USER MANUAL
electriQ 18,000 BTU PORTABLE INDUSTRIAL
AIR CONDITIONER
CMAC20M
Thank you for choosing electriQ
Please read this user manual before using this innovative Air Conditioner and keep it
safe for future reference.
Visit our page www.electriQ.co.uk for our entire range of Intelligent Electricals
Advertisement
Table of Contents
Related Manuals for ElectrIQ CMAC20M
Summary of Contents for ElectrIQ CMAC20M
- Page 1 18,000 BTU PORTABLE INDUSTRIAL AIR CONDITIONER CMAC20M Thank you for choosing electriQ Please read this user manual before using this innovative Air Conditioner and keep it safe for future reference. Visit our page www.electriQ.co.uk for our entire range of Intelligent Electricals...
-
Page 2: Table Of Contents
CONTENTS SAFETY INFORMATION FEATURES APPLIANCE DIAGRAM INSTALLATION OPERATION EMPTYING THE INTERNAL WATER TANK CLEANING AND MAINTENANCE TROUBLESHOOTING SUPPORT TECHNICAL SPECIFICATION... -
Page 3: Safety Information
SAFETY INSTRUCTIONS Important! • Carefully read the instructions before operating the unit • This appliance is for indoor use only. • Rating: This unit must be only connected to a 220-240 V / 50 Hz earthed outlet. • Installation must be in accordance with regulations of the country where the unit is used. •... - Page 4 • Never use the mains plug as a switch to start and turn off the air conditioning unit. Use the provided ON/OFF button located on the control panel. • Always place the unit on a dry and stable surface. • The appliance should not be installed in laundry or wet rooms. •...
-
Page 5: Features
FEATURES 3 in 1 Cooling, Fan, Dehumidifier. • 2 speed fan: Balancing quiet operation with performance. • 24 Hours Start / Stop Timer. • Digital Thermostat. • Auto-Restart to retain the settings in the event of power failure. • Castors for Enhanced Portability. •... -
Page 6: Installation
INSTALLATION COLD AIR OUTLETS 1. Line up the dimple on the Elbow with the notch on the Hose connector on the top of the air conditioner. 2. Rotate anticlockwise until a click can be heard, indicating the elbow has locked into place. -
Page 7: Operation
OPERATION Press the POWER button to turn the unit ON or OFF. POWER Press the MODE button to cycle between the 3 modes, the indicator for the selected mode will be illuminated. The room is cooled with the cold air expelled through the cold air outlets while hot air is expelled through the Hot Air Pipe. - Page 8 INDICATORS Shows the current room temperature. Shows the desired room temperature during cooling Mode. While setting the timer it will display the duration of the timer. Will illuminate when the water tank is full, and the unit will stop operating. Remove the water tank, empty it and replace to extinguish the light and re start operation.
-
Page 9: Emptying The Internal Water Tank
EMPTYING THE INTERNAL WATER TANK MANUAL DRAINAGE: When the internal water tank is full the unit will stop working. Shut off the unit and unplug. Try not to move the appliance as this may cause the water in the internal tank to spill out. -
Page 10: Troubleshooting
TROUBLESHOOTING Do not repair or disassemble the air conditioning. Unqualified repair will invalidate the warranty and may lead to failure, causing injuries and property damage. Only use it as directed in this user manual and only perform operations advised here. Problems Reasons Solutions... -
Page 11: Support
UK SUPPORT www.electriQ.co.uk/support Please, for your own convenience, make these simple checks before calling the service line. If the unit still fails to operate call the number below, or complete the online form. 0330 390 3061 Has the unit been standing upright for at least 2 hours?
