EASTRON SDM630MCT-Mbus User Manual
SDM630MCT-MBUS
DIN Rail Energy Meter for Single and Three Phase Electrical Systems
Measures kWh Kvarh, KW, Kvar, KVA, P,
F, PF, Hz, dmd, V, A, THD,etc.
Bi-directional measurement IMP & EXP
Two pulse outputs
MBUS
Din rail mounting 35mm
1/5A CT connection
Better than Class 1 / B accuracy
Address: No.1369 Chengnan Road, Jiaxing, Zhejiang, 314001, China.
Tel: 0086-573-83698881/83698882 Fax: 0086-573-83698883 Web: www.eastron.com.cn
USER MANUAL
2016 V1.3
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Eastron SDM630MCT-MBUS
Summary of Contents for Eastron SDM630MCT-MBUS
- Page 1 Two pulse outputs MBUS Din rail mounting 35mm 1/5A CT connection Better than Class 1 / B accuracy USER MANUAL 2016 V1.3 Address: No.1369 Chengnan Road, Jiaxing, Zhejiang, 314001, China. Tel: 0086-573-83698881/83698882 Fax: 0086-573-83698883 Web: www.eastron.com.cn...
- Page 2 This uses an MBus port with EN13753-3 protocol to provide a means of remotely monitoring and controlling the Unit. Set-up screens are provided for setting up the MBus port. Address: No.1369 Chengnan Road, Jiaxing, Zhejiang, 314001, China. - 1 - Tel: 0086-573-83698881/83698882 Fax: 0086-573-83698883 Web: www.eastron.com.cn...
- Page 3 In Set-up Mode, this is the “Left” or “Back” button. Select the Frequency and Power factor display screens In Set-up Mode, this is the “Up” button Address: No.1369 Chengnan Road, Jiaxing, Zhejiang, 314001, China. - 2 - Tel: 0086-573-83698881/83698882 Fax: 0086-573-83698883 Web: www.eastron.com.cn...
- Page 4 Each successive pressing of the button selects a new range: Phase to neutral voltages(3p4w) Phase to neutral voltages(3p3w) Current on each phase Phase to neutral voltage THD%(3p4w) Address: No.1369 Chengnan Road, Jiaxing, Zhejiang, 314001, China. - 3 - Tel: 0086-573-83698881/83698882 Fax: 0086-573-83698883 Web: www.eastron.com.cn...
- Page 5 Each successive pressing of the button selects a new range: Frequency and Power Factor (total) Power Factor of each phase Maximum Current Demand Address: No.1369 Chengnan Road, Jiaxing, Zhejiang, 314001, China. - 4 - Tel: 0086-573-83698881/83698882 Fax: 0086-573-83698883 Web: www.eastron.com.cn...
- Page 6 Instantaneous Active Power in kW Instantaneous Reactive Power in kVAr Instantaneous Volt-amps in KVA Total kW, kVArh, kVA Address: No.1369 Chengnan Road, Jiaxing, Zhejiang, 314001, China. - 5 - Tel: 0086-573-83698881/83698882 Fax: 0086-573-83698883 Web: www.eastron.com.cn...
- Page 7 Imported active energy in kWh Exported active energy in kWh Imported reactive energy in kVArh Exported reactive energy in kVArh Total active energy in kWh Address: No.1369 Chengnan Road, Jiaxing, Zhejiang, 314001, China. - 6 - Tel: 0086-573-83698881/83698882 Fax: 0086-573-83698883 Web: www.eastron.com.cn...
- Page 8 If an incorrect password is entered, the display will show: PASS Err To exit setting-up mode, press repeatedly until the measurement screen is restored. Address: No.1369 Chengnan Road, Jiaxing, Zhejiang, 314001, China. - 7 - Tel: 0086-573-83698881/83698882 Fax: 0086-573-83698883 Web: www.eastron.com.cn...
- Page 9 3) After setting the last digit, press to exit the number setting routine. The SET indicator will be removed. Change password Address: No.1369 Chengnan Road, Jiaxing, Zhejiang, 314001, China. - 8 - Tel: 0086-573-83698881/83698882 Fax: 0086-573-83698883 Web: www.eastron.com.cn...
- Page 10 This sets the period in minutes over which the current and power readings are integrated for maximum demand measurement. The options are: off, 5, 8, 10, 15,20, 30, 60 minutes Address: No.1369 Chengnan Road, Jiaxing, Zhejiang, 314001, China. - 9 - Tel: 0086-573-83698881/83698882 Fax: 0086-573-83698883 Web: www.eastron.com.cn...
- Page 11 5minutes from the last time operation on the meter. Notes: If it’s set as 0, the backlit will always be on. Address: No.1369 Chengnan Road, Jiaxing, Zhejiang, 314001, China. - 10 Tel: 0086-573-83698881/83698882 Fax: 0086-573-83698883 Web: www.eastron.com.cn...
- Page 12 The current selection will flash buttons to select the required system option: 1P2(W),3P3(W) ,3P4(W) Press to confirm the selection. SET indicator will appear. Address: No.1369 Chengnan Road, Jiaxing, Zhejiang, 314001, China. - 11 Tel: 0086-573-83698881/83698882 Fax: 0086-573-83698883 Web: www.eastron.com.cn...
- Page 13 From the Set-up menu, use buttons to select the PT option. The screen will show the voltage PT secondary voltage value. The default value is 400V Address: No.1369 Chengnan Road, Jiaxing, Zhejiang, 314001, China. - 12 Tel: 0086-573-83698881/83698882 Fax: 0086-573-83698883 Web: www.eastron.com.cn...
- Page 14 Pulse output option. Press to enter the selection routine. The unit symbol will flash. buttons to choose kWh or kVArh. Address: No.1369 Chengnan Road, Jiaxing, Zhejiang, 314001, China. - 13 Tel: 0086-573-83698881/83698882 Fax: 0086-573-83698883 Web: www.eastron.com.cn...
- Page 15 Pulse Duration The energy monitored can be active or reactive and the pulse width can be 200, 100 or 60ms. Address: No.1369 Chengnan Road, Jiaxing, Zhejiang, 314001, China. - 14 Tel: 0086-573-83698881/83698882 Fax: 0086-573-83698883 Web: www.eastron.com.cn...
- Page 16 There is a Mbus port can be used for communication using Mbus protocol. For Mbus communication, parameters are selected from Front panel. Mbus Address From the Set-up menu, use buttons to select the first Address Address: No.1369 Chengnan Road, Jiaxing, Zhejiang, 314001, China. - 15 Tel: 0086-573-83698881/83698882 Fax: 0086-573-83698883 Web: www.eastron.com.cn...
- Page 17 Baud Rate From the Set-up menu, use buttons to select the Baud Rate option. Press to enter the selection routine. The current setting will flash. Address: No.1369 Chengnan Road, Jiaxing, Zhejiang, 314001, China. - 16 Tel: 0086-573-83698881/83698882 Fax: 0086-573-83698883 Web: www.eastron.com.cn...
- Page 18 Default is NONE. On completion of the entry procedure, press to confirm the setting and press to return to the main set up menu. Stop bits Address: No.1369 Chengnan Road, Jiaxing, Zhejiang, 314001, China. - 17 Tel: 0086-573-83698881/83698882 Fax: 0086-573-83698883 Web: www.eastron.com.cn...
- Page 19 The meter provides a function to reset the maximum demand value of current and power. From the Set-up menu, use buttons to select the reset option. Press to enter the selection routine. The MD will flash. Address: No.1369 Chengnan Road, Jiaxing, Zhejiang, 314001, China. - 18 Tel: 0086-573-83698881/83698882 Fax: 0086-573-83698883 Web: www.eastron.com.cn...
- Page 20 Frd (forward) buttons to Phase B or C setting pages How to operate if phase A is reversely connected Go to phase A setting page Address: No.1369 Chengnan Road, Jiaxing, Zhejiang, 314001, China. - 19 Tel: 0086-573-83698881/83698882 Fax: 0086-573-83698883 Web: www.eastron.com.cn...
- Page 21 Voltage inputs through 4-way fixed connector with 2.5mm² stranded wire capacity. single phase two wire(1p2w), three phase three wire(3p3w) or four phase four wire(3p4w) unbalanced. Line frequency measured from L1 voltage or L3 voltage. Address: No.1369 Chengnan Road, Jiaxing, Zhejiang, 314001, China. - 20 Tel: 0086-573-83698881/83698882 Fax: 0086-573-83698883 Web: www.eastron.com.cn...
- Page 22 1000=1000 kWh/kVArh Pulse width: 200/100(default)/60ms Pulse output 2 is non-configurable. It is fixed up with total kWh. The constant is 3200imp/kWh. MBus Output for EN_13757-3 Address: No.1369 Chengnan Road, Jiaxing, Zhejiang, 314001, China. - 21 Tel: 0086-573-83698881/83698882 Fax: 0086-573-83698883 Web: www.eastron.com.cn...
- Page 23 Up to 2000m Warm up time 1 minute Vibration 10Hz to 50Hz, IEC 60068-2-6, 2g Shock 30g in 3 planes Dimensions Address: No.1369 Chengnan Road, Jiaxing, Zhejiang, 314001, China. - 22 Tel: 0086-573-83698881/83698882 Fax: 0086-573-83698883 Web: www.eastron.com.cn...
- Page 24 EASTRON SDM630MCT-Mbus User Manual Installation Address: No.1369 Chengnan Road, Jiaxing, Zhejiang, 314001, China. - 23 Tel: 0086-573-83698881/83698882 Fax: 0086-573-83698883 Web: www.eastron.com.cn...
- Page 25 EASTRON SDM630MCT-Mbus User Manual Address: No.1369 Chengnan Road, Jiaxing, Zhejiang, 314001, China. - 24 Tel: 0086-573-83698881/83698882 Fax: 0086-573-83698883 Web: www.eastron.com.cn...
- Page 26 EASTRON SDM630MCT-Mbus User Manual Address: No.1369 Chengnan Road, Jiaxing, Zhejiang, 314001, China. - 25 Tel: 0086-573-83698881/83698882 Fax: 0086-573-83698883 Web: www.eastron.com.cn...
- Page 27 EASTRON SDM630MCT-Mbus User Manual Address: No.1369 Chengnan Road, Jiaxing, Zhejiang, 314001, China. - 26 Tel: 0086-573-83698881/83698882 Fax: 0086-573-83698883 Web: www.eastron.com.cn...
