Menu
The DMX1202X features four buttons on the front of this unit: MENU,
ENTER, UP, and DOWN.
Press MENU to choose your Output Mode, DMX Address, Color
Macro, User Color, and PWM (pulse width modulation). There are 4
PWM modes to choose from.
PWM is the rate of current pulses to the LEDs, which affects how
the lights appear to dim on video. When filming, if you notice pulses
when dimming, choose the mode that appears to work best with
your setup.
Color Macro N/A
User Color
PWM
DMX Address
Channel
DMX1202X
Output Mode: White
White 1
White 2
White 3
White 4
12288
8192
4096
2048
001-512
1
2
4
8
000-255
000-255
000-255
000-255
One Zone
Two Zones
Four Zones
Eight Zones
