Trane 2TEH3F18A1000A Installer's Manual

Installer's Guide
Convertible Air Handlers*
1-1/2 – 5 Ton
2TEH3F18A1000A
2TEH3F24A1000A
2TEH3F30A1000A
2TEH3F36A1000A
WARNING:
ALL phases of this installation must comply with NATIONAL, STATE AND LOCAL CODES
IMPORTANT — This Document is customer property and is to remain with this unit. Please return to service information pack
upon completion of work.
A. GENERAL INFORMATION
WARNING
!
THIS INFORMATION IS FOR USE BY INDIVIDUALS
HAVING ADEQUATE BACKGROUNDS OF ELECTRICAL
AND MECHANICAL EXPERIENCE. ANY ATTEMPT TO
REPAIR A CENTRAL AIR CONDITIONING PRODUCT
MAY RESULT IN PERSONAL INJURY AND/OR PROP-
ERTY DAMAGE. THE MANUFACTURER OR SELLER
CANNOT BE RESPONSIBLE FOR THE INTERPRETA-
TION OF THIS INFORMATION, NOR CAN IT ASSUME
ANY LIABILITY IN CONNECTION WITH ITS USE.
CAUTION
!
To prevent shortening its service life, the air handler
should not be used during the finishing phases of
construction. The low return air temperatures can lead
to the formation of condensate. Condensate in the
presence of chlorides and fluorides from paint, var-
nish, stains, adhesives, cleaning compounds, and
cement creates a corrosive condition which may cause
rapid deterioration of the cabinet and internal compo-
nents.
These instructions do not cover all variations in systems or
provide for every possible contingency. Should further
information be desired or particular problems arise which
are not covered sufficiently by this manual, contact your
local distributor or the manufacturer as listed on the air
handler nameplate.
These Air Handlers are shipped from the factory in the
upflow or horizontal right configuration and are fully con-
vertible to downflow or horizontal left. Refer to Section B
beginning on page 3 for additional information.
INSPECTION
Check carefully for any shipping damage. This must be
reported to and claims made against the transportation
company immediately. Check to be sure all major
components are in the unit. Any missing parts should be
reported to your supplier at once, and replaced with
authorized parts only.
2TEH3F42A1000A
2TEH3F48A1000A
2TEH3F60A1000A
HAZARDOUS VOLTAGE - DISCONNECT POWER BEFORE SERVICING
*For use with BAYHTR13 or
BAYHTR33 series heaters
ONLY
Contents
General Information
Installation Limitations & Recommendations
Unit Installation
Upflow
Downflow
Horizontal Left
Horizontal Right
Duct Connections
Refrigerant Piping
Condensate Drain Piping
Electrical — Power Wiring
Control Wiring
Checkout Procedure
Hook-up Diagrams
Outline Drawings
CAUTION
!
Cardboard packing material must be removed from
inside the blower assembly before starting the unit.
Failure to do so may cause indoor blower motor failure.
INSTALLATION LIMITATIONS & RECOMMENDATIONS
The general location of the air handler is normally selected
by the architect, contractor and/or home owner for the most
effective application and satisfaction.
NOTE: Condensation may occur on the
surface of the air handler when installed in an
unconditioned location.When units are in-
stalled in unconditioned spaces, verify that all
electrical and refrigerant line penetrations on
the air handler are sealed completely.
18-GE09D1-1
11-12
9-10
1
1-3
3-4
3
3-4
4
4
5
5
5-6
6
7
7-8
