Quick Start Guide – VBOX Touch (v1): Decel Mode
VBOX Touch features a 10 Hz GNSS receiver and a responsive colour touchscreen. The Decel Mode allows you to
perform deceleration tests using pre-defined configurations, using your own specified values or by using a
Pedal
Trigger.
Registration
Please register your VBOX Touch so that Racelogic can
continue to provide you with notifications about the latest
software releases and firmware upgrades for your
Racelogic product, and offer technical support.
Register your device here.
What is in the box?
When you purchase a VBOX Touch Motorsport (v1) (RLVBTOUCH-M), you will find the following items when you
open the box:
Product Code
VBTOUCH-V1
MECH0298SD
VBOX_Touch_(v1)/Quick_Start_Guides_%E2%80%93_VBOX_Touch_(v1)/Quick_Start_Guide_%E2%80%93_VBOX_Touch_(v1)%3A_Decel_Mode
Quantity
1
1
https://en.racelogic.support//Product_Info/Performance_Meters/VBOX_Touch/
Description
VBOX Touch Unit
Rubber Overmould - Black
VBOX Brake
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the VBTOUCH-V1 and is the answer not in the manual?

Questions and answers

Related Manuals for Racelogic VBTOUCH-V1

Summary of Contents for Racelogic VBTOUCH-V1

  • Page 1 VBOX Brake Pedal Trigger. Registration Please register your VBOX Touch so that Racelogic can continue to provide you with notifications about the latest software releases and firmware upgrades for your Racelogic product, and offer technical support. Register your device here.

  • Page 2: Optional Accessories

    If you are looking to purchase a new SD card, it is recommended that any card used has a write speed of above 7 MB/s (4 MB/s absolute minimum) and a speed class of 10 (4 absolute minimum). Racelogic recommends SD cards from quality brands such as Transcend, SanDisk, Kingston or Lexar to ensure the best results.
  • Page 3 The VBOX Touch unit is powered by a power cable that is unterminated so that you can make a bare-wire connection to a power supply. The cable terminates in a 2-way connector that mates with the Power socket on VBOX Touch. On boot-up, the VBOX Touch will display a splash screen and automatically look for satellites and media. https://en.racelogic.support//Product_Info/Performance_Meters/VBOX_Touch/ VBOX_Touch_(v1)/Quick_Start_Guides_%E2%80%93_VBOX_Touch_(v1)/Quick_Start_Guide_%E2%80%93_VBOX_Touch_(v1)%3A_Decel_Mode...
  • Page 4 If you have come to a stop, but the Record Icon is still on, press the SD Card Icon to stop the logging before removing the card. Sometimes, due to poor satellite visibility in a garage or close to a building, the box may start recording, even if the car is stationary. Always check the Record Icon before ejecting the card. https://en.racelogic.support//Product_Info/Performance_Meters/VBOX_Touch/ VBOX_Touch_(v1)/Quick_Start_Guides_%E2%80%93_VBOX_Touch_(v1)/Quick_Start_Guide_%E2%80%93_VBOX_Touch_(v1)%3A_Decel_Mode...
  • Page 5 • Solution type: Indicator for what the unit is currently using to derive position: 0 = No sats; 1 = Standalone using GNSS only; 2 = DGNSS. • Event 1 time: This is the digital input oversample timer used to interpolate the trigger event time between captured samples. Connectors https://en.racelogic.support//Product_Info/Performance_Meters/VBOX_Touch/ VBOX_Touch_(v1)/Quick_Start_Guides_%E2%80%93_VBOX_Touch_(v1)/Quick_Start_Guide_%E2%80%93_VBOX_Touch_(v1)%3A_Decel_Mode...
  • Page 6 You can find more information about the Serial Output settings in the Serial Output section in the relevant user guide. You can find more detailed connector information on the PIN OUTS page. https://en.racelogic.support//Product_Info/Performance_Meters/VBOX_Touch/ VBOX_Touch_(v1)/Quick_Start_Guides_%E2%80%93_VBOX_Touch_(v1)/Quick_Start_Guide_%E2%80%93_VBOX_Touch_(v1)%3A_Decel_Mode...

  • Page 7: Satellite Reception

    The placement of the GNSS antenna is crucial to the quality of the data recorded by VBOX Touch. Any metal close to a GNSS antenna can unpredictably disturb the signal due to interference from reflections of weak GNSS signals. https://en.racelogic.support//Product_Info/Performance_Meters/VBOX_Touch/ VBOX_Touch_(v1)/Quick_Start_Guides_%E2%80%93_VBOX_Touch_(v1)/Quick_Start_Guide_%E2%80%93_VBOX_Touch_(v1)%3A_Decel_Mode...

  • Page 8: Cold Start

    You can read more about external antenna placement here. Media, iframe, embed and object tags are not supported inside of a PDF. Coldstart To perform a coldstart, press the COLDSTART button within the Diagnostics Settings menu. https://en.racelogic.support//Product_Info/Performance_Meters/VBOX_Touch/ VBOX_Touch_(v1)/Quick_Start_Guides_%E2%80%93_VBOX_Touch_(v1)/Quick_Start_Guide_%E2%80%93_VBOX_Touch_(v1)%3A_Decel_Mode...
  • Page 9 The LEDs provide a live reference Lap Timing Mode lap speed comparison (Delta-V). The current lap is > 5 km/h quicker than the reference lap The current lap is 2.5 km/h quicker than the reference lap https://en.racelogic.support//Product_Info/Performance_Meters/VBOX_Touch/ VBOX_Touch_(v1)/Quick_Start_Guides_%E2%80%93_VBOX_Touch_(v1)/Quick_Start_Guide_%E2%80%93_VBOX_Touch_(v1)%3A_Decel_Mode...
  • Page 10 If a Target Speed LED Alert has Speed Mode been set, the LEDs will flash green when the value is reached. If a screenshot has been saved Screenshot successfully, the LEDs will illuminate yellow in sequence from left to right https://en.racelogic.support//Product_Info/Performance_Meters/VBOX_Touch/ VBOX_Touch_(v1)/Quick_Start_Guides_%E2%80%93_VBOX_Touch_(v1)/Quick_Start_Guide_%E2%80%93_VBOX_Touch_(v1)%3A_Decel_Mode...

  • Page 11: Screen Overview

    Screen Overview Setup 1. Connect the power via the Power socket. 2. Insert the SD card into the Side of the Unit. The SD Card Icon should display as green as long as the card has free space. https://en.racelogic.support//Product_Info/Performance_Meters/VBOX_Touch/ VBOX_Touch_(v1)/Quick_Start_Guides_%E2%80%93_VBOX_Touch_(v1)/Quick_Start_Guide_%E2%80%93_VBOX_Touch_(v1)%3A_Decel_Mode...
  • Page 12 Test Suite or output lap timing parameters, go to Serial Output within the Serial Port Settings and change the Output Mode to either VBOX Stream (live testing with VBOX Test Suite) or Lap Timing. Note: Ensure correct hardware connections are made. https://en.racelogic.support//Product_Info/Performance_Meters/VBOX_Touch/ VBOX_Touch_(v1)/Quick_Start_Guides_%E2%80%93_VBOX_Touch_(v1)/Quick_Start_Guide_%E2%80%93_VBOX_Touch_(v1)%3A_Decel_Mode...
  • Page 13 Note: If for some reason the SD card is removed whilst still recording, it may need to be repaired using a PC before it can be reused. 18. A screenshot of what is displayed on the screen can be taken at any time by pressing the Screenshot Button. https://en.racelogic.support//Product_Info/Performance_Meters/VBOX_Touch/ VBOX_Touch_(v1)/Quick_Start_Guides_%E2%80%93_VBOX_Touch_(v1)/Quick_Start_Guide_%E2%80%93_VBOX_Touch_(v1)%3A_Decel_Mode...
  • Page 14 19. To reset all test results shown on the current screen, press the Reset Button. 20. When you have finished your testing, completed test results can be viewed by pressing the Results Button. More information on Decel Mode testing can be found here. https://en.racelogic.support//Product_Info/Performance_Meters/VBOX_Touch/ VBOX_Touch_(v1)/Quick_Start_Guides_%E2%80%93_VBOX_Touch_(v1)/Quick_Start_Guide_%E2%80%93_VBOX_Touch_(v1)%3A_Decel_Mode...
