HD200 RGBWW
LED Ellipsoidal
USER MANUAL AND
INSTALLATION GUIDE

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HD200 RGBWW LED Ellipsoidal and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Springtree HD200 RGBWW LED Ellipsoidal

  • Page 1 HD200 RGBWW LED Ellipsoidal USER MANUAL AND INSTALLATION GUIDE...
  • Page 2: Table Of Contents

    3. Installation Power supply..........................5 Mounting............................5 Adjusting the shutters........................6 Using a gobo..........................6 Using a gel or filter........................6 DMX linking..........................7 4. Operation Menu buttons..........................7 Operating modes........................7 LED display menu........................8 DMX Modes..........................9 5. Maintenance Cleaning your ellipsoidal......................10 6. Technical Specifications Troubleshooting........................10 Dimensions..........................11 Warranty...........................12 Contact us..........................12 (615) 599-1505 www.springtree.net...
  • Page 3: Before You Begin

    3. One gel frame 4. One Powercon power cord *If any of these items is damaged or missing, please contact Springtree Media Group. Safety Precautions • To reduce the risk of electrical shock or fire, do not expose this unit to moisture. • Be sure that the local power outlet matches that of the required voltage for your unit •...
  • Page 4: Product Information

    Product Information Description The Springtree HD200RGBWW LED Ellipsoidal is a powerful fixture suitable for theat- rical performance halls, schools and houses of worship. With this versatile instrument, you can get many different uses from one single fixture. You can control the size, shape, edge and inten- sity of the beam of light. Features • 200W RGBWW LED • Digital Display • Interchangeable 19°, 26° or 36° lenses (sold separately) •...
  • Page 5: Installation

    When mounting your ellipsoidal, make sure there is adequate room for ventilation. Operating in an insufficiently ventilated room can lead to an overheating of the device and may cause serious accidents. Keep a minimum distance of 6 inches around and above the device. Before deciding on a location, mount in a way that it will be easy to access the unit for maintenance and addressing. (615) 599-1505 www.springtree.net...
  • Page 6: Adjusting The Shutters

    Slide the holder into Framing shutter the slots located in front of the lens. (left) When removing the gel and holder, make sure to let it cool before handling. Framing shutter (bottom) Gel frame (615) 599-1505 www.springtree.net...
  • Page 7: Dmx Linking

    DMX control mode- this function will allow you to control each individual unit with a standard DMX 512 controller • Stand Alone- each ellipsoidal will operate in a manual stand alone mode. No DMX wire nec- essary. (615) 599-1505 www.springtree.net...
  • Page 8: Led Display Menu

    Operation - Menu/DMXTraits (615) 599-1505 www.springtree.net...
  • Page 9: Dmx Modes

    (615) 599-1505 www.springtree.net...
  • Page 10: Maintenance

    1. Check that the DMX cables are connected properly and are wired correctly. DMX output DMX input 2. Check that all cables are connected to the right connectors; it does matter which way the inputs and outputs are connected. (615) 599-1505 www.springtree.net...
  • Page 11: Dimensions

    LED: RGBWW COB • Housing Color: Black • Flicker Free Electronic Strobe: 1-20 flash/s • IP Rating: IP20 • • Environment Temp: -30°C-50°C • Display: 4-digit LED • Dimensions(mm): L25in x W6.5in • Data In/Out: XLR 3Pin • Net Weight: 13lbs Dimensions: (615) 599-1505 www.springtree.net...
  • Page 12: Warranty

    2nd YEAR - Repair/ Replace Springtree discretion. Return shipping covered by customer. Contact Us! Springtree Media Group would like to thank you for choosing our company for your lighting needs! If you have any questions or concerns, please contact us. Office hours:...
