NVP1015 / NVP1017
10. LCD Session
Resolutions Settings

For SUN Servers

•
•
•
•
•
•
•
•
Note : Remember to RESTART the server after these processes.
Note : Remember to RESTART the server after these processes.
Resolution configuration procedures should be run by qualified SUN
server administrator
Sun Servers are using resolution at 1152 x 900 x 76Hz.
Supported resolution mode for 15" LCD:
1024 x 768 x 70/75Hz
Supported resolution mode for 17" LCD:
1280 x 1024 x 75Hz
You need to change the Sun Server resolution before you connect to
LCD Display.
Please do the following procedures to change the resolution settings :
1. As root:
You may find the following comment 7user/sbin/m64config".
2. To view current resolution:
Type 7user/sbin/m64config - prconf.
3. To change to 1024x768 @ 70MHz:
Type 7user/sbin/m64config - res 1024x768x70 now".
4. The screen will be rubbish.
Then type "pkill Xsun".
5.
And Type "pkill Xsession" to restart the Xsession.
• Under Common Desktop Environment (CDE).
• To change the OpenBoot resolution, you can type the following command in
OK prompt.
In OK prompt, type "setenv output-device screen:r1024x768x70".
1.
2. Type "printenv" to confirm the resolution has been changed to 1024x768x70Hz.
Then type, "reset" to restart the system.
3.
