Bardot Electric Fireplace Entertainment Stand
FOLLOW US:
@bellezefurniture
CONTACT INFO:
support@belleze.com
1-800-682-6376
www.belleze.com
ITEM NO. 014-HG-41892
The instruction booklet contains IMPORTANT
safety information. Please read it in full and
keep it for future reference.
Advertisement
Table of Contents
Related Manuals for Belleze Bardot
Summary of Contents for Belleze Bardot
- Page 1 Bardot Electric Fireplace Entertainment Stand FOLLOW US: CONTACT INFO: ITEM NO. 014-HG-41892 The instruction booklet contains IMPORTANT support@belleze.com @bellezefurniture safety information. Please read it in full and 1-800-682-6376 keep it for future reference. www.belleze.com...
- Page 2 Scan this QR Code to view our online tutorial Estimated time for assembly: 90 mins Weight limitations are as follows: Maximum Load 70 lb Maximum Load 30 lb...
- Page 3 Assemble the furniture on an empty carton, carpet, or rug to prevent scratches or damage. For safety, please keep pets and children away from the assembly area. Ensure the product is fully assembled before use. If you are missing any hardware or products, do not use it until you have restored the missing parts.
-
Page 4: Package Contents
PACKAGE CONTENTS... - Page 5 PACKAGE CONTENTS CODE DESCRIPTION Top Panel Bottom Panel Fireplace Extension Panel Side Panel Left Medial Panel Right Medial Panel Center Rear Storage Panel Center Front Storage Panel Side Back Panel Center Back Panel Storage Shelf Panel Cabinet Door v.05102023...
- Page 6 PACKAGE CONTENTS 22x + 2x 22x + 2x 23x + 2x 22x + 2x 24x + 2x Install all hardware perpendicular to the opening.
- Page 7 PACKAGE CONTENTS 16x + 1x 16x + 1x Install all hardware perpendicular to the opening. v.05102023...
- Page 8 Required tools for assembly (Not included) Attach threaded stud bolts to the bottom panel (2).
- Page 9 Insert large wood dowels into the side of the bottom panel (2). v.05102023...
- Page 10 Stick protection pads under the bottom panel (2). Place the bottom panel (2) to its upright position and attach cam bolts.
- Page 11 Insert small wood dowels to the medial panels (5, 6). Attach cam bolts to the medial panels (5, 6). v.05102023...
- Page 12 Attach corner brace joints on the center front storage panel (8). Insert wood dowels to the center front and center rear storage panels (7, 8), then connect the two panels together.
- Page 13 Assemble the center front and center rear storage panels (7, 8) between the left and right medial panels (5, 6). Secure the corner brace joints to the left and right medial panels(5, 6). v.05102023...
- Page 14 Assemble the shelf assemblies on top of the bottom panel (2). Insert wood dowels to the side panels (4).
- Page 15 Assemble side panels (4) on top of the bottom panel (2). v.05102023...
- Page 16 Slide in the side back panels (9) to the back of the assembly. Slide in the center back panel (10).
- Page 17 Attach threaded stud bolts to the top panel (1). Insert wood dowels to the side of the top panel (1). v.05102023...
- Page 18 Attach cam bolts to the underside of the top panel (1).
- Page 19 Assemble the top panel (1) on top of the shelf. v.05102023...
- Page 20 Secure the back panels in place.
- Page 21 Assemble door hinges to the cabinet doors (12). Assemble the door handle to the cabinet doors. v.05102023...
- Page 22 Assemble the cabinet doors to the stand. Adjust the position of the cabinet doors. Up and down In and out Side to side adjustment by adjustment by adjustment using loosening the screws loosening the screws the front adjustment on the mounting on the hinge arm.
- Page 23 Insert shelf pegs inside the stand and put on the storage shelf panels (11). v.05102023...
- Page 24 centered inside the stand. 10mm 12mm...
- Page 25 * Corner Brace and screws are provided in the heater package Screw removed from step 23 v.05102023...
- Page 26 Attach anti-tipping straps behind the stand.
- Page 27 device to prevent the furniture from tipping over. • Mark the drill position on the wall with a pencil. • Drill a small hole on the marked position. • Insert a wall anchor into the drilled hole. • Fixed the anti-tipping strap to the wall with provided screws. YOU’RE FINISHED! v.05102023...
- Page 28 Warning Only place items on top of the product if they meet the recommended size and weight limits. Climbing on, stepping on, or placing overweighted objects on the product may cause property damage and/or injuries. Items placed onto this product must be resting on a support surface without hanging over the edges.
- Page 29 WARNING For use with televisions weighing 70lbs (31.75kg) or less. Use with heavier televisions may result in instability, causing tip over resulting in death or serious injury. Death or serious injury may occur when children climb on audio and/or video equipment furniture. A remote control or toys placed on the furnishing may encourage a child to climb on the furnishing and as a result the furnishing may tip over on to the child.
- Page 30 FURNITURE CARE AND MAINTENANCE Medium - Density Fiberboard Thank you for your purchase. We want your item to last as long as possible. To ensure the product gives you years of longevity, please follow the recommendations in this care and maintenance guide. MAINTENANCE •...
- Page 31 v.05102023...
- Page 33 © All copyright of this document belongs to BELLEZE . This document may not be printed, translated, reproduced, or distributed in whole or in part without written permission from BELLEZE. v.05102023...
-
Page 34: Warranty
WARRANTY BELLEZE products come with a 1-year warranty from the date of delivery. Register your product on our website to enjoy our limited lifetime warranty! AFTER-SALE SERVICE Contact us at 1-800-682-6376 or email us at support@belleze.com We will send you replacement.
