  • Page 1 Springtree Media Group User Manual DMX1202X Power Driver...
  • Page 2 Table of Contents Description & Specifications List of Fixtures Powered Installation Menu DMX Modes Safety & Troubleshooting Contact Us...
  • Page 3 Springtree Media Group Description The DMX1202X is the midsized Lo-Vo power driver for powering and controlling Lo-Vo fixtures. The DMX1202X has the distinction of being the only SKU: DMX1202X rack-mountable Lo-Vo Power Driver. Features Low voltage (24V) LED module control...
  • Page 4 Springtree Media Group Fixtures Powered DMX150 DMX602 DMX1202X DMX1800 30Watt Spatial Flats 50Watt Spatial Flats 50Watt Spatial Flat Pendants LED Spatial Tape 49 feet 171 feet 304 feet 512 feet LED Spatial Bars WW Spatial Minis RGBWW Spatial Minis 30Watt Round LED...
  • Page 5 Location: To install the DMX1202X, you will need a dry, well-ventilated area, such as an electrical closet. Noise: Lo-Vo fixtures are silen t, but Power Drivers aren't. The DMX1202X has an audible fan noise. Space Requirement: The DMX1202X requires 2 rack spaces in a standard 19”...
  • Page 6 Springtree Media Group Installation Continued 1. Electrical Connection: Use the linking power connector located on the rear of the DMX1202X for electrical connection. A linking power output is provided for daisy-chaining to other equipment. Note: Only one DMX1202X can be powered on a single 20amp circuit at maximum load.
  • Page 7 Phoenix Connectors How To Wire RGBW & Large Warm White (50Watt & 120Watt) Fixtures to the DMX1202X Note: All five wires on the 50W & 120W WW fi xtures need to be wired the same as those on an RGBW fixture (red to red, green to green, etc.)
  • Page 8 Springtree Media Group Safety Do not expose this unit to moisture to reduce the risk of electrical shock or fire Be sure the local power outlet matches the required voltage for your unit. Disconnect from the main power before making any connection.
  • Page 9 Springtree Media Group Menu The DMX1202X features four buttons on the front of this unit: MENU, ENTER, UP, and DOWN. Press MENU to choose your Output Mode, DMX Address, Color Macro, User Color, and PWM (pulse width modulation). There are 4 PWM modes to choose from.
  • Page 10 Springtree Media Group Menu - Continued Output Mode: RGBW 000-255 Color Macro 000-255 Amber 000-255 Yellow/Warm 000-255 Yellow 000-255 Green 000-255 Turquoise 000-255 Cyan 000-255 Blue 000-255 Lavender 000-255 Mauve 000-255 Magenta 000-255 Pink 000-255 Warm White 000-255 White 000-255...
  • Page 11 Springtree Media Group Menu - Continued Output Mode: RGBW DMX Address 001-512 Channel One Zone Two Zones Four Zones Eight Zones DMX1202X...
  • Page 12 Springtree Media Group DMX Zones When controlling the DMX1202X via DMX, you have four options to split zones 1 Zone 2 Zones 4 Zones 8 Zones DMX1202X...
  • Page 13 Springtree Media Group DMX Mode White Mode Channel Mode 1 Zone 2 Zones 4 Zones 8 Zones DMX Value Intensity (Zone 1) Intensity (Zone 2) Intensity (Zone 3) Intensity (Zone 4) Intensity (Zone 5) Intensity (Zone 6) Intensity (Zone 7)
  • Page 14 Springtree Media Group DMX Mode RGBW Mode Channel Mode 1 Zone 2 Zones 4 Zones 8 Zones DMX Value Red (Zone 1) Green (Zone 1) Blue (Zone 1) White (Zone 1) Intensity (Zone 1) Red (Zone 2) Green (Zone 2)
  • Page 15 Springtree Media Group DMX Mode RGBW Mode Continued Channel Mode 1 Zone 2 Zones 4 Zones 8 Zones DMX Value CH14 CH14 White (Zone 3) CH15 CH15 Intensity (Zone 3) CH16 CH16 Red (Zone 4) CH17 CH17 Green (Zone 4)
  • Page 16 Springtree Media Group DMX Mode RGBW Mode Continued Channel Mode 1 Zone 2 Zones 4 Zones 8 Zones DMX Value CH27 Green (Zone 6) CH28 Blue (Zone 6) CH29 White (Zone 6) CH30 Intensity (Zone 6) CH31 Red (Zone 7)
  • Page 17 We Are Here For You! Springtree is all about simplifying the AV process. A big part of that is being available to answer your questions. Give us a call or fill out a contact form. We are here to help! Contact Us springtree.net/contact-us/...
