Summary of Contents for Springtree Spartan300-VW

  • Page 1 Springtree Media Group User Manual The Spartan300-VW...
  • Page 2: Table Of Contents

    Table of Contents Description Installation Safety & Troubleshooting Specifications DMX Traits Menu Operation Contact Us...
  • Page 3: Description

    Springtree Media Group Description The Spartan300-VW The Spartan300-VW is a 300Watt, Variable- White LED Fresnel with a comparable output to a traditional 1000Watt incandescent Fresnel. Quick Points CRI > 95 Manually Adjusted Zoom 3200K 5 600K Color Temperature − 6.9″ High-Quality Optical Fresnel Lens...
  • Page 4: Installation

    Mounting Position the Spartan300-VW in any orientation that allows ample room for ventilation. Operating the device in a poorly ventilated space can result in overheating and pose serious safety risks. Maintain a minimum distance of 6- inches around and above the device to ensure proper airflow.
  • Page 5 Springtree Media Group Safety 1. Do not expose this unit to moisture to reduce the risk of electrical shock or fire. 2. Be sure that the local power outlet matches the required voltage for your unit. 3. Do not attempt to operate this unit if the power cord has been frayed or broken.
  • Page 6: Specifications

    Springtree Media Group Specifications Optical Connections Light Source: 300W LED WW+CW 2- 3-pin DMX In/Out in-1 Linking Power Cord In/Out Color Temperature: 3200-5600 K Beam Angle: 15 – 50° Included Color Rendering Index: > 95 1x Spartan300-VW Lumens: 8,000 1x Bracket...
  • Page 7: Dmx Traits

    Springtree Media Group DMX Traits 2 Channel Mode Dimmer 0~255 Color 0~255 Temperature 3 Channel Mode Dimmer 0~255 Warm White 0~255 Cold White 0~255 4 Channel Mode Dimmer 0~255 Warm White 0~255 Cold White 0~255 Strobe 0~255 The Spartan300-VW...
  • Page 8: Menu Operation

    Springtree Media Group Menu Operation Value Description Function ADDR DMX Address d001-d512 CH-M Channel Mode 2CH,3CH,4CH MENU Dimmer Dimm 0-255 MENU Strobe Flas 0Hz-30Hz MENU Warm White WW 0-255 MENU Cold White CW 0-255 DISP Display On/Off DMXF DMX Failure...
  • Page 9: Contact Us

    We Are Here For You! Springtree is all about simplifying the AV process. A big part of that is being available to answer your questions. Give us a call or fill out a contact form. We are here to help! Contact Us springtree.net/contact-us/...
