1.1 MP1501 controller with paired interface for one physical barrier ® The MP1501 intelligent controller provides decision making, event reporting, and database storage for the HID Mercury™ hardware platform. Two reader interfaces configured as paired, or alternate readers provide control for one physical barrier.
HID Mercury MP1501 Controller Installation and Specifications 2.5 Bulk erase configuration memory The bulk erase function can be used for the following: Erase all configuration and cardholder database (sanitize board, less third party applications). Update OEM default parameters after OEM code has been changed.
Page 9
HID Mercury MP1501 Controller Installation and Specifications 2.7 Reader/serial I/O device wiring Reader port 1 supports TTL (D1/D0, Clock/Data), F/2F, or 2-wire RS-485 device(s). Reader port 2 supports TTL (D1/D0, Clock/Data), or F/2F. Power to reader port 1 is 12 V DC at 600 mA maximum per port. The reader connected to reader port 2 may be powered from the 12 V DC auxiliary power supply output;...
Page 10
HID Mercury MP1501 Controller Installation and Specifications 2.7.1 Reader wiring diagrams Reader port 1, typical reader 1 Reader port 1, typical reader 1 (Wiegand or Clock/Data installation) (OSDP installation) Reader port 2, typical reader 1 Reader port 1, typical reader 1...
Page 11
HID Mercury MP1501 Controller Installation and Specifications Reader port 1 Reader port 2 Typical unsupervised F/2F reader Typical unsupervised F/2F reader Reader port 1 Reader port 2 Typical supervised F/2F reader Typical supervised F/2F reader Jumper D1 and LED on supervised F/2F readers *Inputs on supervised F/2F readers may be unsupervised or supervised (supervised shown).
Page 12
HID Mercury MP1501 Controller Installation and Specifications Reader port 1 - remote serial I/O devices using MSP1 protocol (2-wire RS485) Refer to the appropriate remote serial I/O device installation manual for address and baud rate settings. 120Ω end-of- line termination should only be added at each end of the RS-485 bus. If an MP1501 is at one end of the RS-485 bus, jumper J1201 can be installed to to enable the termination resistor.
HID Mercury MP1501 Controller Installation and Specifications 2.8 Communication wiring The MP1501 controller communicates to the host via the on-board 10-BaseT/100Base-TX Ethernet interface. 2.9 Input circuit wiring Typically, these inputs are used to monitor door position, request to exit, or alarm contacts. Input circuits can be configured as unsupervised or supervised.
Page 14
HID Mercury MP1501 Controller Installation and Specifications 2.10 Relay circuit wiring Two Form-C contact relays are provided for controlling door lock mechanisms or alarm signaling devices. The relay contacts are rated at 2 A @ 30 V DC, dry contact configuration. Each relay has a Common pole (C), a Normally Open pole (NO) and a Normally Closed pole (NC).
HID Mercury MP1501 Controller Installation and Specifications 2.12 Status LEDs 2.12.1 Power-up 1.x firmware - All LEDs are OFF. 2.x firmware - NIC LED blinks and all other LEDs are off for eight seconds. 2.12.2 Initialization 1.x firmware - After power is applied, LED 1 is ON for about 15 seconds, then LEDs 2 through 7 are flashed once at the beginning of initialization.
Page 16
HID Mercury MP1501 Controller Installation and Specifications 2.13 IT security Ensure that the MP1501 is installed securely. Create user accounts to the web configuration page using secure passwords. Ensure all DIP switches are to be in the OFF position for the normal operating mode.
Page 18
HID Mercury MP1501 Controller Installation and Specifications 3.1 MP1501 controller specifications The interface is for use in low voltage, Class 2 circuits only. The installation of this device must comply with all local fire and electrical codes. Units are to be installed in accordance to NFPA 70.
Page 19
HID Mercury MP1501 Controller Installation and Specifications CABLE REQUIREMENTS Power 1 twisted pair, 18 AWG (when using local 12 V DC power supply) Ethernet CAT-5, minimum Reader data (TTL) 6-conductor, 18 AWG, 500 feet (152 m) maximum Reader data (F/2F) 4-conductor, 18 AWG, 500 feet (152 m) maximum Reader data (RS-485) 1 twisted pair, shielded.
HID GLOBAL CONFIDENTIAL AND PROPRIETARY INFORMATION. Use and disclosure of this information is strictly restricted by the terms of a non-disclosure agreement with HID Global Corporation. If you have received this information and are not an intended recipient or are not subject to or do not agree to be bound by the terms of the non-disclosure agreement, please immediately return this document to HID Global Corporation, 611 Center Ridge Dr.
Page 21
HID GLOBAL CONFIDENTIAL AND PROPRIETARY INFORMATION. Use and disclosure of this information is strictly restricted by the terms of a nondisclosure agreement with HID Global Corporation. If you have received this information and are not an intended recipient or are not subject to or do not agree to be bound by the terms of the non-disclosure agreement, please immediately return this document to HID Global Corporation, 611 Center Ridge Dr.
HID Mercury MP1501 Controller Installation and Specifications 4.1 Optional items Sources for the optional items shown below: 3-gang stainless steel blank cover. Available from: Leviton: part number 84033-40 Graybar: part number 88158404 Magnetic switch set: G.R.I. part number: 505 PLT-07669 , A.0...
HID Mercury MP1501 Controller Installation and Specifications Revision history Date Description Revision May 2024 Initial release. PLT-07669 , A.0 May 2024...
