USER MANUAL
electriQ 9,200 BTU PORTABLE INDUSTRIAL
AIR CONDITIONER
CMAC10M
Thank you for choosing electriQ
Please read this user manual before using this innovative Air Conditioner and keep it
safe for future reference.
Visit our page, www.electriQ.co.uk, for our entire range of Intelligent Electricals.
Advertisement
Table of Contents
Related Manuals for ElectrIQ CMAC10M
Summary of Contents for ElectrIQ CMAC10M
- Page 1 9,200 BTU PORTABLE INDUSTRIAL AIR CONDITIONER CMAC10M Thank you for choosing electriQ Please read this user manual before using this innovative Air Conditioner and keep it safe for future reference. Visit our page, www.electriQ.co.uk, for our entire range of Intelligent Electricals.
-
Page 3: Table Of Contents
CONTENTS SAFETY INFORMATION FEATURES APPLIANCE DIAGRAM INSTALLATION OPERATION EMPTYING THE INTERNAL WATER TANK CLEANING AND MAINTENANCE TROUBLESHOOTING SUPPORT TECHNICAL SPECIFICATION... -
Page 4: Safety Information
SAFETY INSTRUCTIONS Important! • Carefully read the instructions before operating the unit • This appliance is for indoor use only. • Rating: This unit must be connected only to a 220-240 V / 50 Hz earthed outlet. The fuse rating is on the plug itself. •... - Page 5 • Do not move the air conditioner while it is operating. When operating, the castors should be locked in position. • Ensure the unit is positioned on a flat, level surface and does not interfere with walkways. • This air conditioner is not designed for boats or any other type of transportation. •...
- Page 6 • Do not cover or restrict the airflow from the outlet or inlet grills. • For maximum performance the minimum distance from a wall or objects should be 50cm. • Keep the filters clean. Under normal conditions, filters should only need cleaning once every three weeks (approximately).
-
Page 7: Features
FEATURES The CMAC10M is great for Rooms up to 26 m • two-speed fan: Balancing quiet operation with performance. • Simple operation. • Castors for Enhanced Portability. • Durable metal casing. • HOSE SPECIFICATIONS Hose External Max Permitted Hose Supplied Hose Length... -
Page 8: Installation
INSTALLATION COLD AIR OUTLETS 1. Line up the dimple on the Elbow with the notch on the Hose connector on the top of the air conditioner. 2. Rotate anticlockwise until a click can be heard, indicating the elbow has locked into place. -
Page 9: Operation
OPERATION Turn the control switch to select your desired fan speed between Low and High. Turn the control switch back to the Off position when you have finished. The unit can also be used as a dehumidifier without the hot air hose. We advise setting it up with continuous drainage when using it as a dehumidifier. -
Page 10: Emptying The Internal Water Tank
EMPTYING THE INTERNAL WATER TANK MANUAL DRAINAGE: When the internal water tank is full, the unit will stop working. Shut off and unplug the unit. Do not move the appliance, as this may cause the water in the internal tank to spill out. -
Page 11: Troubleshooting
TROUBLESHOOTING Do not repair or disassemble the air conditioning. Unqualified repair will invalidate the warranty and may lead to failure, causing injuries and property damage. Only use it as directed in this user manual and only perform operations advised here. Problems Reasons Solutions... -
Page 12: Support
UK SUPPORT www.electriQ.co.uk/support Please make these simple checks before calling the service line. If the unit still fails to operate, call the number below or complete the online form. 0330 390 3061 Has the unit been standing upright for at least 2 hours?
