- Page 1 VertX EVO V2000 Installation Guide 72000-901, Rev. A.5 July 2016 hidglobal.com...
- Page 2 HID Global Corporation. Trademarks HID GLOBAL, HID, the HID logo, iCLASS, and VertX, are the trademarks or registered trademarks of HID Global Corporation, or its licensors, in the U.S. and other countries. Revision History...
-
Page 3: Table Of Contents
VertX EVO V2000 Installation Guide, 72000-901, Rev. A.5 Contents Introduction ..........................4 Parts List ..............................4 Product Specifications ........................4 Cable Specifications ........................... 4 Overview ........................... 5 Connect ........................... 6 What you need before getting started ..................6 V2000 ..............................6 Mounting Instructions ........................ -
Page 4: Introduction
Description Quantity VertX EVO V2000 (Reader Interface / Access Controller) 1 V2000 Note: Each VertX EVO V2000 has a plastic base and is covered with a plastic lid. • Lithium Battery • Mounting screws 8 ea. V2000 • 2.2K EOL resistors •... -
Page 5: Overview
VertX EVO V2000 Installation Guide, 72000-901, Rev. A.5 2 Overview The following outlines what is required to install VertX EVO V2000 controller. July 2016 Page 5 of 22... -
Page 6: Connect
VertX EVO V2000 Installation Guide, 72000-901, Rev. A.5 3 Connect What you need before getting started Prior to starting the installation, completely read this guide. See Section Appendix: C Configuration Checklist - Static, and gather the information before proceeding with these instructions. -
Page 7: Wiring Vertx Evo
VertX EVO V2000 Installation Guide, 72000-901, Rev. A.5 Wiring VertX EVO WARNING: VertX EVO V2000 is a NON-PoE device. DO NOT connect J1 (Ethernet port) to a PoE capable port. This applies to both direct PoE Power Sourcing Equipment (Endspan PSE) and PoE injector (Midspan PSE) equipment. - Page 8 Ground Shield Ground Reader Power Output Connections (VertX EVO V2000): All Output connections are used for general purpose controls. The following table shows where the various outputs are located. Pin numbers shown use the convention “NO/C/NC”. For example, Output 1, V2000: P3 Pin 1 is NO (Normally Open,) Pin 2 is C (Common,) and Pin 3 is NC (Normally Closed).
- Page 9 VertX EVO V2000 Installation Guide, 72000-901, Rev. A.5 Input Connections: Input connections are analog inputs used for a combination of specific functions such as Request-to-Exit (REX), Door monitor, etc. They can also be used as general purpose monitoring. Connect one side of the switch or contact to the + (plus) lead and the other to the –...
-
Page 10: Contact
• Virtual Port HID Discovery Application (for DHCP Networks) The HID Discovery Application provides a technician with a method of locating all of the VertX controllers that are connected to a network. Controller information is displayed providing the ability to ‘blink’ the VertX controller Comm LED and configure the unit by launching a browser pointed at the Configuration GUI of the targeted controller. - Page 11 VertX EVO V2000 Installation Guide, 72000-901, Rev. A.5 Virtual Port Contact a VertX controller by directly connecting the computer to the controller using an Ethernet cable. By default, every controller is configured to respond to a fixed address: 169.254.242.121. Ensure you are running a Windows 2000 or XP computer.
-
Page 12: Configure
VertX EVO V2000 Installation Guide, 72000-901, Rev. A.5 5 Configure This section describes the communications configuration that enables the controller to communicate with the host software. There are two methods of communication possible on a V2000 controller: • Dynamic Host Configuration Protocol (DHCP) TCP/IP Addressing •... -
Page 13: Confirmation
VertX EVO V2000 Installation Guide, 72000-901, Rev. A.5 Extended ASCII such as £ (pound) and € (euro) are NOT supported as they lie outside of the original ASCII range. Once configuration changes have been made, click Submit, and the Confirmation window displays. -
Page 14: Communicate
VertX EVO V2000 Installation Guide, 72000-901, Rev. A.5 6 Communicate Now that the controller is connected, contacted and configured, communicate with the controller using the host. Basic setup is now complete! Additional troubleshooting tools are available on the System Status and Supplemental Configuration windows. -
Page 15: Appendix: A Troubleshooting
VertX EVO V2000 Installation Guide, 72000-901, Rev. A.5 Appendix: A Troubleshooting A.1 System Status System Status provides a technician with a method of validating the VertX installation, field wiring and installed devices. Perform the System Status at any time after the VertX controller has been installed and power is available. -
Page 16: Update System
VertX EVO V2000 Installation Guide, 72000-901, Rev. A.5 A.5 Update System Update System allows the user to update the firmware on the interface panel. During a download the interface panel image flashes between grey and yellow. When a download completes the image color changes to green for successful or red for failure. If the download fails, view a tool tip with the error status code by hovering your mouse over the image in question. -
Page 17: Network Defaults Jumper
VertX EVO V2000 Installation Guide, 72000-901, Rev. A.5 A.7 Network Defaults Jumper The Network Defaults Jumper requires that someone with physical access to the V2000, place a jumper over the Debug port while the controller is rebooting, as detailed below. The controller reconfigures its network settings to the factory defaults when the jumper is on the Debug port during a reboot. -
Page 18: Firewall
VertX EVO V2000 Installation Guide, 72000-901, Rev. A.5 A.8 Firewall If the VertX controller is being installed where it communicates through a firewall, then the firewall may need to be configured to allow TCP data transfer on the specified port(s). -
Page 19: Appendix: B Regulatory
VertX EVO V2000 Installation Guide, 72000-901, Rev. A.5 Appendix: B Regulatory All National and local Electrical codes apply. • Connect only to a UL Listed ALVY or APHV Power Limited Power Supply. • Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. -
Page 20: Appendix: C Configuration Checklist - Static
VertX EVO V2000 Installation Guide, 72000-901, Rev. A.5 Appendix: C Configuration Checklist - Static Ensure that the Configuration Checklist contents are provided prior to installing a VertX controller with Static TCP/IP. Note: Advanced setting requirements are shown in gray. Contact... -
Page 21: Appendix: D Vertx Installation Worksheet
VertX EVO V2000 Installation Guide, 72000-901, Rev. A.5 Appendix: D VertX Installation Worksheet This installation worksheet is provided for you to have a historical record of your system settings. Complete each appropriate field, and keep this worksheet in a safe location. - Page 22 hidglobal.com...
