Woodstock Soapstone PROGRESS HYBRID 209a Owner's Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
PROGRESS HYBRID
209a
MODEL
W
S
S
OODSTOCK
OAPSTONE
TOVES
OWNER'S MANUAL
Tested and Listed by
Tested To UL 1482-2011 7th Edition
Listed By PFS Corporation
Woodstock Soapstone Company, Inc.
66 Airpark Road, West Lebanon, NH 03784
Toll Free 1-800-866-4344 • www.woodstove.com
Rev 0221

Advertisement

loading
Need help?

Need help?

Do you have a question about the PROGRESS HYBRID 209a and is the answer not in the manual?

Questions and answers

Related Manuals for Woodstock Soapstone PROGRESS HYBRID 209a

Summary of Contents for Woodstock Soapstone PROGRESS HYBRID 209a

  • Page 1 PROGRESS HYBRID 209a MODEL OODSTOCK OAPSTONE TOVES OWNER’S MANUAL Tested and Listed by Tested To UL 1482-2011 7th Edition Listed By PFS Corporation Woodstock Soapstone Company, Inc. 66 Airpark Road, West Lebanon, NH 03784 Toll Free 1-800-866-4344 • www.woodstove.com Rev 0221...
  • Page 2 Please Note: Tested and Listed for US installations only LIMITED WARRANTY Your Woodstock Soapstone Stove will be carefully inspected before shipment. We will replace any part which is defective in material or workmanship, free of cost, for a peri- od one year from the date of purchase. If a defect is discovered, please contact Woodstock Soapstone Company, Inc.
  • Page 3 MODEL 209a PROGRESS HYBRID CATALYTIC TABLE OF CONTENTS WARRANTY INFORMATION/CERTIFICATIONS.... Inside Cover EPA Certification, UL Listing, Warranty, Catalytic Combustor Warranty INTRODUCTION Progress Hybrid Wood Stove Explained INSTALLATION............1-14 Installation, Location, Chimneys, Fireplace InstallationClearance Table, Wall Protection, Floor Protection OPERATION...
  • Page 4 Introduction In many ways, the Progress Hybrid was inspired by our customers’ request for a larger wood stove capable of heating large spaces. Many wanted the choice of top or rear venting and right or left side loading. A large ash pan option also made the list. Of course everyone wanted a grand view of the mes- merizing flames.
  • Page 5 amount of fuel (smoke and gasses) present will dictate which system (or both) is most active. Simply allowing more air into the firebox will generate more heat there, while also increasing the amount of oxygen to light off the secondary combustion process. The result is a spectacular light show as the sec- ondary flames swirl and tumble around the firebox.
  • Page 6 Read this entire manual carefully. It explains how to install your Woodstock Soapstone Progress Hybrid Wood Stove safely and how to operate it correctly and efficiently. The clearances and procedures recommended in this guide are in compliance with the recommendations of the National Fire Protection Association (NFPA), the Underwriters Laboratories (UL), and the U.
  • Page 7 CHIMNEYS Your chimney is a critical component of your wood heating system. A prop- erly designed and constructed chimney will help to provide safe and efficient woodstove operation. Hot exhaust rising up through the chimney also pulls combustion air into the stove through the air damper. If a chimney is too short, or the flue too large, the hot exhaust will cool and slow down.
  • Page 8 Listed wall passing through a combustible wall. For more information on these kits, protector & please contact Woodstock Soapstone Company. Please note: there are several cover shield UL listed wall pass through kits available, always follow the manufacturers UL listed and approved wall pass thru kit.
  • Page 9 Chimney Connection used with fireplace inserts or factory built fireplaces. These ARE NOT suitable for use with your Woodstock Soapstone stove. At the point of the first penetration of a combustible surface (i.e., wall or ceiling) all subsequent venting components need to be prefabricated “UL Type HT Class A”. If your prefabricated chimney goes through a living space it must be enclosed, and that enclosure must conform to clearance standards for the prefab- ricated chimney.
  • Page 10 the support hangs down below the ceiling far enough to maintain Installation 2 Pitched/Cathedral Ceiling through the roof. proper clearance to the connector pipe (steeper slopes require more pipe below the ceiling). Install the pipe adapter to the first section of chimney pipe and lower it into the support box (or connect it to the bottom of the roof support).
  • Page 11 & cap. FLOOR PROTECTION REQUIREMENTS Your Woodstock Soapstone stove must be set on an approved hearth or floor protection. The hearth protects your floor from two hazards: • Heat Transfer: Heat radiation from the bottom, front, and sides of the woodstove •...
  • Page 12 • A prefabricated hearth pad listed to UL approved standards. These pads are made to be placed on an existing floor. Woodstock Soapstone Company has a good selection of these pre-made pads. • A custom designed pad constructed of approved non-combustible materials which will protect the floor from sparks, hot coals, and ashes;...
  • Page 13 DO NOT USE: Old-fashioned stove boards that were commonly sold in hardware stores as they DO NOT have adequate protection and ARE NOT approved for primary floor protection under your stove. Hearth Rugs also ARE NOT meant to be used as primary hearth protection. These are made to be used in addition to an approved hearth, and are used as auxiliary decorative protection.
  • Page 14 CORNER HEARTH PAD Minimum hearth size in a corner installation must be 54”x54” (with the front corner cut off). NOTE: On a hearth of minimum size, the stove will not be centered left to right, but will meet the minimum required clearances.
  • Page 15 Wall shields: Clearances can also be reduced by mounting a ventilated shield on the wall that extends 36” out beyond the stove (see diagram below). If you are installing wall protection, it should be spaced out from the wall one inch.
  • Page 16 CLEARANCE INSTALLATION DIAGRAMS 1) Parallel Installation, Single Wall Pipe, Top Vent NO HEAT SHIELD A. Back of stove to wall = 36” D. Side of stove to wall = 24” B. Back of pipe to wall = 18” E. Side of pipe to wall = 36”...
  • Page 17 CLEARANCE INSTALLATION DIAGRAMS 3) Corner Installation, Single Wall Pipe, Top Vent TOP VENT NO HEAT SHIELD A. Stove corners to side walls = 36” (determines placement) B. Pipe to side walls =18” C. Pipe to corner =18” WITH REAR HEAT SHIELD & PIPE SHIELD ATTACHED A.
  • Page 18 SETTING UP YOUR STOVE Your Model 209 Progress Hybrid Wood stove has been shipped fully assembled except for five parts: 1) The stove legs 2) A.The bottom heat shield (if no ash pan) or B. Optional ash pan 3) The flue collar/cover plate 4) Loading door handle.
  • Page 19 4. Open ash pan door and slide the ash pan into the holder. REMOVE THE ASH PAN COVER BEFORE LIGHTING YOUR STOVE. (3) How to attach the Progress flue collar & cover plate: Your Progress Hybrid will arrive with the flue collar pre-installed on the rear exit and the cover plate on top of the stove.
  • Page 20 Both soapstone and cast iron need to be seasoned. The seasoning can be accomplished through a series of small to moderate fires. Your Woodstock Soapstone Stove is an easy stove to season, because even a small fire will provide hours of radiant heat once the stove is warm. There are two things you will notice during the first fire: First, there will be a hot, acrid smell as the stove heats up.
  • Page 21 CAUTION 8. Adjust the air control damper to a lower setting by lifting the lever up. The lower the burn rate, as less air is entering the firebox. The final NEVER USE GASOLINE, damper setting will be determined by the desired heat output from the GASOLINE TYPE LANTERN stove, the condition of the wood being burned, and the draft through the FUEL, KEROSENE, CHAR-...
  • Page 22 Never build a roaring fire in a cold stove. It takes at least 30 minutes to heat the soapstone panels of the Progress. Attempts to reach high temperatures very quickly could result in damage to the cast iron or soapstone parts. Burning for Higher Heat Output These instructions are intended as a guide to operating your wood stove.
  • Page 23 36 hours to cool. Woodstock Soapstone Company offers a black metal ash holder with a hinged lid that closes tightly. Four sturdy legs keep it off the floor, and the wooden handle is not only decorative, it will also protect your hands.
  • Page 24 Avoid overfiring by letting the combustor and secondaries do most of the work in the stove. Your stove is operating at peak efficiency when the combustor is “engaged”and the secondaries are ignited, with the damper lever set to a low to moderate setting, and the logs are glowing with secondary flames apparent. You will get the greatest amount of heat per pound of wood when the stove is operated in this manner.
  • Page 25 Firewood Your Woodstock Soapstone Stove is designed to burn seasoned, natural cordwood. Higher efficiency and lower emissions generally result when burning air-dried seasoned hard woods, as compared to green, freshly cut hard woods. It is perfectly fine to burn soft woods in your stove as long as they are properly dried.
  • Page 26 CATALYTIC COMBUSTORS Here is how your catalytic combustor works. The catalytic combustor is a stainless steel honeycomb with hundreds of cells. If you looked at the inside of each cell with a microscope, you would see that the walls are uneven and filled with minute nooks and crannies.
  • Page 27 1) Burn only natural, well-seasoned wood. 2) Wait until the exhaust gases reach about 500 degrees F (internal temperature) before engaging the catalytic combustor (about 10-15 minutes after re-establishing a strong fire). 3) Bypass the combustor before reloading and leave the bypass open for a few minutes after reloading to raise the temperature in the stove.
  • Page 28 6. Close the top lid. Catalytic Combustor Replacement If you feel that your catalytic combustor is not working properly, please contact Woodstock Soapstone Company at 1-800-866-4344 for instructions regarding return and replacement. Accessing the catalyst in your new Progress Hybrid Woodstove is simple, just remove the top soapstone pieces, raise the cast iron cook top, and gently pull the combustor out of its housing.
  • Page 29 The catalytic combustor is additionally warranted for three years from the date of purchase for any deterioration in the stainless steel substrate material. For instruc- tions regarding return or replacement of the catalytic combustor, please contact: Woodstock Soapstone Company, Inc. 66 Airpark Road West Lebanon, NH 03784...
  • Page 30 M INTEN NCE Stove Cleaning The ornamental cast iron frame of the Woodstock Soapstone Stove is painted with two coats of high temperature stove paint. Under normal operating conditions, this paint will not peel or blister. We suggest cleaning by dusting with a soft brush or vacuuming with a brush attachment when the stove is cold.
  • Page 31 Routine Checks And End of Season Maintenance Every few weeks of operation we recommend checking the chimney connector (stovepipe) and combustor (see combustor section) and cleaning, if necessary. When the weather warms up and the burning season is over, it is a good idea to do a thorough spring cleaning and inspection of your stove and chimney system.
  • Page 32 combustors on pages 20-23. 3. Never operate your stove for extended periods of time with the draft control completely closed. Both the wood fire and the catalytic combustor need oxygen to burn efficiently. 4. Re-establish a hot fire, and re-ignite the combustor after every reloading by opening the primary air control for about 10 minutes.
  • Page 33 TROUBLESHOOTING GUIDE Problem Solutions Possible Cause Stove smokes Open bypass and air damper prior to reloading Operating technique stove Examine chimney and stovepipe for blockage and Blocked Chimney creosote accumulations. Check spark arrestor screen on your cap, if you have one. Check the outside inlet for blockage caused by Blocked outside airduct snow, debris, or insects.
  • Page 34 Insufficient Heat Poor quality or green wood Use only well-seasoned wood (dried at least one year). Test with kiln dried wood. Check outside air duct for blockage Blocked outside air duct Heat going up chimney Test with thermometer on 1st section of stovepipe–...
  • Page 35 Installation Your Woodstock Soapstone Stove has been thoroughly tested and listed to UL #1482 by an independent testing laboratory. UL #1482 is the standard for testing solid fuel appliances and is universally recognized by all nation- al building regulatory agencies, (SBCC, BOCA, ICBO) and individual states.
  • Page 36 •A top that closes securely and will not fall off •Legs or other means of preventing downward heat flow •A design that prevents spilling when loading Ashes should never be dumped into a combustible container, such as a cardboard box, and an ash con- tainer should never be set on a combustible floor.
  • Page 37 Front under glass P-361R Top stone right All soapstone parts cut and fabricated P-313-R Right side doorframe P-367 Left side – non-door style by Woodstock Soapstone Company P-313-L Left side doorframe P-368 Left side – door style P-314 Door P-369 Right side –...
  • Page 38 MODEL 209a SOAPSTONE GUIDE MODEL THICKNESS HEIGHT WIDTH EXTERIOR SOAPSTONE EXTERIOR W-350 FULL SIDE 0.75 20.396 13.039 W-351 OVER DOOR 0.75 5.458 13.039 W-352a OVER FRONT 0.75 3.296 20.539 W-352b UNDER FRONT 0.75 3.075 20.539 W-353 1.125 12.494 22.958 W-354 CORNER (4) 0.75 20.396 3.092...
  • Page 39 BOTTOM HEAT SHIELD DIAGRAM NOTE: The fill plate must be installed inside the firebox before the bottom heat shields are attached. Bottom fill plate P-318 Shield #1 P-318b Shield #2 P-318c Shield #3 P-318d Detailed instructions and hardware are included with the bottom heat shield kit. If you have any installation questions, please call us toll free at 1-800-866-4344...
  • Page 40 ASH PAN DIAGRAM Ash Pan Holder P-337 Ash Pan P-335 Ash box bottom heat shield P-341 Detailed instructions and hardware are included with the ash pan kit. If you have any installation questions, please call us toll free at 1-800-866-4344...
  • Page 41 DIMENSIONS & SPECIFICATIONS H x W x D (10” Standard Legs)..33.5”x30.5”x25” Weight........700 lbs. HxWxD (5”...
