01_Getting_Started
This page contains important and useful information about LabSat 4 (P), such as box contents and product
registration, product power supply, media options, etc.
Registration
Please register your LabSat 4 so that Racelogic can continue to provide you with notifications about the latest software
releases and firmware upgrades for your Racelogic product, and offer technical support.
Register your device
here.
What is in the box?
LabSat 4 (P) (RLLS04-P) is supplied with:
Product Code
Quantity
LS04-V1
RLVBACS020-X
RLACS313
RLCAB071-1
RLCAB082-1
RLCAB083-1
RLCAB084-1
RLACS202
RLACS289
RLCAB042
Description
1
LabSat 4 Unit
1
Mains power Supply - Lemo 2W cable (country-specific)
1
8 GB SD Ultima Pro UHS-1 Memory Card
1
SMA connector - non-hex SMA plug to non-hex SMA plug RG174 (1-metre cable)
1
SMA Plug - MCX plug RG174 (1-metre cable)
1
SMA plug - MMCX plug RG174 (1-metre cable)
1
SMA plug - TNC plug RG174 (1-metre cable)
1
LabSat 3/4 - Expansion Connector Adapter (including screwdriver)
1
USB 3.0 to SATA adapter cable
1
USB 'A' to USB 'B' - 2m cable
1
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Racelogic LabSat 4
Summary of Contents for Racelogic LabSat 4
- Page 1 Registration Please register your LabSat 4 so that Racelogic can continue to provide you with notifications about the latest software releases and firmware upgrades for your Racelogic product, and offer technical support. Register your device here.
- Page 2 Product Code Quantity Description RLACS197 LabSat 3/4 Carry Case PARAGON-LIC Paragon Software Free Licence Code Flyer LS-WARR NOTE Warranty Note RLCALUKAS Certificate of Calibration BATTERY DEC Battery Declaration for international shipping Optional Extras Product Code Description RLACS225 GNSS Test Enclosure RLACS278 Passive Rebroadcast Antenna RLACS261...
-
Page 3: Power Supply
External Power You can apply power to the LabSat 4 (P) unit via mains power with the RLVBACS020 power supply. When you power the LabSat 4 unit from an external source, it will automatically charge the internal battery pack, and seamlessly switch to battery operation when the external power is removed. -
Page 4: Web Server
SD Card The 8 GB SD card that is included with LabSat 4 (P) is for firmware upgrades only. Do not use this to replay or transfer scenario files. Note: To reduce the risk of any unwanted signal noise, you should remove the SD card from the LabSat 4 unit when you are not performing a firmware update. - Page 5 Notice: System Heat Management for LabSat 4 Labsat 4 is equipped with a high-performance processor that generates heat during operation. To manage this heat, an internal fan is used to extract warm air from the enclosure. Additionally, the aluminium casing will radiate some heat, causing the system to become warm during use.
