  • Page 1 MaxiCOM MK808Z-TS...

  • Page 2: Copyright Information

    Autel will not be liable for any direct, special, incidental, or indirect damages, or for any economic consequential damages (including the loss of profits) as a result of using this product.

  • Page 3: Safety Information

    The safety messages herein cover situations Autel is aware of at the time of publication. Autel cannot know, evaluate or advise you as to all of the possible hazards. You must be certain that any condition or service procedure encountered does not jeopardize...
  • Page 4 DANGER When an engine is operating, keep the service area WELL VENTILATED or attach a building exhaust removal system to the engine exhaust system. Engines produce carbon monoxide, an odorless, poisonous gas that causes slower reaction time and can lead to serious personal injury or loss of life. SAFETY WARNINGS ...

  • Page 5: Table Of Contents

    CONTENTS 1 USING THIS MANUAL ..................... 1 ..................... 1 ONVENTIONS 2 GENERAL INTRODUCTION .................... 3 COM MK808Z-TS T ................3 ABLET VCI M ...................... 7 ................... 9 THER CCESSORIES 3 GETTING STARTED ....................... 10 ....................10 OWERING ....................14 OWERING 4 DIAGNOSTICS........................
  • Page 6 ..................68 ENSOR ROGRAMMING TPMS R ....................74 ELEARN TPMS OEM P NO.................. 80 7 TOOLKIT ......................... 84 8 TPMS RETROFIT......................85 9 UPDATE .......................... 87 10 DATA MANAGER ......................88 10.1 ....................89 EHICLE ISTORY 10.2 ................... 92 ORKSHOP NFORMATION 10.3...
  • Page 7 15.4 ......................122 RAINING 15.5 FAQ ....................... 123 16 MAXIVIEWER ......................124 17 MAXIVIDEO ........................ 126 18 QUICK LINK ....................... 127 19 AUTEL USER CENTER ....................128 20 MAINTENANCE AND SERVICE................. 130 20.1 ................130 AINTENANCE NSTRUCTIONS 20.2 ................. 131...

  • Page 8: Using This Manual

    Using This Manual This manual contains device usage instructions. Some illustrations shown in this manual may make reference to modules and optional equipment that are not included in your system. Contact your sales representative for availability of other modules and optional tools or accessories. 1.1 Conventions The following conventions are used: 1.1.1 Bold Text...
  • Page 9 1.1.4 Illustrations Illustrations used in this manual are samples; the actual testing screen may vary for each vehicle being tested. Observe the menu titles and on-screen instructions to make correct option selection. 1.1.5 Procedures An arrow icon indicates a procedure. Example: ...

  • Page 10: General Introduction

    General Introduction Together with the ability to quickly read and clear DTCs for all available modules of the majority of the makes and models on the market, MaxiCOM MK808Z-TS provides superior special functions, including Oil Reset, EPB (Electronic Parking Brake), SAS (Steering Angle Sensor), and BMS (Battery Management System).
  • Page 11 7.0” LCD Touchscreen Ambient Light Sensor — detects ambient brightness. Power LED — indicates battery level & charging or system status. TPMS Service Symbol — indicates the position of the embedded TPMS antenna. The power LED displays green, yellow or red depending on power level and operating state.
  • Page 12 Figure 2-3 Tablet Top View Micro SD Card Slot — holds the Micro SD card. HDMI (High-Definition Multimedia Interface) Port 10. USB Port 11. Power/Lock Button — turns the device on/off with long press, or locks the screen with short press. 2.1.2 Power Sources The tablet can receive power from any of the following sources: ...

  • Page 13: Technical Specifications

    2.1.3 Technical Specifications Table 2-1 Specifications Item Description Recommended Use Indoor Operating System Android Processor Quad-core processor (1.8 GHz) Memory 4GB RAM & 64GB ROM Display 7-inch LCD screen with 1024 x 600 resolution  Mini USB 2.0  USB 2.0 ...

  • Page 14: Maxivci Mini

    Item Description Net Weight 885 g (2.31 lbs.) ISO9141-2, ISO14230-2, ISO15765, K/L-Line, Flashing Code, SAE-J1850 VPW, SAE-J1850PWM, ISO11898 (High-speed, Protocols Middle-speed, Low-speed and Single-wire CAN, fault-tolerant CAN), SAE J2610, GM UART, UART Echo Byte Protocol, Honda Diag-H Protocol, TP2.0, TP1.6 2.2 MaxiVCI Mini MaxiVCI Mini is a small vehicle communication interface (VCI) that wirelessly connects to the tablet vehicle’s data link connector (DLC) for vehicle data transmission.

  • Page 15: Power Source

    Table 2-2 Power LED Color Description Lights solid green when powered on. Green Flashes red when a system failure occurs. Power Note: The power LED briefly lights red each time the device powers on and then lights green when the device is ready. Table 2-3 Connection LED Color Description...

  • Page 16: Other Accessories

    2.2.3 Technical Specifications Table 2-4 Specifications Item Description  BT V.2.1 + EDR Communications  Mini USB 2.0 Wireless Frequency 2.4 GHz Input Voltage Range 12 V DC to 24 V DC Supply Current 150 mA @ 12 V DC Operating Temp.

  • Page 17: Getting Started

    Getting Started Ensure the tablet is sufficiently charged or is connected to an external power supply (see Power Sources). NOTE The images and illustrations depicted in this manual may differ slightly from those in the most recent product. 3.1 Powering Up Long press the Power/Lock button on the top-right side of the tablet to power on the unit.

  • Page 18: Application Buttons

    NOTE The tablet screen is locked by default when first powered on. We recommend you lock the screen to protect the information in the system and conserve the power. The touchscreen navigation is menu-driven, enabling quick access to functions and features by tapping on the buttons on the screen.
  • Page 19 Configures the unit to receive remote support using the Remote TeamViewer application. See Remote Desktop Desktop details. Launches the Support platform which synchronizes Autel’s on-line service base station with the MaxiCOM Support tablet. See Support for details. Provides quick search for the supported functions and MaxiViewer vehicles of Autel diagnostic tools.

  • Page 20: Locator And Navigation Buttons

    Button Name Description MaxiTools Includes log collection and factory data reset two parts. Manages the permissions for unlocking the OE gateway. Authorization 3.1.2 Locator and Navigation Buttons Operations of the navigation buttons at the bottom of the screen are described in the table below: Table 3-2 Locator and Navigation Buttons Button...

  • Page 21: System Status Icons

    Button Name Description Display Supports the display brightness automatically or manually Brightness adjustment. Opens the VCI Manager application. The BT or the cable badge at the bottom-right corner indicates the tablet is Manager communicating with the VCI device. An X badge will display Shortcut at the bottom-right corner if the tablet is not connected to the VCI device.

  • Page 22: Reboot System

    3.2.1 Reboot System In case of a system crash, long press the Power/Lock button and tap the Restart option to restart the system.

  • Page 23: Diagnostics

    Diagnostics The Diagnostics application can retrieve ECU information, read & erase DTCs, and view live data. The Diagnostics application can access the electronic control unit (ECU) for various vehicle control systems, including engine, transmission, antilock brake system (ABS), and airbag system (SRS). 4.1 Establishing Vehicle Communication Prior to performing the Diagnostics function, ensure the tablet is connected to the test vehicle through the MaxiVCI Mini.

  • Page 24: No Communication Message

    4.1.2.1 Bluetooth Connection Bluetooth pairing is recommended as the first choice for the communication between the tablet and the MaxiVCI Mini. This is because the Bluetooth connection does not need to repeat the plugging and unplugging procedure which is unavoidable when using traditional wired connection, saving more time and providing higher efficiency.

  • Page 25: Getting Started

    displays with check instructions. The following conditions are the possible causes:  The MaxiVCI Mini is unable to establish a communication link with the vehicle.  The system selected for testing is not equipped on the vehicle.  There is a loose connection. ...

  • Page 26: Top Toolbar Buttons

    4.2.2 Top Toolbar Buttons The operations of the toolbar buttons at the top of the screen are listed and described in the table below: Table 4-1 Top Toolbar Buttons Button Name Description Home Returns to the MaxiCOM Job Menu. Provides a fast way to identify the test vehicle. Vehicle Identification for details.

  • Page 27: Vehicle Identification

    4.3 Vehicle Identification The MaxiCOM diagnostics system supports four methods for vehicle identification: Auto Detect Manual Input Automatic Selection Manual Selection 4.3.1 Auto Detect The MaxiCOM diagnostics system features the latest VIN-based Auto Detect function to identify vehicles and scan all the diagnosable ECUs and run diagnostics on the selected system.
  • Page 28 Figure 4-3 Auto Detect Screen Tap Yes to confirm the vehicle profile, or tap No if the information is incorrect. Figure 4-4 Vehicle Profile Screen The tool establishes communication with the vehicle and reads the control unit information. Choose Auto Scan to scan all the test vehicles’ available systems or tap Control Unit to access a specific system to diagnose.

  • Page 29: Manual Input

    Figure 4-5 Diagnostic Menu Screen 4.3.2 Manual Input For vehicles not supporting the Auto Detect function, you may manually enter the VIN.  To perform Manual Input Tap the Diagnostics application button from the MaxiCOM Job Menu. The Vehicle Menu displays. Tap the VID button on the top toolbar to open the dropdown list.

  • Page 30: Automatic Selection

    Figure 4-6 Manual Input Screen Tap OK. Once the vehicle is identified, the Vehicle Diagnostics screen displays. at the top-right of the dialog box to exit Manual Input. 4.3.3 Automatic Selection The vehicle VIN can also be automatically acquired after a vehicle manufacturer is selected.

  • Page 31: Manual Selection

     To perform Automatic Selection Tap the Diagnostics application button from the MaxiCOM Job Menu. The Vehicle Menu displays. Select a vehicle manufacturer. Tap Automatic Selection and the VIN information will be acquired automatically. Follow the on-screen instruction to display the Diagnostic Menu screen.
  • Page 32 When encountering Data an error during testing and diagnosing, use this Logging function to contact Autel's technical staff for solutions. See Data Logging for details.  To print data in Diagnostics Tap the Diagnostics application button from the MaxiCOM Job Menu.

  • Page 33: Screen Messages

     Print This Page — prints a screenshot of the current screen.  Print All Data — prints a PDF file of all displayed data. A temporary file will be created and sent to the connected PC for printing. When the file is transferred successfully, a confirmation message will appear. ...

  • Page 34: Making Selections

    4.4.2.1 Confirmation Messages Confirmation messages inform you when you about to perform an action that cannot be reversed or when an action has been initiated and confirmation is needed to continue. When a user-response is not required to continue, the message displays briefly. 4.4.2.2 Warning Messages This type of messages displays a warning that a selected action may result in an...
  • Page 35 Figure 4-9 Auto Scan Screen Navigation Bar Main Section Function Buttons 4.5.1.1 Navigation Bar List Tab — displays the scanned data in list format. Progress Bar — indicates the test progress. 4.5.1.2 Main Section Column 1 — displays the sequence numbers. Column 2 —...

  • Page 36: Control Unit

    Table 4-3 Function Buttons in Auto Scan Name Description Report Displays the diagnostic data in a report form. Deletes codes. A warning message screen will display Quick to inform you of possible data loss when this function is erase selected. Confirms the test result.

  • Page 37: Ecu Information

    The Diagnostic Functions are listed on the Function Menu screen. The Function Menu options vary slightly for different vehicles, which may include: ECU Information — provides the retrieved ECU information in detail. An  information screen opens upon selection. Trouble Codes — contains Read Codes and Erase Codes. The former displays ...

  • Page 38: Trouble Codes

    Figure 4-11 ECU Information Screen Diagnostics Toolbar Buttons — see Table 4-2 Diagnostics Toolbar Buttons detailed descriptions of the operations for each button. Main Section — the left column displays the item names; the right column shows the specifications or descriptions. Function Button —...
  • Page 39 Figure 4-12 Read Codes Screen Diagnostics Toolbar Buttons — see Table 4-2 Diagnostics Toolbar Buttons detailed descriptions of the operations for each button. Main Section Column 1 — displays the retrieved codes from the vehicle.  Column 2 — indicates the status of the retrieved codes. ...
  • Page 40 is successfully done.  Tap No to exit. Tap ESC on the Confirmation screen to exit Erase Codes. Perform the Read Codes function again to check if the codes have been erased successfully. 4.6.3 Live Data When this function is selected, the screen displays the data list for the selected module. The items available for any control module vary by vehicle.
  • Page 41 parameter name to open a sub menu, providing data display mode options. Value Column — displays the values of the parameters.  Range Column — displays the ranges of the parameters.  Unit Column — displays the unit for the parameters (Tap the Settings button ...
  • Page 42 NOTE Status parameters, such as a switch reading like ON, OFF, ACTIVE, and ABORT, can only be displayed in Text Mode. Value parameters, such as a sensor reading, can be displayed in both text and graph modes.  Waveform Graph Mode — displays the parameters in waveform graphs. In this mode, five control buttons will display on the right side of the parameter item, allowing you to manipulate the display status.
  • Page 43 three scales available for the Y axis: x1, x2, and x4. Edit Button — tap to open an edit window, in which you can set the waveform  color and line thickness displayed for the selected parameter. Zoom-out Button — tap to exit full screen display. ...
  • Page 44 Figure 4-17 Trigger Settings Screen Two buttons and two input boxes are available in the Trigger Settings screen. Trigger — switches the trigger on or off. The trigger is ON by default. Buzzer Alarm — switches the alarm on or off. The alarm function makes a beeping sound as an alert when the data reading reaches the preset minimum or maximum point.
  • Page 45 C. Function Buttons The operations of the available Function Buttons on the Live Data screen are described below: Cancel All — tap this button to cancel all selected parameters. Up to 50 parameters can be selected at one time. Show Selected/Show All — tap this button to switch between the two options: one displays the selected parameters, the other displays all the available items.
  • Page 46 and save the setting, and return to the Live Data screen, or tap Cancel to exit without saving. Clear Data — tap this button to clear all cached live data. Freeze — displays the retrieved data in freeze mode. Previous Frame — moves to the previous frame of frozen data. ...

  • Page 47: Active Test

    4.6.4 Active Test The Active Test function is used to access vehicle-specific subsystem and component tests. Available tests vary by vehicle. During an active test, the tablet sends commands to the ECU to activate the actuators. This test determines the integrity of the system or part by reading ECU data, or by monitoring the operation of the actuators.
  • Page 48 Figure 4-19 Special Function Screen 1 Select a function to display detailed information and the execution screen. Figure 4-20 Special Function Screen 2 List Tab Page:  Column 1 — displays the description of the function being performed or the live data corresponding to the special function.

  • Page 49: Generic Obdii Operations

    4.7 Generic OBDII Operations This option presents a quick way to check for DTCs, isolate the cause of an illuminated malfunction indicator lamp (MIL), check monitor status prior to emissions certification testing, and perform a number of other services that are emissions-related. The OBD direct access option is also used for testing OBDII/EOBD compliant vehicles that are not included in the database.

  • Page 50: Function Descriptions

    Figure 4-21 OBDII Diagnostic Menu Select a function to continue.  DTC & FFD  I/M Readiness  Live Data  On-Board Monitor  Component Test  Vehicle Information  Vehicle Status NOTE The supported functions may vary by vehicles. 4.7.2 Function Descriptions This section describes the various functions of each diagnostic option: 4.7.2.1...
  • Page 51 priority codes overwriting lower priority codes. The priority of the code determines the illumination of the MIL and the codes erase procedure. Manufacturers rank codes differently, so DTCs may vary by vehicle.  Pending Codes These are codes that were generated during the last drive cycle, but before the DTC actually sets, two or more consecutive drive cycles are needed.

  • Page 52: Exiting Diagnostics

    4.7.2.3 Live Data This function displays the real time PID data from ECU. Displayed data includes analog inputs and outputs, digital inputs and outputs, and system status information broadcast on the vehicle data stream. Live data can be displayed in various modes. See Live Data for detailed information.
  • Page 53 Or tap the Vehicle Swap button on the Diagnostics Toolbar to return to the Vehicle Menu screen. On the Vehicle Menu screen: Tap the Home button on the top toolbar. Or tap the Back button on the Navigation Bar at the bottom of the screen. Or tap the Home button on the Diagnostics Toolbar to exit the application directly and return to the MaxiCOM Home Menu.

  • Page 54: Service

    Service The Service application is specially designed to provide quick access to the vehicle systems for various scheduled service and maintenance tasks. The typical service operation screen is a series of menu-driven executive commands. Follow on-screen instructions to select appropriate execution options, enter correct values or data, and perform necessary actions.

  • Page 55: Tire Pressure Monitoring System (Tpms) Service

    Ensure that the EPB control system is reactivated after the maintenance work has been completed. NOTE Autel accepts no responsibility for any accident or injury arising from the maintenance of the Electric Parking Brake system. 5.3 Tire Pressure Monitoring System (TPMS) Service This function allows you to quickly look up the tire sensor IDs from the vehicle’s ECU, as...

  • Page 56: Steering Angle Sensor (Sas) Service

    Accident repairs where damage to the steering angle sensor, SAS assembly, or any part of the steering system may have occurred. NOTE Autel accepts no responsibility for any accident or injury arising from servicing the SAS system. When interpreting DTCs retrieved from the vehicle, always follow the manufacturer’s recommendation for repair.
  • Page 57 driven more with higher load and speed. In order for regeneration to take place, a prolonged high exhaust temperature must be obtained. In the event of the car being driven in such a way that regeneration is not possible, i.e., frequent short journeys, a diagnostic trouble code will eventually be registered in addition to the DPF light and “Check Engine”...

  • Page 58: Tpms

    TPMS The TPMS application is used to check the TPMS sensor conditions, program the MX-Sensor, and perform the TPMS Relearn procedure and other basic TPMS diagnostic functions. 6.1 Getting Started 6.1.1 TPMS Service Menu Layout Tap TPMS on the MaxiCOM Job Menu. The Vehicle Menu displays. Select a specific vehicle to perform TPMS service.

  • Page 59: Vehicle Selection

    Button Name Description Displays the stored test vehicle history History records. See Vehicle History for details. Tap the dropdown button to select the correct market, then the vehicle manufacturer icons of the selected market will be displayed. Market Note: Please double check whether the market is selected correctly if the vehicle cannot be found.
  • Page 60  To perform Auto Detect in TPMS application Tap the TPMS application button from the MaxiCOM Job Menu. The Vehicle Menu displays. Tap the VID button on the Top Toolbar to open the dropdown list. Figure 6-2 VID Screen in TPMS Application Select Auto Detect.
  • Page 61 Tap OK to confirm the vehicle information such as Model, Year, OEM Sensor Part NO., and Area, or tap ESC to return to the previous screen. Figure 6-4 Vehicle Information in TPMS Application Then the TPMS Service Menu will display. See Figure 6-14 TPMS Service Screen.
  • Page 62 Figure 6-5 Manual Input in TPMS Application A VIN Confirmation screen will display. If the VIN is correct, tap OK to enter the Vehicle Information screen. NOTE Before acquiring the vehicle VIN, make sure the tablet is connected to the network. After confirming the vehicle information, tap OK to enter the TPMS Service Menu.
  • Page 63 Figure 6-6 Vehicle Manufacturer Selection Tap Automatic Selection on the Select Diagnostic Type screen. Figure 6-7 Selection Screen in TPMS Application Tap Read to automatically acquire the VIN, or you can manually input the VIN information. If the VIN is correct, tap OK to proceed.
  • Page 64 Figure 6-8 Automatic Selection in TPMS Application Follow the on-screen instructions to confirm the vehicle information and finally enter the TPMS Service screen. See Figure 6-14 TPMS Service Screen. 6.2.4 Manual Selection You can also tap Manual Selection on the Select Diagnostic Type screen to select the vehicle information like model and year step by step.
  • Page 65 Figure 6-9 Vehicle Model Selection Figure 6-10 Vehicle Year Selection The following screen may display for vehicles using Indirect TPMS.
  • Page 66 Figure 6-11 Indirect TPMS Selection Screen For indirect TPMS vehicle, only the Relearn function is supported. Tap the vehicle year information button, in the case of the above screen — 2008/08-2019/12 (indirect), to display the Relearn Procedure screen. Follow the on-screen instructions to complete the operation.

  • Page 67: Tpms Service Screen Layout

    Figure 6-13 Relearn Procedure for Direct TPMS 6.3 TPMS Service Screen Layout The TPMS Service screen typically includes four sections: Figure 6-14 TPMS Service Screen Top Toolbar Buttons Navigation Tab Main Section Function Buttons...

  • Page 68: Tpms Check

    6.3.1 Top Toolbar Buttons The top toolbar contains a number of buttons. See Table 4-2 Diagnostics Toolbar Buttons for details. 6.3.2 Navigation Tab The navigation tab at the top of the Main Section screen contains the following items: Check Tab — displays the triggered sensor data. Diagnostics Tab —...
  • Page 69 Figure 6-15 Check Screen Sensor ID Tire Pressure Sensor Frequency Tire Temperature Sensor Battery Status Low Battery Icon Successfully Triggered NOTE The default check order on the tablet is LF (left front), RF (right front), RR (right rear), and LR (left rear). The wheel positions correspond with the descriptions on the right of the screen.
  • Page 70  To check the sensors Select the Check tab. Tap the desired wheel position on the vehicle thumbnail. Hold the tablet with its top-right corner (with the TPMS service symbol) close to the tire sidewall near the valve stem, and then tap the Trigger button. The tablet will send low frequency signal to trigger the sensor.

  • Page 71: Tpms Diagnostics

    6.5 TPMS Diagnostics The Diagnostics function is used to check the status of the TPMS system. This function requires connection with the test vehicle. Refer to Establishing Vehicle Communication for details.  To perform TPMS diagnostics function Tap the Diagnostics tab. The tablet will automatically communicate with the vehicle.
  • Page 72 Sensor IDs Retrieved by Activation Sensor IDs Retrieved by OBD — Saved in the TPMS ECU DTCs Retrieved by OBD — Existed in the TPMS ECU NOTE If the OBD function is supported by the test vehicle, the sensor ID saved in the TPMS ECU will be retrieved and displayed on the screen with an OBD mark before it when the communication is completed.
  • Page 73 Figure 6-19 DTCs Screen In the screen above, the detailed fault descriptions will be displayed. Select one of the DTCs and tap Search, the additional information will display. If no DTCs are present in the TPMS ECU, a green “No DTC” message will display in the DTC column.

  • Page 74: Clear Dtcs

    6.5.3 Clear DTCs Tap the Clear DTCs button, and the data trouble codes existed in the TPMS ECU will be cleared. 6.5.4 Live Data Tap Live Data to view the data stream of the sensor information. Figure 6-21 Live Data Screen All the parameters displayed on the Live Data screen are default values.

  • Page 75: Sensor Programming

    The Programming function is used to program the sensor data to the MX-Sensor and replace the faulty sensor (poor battery life or malfunction). NOTE Programming function will only work with Autel MX-Sensor. The 1-Sensor (Press In) is taken as an example in this manual. Please choose the proper MX-Sensor when programming.
  • Page 76 As shown in the screen above, there are four options available when programming MX-Sensor: Copy by Activation, Copy by OBD, Copy by Input, and Auto Create 1-20 Sensors. The main section of the screen may include: Column 1 — displays wheel positions. ...
  • Page 77 Figure 6-25 Programming Screen 2 6.6.1 Copy by Activation This function allows the user to copy the retrieved sensor ID from the activated sensor to the new MX-Sensor. It is used after the original sensor is triggered.  To copy by activation After performing TPMS check (see TPMS Check for details), the trigger marks...
  • Page 78 Figure 6-27 Copy by Activation Screen Figure 6-28 Copy by Activation Complete Screen When the programming is complete, the programmed ID will display in the column to the right of the wheel designation. In the pictured example, the new ID is displayed to the right of the LF column.

  • Page 79: Copy By Obd

    NOTE If the IDs of the original sensor and the new MX-Sensor are the same and the ID is already registered to the vehicle ECU, there is no need to perform the Relearn function when the new programmed sensor has been installed to the same wheel. If the IDs retrieved from sensor activation and those registered to the TPMS ECU are different, tap Copy by OBD to program the IDs saved in the ECU to the new MX-Sensor.
  • Page 80 6.6.3 Copy by Input The Copy by Input function allows users to program a new MX-Sensor with the ID of an original TPMS sensor.  To copy by input Select one sensor position and place a MX-Sensor near the TPMS antenna of the tablet (the top-right corner), then tap Copy by Input to program the new MX-Sensor.

  • Page 81: Tpms Relearn

     To auto create 1-20 sensors Select the vehicle model, and select a wheel location on the display and place the MX-Sensor(s) near the top-right corner of the tablet. Tap Auto Create 1-20 Sensors to program the new MX-Sensor. When the programming is complete, the programmed ID will display in the table on the screen.
  • Page 82 There are four ways for relearn, namely OBD Relearn, Automatic Relearn, Stationary Relearn, and Copy Relearn. The first three are new sensor ID relearn methods, while the Copy Relearn is a method to clone the sensor ID. 6.7.1 OBD Relearn OBD Relearn is completed via the OBD diagnostic function without needing to drive, and the relearn procedures are basically the same for different models.
  • Page 83 Figure 6-33 OBD Relearn Screen 2 6.7.2 Automatic Relearn Automatic Relearn requires driving to complete. For some vehicle models, the Automatic Relearn procedures can be completed directly by driving, while for some vehicle models, you need to follow the on-screen Learning Process Guide to let the vehicle enter the Automatic Relearn mode before driving.

  • Page 84: Stationary Relearn

    Figure 6-35 Automatic Relearn Screen 2 6.7.3 Stationary Relearn Stationary Relearn can be completed without relying on driving and the OBD diagnostics. To activate this mode, it is usually necessary to perform a series of operations to let the vehicle enter the relearn mode first, then use TPMS tools to perform activation or deflation to complete the relearn.
  • Page 85 Copy Relearn is to clone the sensor ID and tire location. Before performing Copy Relearn, you need to first obtain the sensor ID and tire location needed to be cloned, then use Autel tools to clone and program the sensor ID, and install the sensor to the corresponding tire to complete Copy Relearn.
  • Page 86 NOTE Ensure the original sensor will not interfere with the relearn procedures. It is recommended to keep the original sensor at least 100 meters away from the vehicle, or put the sensor in an enclosed metal box to avoid signal interference. Normally, it is not necessary to perform relearn procedures after cloning.

  • Page 87: Tpms By Oem Part No

    6.8 TPMS by OEM Part NO. If the sensor’s OEM part number is known, this function is an efficient method to activate and program MX-Sensors. 6.8.1 Application Scenarios This method is ideal for the following two cases: 6.8.1.1 In the workshop If the mounted sensor is faulty and the part number is known to the technician, the technician can use this method to check the original sensor, and then write the retrieved information into a new MX-Sensor via Programming function.
  • Page 88 Or tap the search box on the top-right corner of the screen to enter the part number. Figure 6-41 OEM Part NO. Search Screen When a specific OEM part NO. is selected, the screen will display as below. Figure 6-42 OEM Part NO. Service Menu Screen NOTE Only sensor Check and Programming functions are available with the OEM Part NO.
  • Page 89 information. The original sensor ID, tire pressure, tire temperature, sensor battery status, and sensor frequency will populate the displayed table. Figure 6-43 Check Screen via OEM Part NO. 6.8.2.2 Programming The programming function is used to program the sensor data to the MX-Sensor and replace the faulty sensor (poor battery life or malfunction).
  • Page 90 PSN Code on MX-Sensor NOTE By tapping Auto Create 1-20 Sensors, up to 20 MX-sensors can be programmed at a time. The Product Serial Number (PSN) code, which is printed on the MX-Sensor, acts as a reference to identify the corresponding sensor ID. This can be especially useful when programming multiple MX-Sensors.

  • Page 91: Toolkit

    ToolKit This chapter describes auxiliary functions for TPMS service and vehicle diagnostics. Figure 7-1 ToolKit Screen RKE & RF This function is used to check the signal strength of 315 and 433 MHz frequencies of remote keyless entry fobs. Unlock RED I 7002A This function is used to unlock the specified Redi-sensor: 7002A.

  • Page 92: Tpms Retrofit

    Tap OK at the bottom of the screen to confirm the information of the vehicle. The Retrofit screen opens. Follow the instructions displayed on the screen, which will guide you to choose the procedure, including the Back-up, Retrofit, Restore, Program Autel ECU, Autel ECU Relearn and Service Function buttons. Figure 8-1 TPMS Retrofit Screen...
  • Page 93 NOTE The Retrofit screen has the same layout as the TPMS screen. After the retrofit function is finished, tap on the other tabs to perform optional functions. Accesses the TPMS Retrofit function either by tapping TPMS on the MaxiCOM Job Menu or by directly tapping TPMS Retrofit.

  • Page 94: Update

    Internet. Any updates that are found can be downloaded and installed on the device. NOTE Ensure the tablet is registered before utilizing the Update application. See Autel User Center for details.  To update the software Ensure the tablet is connected to a power source and has a stable Internet connection.

  • Page 95: Data Manager

    Data Manager The Data Manager application allows you to store, print, and review the saved files, manage the workshop information, and customer information records, and keep test vehicle records. Selecting the Data Manager application opens the file system menu. There are nine main functions available.

  • Page 96: Vehicle History

    Button Name Description Tap to view the local reports on your tablet. If the report is successfully Cloud Report uploaded to cloud, you can also share the report with others. Tap to review the reports stored as PDF format. Review Data Tap to review the recorded data.

  • Page 97: Historical Test Record

    Figure 10-2 Vehicle History Screen Top Toolbar Buttons — displays navigation and application controls. Main Section — displays all the vehicle history records.  To activate a test session for the recorded vehicle Tap the Data Manager application on the MaxiCOM Job Menu. Select Vehicle History to open the screen.
  • Page 98 NOTE The MaxiCOM tablet must establish connection to the MaxiVCI Mini device to restart test sessions on the previously tested vehicles. Figure 10-3 Historical Test Record Sheet  To edit the Historical Test record Tap Data Manager on the MaxiCOM Job Menu. Select Vehicle History.

  • Page 99: Workshop Information

    10.2 Workshop Information The Workshop Information form allows you to edit, input, and save the detailed workshop information, such as shop name, address, phone number, and other remarks, which, when printing vehicle diagnostic reports and other associated test file, will display as the header of the printed documents.

  • Page 100: Image

    NOTE The items that must be filled are indicated as required fields. Some customers may have more than one vehicle for service. You can always add new vehicle information to the account. Tap Add New Vehicle Information, and then fill in the vehicle information. Tap the button to cancel.
  • Page 101 Figure 10-5 Image Screen Top Toolbar Buttons — used to edit, print, and delete the stored image files. See the following table for detailed information. Main Section — displays the stored images. Table 10-2 Toolbar Buttons in Image Screen Button Name Description Returns to the previous screen.

  • Page 102: Cloud Report

    Print to print the selected image(s). Tap Email to send the selected image(s) to an email. 10.5 Cloud Report This section displays the saved reports, which can be transferred to the Autel cloud platform once a stable network connection is established. These reports can then be viewed or shared with others.

  • Page 103: Data Logging

    Navigation Toolbar — allows you to manipulate data playback. Use the Navigation Toolbar buttons to play back the recorded data from frame to frame. Tap Back to exit data playback. 10.8 Data Logging The Data Logging section allows you to launch Support platform directly to view all records of all feedback or no feedback data loggings on the diagnostic system.

  • Page 104: Settings

    Settings Access the Settings menu to adjust default settings and view information about the MaxiCOM system. The following options are available for the MaxiCOM system settings:  Unit  Language  Printing Settings  Report Settings  Push Notifications  Auto Update ...

  • Page 105: Printing Settings

    To install the PC Link driver program Download the Maxi PC Suite software from www.autel.com > Support > Downloads > Autel Update Tools, and install it to your windows-based computer. Double click on Setup.exe. Select the installation language and the wizard will load momentarily.

  • Page 106: Report Settings

    NOTE  Make sure the tablet is connected to the same network with your computer, either via Wi-Fi or LAN, before printing.  Make sure the computer installed with the Printing Services program is connected to a printer.  To perform printing through the PC Run the PC Link program on the PC.

  • Page 107: Auto Update

    Per Week, Limit to 1 Notification Per Week, and Disable All Notifications. Select whichever you prefer. NOTE  Notifications will display on the screen. Slide the screen from top to check the received messages. If the message list covers more than one screen, slide the list up or down to view them.

  • Page 108: System Settings

     To adjust the vehicle list setting Tap Settings on the MaxiCOM Job Menu. Tap Vehicle list on the left column. Select the desired sort type. A check mark will display to the right of the selected item. Tap the Home button on the top-left corner to return to the MaxiCOM Job Menu, or select another setting option for the system setup.

  • Page 109: Vci Manager

    VCI Manager This application pairs the tablet with the MaxiVCI Mini, checks the communication status and update the VCI firmware. Figure 12-1 VCI Manager Screen Connection Mode — there are four connection modes available for selection. The connection status is displayed alongside. ...

  • Page 110: Vci Bluetooth Pairing

    12.1 VCI Bluetooth Pairing The MaxiVCI Mini needs to be connected to a vehicle, so that it is powered during the synchronization procedure. Ensure the tablet has sufficient battery power or is connected to an external power supply.  To pair the MaxiVCI Mini with the tablet Power on the tablet.

  • Page 111: Vci Update

    > Support > Downloads > Autel Update Tools, and install it onto your PC. Using a Mini USB cable to connect the MaxiVCI Mini to the PC. Launch the PC Suite on the PC which is installed after the installation of Maxi PC Suite and click the MaxiVCI Mini icon in the Device Selection window.

  • Page 112: Bas Update

    12.4 BAS Update Before updating the battery tester firmware, please make sure the network connection is stable.  To update the battery tester’s firmware Power on the diagnostic tablet and the battery tester. Connect the battery tester to the tablet via Bluetooth. Tap the VCI Manager application on the MaxiCOM Job Menu of the tablet.

  • Page 113: Battery Test

    The Battery Test application allows the user to perform in-vehicle battery test and out-vehicle battery test functions when the BT506 battery tester is connected to the MaxiCOM MK808Z-TS tablet and a battery. The BT506 battery tester enables technicians to view the health status of the vehicle's battery and electrical system.

  • Page 114: Maxibas Bt506 Battery Tester

    13.1 MaxiBAS BT506 Battery Tester 13.1.1 Function Description Figure 13-2 MaxiBAS BT506 Tester Power Button Status LED Power LED USB Port Battery Clamp Cable Table 13-1 LED Description Color Description The tester is communicating via USB Flashing Green cable. The tester is communicating via Status LED Flashing Blue Bluetooth.

  • Page 115: Power Sources

    Color Description The tester is powered on and the Solid Green battery is sufficiently charged. The tester is charging. (Turns solid Flashing Green green when battery is fully charged.) Power LED Solid Red The device is in boot mode. The battery level is low. Please Flashing Red charge.

  • Page 116: Test Preparation

    13.2.3 Technical Specifications Table 13-2 Technical specifications Item Description  USB 2.0, Type C Connectivity  Bluetooth 4.2 Input Voltage 5 V DC Working Current < 150 mA at 12 V DC Internal Battery 3.7 V/800 mAh Lithium-ion Polymer battery CCA Range 100 to 2000 A Voltage Range...
  • Page 117  To pair with the MaxiCOM tablet Turn on both the MaxiCOM MK808Z-TS tablet and the BT506 battery tester. Ensure that the units are sufficiently charged before you begin. Enable Bluetooth on the tablet by tapping VCI Manager > BAS BT. Tap Scan at the top-right corner.

  • Page 118: In-Vehicle Test

    13.4 In-vehicle Test The In-vehicle Test is used for testing batteries that are installed in a vehicle. An in-vehicle test includes the Battery Test, Starter Test, and Generator Test. These tests help determine the health of the battery, the starter, and the generator. IMPORTANT A disclaimer will appear when first accessing any function on the Home screen.
  • Page 119 Please refer to the table below for a list of buttons that may appear when accessing the functions: Table 13-3 Top Toolbar Buttons Button Name Description The value on the icon indicates the real-time Battery voltage of the tested battery. In the battery test, Connection the button will turn green if the battery is good.
  • Page 120 Figure 13-6 Battery Screen Wait until the test is completed. The test results will be displayed on the tool. Figure 13-7 Battery Test Results Screen The battery test results include a color-coded results summary and a list of test data. Possible in-vehicle test results are as follows:...
  • Page 121 Table 13-4 Test Results Result Description Good Battery Battery is good. Good & Battery is good but insufficiently charged. Recharge the battery. Recharge Charge & Retest Battery requires charge to determine its condition. Bad Cell Replace the battery. Replace Battery Replace the battery.

  • Page 122: Generator Test

    Table 13-5 Starter Test Results Result Description Cranking Normal The starter is good. Current Too Low Low momentary discharge capacity. Voltage Too Low Low battery storage capacity. Not Started The starter is not detected for starting. 13.4.3 Generator Test Follow the on-screen instructions to complete the test. The test results will appear as follows: Figure 13-9 Generator Test Results Screen...

  • Page 123: Out-Vehicle Test

    Table 13-6 Generator Test Results Result Description Charging Normal The generator is functioning normally.  The belt linking the starter and the generator is loose; Output Too Low  The cable linking the starter and battery is loose or corroded. ...
  • Page 124 Figure 13-10 Out-vehicle Test Screen The test results will display in a few seconds. Figure 13-11 Out-vehicle Test Results Screen...

  • Page 125: Test Results

    13.5.2 Test Results Table 13-7 Out-Vehicle Test Results Result Description Good Battery Battery meets required standards. Battery is good, but low on charge. Fully charge the Good & Recharge battery. Check for causes of low charge. Charge & Retest Battery requires charge to determine its condition. Replace Battery Battery fails to meet industry-accepted standards.

  • Page 126: Remote Desktop

    The Remote Desktop application launches the TeamViewer QuickSupport program, which is a simple, fast, and secure remote-control interface. You can use the application to receive remote support from Autel’s support center, colleagues or friends, by allowing them to control your MaxiCOM tablet on their PC via the TeamViewer software.
  • Page 127 downloading TeamViewer program (full version) online (see http://www.teamviewer.com), and then launch the software. Provide your ID to your partner and wait for him/her to send you a remote-control request. A prompt will appear asking you to allow remote control on your device. Tap Allow to accept, or tap Deny to reject.

  • Page 128: Support

    Support This application launches the Support platform which synchronizes Autel’s online service base station with the tablet. Connected to Autel’s service channel and online communities, the Support application provides the quickest way for problem solutions, allowing you to send help requests to obtain direct service and support.

  • Page 129: Data Logging

    Tap Send to deliver your message to Autel support. 15.4 Training The Training section provides quick links to Autel’s online video library. Select a video channel by language to see all available online tutorial videos on topics such as product...

  • Page 130: Faq

    15.5 FAQ The FAQ section provides comprehensive references for all questions frequently asked and answered about the use of Autel's online member account, shopping, and payment procedures. Account — displays questions and answers about the use of Autel's online user ...

  • Page 131: Maxiviewer

    MaxiViewer The MaxiViewer allows you to search the functions supported by our tools and the software version information. There are two ways of searching, either by searching the tool and the vehicle or searching the functions.  To Search by the vehicle Tap the MaxiViewer application on the MaxiCOM Job Menu.
  • Page 132 Figure 16-2 Function Viewer Screen 2  To search by the functions Tap the MaxiViewer application on the MaxiCOM Job Menu. The Function Viewer screen displays. Tap the tool name on the top-left to drop down the tool list. Tap the one you want to search.

  • Page 133: Maxivideo

    MaxiVideo The MaxiVideo application configures the MaxiCOM diagnostics tablet to operate as a digital video scope by simply connecting the tablet to a MaxiVideo Camera. This function allows you to examine difficult-to-reach areas normally hidden from sight, with the ability to record digital still images and videos, which offers you an economical solution to inspect machinery, facilities, and infrastructure in a safe and quick way.

  • Page 134: Quick Link

    Quick Link The Quick Link application provides you with convenient access to Autel’s official website and many other well-known sites in automotive service industry to provide technical help, knowledge bases, forums, and training and expertise consultations. Figure 18-1 Quick Link Screen ...

  • Page 135: Autel User Center

    Figure 19-1 Autel User Center Screen If you already have an Autel ID, you can log in with your phone number and verification code, or tap Log In with Password to log in with your Autel ID and password. If you don’t have an Autle ID yet, tap Register to create an Autel ID.
  • Page 136 If you have an Autel account, sign in with your account ID and password and skip to step 7. If you are a new member to Autel, click the Register button to create your Autel Enter the required personal information in the input fields.

  • Page 137: Maintenance And Service

    Maintenance and Service To ensure that the MaxiCOM diagnostic tablet performs at its optimum level, we advise that the product maintenance instructions covered in this section is read and followed. 20.1 Maintenance Instructions The following shows how to maintain your devices, together with precautions to take. ...

  • Page 138: Troubleshooting Checklist

    Your device may have not been connected to the charger properly. Check the connector. NOTE If your problems persist, please contact Autel’s technical support personnel or your local selling agent. 20.3 About Battery Usage Your tablet is powered by a built-in Lithium-ion Polymer battery. This means that, unlike other forms of battery technology, you can recharge your battery while some charge remains without reducing your tablet’s autonomy due to the “battery memory effect”...

  • Page 139: Service Procedures

    This section introduces information for technical support, repair service, and application for replacement or optional parts. 20.4.1 Technical Support If you have any question or problem on product operations, please contact us. Autel China Headquarters  Phone: +86 (0755) 8614-7779 (Monday-Friday, 9AM-6PM Beijing Time) ...
  • Page 140 Email: imea-support@autel.com  Address: 906-17, Preatoni Tower (Cluster L), Jumeirah Lakes Tower, DMCC, Dubai, UAE  Web: www.autel.com Autel Latin America Mexico:  Phone: +52 33 1001 7880 (Spanish in Mexico)  Email: latsupport@autel.com  Address: Avenida Americas 1905, 6B, Colonia Aldrete, Guadalajara, Jalisco,...

  • Page 141: Repair Service

    20.4.2 Repair Service If it becomes necessary to return your device for repair, please contact us first and then download the repair service form from www.autel.com, and fill it in. The following information must be included:  Contact name ...

  • Page 142: Compliance Information

    Compliance Information FCC Compliance FCC ID: WQ8-MX808S-TS2152 This device complies with Part 15 of the FCC rules and Industry Canada’s license-exempt RSSs. Operation is subject to the following two conditions: This device may not cause harmful interference. This device must accept any interference received, including interference that may cause undesired operation.
  • Page 143 -- Consult the dealer or an experienced radio/TV technician for help. Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. The radiated output power of this device is below the FCC radio frequency exposure limits.

  • Page 144: Warranty

    Warranty Limited One Year Warranty Autel Intelligent Technology Corp., Ltd. (the Company) warrants to the original retail purchaser of this MaxiCOM diagnostics device that should this product or any part thereof during normal usage and conditions, be proven defective in material or...
  • Page 145 IMPORTANT All contents of the product may be deleted during the process of repair. You should create a back-up copy of any contents of your product before delivering the product for warranty service.

Table of Contents
