OUTDOOR UNIT
SERVICE MANUAL
Models
NTXSMT09A112AA
NTXSMT12A112AA
NTXSMT15A112AA
NTXSMT18A112AA
NTXSMT24A112AA
NTXSMT24A112AA
Revision B:
• Some descriptions have been modified.
OBHT747 REVISED EDITION-A is void.
HFC
utilized
R410A
NTXSMT09A112AB
NTXSMT12A112AB
NTXSMT15A112AB
NTXSMT18A112AB
Indoor unit service manual
NTXWMT•A112AA Series (OBHT746)
CONTENTS
1. TECHNICAL CHANGES ······························3
2. PART NAMES AND FUNCTIONS ··················4
3. SPECIFICATION ········································5
4. OUTLINES AND DIMENSIONS ··················· 10
5. WIRING DIAGRAM ··································· 12
6. REFRIGERANT SYSTEM DIAGRAM ··········· 15
7. DATA ······················································ 18
8. ACTUATOR CONTROL ····························· 31
9. SERVICE FUNCTIONS ······························ 32
10. TROUBLESHOOTING ······························· 33
11. DISASSEMBLY INSTRUCTIONS ················· 58
PARTS CATALOG (OBBT747)
No. OBHT747
REVISED EDITION-B
