- Page 1 Viper TQS Mission pack Calibration VIPER TQS Mission pack Throttle Calibration Thrustmaster page 1 of 6...
- Page 2 Viper TQS Mission pack Calibration Introduction Description The calibration will be done in hardware without having to use any software. Noticeable position of throttle CUT-OFF IDLE MAX Afterburner • CUT-OFF → Button 18 • IDLE → 0 % (Z axis) •...
- Page 3 1. First step before to plug the throttle, place it to IDLE position. IDLE 2. Plug the VIPER TQS to USB port and holding down button 5 ( Center push on ) and stay press during 3sec before releasing it.
- Page 4 Viper TQS Mission pack Calibration 4. Go to MIL position 5. Press CHAFF/FLARE button to save MIL position 6. Move slowly and without applying too much force on all maximum positions of the mini stick (X/Y axis). page 4 of 6...
- Page 5 Viper TQS Mission pack Calibration 7. Move slowly Antenna potentiometer (Ry axis) to each stopper end and return on center detent position. 8. Move slowly Manual Range potentiometer (Rx axis) to each stopper end and return on center detent position.
- Page 6 Viper TQS Mission pack Calibration 9. Move the TRIM potentiometer from min to max without applying too much force on each end. 10. To validate the calibration process, push again the button 5 ( Center push on Communication HAT) 11.To set position of button 19 (...
