Summary of Contents for Autel MaxiCOM MK908 II

  • Page 1 MaxiCOM MK908 II & MK908Pro II...
  • Page 2 Autel will not be liable for any direct, special, incidental, or indirect damages, or for any economic consequential damages (including lost profits) as a result of using this product.

  • Page 3: Safety Information

    The safety messages herein cover situations Autel is aware of at the time of publication. Autel cannot know, evaluate or advise you as to all of the possible hazards. You must be certain that any condition or service procedure encountered does not jeopardize your...
  • Page 4 DANGER When an engine is operating, keep the service area WELL VENTILATED or attach a building exhaust removal system to the engine exhaust system. Engines produce carbon monoxide, an odorless, poisonous gas that causes slower reaction time and can lead to serious personal injury or loss of life.
  • Page 5  To avoid damaging the test equipment or generating false data, make sure the vehicle battery is fully charged and the connection to the vehicle DLC is clean and secure.  Do not place the test equipment on the distributor of the vehicle. Strong electro- magnetic interference can damage the equipment.

  • Page 6: Table Of Contents

    CONTENTS ......................AFETY NFORMATION ......................AFETY ESSAGES ......................AFETY NSTRUCTIONS 1 USING THIS MANUAL ....................1 ......................1 ONVENTIONS 2 GENERAL INTRODUCTION ..................3 COM T ....................3 ABLET VCI — W ..............7 IRELESS IAGNOSTIC NTERFACE VCI — J2534 ECU P ...............
  • Page 7 4.10 ....................59 IAGNOSTICS 5 DATA MANAGER ......................61 ....................62 EHICLE ISTORY ..................64 ORKSHOP NFORMATION ......................65 USTOMER ........................66 MAGE ...................... 67 LOUD EPORT PDF F ......................68 ILES ......................68 EVIEW ....................... 68 OGGING ....................69 NINSTALL 6 BATTERY TEST ......................
  • Page 8 UPPORT CREEN AYOUT 13 QUICK LINK ......................... 95 14 MAXISCOPE ........................ 96 15 MAXIVIEWER ....................... 97 16 MAXIVIDEO ........................98 17 AUTEL USER CENTER ....................99 18 MAINTENANCE AND SERVICE ................101 18.1 ................101 AINTENANCE NSTRUCTIONS 18.2 ................102...

  • Page 9: Using This Manual

    Using This Manual This manual contains device usage instructions. Some illustrations shown in this manual may make reference to modules and optional equipment that are not included in your system. 1.1 Conventions The following conventions are used: 1.1.1 Bold Text Bold text is used to highlight selectable items such as buttons and menu options.
  • Page 10 1.1.5 Procedures An arrow icon indicates a procedure. Example:  To power down the MaxiCOM tablet Long press the Power/Lock button. Tap Power Off. Tap OK.

  • Page 11: General Introduction

    NOTE Autel provides two optional VCIs for your choice. One is the Wireless Diagnostic Interface; the other is the J2534 Programming Device. Both will be introduced in this chapter. This manual describes the construction and operation of these devices and how they work together to deliver diagnostic solutions.
  • Page 12 — Power LED indicates battery level & charging or system status Microphone The power LED displays green, yellow or red depending on power level and operating state. A. Green  Illuminates green when the tablet is charging and the battery level is above 90%. ...
  • Page 13 Figure 2-3 MaxiCOM Tablet, Top View 10. DC Power Supply Input Port 11. Headphone Jack 12. USB Port 13. HDMI (high-definition multimedia interface) Port 14. USB Port 15. Mini USB Port 16. Power/Lock Button — long press to turn the tablet on or off, or short press to lock the screen.
  • Page 14 2.1.3 Technical Specifications Table 2-1 Tablet Specifications Item Description Operating System Android Processor Qualcomm Longevity Platform: 2.2 GHz + 1.9 GHz Memory 4 GB RAM & 128 GB On-board Memory 10.1-inch LED capacitive touchscreen with 1920 x Display 1200 resolution ...

  • Page 15: Vci - Wireless Diagnostic Interface

    J1939, SAE J1708, Fault-Tolerant CAN 2.2 VCI — Wireless Diagnostic Interface 2.2.1 Function Descriptions Figure 2-4 Wireless Diagnostic Interface — for MaxiCOM MK908 II Vehicle Data Connector (DB15-Pin) Power LED — lights solid green when the device is powered on.
  • Page 16 Bluetooth LED — lights solid green when the device is connected with the tablet via Bluetooth communication; also flashes green when the data is being transmitted between the vehicle and the tablet. USB LED — lights solid green when the device is properly connected and communicating with the tablet via the USB cable.

  • Page 17: Vci - J2534 Ecu Programming Device

    2.3 VCI — J2534 ECU Programming Device 2.3.1 Function Descriptions Figure 2-5 J2534 ECU Programming Device DC Power Supply Input Port Vehicle Data Connector (DB26-Pin) flashes green when the device is communicating with the vehicle’s — Vehicle LED system. IMPORTANT Do not disconnect the J2534 ECU programming device while this vehicle LED is on! If the flash reprogramming procedure is interrupted while the vehicle’s ECU is blank or only partially programmed, the module may be unrecoverable.
  • Page 18 70 m). A signal lost due to moving out of range automatically restores itself when the tablet unit is brought closer to the VCI unit. 2.3.2 Power Sources The J2534 programming device can receive power from both of the following sources: ...

  • Page 19: Accessories Kit

    Item Description Weight 0.29 kg (0.64 lb.) 2.4 Accessories Kit 2.4.1 Main Cable The VCI can be powered through the Main Cable when connected to an OBDII/EOBD compliant vehicle. The Main Cable connects the VCI to the vehicle’s Data Link Connector (DLC), through which the VCI can transmit vehicle data to the tablet.
  • Page 20 Suitable for Suitable for Suitable for Benz- Suitable for Mitsubishi/Hyu Volkswagen/Au- PSA-2 n-dai-12+16 di-2+2 2.4.3 Other Accessories Standard 2.0 USB Cable Connects the tablet to the VCI. Mini USB Cable Connects the tablet to the Windows-based PC. AC/DC External Power Adapter Connects the tablet to the external DC power port for power supply.
  • Page 21 Spare Fuse x2 A safety device for the auxiliary power outlet adapter. BMW Ethernet Cable (Optional) Used for BMW F/G chassis programming and coding. USB to Ethernet Adapter Network connection function can be realized through this device.

  • Page 22: Getting Started

    Getting Started Make sure the tablet is fully charged or is connected to an external power supply (see Power Sources for details). 3.1 Powering Up Long press the Power/Lock button on the top right side of the tablet to switch the unit on.
  • Page 23 VCI Manager Manager for details. Configures your unit to receive remote Remote Desktop support using the TeamViewer application. Remote Desktop for details. Launches Support platform that synchronizes Autel’s online service base Support station with the MaxiCOM tablet. See Support for details.
  • Page 24 Accesses special functions menu. See Service Service for details. Allows you to register an account, view, and Autel User Center edit your personal profile and link your device. Autel User Center for details. 3.1.2 Page Control and Navigation Buttons Operations of the page control and navigation buttons are described as below:...
  • Page 25 Table 3-2 Page Control and Navigation Buttons Name Button Description Indicates the location of the current screen. Swipe the Page Control screen to left or right to view the previous or next screen. Back Returns to the previous screen. MaxiCOM Returns to the MaxiCOM Job Menu.

  • Page 26: Powering Down

    Name Button Description Service Returns to the Service screen. Shortcut  To use the camera Tap the Camera button. The camera screen opens. Focus the image to be captured in the viewfinder. Tap the Camera icon on the right of the screen. The viewfinder now shows the captured picture and auto-saves the taken photo.

  • Page 27: Printing

    3.3.1 Installing Computer Software The MaxiCOM MK908 II/MaxiCOM MK908Pro II Diagnostic Platform allows you to realize some of its functions on a computer to enhance capabilities and improve user experience. To realize these functions on a computer, you need to install certain software.
  • Page 28 Follow the instructions on the screen and click Next to continue. Click Install. The printer driver program will be installed to the PC. Click Finish to complete the installation.

  • Page 29: Diagnostics

    Airbag System (SRS) and more. 4.1 Establishing Vehicle Communication The Diagnostics operations require connecting the MaxiCOM MK908 II & MaxiCOM MK908Pro II Diagnostics Platform to the test vehicle through the VCI using the main cable or test adapters (for non-OBDII vehicles). To establish proper vehicle communication to the tablet, you need to perform the following steps: Connect the VCI to the vehicle’s DLC for both communication and power source.
  • Page 30  To connect to an OBDII vehicle Connect the main cable’s female adapter to the Vehicle Data Connector on the VCI, and tighten the captive screws. Connect the cable’s male adapter to the vehicle’s DLC, which is generally located under the vehicle dashboard. NOTE The vehicle’s DLC is not always located under the dashboard.
  • Page 31 The Wireless Diagnostic Interface (included with the MaxiCOM MK908 II tool kit) supports two communication methods with the MaxiCOM tablet: Bluetooth and USB. The J2534 ECU Programming Device (included with the MaxiCOM MK908Pro II tool kit) supports two communications methods with the MaxiCOM tablet: Bluetooth and USB.
  • Page 32 between the tablet and the VCI. The working range for Bluetooth communication is about 210 feet (70 m); this means you can perform vehicle diagnosis freely around the workshop with greater convenience. To expedite multi-vehicle diagnostics, more than one VCI can be used in busy repair shops, enabling technicians to quickly pair (via Bluetooth) their diagnostic tablets to each VCI separately and therefore eliminating the need to physically connect the VCI to each vehicle.
  • Page 33 Please contact Autel or local distributor for further technical support. B. If the VCI is unable to establish a communication link, a prompt message will display with further instructions.

  • Page 34: Getting Started

    4.2 Getting Started Prior to first use of the Diagnostics application, the VCI must be synchronized with the tablet to establish a communication link. See Manager for details. 4.2.1 Vehicle Menu Layout When the VCI is properly connected to the vehicle and paired to the tablet, the platform is ready to start vehicle diagnosis.

  • Page 35: Vehicle Identification

    Name Button Description Opens a drop-down list:  Tap Auto Detect for auto VIN detection. VID Scan  Tap Manual Input to enter VIN manually.  Tap Scan VIN/License to scan the VIN/license number by camera. Displays all the vehicle makes in the vehicle menu. Favorites Displays user-favorited vehicle makes.
  • Page 36 Auto VIN Scan Manual VIN Input Scan VIN/License Manual Vehicle Selection OBD Direct Entry 4.3.1 Auto VIN Scan The MaxiCOM diagnostic system features the latest VIN-based Auto VIN Scan function to identify vehicles with just one tap, which allows the technician to quickly detect vehicles, scan all the diagnosable ECUs on every vehicle, and run diagnostics on the selected system.
  • Page 37 Figure 4-4 Vehicle Selection Screen 4.3.2 Manual VIN Input For some vehicles that do not support the Auto VIN Scan function, the MaxiCOM diagnostic system allows you to enter the vehicle VIN manually, or simply take a photo of the VIN sticker for quick vehicle identification. ...
  • Page 38 Tap OK. The vehicle will be identified in a few seconds, and once the matching is successful, the system will guide you to the Vehicle Diagnostics screen directly. Tap “x” to exit Manual Input. 4.3.3 Scan VIN/License Tap Scan VIN/License in the drop-down list. The camera app will launch. On the right side of the screen, three options are available: Scan QR Code/Barcode, Scan VIN, and Scan License.

  • Page 39: Navigation

    4.3.4 Manual Vehicle Selection When the vehicle’s VIN is not automatically retrievable through the vehicle's ECU, or when the specific VIN is unknown, you can choose to select the vehicle manually. 4.3.4.1 Step-by-step Vehicle Selection This mode of vehicle selection is menu driven. Select the Vehicle Makes icon on the Vehicle Menu screen and the “Select Diagnostic Type”...
  • Page 40 Diagnostics Toolbar Current Directory Path Status Information Bar Main Section Function Buttons 4.4.1.1 Diagnostics Toolbar The Diagnostics Toolbar contains a number of buttons that allow you to print or save the displayed data and make other controls. The table below provides a brief description for the operations of the Diagnostics toolbar buttons: Table 4-2 Diagnostics Toolbar Buttons Name...
  • Page 41 The Status Information Bar at the top of the Main Section displays the following items: Cloud Server Icon — indicates the communication status between the tablet and the Autel Cloud Server. VCI Icon — indicates the communication status between the tablet and the VCI.

  • Page 42: Main Menu

    4.4.2 Screen Messages Screen messages appear when additional input is needed before proceeding. There are mainly three types of on-screen messages as to their purposes: Confirmation, Warning, and Error. 4.4.2.1 Confirmation Messages This type of messages usually displays as an “Information” screen, which informs you when you are about to perform an action that cannot be reversed or when an action has been initiated and your confirmation is needed to continue.

  • Page 43: Diagnosis

    Service — a separate section designed to perform vehicle scheduled service and maintenance, such as to reset the service lights and perform calibration for various systems Programming/Coding — a separate section designed for quick access to ECU reprogramming operations After a section is selected and the tablet establishes communication with the vehicle via the VCI, the corresponding function menu or selection menu displays.
  • Page 44 Progress Bar — indicates the test progress  Main Section A. List Tab  Column 1 — displays the system numbers  Column 2 — displays the scanned systems  Column 3 — displays the diagnostic marks indicating different conditions of the test result: Fault | #: Indicates there is/are fault code(s) present;...
  • Page 45 follow the menu-driven procedure and the program will guide you to the diagnostic function menu. The Function Menu options vary slightly for different vehicles. The function menu may include:  ECU Information — provides the retrieved ECU information in detail. Selecting it opens an information screen.
  • Page 46 Figure 4-9 Function Menu Screen 4.6.3 ECU Information This function retrieves and displays the specific information for the tested control unit, including unit type, version numbers, and other specifications. The sample ECU Information screen displays as below: Figure 4-10 ECU Information Screen Diagnostics Toolbar Buttons —...
  • Page 47 4.6.4 Trouble Codes 4.6.4.1 Read Codes Figure 4-11 Read Codes Screen This function retrieves and displays the DTCs from the vehicle’s control system. The Read Codes screen varies for each vehicle being tested on some vehicles, freeze frame data can also be retrieved for viewing. The sample Read Codes screen displays as above. Diagnostics Toolbar Buttons —...
  • Page 48 Name Description Erases codes from the ECU. It is recommended that Erase codes DTCs are read and needed repairs are performed before erasing codes. Retrieves and displays the DTCs from the vehicle control Read codes system. The Read Codes screen varies for each vehicle being tested.
  • Page 49 Gesture scrolling allows you to quickly move through the data list. Simply swipe the screen up or down to reposition the parameters being displayed if the data covers more than one screen. The figure below shows a typical Live Data screen: Figure 4-12 Live Data Screen Diagnostics Toolbar Buttons Main Section...
  • Page 50  To change the Unit mode  Tap the Settings button in the top toolbar and select a required mode. See Units for more information. 4.6.5.1 Display Mode There are four types of display modes available for data viewing, allowing you to view various types of parameters in the most suitable way for data check-ups.
  • Page 51 Figure 4-14 Waveform Graph Mode Screen Settings Button (SetY) — sets the minimum and maximum value of the Y-axis. Scale Button — changes the scale values. Which can be used to change the scale values of the X-axis and Y-axis of the graph. There are four scales available for the X-axis: x1, x2, x4 and x8, and three scales available for the Y- axis: x1, x2, and x4.
  • Page 52 Figure 4-15 Waveform Edit Screen The parameter is selected automatically in the left column. Select a color from the middle column. Select a line thickness from the right column. Tap Done to save the setting and exit, or tap Cancel to exit without saving. NOTE In the full screen display mode, you can edit the waveform’s color and line thickness by tapping the Edit button on the upper-right side of the screen.
  • Page 53 Figure 4-16 Trigger Settings Screen Two buttons and two input boxes are available in the Trigger Settings window. Trigger — switches the trigger on and off. The trigger is ON by default. Buzzer alarm — switches the alarm on and off. The alarm function makes a beeping sound as an alert when the data reading reaches the threshold values.
  • Page 54 the alarm point. The threshold lines are shown in different colors to differentiate them from the parameter waveforms. Function Buttons The operations of the function buttons on the Live Data screen are described below:  Cancel All — tap to cancel all selected parameters. Up to 50 parameters can be selected at one time.
  • Page 55 Tap OK to save the settings and return to the Live Data Settings screen, or tap the “X” button on the upper-right corner to exit without saving. Tap Done at the upper-right corner of the Live Data Setting screen to confirm and save the settings and return to the Live Data screen, or tap Cancel to exit without saving.
  • Page 56 actuators. This test determines the integrity of the system or parts by reading the engine ECU data, or by monitoring the operation of the actuators, such as toggling a solenoid, relay, or switch, between two operating states. Selecting Active Test opens a menu of test options that varies by make and model. Selecting a menu option activates the test.

  • Page 57: Generic Obdii Operations

    The second part shows the preconditions or requirements for executing the operation being selected. The third part displays the current conditions of the vehicle control module being learned for comparison to the preconditions suggested by the second part. If the current condition of the control module is out of the suggested limit value, then it must be adjusted to meet the requirement.
  • Page 58 between an ECU and a diagnostic tool. Global OBD may use several different communication protocols. Select a specific protocol if the Protocol option is selected. Wait for the Function menu screen to appear. Figure 4-18 Function Menu Select a function option to continue. ...
  • Page 59 4.7.2.1 DTC & FFD When this function is selected, the screen displays a list of Stored Codes and Pending Codes. When the Freeze Frame data of certain DTCs are available for viewing, a snowflake icon will display on the right side of the DTC item. The Erase Codes function can be applied by tapping the Erase codes button at the bottom of the screen.
  • Page 60 A confirmation screen displays when the clear codes option is selected to prevent accidental loss of data. Select Yes on the confirmation screen to continue, or No to exit. 4.7.2.2 I/M Readiness This function is used to check the readiness of the monitoring system. It is an excellent function to use prior to having a vehicle inspected for compliance to a state emissions program.

  • Page 61: Service

    4.7.2.8 Vehicle Status This item is used to check the current condition of the vehicle, including communication protocols of OBDII modules, retrieved codes amount, status of the Malfunction Indicator Light (MIL), and other additional information may be displayed. 4.8 Service The Service section is specially designed to provide quick access to the vehicle systems for various scheduled service and maintenance tasks.
  • Page 62 Ensure that the EPB control system is reactivated after the maintenance work has been completed. NOTE Autel accepts no responsibility for any accident or injury arising from the maintenance of the Electric Parking Brake system. 4.8.1.3 Battery Management System (BMS) Service...
  • Page 63 NOTE This function is not supported by all vehicles. The sub functions and actual test screens of the BMS may vary by vehicle, please follow the on-screen instructions to make correct option selection. The vehicle may use either a sealed lead-acid battery or an AGM (Absorbed Glass Mat) battery.
  • Page 64 NOTE AUTEL accepts no responsibility for any accident or injury arising from servicing the SAS system. When interpreting DTCs retrieved from the vehicle, always follow the manufacturer’s recommendation for repair. All software screens shown in this manual are examples, actual test screens may vary by test vehicle.
  • Page 65 NOTE The DPF will not regenerate if the engine management light is on, or there is a faulty EGR valve. The ECU must be re-adapted when replacing the DPF and when topping up the fuel additive Eolys. If the vehicle needs to be driven in order to perform a DPF service, ALWAYS have a second person help you.

  • Page 66: Coding

     To program the replacement key fob(s) Tap IMMO KEYS after entering the Service function from the Job Menu. Tap Automatic Selection or Manual Selection to acquire vehicle VIN information and tap Yes to confirm. Tap Erase/Program all key fobs in the IMMO function list after it is displayed, the list may vary for different vehicles being tested.

  • Page 67: Exit Diagnostics

    being performed. 4.9.1 Variant Coding Figure 4-19 Variant Coding Screen The main section of the Variant Coding screen displays a list of vehicle components: The top line on the list displays all available systems for coding on the left side, and the coding data or values on the right side.
  • Page 68 NOTE Damage to the vehicle Electronic Control Module (ECM) may occur if communication is disrupted. Make sure all connections, such as data cable, USB cable, and wireless or wired network, are properly connected at all times during testing. Exit all tests before disconnecting the test cable or powering down the tool.

  • Page 69: Data Manager

    Data Manager The Data Manager application is used to store, print, and review the saved files. Selecting the Data Manager application opens the file system menu. There are nine types of information files to be viewed or played back. Figure 5-1 Data Manager Main Screen The table below describes each of the function buttons in the Data Manager.

  • Page 70: Vehicle History

    Review Data Tap to view recorded data. Uninstall Apps Tap to uninstall applications. Tap to view communications with Autel support service and ECU information for the test vehicle. Data Logging The saved data can be reported and sent to the technical center via the Internet.
  • Page 71 ① Top Toolbar Buttons — navigation and application controls. ② Main Section — displays all the test records.  To activate a test session for a recorded vehicle Tap Data Manager on the MaxiCOM Job Menu. Select Vehicle History to open the screen. Tap Diagnostics or Service to select diagnostic test records or service test records.

  • Page 72: Workshop Information

     To edit a previous Test Record Tap Data Manager in the MaxiCOM main screen. Select Vehicle History. Select a specific vehicle history record thumbnail from the main section. The test record will display. Tap the Edit button (the pen icon) to start editing. Tap each item to enter information or attach files or images.

  • Page 73: Customer

     To edit the Workshop information sheet Tap Data Manager on the MaxiCOM Main Screen. Select Workshop Information. Tap on each field to enter the corresponding information. Tap Done to save the updated workshop information, or tap Cancel to exit without saving.

  • Page 74: Image

    Tap Complete to save the updated information, or tap Cancel to exit without saving.  To delete a customer account Tap Data Manager on the MaxiCOM Job Menu. Select Customer. Tap Delete on the right of a customer account. A reminder message displays. Tap OK to confirm the command and delete the account.

  • Page 75: Cloud Report

    5.5 Cloud Report This section displays the saved reports, which can be transferred to the Autel cloud platform once a stable network connection is established. These reports can then be viewed or shared with others.

  • Page 76: Pdf Files

    5.6 PDF Files The PDF files designated for local viewing are displayed in this section. After entering the PDF database, select a file to view. This section uses the standard Adobe Acrobat Reader application for file viewing and editing. Please refer to the associated Adobe Acrobat Reader manual for more detailed instructions.

  • Page 77: Uninstall Apps

    5.9 Uninstall Apps This section allows you to manage the software application installed on the MaxiCOM diagnostics system. Selecting this section opens a management screen, on which you can check all available vehicle diagnostics applications. Select the vehicle software you want to delete by tapping on the vehicle brand icon, the selected item will display a blue tick at the bottom-right corner.

  • Page 78: Battery Test

    Battery Test The MaxiBAS BT506 is a battery and electrical system analysis tool that uses Adaptive Conductance, an advanced battery analysis method to produce a more accurate examination of the battery cold cranking ability and reserve capacity, which is vital to determining a battery’s true health.
  • Page 79 Table 6-1 LED Description Color Description Flashing Green The tester is communicating via USB cable. Status Flashing Blue The tester is communicating via Bluetooth. Battery clamps are connected to the wrong battery Flashing Red terminals. Solid Green The tester is powered on and sufficiently charged. The tester is charging.

  • Page 80: Test Preparation

    6.1.3 Technical Specifications Table 6-2 Technical specifications Item Description  USB 2.0, type C Connectivity  Bluetooth 4.2 Input Voltage 5 V DC Working Current < 150 mA at 12 V DC Internal Battery 3.7 V/800 mAh Lithium-ion polymer battery CCA Range 100 to 2000 A Voltage Range...
  • Page 81 6.2.2 Connect the Battery Tester  To pair the BT506 with the MaxiCOM tablet Press and hold the Power button to turn on both the MaxiCOM tablet and BT506. Ensure that the units are sufficiently charged before using. Enable Bluetooth on the MaxiCOM tablet by tapping VCI Manager > BAS BT, and the tablet automatically scans for an available tester for Bluetooth pairing.

  • Page 82: In-Vehicle Test

    6.3 In-vehicle Test In-vehicle Test is used for testing batteries that are installed in a vehicle. An in-vehicle test includes Battery Test, Starter Test, and Generator Test. These tests help determine the health status of the battery, the starter, and the generator. IMPORTANT Before using the diagnostic functions, download the desired vehicle software on the Update screen.
  • Page 83 Table 6-3 Top Toolbar Name Button Description The value on the icon indicates the real-time Battery voltage of the tested battery. In the battery test, Connection the button will turn green if the battery is good; otherwise, it will turn red. Next Tap to proceed.
  • Page 84 Figure 6-6 Battery Test Results Screen Battery Test Results The battery test results include a color-coded results summary and a list of test data. Table 6-4 Test Results Result Description Good Battery Battery is good. Good & Recharge Battery is good but insufficiently charged. Recharge the battery. Charge &...
  • Page 85 Figure 6-7 Starter Test Result Screen Table 6-5 Starter Test Results Result Description Cranking Normal The starter is good. Current Too Low Low momentary discharge capacity. Voltage Too Low Low battery storage capacity. Not Started The starter is not detected for starting. 6.3.3 Generator Test Follow the on-screen instructions to complete the test.
  • Page 86 Figure 6-8 Generator Test Results Screen Table 6-6 Generator Test Results Result Description Charging Normal The generator is functioning normally.  The belt linking the starter and the generator is loose;  The cable linking the starter and battery is loose or Output Too Low corroded.

  • Page 87: Out-Vehicle Test

    6.4 Out-vehicle Test Out-vehicle Test is used to test the conditions of batteries that are not connected to a vehicle. This function aims to check the health status of the battery only. 6.4.1 Test Procedure  To start the out-vehicle test Tap Battery Test application from the Job Menu.
  • Page 88 Figure 6-10 Out-vehicle Test Results Screen 6.4.2 Test Results Icons are color-coded to indicate status. Table 6-7 Out-vehicle Test Results Result Description Good Battery Battery meets required standards. Battery is good, but low on charge. Fully charge the Good & Recharge battery.

  • Page 89: User Feedback

    PDF files to the form. To help us resolve the issue more efficiently, we recommend you complete the form as many details as possible. Tap Submit to send the completed form to Autel's online service center. The submitted feedback will be carefully read and handled by our support personnel.

  • Page 90: Settings

    Settings Selecting Settings application opens a setup interface, on which you can adjust default settings and view information about the MaxiCOM system. The following options are available for the MaxiCOM system settings:  Units  Language  Printing Settings  Scan Report ...

  • Page 91: Printing Settings

     To adjust the language setting Tap the Settings application on the MaxiCOM Job Menu. Tap the Language option on the left column. Select the required language. A tick icon will display to the right of the selected language. Tap the Home button on the top left corner to return to the MaxiCOM Job Menu, or select another setting option for the system setup.

  • Page 92: Push Notifications

    8.5 Push Notifications This option allows you to manage notifications. The Notification Preference is turned on by default and cannot be turned off by users so that certain system notifications such as system security warnings will not be blocked. Internet access is required for receiving on-line messages.

  • Page 93: Vehicle List

    NOTE An Internet connection is necessary for auto update to work properly. Make sure the device is connected to the Internet during your scheduled time. 8.7 Vehicle List This option allows you to sort the vehicles either by alphabetic order or by frequency of use.

  • Page 94: Update

    Internet. Any updates that are found can be downloaded and installed on the device. NOTE Make sure the tablet is registered before activating the Update application. See Autel User Center for details.  To update the software Power up the tablet, and ensure that it is connected to a power source and has a steady Internet connection.

  • Page 95: Vci Manager

    Device’s vehicle data connector (for MaxiCOM MK908 Pro II); Or connect the 15-pin end of the main cable to the Wireless Bluetooth Diagnostic Interface’s vehicle data connector (for MaxiCOM MK908 II) Connect the 16-pin end of the main cable to the vehicle Data Link Connector (DLC).

  • Page 96: Bas Bluetooth Pairing

    Select VCI BT from the connection mode list. Toggle Bluetooth ON. The device will start searching for available units for pairing. Depending on the VCI type you use, the device name may display as “Maxi” suffixed with a serial number. Select the required device for pairing. When paring is successfully done, the connection status reads as “Connected.”...

  • Page 97: Vci Update

    10.3 VCI Update Before updating the VCI software, please make sure the MaxiCOM tablet network connection is stable.  To update the VCI Power on the MaxiCOM tablet. Connect the VCI to MaxiCOM tablet via Bluetooth or USB. Tap the VCI Manager application on the MaxiCOM Job Menu of the tablet. Select VCI Update from the connection mode list.

  • Page 98: Remote Desktop

    You can use the application to receive ad-hoc remote support from Autel’s support center, colleagues, or friends, by allowing them to control your MaxiCOM tablet on their PC via the TeamViewer software.
  • Page 99  To receive remote support from a partner Power on the tablet. Tap the Remote Desktop application on the MaxiCOM Job Menu. The TeamViewer interface displays and the device ID is generated and shown. Your partner must install the Remote Control software to his/her computer by downloading TeamViewer full...

  • Page 100: Support

    Support This application launches the Support platform which synchronizes Autel’s online service base station with the MaxiCOM tablet. Connected to Autel's service channel and online communities, the Support application provides the quickest way for problem solutions, allowing you to send help requests to obtain direct service and support.
  • Page 101 The Service Info tab displays a detailed record list of the device’s service history information. Every time the device has been sent back to Autel for repair, the device’s serial number and other information, including Service date, Type of faults, and Repair content, will be recorded and updated to the associated online product account, which will be synchronized to the Service Info section.
  • Page 102 Autel’s online member account, shopping, and payment procedures.  Account — displays questions and answers about the use of Autel’s online user account.  Shopping — displays questions and answers about online product purchases.

  • Page 103: Quick Link

    Quick Link The Quick Link application provides you with convenient access to Autel’s official website and many other well-known sites in automotive service, which offers you abundant information and resources, such as technical help, knowledge base, forums, training, and expertise consultations.

  • Page 104: Maxiscope

    Please download the latest user manual for Autel MaxiScope device from www.autel.com > Specialty Tools > MORE PRODUCTS > MaxiScope MP408 >...

  • Page 105: Maxiviewer

    MaxiViewer MaxiViewer allows you to search functions and the version information supported by our tools. There are two ways of searching, either by searching the tool and the vehicle or searching the functions.  To search by the vehicle Tap the MaxiViewer application on the MaxiCOM Job Menu. The MaxiViewer screen displays.

  • Page 106: Maxivideo

    MaxiVideo The MaxiVideo application configures the MaxiCOM diagnostics device to operate as a digital video scope by simply connecting the tablet to a MaxiVideo Camera. This function allows you to examine difficult-to-reach areas normally hidden from sight, with the ability to record digital still images and videos, which offers you an economical solution to inspect machinery, facilities, and infrastructure in a safe and quick way.

  • Page 107: Autel User Center

    If you have an Autel account, input your email or mobile number and password to log in or log in with verification code. If you are a new member to Autel, click Register to create your Autel ID. Enter your personal information. Fields marked with an asterisk (*) are mandatory.
  • Page 108 Agreement and Autel Privacy Policy, then check the box to accept the terms and click Register. Once your account is successfully registered, you will be redirected to the Product Registration screen. If not, click the button on the screen. Your product serial number and password are required to enter. To find your serial number and password on the tablet: go to Settings ＞...

  • Page 109: Maintenance And Service

    Maintenance and Service To ensure that the tablet and the combined VCI unit perform at their optimum level, we advise that the product maintenance instructions covered in this section is read and followed. 18.1 Maintenance Instructions The following shows instructions on how to maintain your devices, together with precautions to take.

  • Page 110: Troubleshooting Checklist

    Your device may have not been connected to the charger properly. Check the connector. NOTE If your problems persist, please contact Autel’s technical support personnel or your local selling agent. 18.3 About Battery Usage Your tablet is powered by a built-in Lithium-ion Polymer battery. This means that, unlike other forms of battery technology, you can recharge your battery while some charge remains without reducing your tablet’s autonomy due to the “battery memory effect”...

  • Page 111: Service Procedures

    Do not modify or remanufacture, attempt to insert foreign objects into the battery, expose to fire, explosion or other hazard.  Use only the included charger and USB cables. Failure to use Autel-authorized charger and/or USB cables, may result in device malfunction or failure. ...
  • Page 112  Email: imea-support@autel.com  Address: 906-17, Preatoni Tower (Cluster L), Jumeirah Lakes Tower, DMCC, Dubai,  Web: www.autel.com Autel Latin America Mexico:  Phone: +52 33 1001 7880 (Spanish in Mexico)  Email: latsupport@autel.com  Address: Avenida Americas 1905, 6B, Colonia Aldrete, Guadalajara, Jalisco,...
  • Page 113 Campinas – SP, Brazil  Web: www.autel.com/br. 18.4.2 Repair Service If it becomes necessary to return your device for repair, please download the repair service form from www.autel.com, and fill in the form. The following information must be included:  Contact name ...
