- Page 1 WIREGUIDE-SKYLIGHT INSTALLATION MANUAL November 2018...
-
Page 2: Table Of Contents
�����������������������������������������������������������������������������������������������������������������������������������08 DISCLAIMER INTRODUCTION This Installation manual for WireGuide Skylight has been produced by Rollease Acmeda to supply the necessary information for the safe and correct installation of WireGuide Skylight. DISCLAIMER Rollease Acmeda has used reasonable care in preparing the information included in this document, but makes no representations or warranties as to the completeness or accuracy of the information. -
Page 3: Section A: | Items Required
SECTION A: | ITEMS REQUIRED ASSEMBLED PARTS 1� 2� 3� 4� 5� 1� Spring/Fabric Box 2� Motor/Spool Box 3� Spring/Fabric Tube 4� Motor/Spool Tube 5� Wire Components Page� 01 Wireguide Skylight Installation Manual | November 2018 2018 ©Copyright All Rights Reserved Rollease Acmeda... -
Page 4: Section B: | Installation
THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE PROPERTY OF DETAIL F IN "MM" ROLLEASE ACMEDA. ANY REPRODUCTION IN PART OR WHOLE WITHOUT THE REV. WRITTEN PERMISSION OF ROLLEASE ACMEDA IS PROHIBITED. SCALE 1 : 1 SECTION E-E... -
Page 5: Install Fabric/Spring Tube Into Box
Pre-Turn Spanner available through Rollease Acmeda Order Part #: RB10-9102-025008 REFER TO PRE-TENSION CHARTS FOR PRE-TURNS REQUIRED (SEE FOLLOWING PAGES) Rollease Acmeda does not recommend exceeding suggested pre-turn values STEP 3� INSTALL FABRIC/SPRING TUBE Ensure idler shafts are correctly installed STEP 4�... -
Page 6: Wireguide | 60Mm Tube Pre-Tension Chart
10 10 10 10 10 10 2.80 3.00 LEGEND DESCRIPTION Short Booster EXTRA Heavy Booster Optimal fabric Performance Pre-Turns Required Cannot be achieved - outside product specifications Page� 04 Wireguide Skylight Installation Manual | November 2018 2018 ©Copyright All Rights Reserved Rollease Acmeda... -
Page 7: Wireguide | 80Mm Tube Pre-Tension Chart
12 12 12 12 3.00 LEGEND DESCRIPTION Short Booster EXTRA Heavy Booster Optimal fabric Performance Pre-Turns Required Cannot be achieved - outside product specifications Page� 05 Wireguide Skylight Installation Manual | November 2018 2018 ©Copyright All Rights Reserved Rollease Acmeda... -
Page 8: Install Motor/Spool Tube Into Box
INSTALL MOTOR/SPOOL TUBE INTO BOX STEP 1� INSTALL MOTOR HEAD ONTO MOTOR BRACKET AU/EU STEP 2� SWING IDLER END INTO BRACKET Ensure idler shafts are correctly installed Page� 06 Wireguide Skylight Installation Manual | November 2018 2018 ©Copyright All Rights Reserved Rollease Acmeda... -
Page 9: Install Spool Cord
STEP 3� ALIGN SPOOL WITH WEIGHT BAR, ENSURE CORD IS STRAIGHT & FIX TO TUBE NOTE: Cord should be perpendicular to weight bar and tube� Page� 07 Wireguide Skylight Installation Manual | November 2018 2018 ©Copyright All Rights Reserved Rollease Acmeda... -
Page 10: Function Check
It is recommended that the Box covers are fixed in place to ensure they can not be accidentally dislodged� HOLE LOCATIONS X4 [3/4"] 20mm [3/8"] 10mm Page� 08 Wireguide Skylight Installation Manual | November 2018 2018 ©Copyright All Rights Reserved Rollease Acmeda DETAIL B SCALE 2 : 1...
