- Page 1 Springtree Media Group User Manual SM-8 Switch DMX Desk Station...
- Page 2 Table of Contents Description Specifications & Connections Programming Safety & Troubleshooting Contact Us...
- Page 3 Springtree Media Group Description The SM-8 Switch The SM-8 Switch is the easiest way to control your DMX lighting for everyday use. It requires no installation and features 8 easy-to-program scenes with built-in fade times. The SM-8 Switch is a desk station designed to sit on any flat surface and is expandable to up to 5 Satellite Wall Stations.
- Page 4 Springtree Media Group Specifications Dimensions 4 3/4" Weight: 1.7lbs 1 3/4" 4 3/4" Connections 3-pin DMX In/Out Permanently Attached Edison Cable Ethernet Port For Expansion To Satellite Stations SM-8 Switch...
- Page 5 Springtree Media Group Programming 1. Hold down buttons 1 and 8 to enter programming mode (light will turn red). 2. Set desired look on lighting console. 3. Press desired preset button 1-8. Light will flash. Scene is stored. 4. Set new look on lighting console.
- Page 6 1. Check that the DMX cables are connected properly and are wired correctly. 2. Check that the Switch is flipped to the setting you need. “DMX On” gives control to your console/computer. “DMX Off” gives control to your SM-8 Switch and optional Satellite Stations.
- Page 7 We Are Here For You! Springtree is all about simplifying the AV process. A big part of that is being available to answer your questions. Give us a call or fill out a contact form. We are here to help! Contact Us springtree.net/contact-us/...
