Racelogic VBOX 4 Quick Start Manual page 3

ANT A
ANT B
LEDs
LOG
SATS
DUAL
WIFI/BT
PWR
DGPS
IMU
D IN
You can find the full description of the different LED behaviours here.
LOG Button
The LOG button will override any of the automatic logging thresholds set in the VBOX unit. For example, if you have
set the VBOX unit to log all the time, the LOG button will toggle logging on and off. If you have set the VBOX unit to
'log only when moving' and you are moving, pressing the LOG button will stop the VBOX unit logging and close the
file on the SD card. Logging will now not continue, even if you are moving, until you press the LOG button again or
you remove the SD card and reinsert it. The VBOX unit will then continue to log only when moving.
Notes:
• If the VBOX unit is using Log only when moving log mode, and the vehicle has been stationary from power-
up, the LOG button will not initiate logging. If you want the VBOX unit to log in this situation, you have to use
https://en.racelogic.support//Product_Info/VBOX_Data_Loggers/VBOX_4_Product_Range/VBOX_4_ADAS/User_Guide/
The primary antenna connector.
The secondary antenna connector.
Indicates the logging status of the VBOX unit and if the
firmware is being updated.
Indicates the number of satellites being tracked.
Indicates if dual antenna mode is enabled/disabled and
the antenna lock is fixed.
Indicates that the VBOX unit is waiting for connection or
has been connected to a device.
Indicates if the unit is powered and ready to use or not.
Indicates the DGPS status and RTK lock.
Indicates IMU integration and initialisation status.
Indicates activated/triggered event marker input.
