Placement and Maintenance
Your Vail Extendable Table is designed for indoor use on level
floors. Furniture with hard lacquer, wax polish or painted
surface should be dusted with a dry cloth. Spillages should be
wiped up as soon as possible. Our furniture will endure most
temperatures in the home but it is best to avoid placing furniture
next to heat sources such as radiators or fires.
Step 1
Unpack and identify the parts listed below. It is required to have
2 people to carry and assemble the units over 50Ibs.
The assembly workspace should be a non-marring surface
such as carpet. For missing hardware pieces, visit our website
www.mossdesign.us
VAIL
EXTENDABLE TABLE
YNG TAL 14 / MFMT34 D:07.03.2022 / RN 001
Tool Provided:
T1 M6 Allen Key x 1
H1 Bolt
(8x50mm) x 8
H2 Washer x 8
C1 Table Top x 1
C2 Leg x 4
Advertisement
Related Manuals for moss DESIGN VAIL
Summary of Contents for moss DESIGN VAIL
- Page 1 Placement and Maintenance T1 M6 Allen Key x 1 Your Vail Extendable Table is designed for indoor use on level floors. Furniture with hard lacquer, wax polish or painted surface should be dusted with a dry cloth. Spillages should be H1 Bolt wiped up as soon as possible.
- Page 2 Step 2 - Remove the wedges. Remove 4 wedges from the Table top C1 by using an allen key (T1). ATTENTION The bolts (H1) and washers (H2) from here, you will use in the 3th step. Step 3 - Attach legs to the table top. Attach 4 legs C2 to the table top C1 by using 8 bolts H1, 8 washers H2, and the allen key T1.
- Page 3 Step 4 - End of the assembly. Lift the unit to standing position carefully. Step 5 - Extend the table. In order to extend the table, first free the locks under the table top and slide apart the two halves of the table top as shown below.
- Page 4 Step 5 - Rotate and open the extension leave. Rotate and open the extension leaves as shown below. Caution! Watch your hands when closing the extension leaves. Be sure to hold two leaves of the extension with both hands while folding it. Step 7 - Place the extension leaf.
- Page 5 Step 8 - End of the assembly. Moss Design is a trade name of a Colorado company Moss Furniture LLC www.mossdesign.us...
