Roland TD-27 Supplementary Manual

TD-27 Version 2.10 Supplementary Manual
This manual explains the new features that were added in TD-27
version 2.10.
Introduction
The following functions have been added or changed as of TD-27
version 2.10.
DWe (DW-brand convertible drum) pads can now be used. DWe (DW-brand convertible drum) pads can now be used.
Trigger types have been added, allowing more pads to be used. Trigger types have been added, allowing more pads to be used.
The auto off function specifications have been changed. The auto off function specifications have been changed.
Checking the system program version of
the TD-27
Make sure that the system program version of the TD-27 is
or later.
If the current version is earlier than Ver. 2.10, update the system.
Checking the TD-27 version
1.
Press the [SYSTEM] button on the TD-27.
The SYSTEM screen appears.
2.
Use the cursor buttons to select "INFO" and press
the [ENTER] button.
The information screen appears.
3.
Press the [F1] (PROGRAM) button to show the
program version.
How to get the update (system program)
You can download free updates for TD-27 Ver. 2 and later via
Roland Cloud Manager. Refer to the following for details.
https://www.roland.com/products/rc_td-27_version_2_update/
1
Using a DWe pad
You can now connect a DWe (DW-brand convertible drum) pad to
the TD-27.
Refer to "Configuring the TD-27 to use the DWe pads" (Roland
website) for how to make the settings.
Configuring the additional trigger types
Trigger types have been added for the following pads.
KD-22, KD-18, KD-12
PD-12X, PD-10X
KDQ-8, PDQ-8S, PDQ-8, CYQ-12
* See the Owner's Manual included with the pad in question for
how to set up and play each pad.
MEMO
Trigger type
Ver. 2.10
The trigger type is a collection of various trigger parameters,
adjusted to values that are appropriate for each pad. To make the
optimal settings for a connected pad, specify the model (trigger
type) of that pad.
Setting the trigger type
1.
Press the [SYSTEM] button.
The SYSTEM screen appears.
2.
Use the cursor buttons to select "TRIGGER" and
press the [ENTER] button.
The TRIGGER MENU screen appears.
3.
Use the cursor buttons to select "BANK", and press
the [ENTER] button.
The TRIGGER BANK screen appears.
Trigger bank number
Trigger type
4.
To select the pad for which to make settings, either
strike that pad or use the cursor buttons.
Display
K
S
T1–T3
HH
© 2024 Roland Corporation
Explanation Display
KICK C1, C2
SNARE R
TOM 1–3 A1–A3
HI-HAT
Explanation
CRASH 1, 2
RIDE
AUX1–3
01
