MEDIUM ROLLER BLIND
INSTALLATION MANUAL
v1.1 | June 2024

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MEDIUM and is the answer not in the manual?

Questions and answers

Related Manuals for rollease acmeda MEDIUM

Summary of Contents for rollease acmeda MEDIUM

  • Page 1 MEDIUM ROLLER BLIND INSTALLATION MANUAL v1.1 | June 2024...

  • Page 2: Table Of Contents

    DISCLAIMER INTRODUCTION This installation manual has been produced by Rollease Acmeda to supply the necessary information for the safe and correct installation of Medium Roller Blinds. DISCLAIMER Rollease Acmeda has used reasonable care in preparing the information included in this document, but makes no representations or warranties as to the completeness or accuracy of the information.

  • Page 3: Section A | Tools Required

    SECTION A | TOOLS REQUIRED Drill Screw Driver Measuring Tape Booster Pre-tension tool Pencil Page. 5 Medium Roller Blinds Installation Manual | v1.1 | June 2024 Page. 3 ©Copyright All Rights Reserved Rollease Acmeda...

  • Page 4: Section B | Shade Items Required

    MOTORISED SYSTEM - DUAL SHADES SYSTEM INDEX: SHADE ASSEMBLY REMOTE • Optional BRACKET SET 4. BRACKET COVER SET • Optional MOTOR CAP • Optional FASTENERS Medium Roller Blinds Installation Manual | v1.1 | June 2024 Page. 4 ©Copyright All Rights Reserved Rollease Acmeda...

  • Page 5: Section C | Preparation

    CEILING MOUNT WALL MOUNT INSIDE MOUNT CEILING MOUNT WALL MOUNT Use 2 screws per bracket - use different holes for each screw. NOTE Medium Roller Blinds Installation Manual | v1.1 | June 2024 Page. 5 ©Copyright All Rights Reserved Rollease Acmeda...

  • Page 6: Control Orientation

    P1 Button CHAIN SYSTEM ZERO MOTOR SYSTEM E6/M6 MOTOR SYSTEM Medium HD Bracket Adaptor + Screw is required for E6/M6 motor installations. NOTE Ensure correct orientation for optimal chain performance/Motor P1 button & charging port access. TOP FRONT EXAMPLE TOP BACK EXAMPLE MEDIUM HD SCREW ADAPTOR Medium Roller Blinds Installation Manual | v1.1 | June 2024...

  • Page 7: Section D | Installation

    Rotate COUNTER-CLOCKWISE to retract the pin. RB08 MKII IDLER ADJUSTMENT Rotate CLOCKWISE to extend the pin 7mm. Rotate COUNTER-CLOCKWISE to retract the pin. Medium Roller Blinds Installation Manual | v1.1 | June 2024 Page. 7 ©Copyright All Rights Reserved Rollease Acmeda...

  • Page 8: Bracket Covers

    Single Bracket Covers. Double Bracket Covers. NOTE Ensure bracket covers are engaged securely onto the brackets. MOTOR CAP OPTIONAL | MOTOR ONLY Medium Roller Blinds Installation Manual | v1.1 | June 2024 Page. 8 ©Copyright All Rights Reserved Rollease Acmeda...

  • Page 9: Optional Accessories

    Geared Winders require a longer chain when using 2x Ball Stops, refer to the Minimum Chain Length for Geared Winders table in the Appendix. Medium Roller Blinds Installation Manual | v1.1 | June 2024 Page. 9 ©Copyright All Rights Reserved Rollease Acmeda...

  • Page 10: Section E | Easy-Lift Chain Booster Retro-Fit Booster | Pre-Turns

    WEIGHT BAR: D30 Bottom Rail S40 | PRE-TURN EST. SIMPLIFIED WIDTH 0.80 1.20 10 11 1.60 2.00 2.40 10 11 2.80 Medium Roller Blinds Installation Manual | v1.1 | June 2024 Page. 10 3.20 ©Copyright All Rights Reserved Rollease Acmeda 3.60...

  • Page 11: Adjust Preturns

    Hold the tube & winder securely when removing the winder, the live tension will cause the parts to spin. LEFT HAND CONTROL RIGHT HAND CONTROL BACK ROLL FRONT ROLL BACK ROLL FRONT ROLL Medium Roller Blinds Installation Manual | v1.1 | June 2024 Page. 11 ©Copyright All Rights Reserved Rollease Acmeda...

  • Page 12: Section F | Retro-Fit Installation

    Assemble motor + kit. Refer to shade installation Remove chain hardware. steps. FABRIC TIPS & TRICKS Medium Roller Blinds Assembly Manual | v1.0 | November 2023 Page. 14 ©Copyright All Rights Reserved Rollease Acmeda Fabric tracking example. Apply tape to tube.

  • Page 13: Section G | Appendix

    3600 22.6 5369 2684 2750 3700 23.1 5496 2748 2750 3800 23.7 5623 2812 3900 24.2 5749 2875 4000 24.8 5875 2937 Medium Roller Blinds Installation Manual | v1.1 | June 2024 Page. 13 ©Copyright All Rights Reserved Rollease Acmeda...
