Summary of Contents for Elegoo Centauri Carbon
- Page 1 Centauri Carbon 3D Printer Centauri Carbon User Manual Please refer to the included USB drive for a setup and installation instructional video.
- Page 2 For any questions or issues not covered in this manual, please contact us directly via our customer support email address: 3dp@elegoo.com. The ELEGOO team is always ready to provide you with quality service. To provide you with the best product experience, in addition to this manual, you can find supplemental information for the operation of your new printer via:...
- Page 3 4.When printing low-temperature filaments such as PLA and flexible filaments, please remove the glass top cover. 5.We recommend using ELEGOO's slicing software to ensure the proper functioning of the machine and achieve optimal printing results. 6.Perform regular maintenance on the printer by cleaning the machine body with a dry cloth to remove dust and any sticky filament residue.
-
Page 4: Table Of Contents
Contents Machine Parameters Component Introduction Accessory Specification Machine Setup & Installation Screen Operation Instruction First Print Filament Replacement Slicing Software LAN (Network) Printing Mainboard Circuit Wiring Diagram... -
Page 5: Machine Parameters
Ambient Environment Temperature: 5°C~40°C Operating Temperature Specifications Maximum Temperature of Nozzle: 300°C Maximum Temperature of Heated Bed: 110°C Software Specifications Slicer Software: ELEGOO Slicer (recommended) Input File Format: STL, OBJ, 3MF, STP Output File Format: G-code Interface: USB Drive, WIFI Power Supply Specifications Input Power: 100-240V;... -
Page 6: Component Introduction
Component Introduction Auxiliary Part Cooling Fan Filament Detection Sensor (Filament Printhead Detector) Chamber Camera Filament Spool Holder USB Drive Port Touch Screen Filament Inlet Air Filter Excess Chute Power Socket... -
Page 7: Accessory Specification
Accessory Specification Filament Sample Centauri Carbon 3D Printer Centauri Carbon User Manual Please refer to the included USB drive for a setup and installation instructional video. -
Page 8: Machine Setup & Installation
Machine Setup & Installation Scan to access tutorials 1.Take out the foam and tool kit from the printer. 3.Insert the ribbon cable into the port by pressing the terminal 2.Unlock the heated bed and use a 2.0mm Allen wrench to as pictured. - Page 9 Machine Setup & Installation 4.Install the screen into the corresponding slot on the printer 5.Mount the spool holder onto the hole on the right side of the and push it down to lock it in place. machine and secure it by turning counterclockwise. 6.Load the filament by inserting one end into the filament detector and pushing it forward until it reaches its maximum position.
-
Page 10: Screen Operation Instruction
Screen Operation Instruction 1.Language Selection 2.Follow the on-screen prompt to remove the three fixed screws of the build platform. 3.Ensure the collision block is correctly installed and click 4.Ensure the printer chamber is free from foreign objects, then “Confirm.” click “Confirm” to proceed. - Page 11 5.Enter the initial self-check process. Vibrations and noises during 6.Do not tap or shake the machine during the self-check process the self-check are normal. to avoid error prompts. Important note: If you have disassembled machine components such as the nozzle assembly or build platform, make sure to re-level the platform before printing.
-
Page 12: First Print
First Print 2.Click Local to select a model for test printing. 3.If the adhesion of the build plate decreases after prolonged use, 4.After the printed model cools down, detach the flexible build you can apply solid glue or use platform adhesive spray to plate together with the model from the device. - Page 13 2.After unloading is complete, press the pneumatic connector 1.Click and switch to the Extruder option. Click above the printhead to detach the filament guide tube. Extract “Unload” and wait for the machine to complete the unloading the old filament from the tube and replace it with a new one. process.
-
Page 14: Slicing Software
Slicing Software The included USB drive contains slicing software for installation and use. * Select your printer model before starting the slicing process. - Page 15 Slicing Software 1.Importing model for slicing: You can simply drag and drop the model file into the slicing software or click “File” in the top left corner and select “Import.” 2.Exporting G-code file: You can use the web interface to send the generated G-code file directly to the printer for online printing or save it to a USB drive for offline printing.
-
Page 16: Lan (Network) Printing
LAN (Network) Printing 1.The device supports Wi-Fi connection. Go to the “Network” interface, establish a successful connection, and check the IP address on the screen (refer to the image on the right). 2.Connect your computer and printer to the same local area network (LAN). Open your browser and enter the printer's IP address in the address bar to access the backend management. -
Page 17: Mainboard Circuit Wiring Diagram
Mainboard Circuit Wiring Diagram 24V Power X-Axis Input Interface Motor Filament Detector Chamber Auxiliary Part Temperature Cooling Fan Case Fan Chamber Camera Camera Communication Leveling Module Port Type-C Interface Heated Bed Temperature (24V) Heated Bed Control Interface Screen Ribbon Cable Interface Mainboard Fan Z-Axis Optical Limit Switch... - Page 18 After-sales service registration card Date of purchase: Place of purchase: Printer: S/N: Fault description:...
- Page 19 Centauri Carbon ELEGOO official website: www.elegoo.com Happy Printing!
- Page 20 FCC Warning This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.
