A U TO M AT E | FT M OTOR IN S TR U CTI O NS
D ES C R IPT IO N
AUTOMATE | FT MOTOR is a multifunction tubular motor offering three different modes of operation;
• E-type for standard use,
• MANUAL FT Mode for use with conventional locking devices with fabric tensioning,
• AUTO FT Mode for use with Rollease Acmeda's proprietary ULTRA LOCK providing automatic fabric
tensioning.
Activating fabric tension (FT) mode delivers a choice of 3 distinct tensioning levels to suit a wide range of
sizes and external applications.
Functional options in each operating mode include; IMPACT DETECTION & FAVOURITE POSITION.
Impact detection senses an obstacle in the blinds path and redirects the blind to protect the motor,
hardware and fabric, ensuring product longevity.
An intermediate setting allows for a customised favorite position to be pre-set.
F UN CTIO N S
ELECTRONIC
LIMIT SWITCH
LIMIT SWITCH
TECHNICAL SPECIFICATIONS
Rated Torque
Fabric Tension Torque
Rated speed
RF receiver
Protection class
Rated Voltage
Frequency
Motor Weight
Rated current
Rated power
Motor diameter
Max Running Time
Page. 1 of 12
BRAKE FABRIC
BRAKE M T R
TENSION
15Nm
(Electronically Selectable 5Nm / 10Nm / 15Nm)
15rpm
433.92MHz
IP44
220 - 240V AC
50Hz
1.98Kg
140W
0.61A
45mm
4 min
AUTOMATE | FT MOTOR [Ø45/15Nm/15rpm]
P/N: RB24-6005-069005
FAVORITE
ULTRA-LOCK
EARB
POSITION
IMPACT
DETECTION
