Toa HY-CM-FB08B Installation Manual

SUBWOOFER CEILING MOUNTING BRACKET
Thank you for purchasing TOA's Subwoofer Ceiling Mounting Bracket.
Please carefully follow the instructions in this manual to ensure long, trouble-free use of your equipment.
TABLE OF CONTENTS
1. SAFETY PRECAUTIONS ............................. 1
2. GENERAL DESCRIPTIONS ......................... 2
3. DIMENSIONAL DIAGRAM ........................... 2
1. SAFETY PRECAUTIONS
• Before installation or use, be sure to carefully read
all the instructions in this section for correct and
safe operation.
• Be sure to follow all the precautionary instructions in
this section, which contain important warnings and/
or cautions regarding safety.
• After reading, keep this manual handy for future
reference.
WARNING
Indicates a potentially hazardous situation which,
if mishandled, could result in death or serious
personal injury.
• Install the bracket only in a location that can
structurally support the weight of the bracket and the
speaker. Doing otherwise may result in the bracket
and speaker falling down and causing personal
injury and/or property damage.
• Do not use other methods than specified to mount
the bracket. Extreme force is applied to the bracket
and the speaker could fall off, possibly resulting in
personal injuries.
• Use nuts and bolts that are appropriate for the
ceiling's structure and composition. Failure to do so
may cause the speaker to fall, resulting in material
damage and possible personal injury.
• Tighten each nut and bolt securely. Ensure that the
bracket has no loose joints after installation to prevent
accidents that could result in personal injury.
INSTALLATION MANUAL
HY-CM-FB08B
HY-CM-FB08W
4. SPECIFICATIONS ......................................... 2
5. INSTALLATION ............................................. 3
• Use the specified speaker in combination. Doing
otherwise may cause the bracket and speaker to
fall off, resulting in personal injury.
• Do not mount the bracket in locations exposed to
constant vibration. It can be damaged by excessive
vibration, potentially causing the bracket and
speaker to fall, which could result in personal injury.
• Do not install the speaker near the seashore or
in locations where corrosive gas is generated,
such as swimming pool facilities. If installed in
such environments, its mounting bracket may rust
or corrode. This could cause the speaker to fall,
potentially resulting in personal injury.
CAUTION
Indicates a potentially hazardous situation which,
if mishandled, could result in moderate or minor
personal injury, and/or property damage.
• Avoid touching the bracket's sharp metal edge to
prevent injury.
• Have the bracket and speaker checked periodically
by the shop from where they were purchased. Failure
to do so may result in corrosion or damage to the
bracket and speaker that could cause the bracket
and speaker to fall, possibly causing personal injury.
133-01-00379-00
