C o n n e c t t h e fi rs t w i re y o u u n s c re w t o t h e
a s s o c i a t e d s c re w t e r m i n a l o n t h e I n - w a l l
S w i t c h ; d o t h e s a m e fo r t h e re m a i n i n g
t h re e w i re s
B efo re co n n e c n g t h e w i re to t h e te r m i n a l ,
e n s u re t h e re i s a b o u t 1 / 2 i n c h o f b a re w i re
v i s i b l e ( st r i p o ff i n s u l a o n a s n e e d e d )
1/2 inch
Insert the associated (hot, neutral,
load, ground) wires wire into the
terminal
Ground
Tighten the screw terminal
Neutral Wire
Load
Live
Load
Ligh ng
Gently tug on the wire to ensure
a ght connec on
Hot/Live
Neutral
