OPER TION
The Survival Hybrid Wood Stove is designed to burn clean at all times. The directions below detail how to maintain peak
efficiency and clean-burning.
Seasoning Your Stove
Seasoning is accomplished through a series of small to moderate wood fires. Don't place anything on the top surface of
the stove until the paint has finished curing. There are two things you will notice during the first fire:
First, there will be a hot, acrid smell as the stove heats up. This smell is a result of the paint on the stove and pipe
curing. You will want to have your first fire on a day when you can open the windows in the house to provide adequate
ventilation. The odor is non-toxic and will only be present for the first few fires.
Second, there will be some condensation on the glass. This condensation is a result of any moisture being driven out of
the stove and condensing on the inner surface of the glass. It takes a couple of small fires to season the stove and remove
this excess moisture.
Getting to Know the Survival Stove Controls
Bypass Damper
When the bypass damper is open, smoke
travels directly from the firebox to the chim-
ney. When the bypass damper is closed,
smoke travels through the catalytic combus-
tor. The catalytic combustor burns the smoke
to produce more heat and cleaner exhaust.
Air Control
The air control damper on the load door con-
trols the rate the fuel is burned and the
amount of heat that the stove produces.
Move the air damper all the way to the right to
kindle a fire or maximum heat.
Slide the damper slowly to the left to decrease
the burn rate or heat output. The damper is very
sensitive; moving the damper just a fraction of
an inch will affect the burn rate and heat output.
Door Latch Detent
There is a small notch in the door handle. If
you close the door just to this notch, it will let
air in at the edge of the door. This will provide
a small boost when kindling a fire. Use the
detent to add a little air when starting a wood
fire, or just after reloading.
Bypass Damper Handle
Open Position
The Bypass Damper Handle must be opened to kindle a fire and to reload the stove. Close
the Bypass Damper Handle when the stove is in operation. The stove will produce more heat
and less smoke with the handle closed.
Push RIGHT To Kindle a Fire, or
High Heat
8
Push LEFT For Low Fire, or
Long Burn Time
