INVERTER
A800
F800
SynRM DRIVING
FUNCTION MANUAL
FR-A820-00046(0.4K)-04750(90K)-SYN
FR-A840-00023(0.4K)-06830(280K)-SYN
FR-A842-07700(315K)-12120(500K)-SYN
FR-F820-00046(0.75K)-04750(110K)-SYN
FR-F840-00023(0.75K)-06830(315K)-SYN
FR-F842-07700(355K)-12120(560K)-SYN
SynRM Driving Function
The FR-A800-SYN and FR-F800-SYN inverters have the SynRM driving functions, in addition to the functions of
the standard FR-A800 and FR-F800 inverters.
This SynRM Driving Function Manual explains the functions dedicated to the FR-A800-SYN and FR-F800-SYN.
For the functions not found in this Function Manual, refer to the FR-A800 or FR-F800 Instruction Manual.
In addition to this SynRM Driving Function Manual, please read the FR-A800 or FR-F800 Instruction Manual
800-SYN
carefully. Do not use this product until you have full knowledge of this product mechanism, safety information and
instructions.
Please forward this Function Manual to the end user.
800-SYN
