madbeanpedals Touchstone24 Manual

Touchstone24 Touchstone24
F
MODULATION
X Type:
Build Level: Intermediate
Based On: EHX® Small Clone™
The 2024 version of the Touchstone has no circuit changes and minor layout tweaks.
It's warm. It's lush. It's a classic! The Touchstone is based around the big box MN3007 Small
Clone. A little less complicated than the venerated CE-2 but a righteous chorus all on its own.
Capable of dense slow chorus tones while the large depth range can take you well into seasick
territory. If you've never built/played a Small Clone you will not be disappointed.
• RATE, DEPTH: Min to max in both controls.
• T1: This trimmer sets the bias for the input of the MN3007.
This link has some interesting info and history on the Small Clone:
https://www.ehx.com/forums/viewthread/5555
Terms of Use: You are free to use purchased Touchstone24 circuit boards for both DIY and small commercial operations. You may not offer Touchstone24 PCBs for
resale or as part of a "kit" in a commercial fashion. Peer to peer re-sale is fine, though.
Technical assistance for is available via the
available to respond via email in a timely and continuous manner, and (2) posting technical problems and solutions in the forum creates a record from which other
members may benefit.
