barbas EVO 80-65

Page 1 EVO 80-65 Wood-burning built-in appliance Barbas wishes you many cosy evenings with your new appliance This document is an essential part of your ﬁ re. Read it carefully before installation and maintenance of the gas ﬁ re and keep it in a safe place!
Page 3: Table Of Contents
EVO 80-65 TABLE OF CONTENTS Page Introduction ....................Placing ......................Installation ....................Annual maintenance ................... Dimensions ....................Replacement parts ..................Technical data ..................... Warranty terms ................... Installation instructions...
Page 4 EVO 80-65 Installation instructions...
Page 5 EVO 80-65 Installation instructions...
Page 6 EVO 80-65 Installation instructions...
Page 7: Introduction
EVO 80-65 INTRODUCTION 1.1 GENERAL The appliance must be positioned and connected by a Barbas dealer/specialist in accordance with these Installation instructions, nationally and locally applicable regulations. This manual contains directions for both positioning and for connecting the appliance. It also contains indications for the annual maintenance, technical data for the appliance, parts information and directions in the event of problems.
Page 8 The required constructive adaptations should be satisﬁ ed as well. • It is essential that the appliance, the ﬂ ue and combustion air supply are cleaned and inspected annually by a Barbas dealer/specialist. The safe operation of the appliance will thus remain guaranteed.
Page 9: Placing
EVO 80-65 PLACING APPLIANCE DESCRIPTION Figure 1: Overview appliance Figure 2: Overview appliance including optional stone plateau Ceramic heat-proof glass Outlet opening (2x grate) (chimney breast) natural convection air Outlet opening (2x grill convection set) (chimney breast) convection air Wall dimmer switch (optional) with integrated ON/OFF switch to control the speed of the built-in Perma Air ®...
Page 10 EVO 80-65 Supplied with the appliance: Documentation • Installation instructions • Instructions for use Attributes • Glove (Heat resistant up to max. 95°C) • Operating hook / Poker • Remote control N.B. If any part is missing, please contact your dealer.
Page 11 EVO 80-65 • Check whether the retardant plates (brake plates) are located correctly. • Check the operation of the slider for the regulation of the combustion air intake (middle below the window). • Check whether the ashtray is completely empty.
Page 12 EVO 80-65 2.2.2 Connection Possibilities: Important: The appliance is supplied with a pre-ﬁ tted air box or fan box (if applicable). It is not possible to alter this after delivery. Installing in an existing or new ﬁ replace. A Build-in.
Page 13 EVO 80-65 C Build-in with air box. Without convection set. Convection air through the chimney breast. D Build-in with air box. With convection set. Convection air supply through a grate in the bottom side of the ﬁ replace. Convection air through the chimney breast.
Page 14 EVO 80-65 Installing the appliance with a fan box. • Directly external combustion air supply • Convection fan with built-in dimmer switch • Convection air supply through a grate/opening from the living room A Build-in with fan box. With convection set.
Page 15 EVO 80-65 = Closed (“break away” discs) = Open (“break away” discs) = Grate Ventilation openings chimney breast = Grate Combustion air supply via wall outlet Convection set: 2.2.3 Combustion air intake The local chimney sweep/authorities must be consulted prior to ﬁ tting regarding the suitability and combustion air supply.
Page 16 EVO 80-65 • Combustion air from the living-room: When using the appliance, please ensure there is a sufﬁ cient supply of fresh air: use a grate with a minimum net opening in the outer wall of 150 cm When necessary, the combustion air inlet Ø125 mm at the underside of the appliance may be used.
Page 17 EVO 80-65 2.2.4 Combustion air supply / Chimney Every appliance needs its own chimney. Multiple connections to one main chimney is not permitted. Ensure that any existing chimney is completely air-tight and in good condition. It must be suitable to accommodate the appliance in question. Make sure your chimney has a proper cap to prevent rain getting in and birds nesting on it.
Page 18 EVO 80-65 2.2.5 Convection air supply and- outlet Convection air (heating air) is exclusively for the transfer of heat from the appliance to the living space. This air comes from the room and stays in the room. • Use convection set: The function of the convection set (option) is to improve the convection through the appliance, resulting in efﬁ...
Page 19 EVO 80-65 Knock out two “break-away” discs of the fan box with a hammer. 1x circular disc left or right - back. This will be the convection air inlet. Place the collar adapter (125 mm) on the convection air intake opening.
Page 20 EVO 80-65 Built-in box for dimmer. Refer to the electrical wiring diagram supplied separately with the fan box, connect the dimmer to the fan. For maintenance, the convection fan can be reached after removal of the complete ﬂ oor of the combustion.
Page 21 EVO 80-65 Place the included collar adapter in the air intake opening. Construct a direct combustion air supply from the outside by means of a metal (ﬂ exible) tube (125 mm) and a grate on the outer wall. Only replace the door in the appliance after ﬁ tting the complete appliance.
Page 22 EVO 80-65 Insulation Delevired Heat Max user Density material in ... conductivity temperature Can be Sort Form ºC kg/m³ delivered as Mineral ﬁ bre Strips Mats (1) Glass ﬁ bre Individual ﬁ bres Mats (2) Stone ﬁ bre Granular ﬁ bres Cinter ﬁ...
Page 23: Installation
EVO 80-65 INSTALLATION 3.1 GENERAL When ﬁ tting one of these appliances local and/or national regulations relating to ﬁ re safety must be followed. In case of doubt, consult the ﬁ re safety department of the local ﬁ re brigade, particularly if the ﬁ re is to be ﬁ tted in a home with walls and/or ﬂ oors containing ﬂ...
Page 24 EVO 80-65 Example build-in in a ventilated chimney. Appliance is ﬁ tted with a convection set. Example build-in in a ventilated chimney. Convection air through the chimney breast. Legend page 26 Installation instructions...
Page 25 EVO 80-65 Example build-in in a ventilated chimney. Appliance is ﬁ tted with an air box and a convection set. For a direct combustion air supply from outside. Example build-in in a ventilated chimney. For a direct combustion air supply from outside and ﬁ tted with a convection fan with a build-in fanspeed controller.
Page 26 EVO 80-65 Legend: Inlet opening combustion air / convection air / chimney-ventilation air (grate, bottom of chimney) Inlet opening combustion air (bottom of appliance Ø125 mm) / (air-box, Ø125 mm) / (fan box, Ø125 mm) Inlet opening convection air (fan box, Ø125 mm) / (side of appliance) / (bottom of appliance) Flue connection (topside of appliance, Ø250 mm)
Page 27 EVO 80-65 • If the appliance is to be placed against a bearing wall or against a wall containing ﬂ ammable material, an air gap of at least 20 mm should ﬁ rst be created. Before it a false wall, 100 mm thick, must be built of masonry or aerated concrete.
Page 28 EVO 80-65 - Appliance with substructure fan box (convection fan): Use the Ø125 mm (external) combustion air supply connection at the left of right front side of the fan box. Fit a rigid or ﬂ exible pipe measuring Ø125 mm between this air supply connection and the “outside air supply opening in the wall/ﬂ...
Page 29 • Ventilate the chimney, by placing ventilation openings at the top and bottom of the chimney breast. • Close up the front. (Note for installation without stone plateau the motor remains accessible!) Available BARBAS grids (option) for ventilating the chimney: COLOUR DIMENSION (cm) CLEAR OPENING (cm Brass or white 13.5 x 13.5 (incl.
Page 30 EVO 80-65 Put the lift door in the top position and place the plateau in its designated position in the appliance. Fix the plateau at the rear with the 2 ﬂ ange bolts. The plateau can be levelled using the 2 allen set screws on the underside of the plateau.
Page 31: Annual Maintenance
ANNUAL MAINTENANCE It is essential that the appliance, the chimney and the combustion air supply are cleaned and inspected annually, by a Barbas-dealer/expert. The safe operation of the appliance will thus remain guaranteed. Start with maintence 24 hours after the last burning period.
Page 32 Wait for the appliance to cool down sufﬁ ciently before cleaning. Never use scouring powder, aggressive cleaners or ﬁ re polish on the appliance. • Any lacquer damage can be repaired with a BARBAS heat resistant paint spray can. (Pay atention that the appliance is sufﬁ ciently cooled down !) Ventilation house: •...
Page 33: Dimensions
EVO 80-65 DIMENSIONS 5.1 EVO 80-65 • with 80 mm frame Installation instructions...
Page 34 EVO 80-65 5.2 EVO 80-65 • with 80 mm frame • with natural stone plateau Installation instructions...
Page 35: Replacement Parts
EVO 80-65 REPLACEMENT PARTS Article number Item no Description 334526 Retardant plate top, right 334527 Retardant plate top, left 334532 Retardant plate under 333984 Side panel, left 333979 Rear panel 333985 Side panel, right 334515 Grate 334483 Door 333986 Bottom stone...
Page 36: Technical Data
13 g/s Flue temperature 195°C Chimney draught 0.12 mbar Flue gas connection Ø250 mm (Ø248 mm ext.) Weight - EVO 80-65 315 kg - Natural stone plateau 31 kg - Fan box 19 kg - Air box 3 kg Inside:...
Page 37 EVO 80-65 Combustion air supply: At least 150 cm opening in the room where the ﬁ re is located or a outside air supply opening of Ø125 mm in wall/ﬂ oor. ® Opties: • Fan box with 230 VAC / 95 W fan (Perma Air for transport of heating air.
Page 38: Warranty Terms
2.3. Complaints will only be accepted if they are reported to the Barbas dealer, together with the serial number of the Barbas appliance which is stated on the front of the instructions for use. 2.4. In addition, the original receipt (invoice, receipt, cash receipt) showing the date of purchase must also be submitted.
Page 39 Article 5: Warranty period 5.1. This warranty will only be granted during the warranty period. 5.2. The body of the Barbas appliance is guaranteed for a period of 10 years against construction and/or material faults, starting from the moment of purchase.
Page 40 Your Barbas dealer 01 - 151013 - 334801...
