INSTRUCTIONS FOR USE

COUNTRY

NATURAL GAS

Great-Britain/

ATLANTA / SAVANNAH NG

Ireland

ECO 550 / ECO 650 / ECO 750 NG

Italia

ATLANTA / SAVANNAH NI

ECO 550 / ECO 650 / ECO 750 NI

España

ATLANTA / SAVANNAH NE

ECO 550 / ECO 650 / ECO 750 NE

Portugal

ATLANTA / SAVANNAH NP

ECO 550 / ECO 650 / ECO 750 NP

ATLANTA

SAVANNAH

ECO 550

ECO 650

ECO 750

INSTALLATION INSTRUCTIONS

PROPANE

ATLANTA / SAVANNAH PG

ECO 550 / ECO 650 / ECO 750 PG

ATLANTA / SAVANNAH PI

ECO 550 / ECO 650 / ECO 750 PI

ATLANTA / SAVANNAH PE

ECO 550 / ECO 650 / ECO 750 PE

ATLANTA / SAVANNAH PP

ECO 550 / ECO 650 / ECO 750 PP

Table of Contents

Need help?

Do you have a question about the ATLANTA and is the answer not in the manual?

Questions and answers

Summary of Contents for barbas ATLANTA

Page 1 ECO 650 ECO 750 COUNTRY NATURAL GAS PROPANE Great-Britain/ ATLANTA / SAVANNAH NG ATLANTA / SAVANNAH PG Ireland ECO 550 / ECO 650 / ECO 750 NG ECO 550 / ECO 650 / ECO 750 PG Italia ATLANTA / SAVANNAH NI...
Page 2: Table Of Contents
ECO 550 ECO 650 A TLANTA SAVANNAH ECO 750 CONTENTS Page INSTRUCTIONS FOR USE............INSTALLATION INSTRUCTIONS..........MAINTENANCE..............FAULTS................. DISASSEMBLY / ASSEMBLY OF THE REGULATOR AND BURNER........DIMENSIONS................. TECHNICAL DETAILS/REGULATIONS........REPLACEMENT PARTS LIST..........
Page 3 ECO 550 ECO 650 ECO 750 SAVANNAH A TLANTA...
Page 4: Instructions For Use
INSTRUCTIONS FOR USE INTRODUCTION Congratulations on your purchase of this modern BARBAS gas fire. This quality product will provide you with many years of enjoyment due to the flame effect and warmth that it provides. Please read the instructions for use carefully before using the appliance for the first time.
Page 5 OPERATION GENERAL The gas regulating block, with which the fire is operated, is located behind the flap. Opening the operating knob: ATLANTA, SAVANNAH, ECO 650 : Panel can be opened by pulling forwards. ECO 550, ECO 750 : Lift the right-hand side of the panel...
Page 6 ECO 550 ECO 650 A TLANTA SAVANNAH ECO 750 IGNITING THE FIRE Open the gas supply valve in the gas pipe to the fire. Lock the slider into “ ” position. Turn the thermostat knob to the ignition position “ ”...
Page 7 Never use scouring powder, aggressive cleaners or fire polish on the gas fire. Use only a dry lint free cloth. Barbas heat resistant lacquer in aerosols can be obtained from your distributor. During the yearly maintenance, the lacquer can be used to repair small areas of damage.
Page 8: Installation Instructions
ECO 550 ECO 650 A TLANTA SAVANNAH ECO 750 INSTALLATION INSTRUCTIONS GENERAL The appliance has a decorative fire. The gas fire must be positioned and connected as a “open” appliance by a CORGI registered gas installation engineer in accordance with the following installation instructions, nationally and locally applicable regulations (see “Technical Details/ Regulations”...
Page 9 ECO 550 ECO 650 ECO 750 SAVANNAH A TLANTA PREPARATIONS BEFORE INSTALLATION The following preparation must be carried out before the gas fire can be installed. 2.3.1 The most important considerations according to the regulations: 1. NATURALLY VENTILATED HOUSE (see Figure 2). The room in which the appliance is to be fitted must have a non- •...
Page 10 ECO 550 ECO 650 A TLANTA SAVANNAH ECO 750 2 MECHANICALLY VENTILATED HOUSE (see Figure 3) The room in which the appliance is to be fitted must have a non- • closable combustion air supply opening. The minimum dimensions are detailed in “Technical Details/Regulations” at the rear of this manual (see also Paragraph 2.4, point 2).
Page 11 ECO 550 ECO 650 ECO 750 SAVANNAH A TLANTA GENERAL SERVICES FLUE Before installation, it must be verified that the flue has sufficient draw. Remove all flue gas dampers (if present) in the flue or fix them in the open position.
Page 12 In the case of the ATLANTA/SAVANNAH, the top connection opening can be dismantled after removal of the top plate of the appliance, which is fastened with 4 bolts.
Page 13 ECO 550 ECO 650 ECO 750 SAVANNAH A TLANTA 2.5.2 Placing soapstone panels ECO 550 / ECO 650 / ECO 750 Position the bottom stone, with the widest part underneath, on the floor. Position the appliance on top. Secure the side stones by gently sliding them downwards over the rail.
Page 14 ECO 750 2.5.3 Chimney connection The flue pipe/liner (Ø100 mm: ATLANTA / SAVANNAH or Ø150 mm: ECO 550 / ECO 650 / ECO 750) can now be connected to the appliance. Make sure that the connection is completely gas tight.
Page 15 ECO 750 SAVANNAH A TLANTA Figure 5: Log set natural gas ATLANTA / SAVANNAH / ECO 550 / ECO 650 / ECO 750 Figure 6: Log set propane ATLANTA / SAVANNAH / ECO 550 / ECO 650 / ECO 750 2.5.7 Checking the Appliance Following Installation...
Page 16: Maintenance
ECO 550 ECO 650 A TLANTA SAVANNAH ECO 750 MAINTENANCE ANNUAL MAINTENANCE The appliance must be checked and cleaned annually by an authorised engineer. This also applies to the chimney. The annual maintenance consists of the following points: Cleaning the main burner, pilot light and chimney liner(s)l/combustion air supply.
Page 17: Disassembly / Assembly Of The Regulator And Burner
DISASSEMBLY / ASSEMBLY OF THE REGULATOR AND BURNER DISASSEMBLY: (see fig. 7 and 8.) ATLANTA / SAVANNAH / ECO 550 : Open the glass door by unscrewing the allen socket bolt. ECO 650 : The front is mounted to the casing by “stud” connections in the corners.
Page 18 ECO 550 ECO 650 A TLANTA SAVANNAH ECO 750 Figure 7: ATLANTA / SAVANNAH / ECO 550...
Page 19 ECO 550 ECO 650 ECO 750 SAVANNAH A TLANTA Figure 8: ECO 650 / ECO 750 ASSEMBLY Assemble in the reverse order. Ensure that the bottom plate sealing cord and the glass plate mate correctly. Re-check all re-fitted gas connections for leaks using soapy water or a leak tester.
Page 20: Dimensions
ECO 550 ECO 650 A TLANTA SAVANNAH ECO 750 DIMENSIONS ATLANTA / SAVANNAH...
Page 21 ECO 550 ECO 650 ECO 750 SAVANNAH A TLANTA ECO 550...
Page 22 ECO 550 ECO 650 A TLANTA SAVANNAH ECO 750 ECO 650 Gas connection...
Page 23 ECO 550 ECO 650 ECO 750 SAVANNAH A TLANTA ECO 750...
Page 24: Technical Details/Regulations
: nr. 130 (=Ø1,30mm) - Manual burner : standard : standard Main burner : Barbas 270 x 122 : Barbas 270 x 122 Primary air inlet main burner : 4x Ø8,5 mm : 4x Ø8,5 mm + 4x Ø6,5 mm Main burner orifice : nr.
Page 25: Replacement Parts List
When requesting service or ordering replacement parts, please quote the model type and serial number. All parts listed in this manual may be ordered from a Barbas dealer. ATLANTA / SAVANNAH / ECO 550 / ECO 650 / ECO 750 Part no. Description 302056 Gas regulator block, EuroSIT Plus 0.630.704...
Page 26 ECO 550 ECO 650 A TLANTA SAVANNAH ECO 750 Part no. Description 301516 Glass clamp model T 301509 Glass clamp model L 301526 Glass clamp model W 301669 Tube ceramic glue 301846 Log set Natural gas 301848 Log set Propane 301839 Vermiculite granules ±...
Page 27 INTERFOCOS B.V. HALLENSTRAAT 17 5531 AB BLADEL NEDERLAND E-mail: info@barbas.nl Internet: www.barbas.com 01 - 151205 - 303376...

This manual is also suitable for:

Savannah Eco 550 Eco 650 Eco 750
