- Page 1 Model: HX V06S OPERATOR’S MANUAL 4V GARDEN TOOL KIT WARNING! Read this manual carefully before using your tool kit and keep it in a safe place for future reference. Hotline : 1300 418 640 Monday /Friday : 9.00am to 4.30pm Saturday: 9.00am to 3.00pm Email: service@actionspares.com.au...
- Page 2 Read this manual carefully prior to assembling and operating the tools in this tool kit. It is dangerous to operate these tools without being familiar with these instructions. Keep this manual in a safe place and have it ready for future reference.
-
Page 3: Table Of Contents
HX V06S Original instructions CONTENT 1. INTENDED USE………………………………………………………………………………….….3 2. PARTS DESCRIPTION…………………………………………………………………………..….3 3. PACKAGE CONTENTS LIST……………………………………………………………………….4 4. SYMBOLS………………………………………………......……………………..5 5. GENERAL SAFETY WARNINGS………………………………………………………………..…6 6. OPERATION…………………………………………......……………………..14 7. CLEANING, MAINTENANCE AND STORAGE......………………………..16 8. TROUBLESHOOTING..............……………………..17 9. DISPOSAL..................……………………..18 10. TECHNICAL DATA.................……………………..18 11. WARRANTY..................……………………..19... -
Page 4: Intended Use
1. INTENDED USE This 4V Tool kit included garden tools for general garden maintenance. The pruner is designed for pruning branches and plants with a thickness up to 14 mm. The mini trimmer is for cutting and trimming grass, hedges and bushes. -
Page 5: Package Contents List
3. PACKAGE CONTENTS LIST Fig. 2 A. Pruner and blade cover B. Battery C. Charging cable D. Instruction manual E. Mini trimmer Hedge trimmer blade and cover G. Grass shear blade and cover H. Gardening rake Gardening trowel J. Gardening fork •... -
Page 6: Symbols
4. SYMBOLS The following symbols are used in this manual and/or on the tool kit. Denotes risk of Read instruction manual personal injury or before use damage to the tool Do not throw into water Do not throw on fire Do not subject the Dispose of rechargeable battery to strong... -
Page 7: General Safety Warnings
5. GENERAL SAFETY WARNINGS WARNING! Read all safety warnings, instructions, illustrations and specifications provided with this power tool. Failure to follow all instructions may result in an electric shock, fire and/or serious injury. Save all warnings and instructions for future reference. The term “power tool”... - Page 8 IF OPERATING A POWER TOOL IN A DAMP LOCATION IS UNAVOIDABLE, USE A RESIDUAL CURRENT DEVICE (RCD) PROTECTED SUPPLY. Use of an RCD reduces the risk of electric shock. 5.3 PERSONAL SAFETY a. STAY ALERT, WATCH WHAT YOU ARE DOING AND USE COMMON SENSE WHEN OPERATING A POWER TOOL.
- Page 9 for your application. The correct power tool will do the job better and safer at the rate for which it was designed. b. DO NOT USE THE POWER TOOL IF THE SWITCH DOES NOT TURN IT ON AND OFF. Any power tool that cannot be controlled with the switch is dangerous and must be repaired.
- Page 10 metal objects, that can make a connection from one terminal to another. Shorting the battery terminals together may cause burns or a fire. d. Under abusive conditions, liquid may be ejected from the battery; avoid contact. If contact accidentally occurs, flush with water. If liquid contacts eyes, additionally seek medical help.
- Page 11 5.8 MINI TRIMMER SAFETY WARNINGS a) Keep all parts of the body away from the blade. Do not remove cut material or hold material to be cut when blades are moving. Blades continue to move after the switch is turned off. A moment of inattention while operating the hedge trimmer may result in serious personal injury.
- Page 12 5.9 RESIDUAL RISK Additional residual risks may arise when using the tool which may not be included in the safety warnings. These risks can arise from misuse, prolonged use etc. Even with the application of the relevant safety regulations and the implementation of safety devices, certain residual risks cannot be avoided.
- Page 13 6. BATTERY PACK WARNING! Inspect the battery pack before charging, do not charge a cracked or leaking battery pack. Note: The battery pack is supplied partially charged. To ensure full capacity, fully charge the battery pack before use. To charge the battery pack, connect the battery pack's type C socket to a power source that is 5Vdc 2A or less via a charging cable.
- Page 14 Fig. 4 5V 1A Power indicator Light up Flasing Green LED Red LED Using as a power bank Torch function...
-
Page 15: Operation
7. OPERATION 7.1 Installing and removing the battery a) Make sure the battery is in the right orientation (i.e. battery's button is on the up side). Insert the battery into the battery compartment of the pruner/mini trimmer until it clicks into position. Fig. - Page 16 c) Release the trigger switch to stop the pruner. Note: For safety, the pruner should be stopped when the blade is closed. Release the trigger switch only when the blade is closed. d) Press the ON/OFF button again to switch off the pruner. The green light on the battery will be off when the pruner is switched off.
-
Page 17: Cleaning, Maintenance And Storage
Fig. 10 c) Release the trigger switch to stop the mini trimmer. d) Press the ON/Off button backward to switch off the mini trimmer. 8. CLEANING, MAINTENANCE AND STORAGE WARNING: Remove the battery from the pruner/mini trimmer before cleaning, maintenance and storage. WARNING: Always wear protective gloves when handling the blades. -
Page 18: Troubleshooting
the battery from the pruner/mini trimmer before storage. b) Store the garden tools, pruner/mini trimmer and the battery in the toolbox, and put it in a secure place out of the reach of children. 9. TROUBLESHOOTING Problem Possible cause Possible solution Battery is not properly Insert the battery to the inserted properly... -
Page 19: Technical Data
11. TECHNICAL DATA Battery Model number AL V40 Battery voltage 4 Vdc Capacity 4.0 Ah Input 5 Vdc, max. 1 A Output (Type A) 5 Vdc; 1A Pruner Model number LS V14 Rated voltage 4 Vdc Max. cutting diameter 14 mm Net weight 0.65 kg Degree of ingress protection... -
Page 20: Warranty
WARRANTY This product (included battery) is covered by a 1 year parts and labour warranty against manufacturing defects. Our goods come with guarantees that cannot be excluded under the Australian Consumer Law. Our goods come with guarantees that cannot be excluded under the Australian Consumer Law.
