I N S T A L L A T I O N
FLAMMABLE MATERIAL WARNING!
Keep device at least 5.0 feet (1.5m) away from any flammable materials,
decorations, pyrotechnics, etc.
DO NOT INSTALL THE DEVICE IF YOU ARE NOT QUALIFIED TO DO SO!
The myDMX GO WiFi DMX device MUST be installed following all local, national, and country
commercial electrical and construction codes and regulations.
Ambient operating temperature range for this device is 35° to 113°F (2° to 45°C).
DO NOT use the device under or above this temperature range.
DO NOT install the device in areas were unauthorized personnel might reach the device.
MINI OMEGA BRACKET / CLAMP INSTALLATION
The myDMX GO WiFi DMX device can be placed on the flat surface, attached to a surface
using the provided mounting bracket or attached to truss using included mini omega bracket
and a properly rated clamp. (Clamp not included) (See images below)
INSTALLATION LOCATION ON TRUSS MUST BE CLEAR OF ANY MOVING HEAD FIXTURES!
