Chungho OMNI CHP-4030D User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
User's Manual
CHP-4030D
Read the user's manual thoroughly before using the unit.
Design and color may differ from the picture.
ut prior notice
if necessary for improving unit performance.
The rated voltage of this unit is 220-240 V~ / 50 Hz only.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the OMNI CHP-4030D and is the answer not in the manual?

Questions and answers

Related Manuals for Chungho OMNI CHP-4030D

Summary of Contents for Chungho OMNI CHP-4030D

  • Page 1 User's Manual CHP-4030D Read the user’s manual thoroughly before using the unit. Design and color may differ from the picture. ut prior notice if necessary for improving unit performance. The rated voltage of this unit is 220-240 V~ / 50 Hz only.

  • Page 2: Table Of Contents

    We are sure that the ChungHo Nais water purifier, which is produced through this production process, will be able to satisfy you with its excellent quality.

  • Page 3: Product Features

    1. Product features Compact size (width: 29 cm) Compact-sized water purifier can be installed freely where you want as effectively utilizing the space. Extended water dispensing space It is convenient to take water by any shape of bottle as big as 1.5L bottle as capacity with the dispensing height of more than 25cm.
  • Page 4 1. Product features Operation by sensors Hot water temp. sensor/room temp. sensor, cold water temp/ sensor are built in the machine. Water leakage valve The source water is blocked by water leakage valve, if it detects any leakage inside the product. Display of abnormal occurrence and reinforced safety function The safety features of the unit have been enhanced in order to prevent various problems from occurring.

  • Page 5: Safety Precautions

    2. Safety precautions ※ Precaution is classified into “Warning” “Caution” and it has the following meaning. Warning In case of possible accident with serious injury or death due to breach of the indication ● Keep the cord out of heavy ●...
  • Page 6 2. Safety precautions In case of possible Injury or property damage and product degradation due to Warning breach of the indication ● Do not pull on the power cord. Be sure to hold the power plug to pull ● This product is only for 220-240 it out.
  • Page 7 2. Safety precautions In case of possible Injury or property damage and product degradation due to Caution breach of the indication ● Do not put any covering on the rear ● After the product has been After more than and side of the unit. 30 minutes moved, supply the power after (Blocking ventilation holes may...

  • Page 8: Installation Precautions

    3. Installation precautions When installing the product, do not install it in the following places. • Nearby fire • Nearby flammable materials • Humid place • In front of the cooling and heating device • Exposed to snow or rain •...

  • Page 9: Installation Guide

    4. Installation guide ※ Service engineer install the unit. You should check if the unit is properly installed. Install the product vertically(Vertical degree of product should be adjusted vertically using crutch and verified by leveler). ※ It is recommended to install the product on a sink band or table higher than 80cm above the floor. Shut off water supply valve and separate the connector part of tap water in order to connect an adapter(Source water valve).

  • Page 10: How To Use

    5. How to use Display and function setting WATER FULL Lights up when the deposit tank is full of water. WATER FULL COLD WATER Lights up when cold water is set. COLD WATER HOT WATER Lights up when hot water is set. HOT WATER HOT (STAND-BY) Lights up when hot water is selected.

  • Page 11: Activate And Deactivate Functions

    5. How to use Activate and deactivate functions • Hot tank heating function setting ① Turn the hot water method selection switch on the back of the product to the position. ② The hot water LED (Orange color) on the front part lights up. •...

  • Page 12: Water Intake

    5. How to use • How to disable cold water Disable the cold water dispense Press “COLD/AMBI. SELECTION BUTTON” for 5 seconds to disable cold water. seconds COLD WATER • Re-active the cold water dispense Press “COLD/AMBI. SELECTION BUTTON” for 5 seconds to re-activate cold water.
  • Page 13 5. How to use ※ If there is no heated water, the hot water dispense will not be available. • Instant heating water dispensing mode ① Set up the hot water type selection switch on the back of the product to enter instant heating water dispensing mode. ※...

  • Page 14: Acs Smart Cleaning Function

    5. How to use ACS Smart Cleaning Function It is the function to automatically clean the inside of the water tank in order to prevent the contamination during the time when people seldom use the unit once everyday 4 days. ACS cleaning function makes users to always drink clean and safe water as any chemical and electrolysis equipment is not used.

  • Page 15: Precautions For Use

    6. Precautions for Use Refer to the voltage on the front page. Connect to the proper power source. Keep the cord out of heavy traffic areas. (Possible cause of fire due to abnormal electricity outlet heating.) Never move the product during its operation. (It may cause breakdown.) Do not touch the wire condenser on the rear side of unit.

  • Page 16: Cleaning

    7. Cleaning How to clean the water dispensing faucet ① Turn the COLD / AMBI. faucet to the left and pull it out. ② Wipe the inside of the water dispensing faucet with a cotton swab. ※ When cleaning, do not use detergent, thinner, benzene, or wax.
  • Page 17 ④ Loosen the 1 fixing screw on the back of the product using a screwdriver, then remove the purified water tank cover. ⑤ Open the source water supply valve. ⑥ Turn the drain switch on the product backside to the OFF position. ⑦...

  • Page 18: Sanitary Maintenance

    8. Sanitary Maintenance Classification Description Location - The unit can be installed at low water pressure place within water quality range. Installation <Do not install the unit in places below> - A place exposed to direct sunlight or outside Environment - Nearby toilet - In front of cooling-heating device - Cleaning up water dispensing faucet once a week is recommended.

  • Page 19: Filters

    9. Filters Function of the filter 1/2 step : T-Pre-rs-carbon filter The carbon composite filter effectively removes the rust particle and suspended solid. It uses the 3-stage filtration method maintaining the effectiveness of standard sediment while extending the filter replacement cycle. At the same time, it eliminates effectively the dissolved particle in water such as the chorine component, trihalomethanes (THMs), and organic chemicals.

  • Page 20: How To Replace The Filter

    10. How to replace the filter ① Shut off the source water valve and detach the cover after loosening the fixed screw on the right side of the unit. ② Turn the drain switch ON after lifting the filter. ※ Cold water and ambient water are automatically drained for 30 minutes.

  • Page 21: Product Specifications

    Dimensions 290Wx497Dx474H(mm) Product name ChungHo Water Purifier OMNI Compressor Model name CHP-4030D Reciprocating type Heat dissipation – Ultraviolet sterilizer Wire Condenser (Forced convection) method Cold water temperature Thermistor 19.5 kg Product weight control Hot water temperature 1,750 W Thermistor control...

  • Page 22: Troubleshooting

    12. Troubleshooting ※ It takes about 60 minutes for each storage tank to become full of water status (based on water temperature 25 ※ It takes about 80 minutes to make COLD from AMBI. Symptom Check item Request follow-up service Is the power plug of When the display is when you still have...
  • Page 23 MEMO...
  • Page 24 Selected for 4 consecutive Selected for 6 consecutive years years years years years Call center: 1588-2290 ChungHo Malaysia, 10TH FL, FABER IMPERIAL COURT, JALAN SULTAN ISMAIL, 50250 KUALA LUMPUR, MALAYSIA TEL:+60-32-603-1800 / 1800-886677 / E-MAIL: info@chunghomy.com.my / HOMPAGE: www.chunghomy.com.my MANUAL DOWNLOAD: http://www.chunghomy.com.my/base/download Rev,No.00...
