- Page 1 23" Insert Fireplace Heater FOLLOW US: CONTACT INFO: ITEM NO. 050-HA-50323 The instruction booklet contains IMPORTANT support@belleze.com @bellezefurniture safety information. Please read it in full and 1-800-682-6376 keep it for future reference. www.belleze.com...
-
Page 2: Technical Specification
Scan this QR Code to view our online tutorial Estimated time for assembly: 15 mins TECHNICAL SPECIFICATION Model Number 050-HA-50323 Power Rating 1400 W Voltage 120 V Frequency 60 Hz... - Page 3 When using electrical appliances, basic safety precaution should always be followed including the following: READ ALL INSTRUCTION BEFORE USE 1. Read all instructions before using this heater. 2. Do not use this heater outdoors. 3. This heater is not intended for use in bathrooms, laundry areas and similar indoor locations.
- Page 4 ⚠ WARNING There is no user serviceable parts inside the fireplace / heater. If the unit appears to be malfunction, turn off the unit and unplug from the wall outlet immediately, and then contact the customer service. ⚠ WARNING The heater is hot when in use. To avoid burns, do not touch hot surfaces. Keep combustible materials such as furniture, pillows, bedding, papers, clothes, and curtains at least 3 ft (0.9 m) away from the front of the heater, and away from the side or rear of the heater.
- Page 5 Assemble the furniture on an empty carton, carpet, or rug to prevent scratches or damage. For safety, please keep pets and children away from the assembly area. Ensure the product is fully assembled before use. If you are missing any hardware or products, do not use it until you have restored the missing parts.
-
Page 6: Package Contents
PACKAGE CONTENTS... - Page 7 PACKAGE CONTENTS CODE DESCRIPTION Heater Remote Control 4X12mm screw v.11282022...
- Page 8 Set the unit from the back of the fireplace mantel and center it in the opening. Check the alignment and attach the unit to the mantel by inserting screws through the drilled holes on the mantel. NOTE: Do not attempt to install the unit from the front of tha mantel.
-
Page 9: User Instruction
USER INSTRUCTION Before use • Check that the air intake and exhaust is not covered or obstructed in anyway. • Keep combustible objects at least 3 ft (0.9 m) away from the unit. • Plug the unit to a grounded power socket Grounding •... - Page 10 USER INSTRUCTION (CONTROLS) Heater Control Power Button Display Flame Control Timer Control Control Panel The control panel is located on the top right corner of the unit. Power Button Flame Control Heater Control Timer Control Temperature Control Remote Control The operation of the remote control buttons work the same as the button on the control panel. NOTE: The remote control cannot be used to switch between degree Fahrenheit and degree Celsius.
- Page 11 USER INSTRUCTION (CONTROL PANEL) Power ON / OFF Press the power button to turn on the unit. Press again to turn off the unit. NOTE: There is a thermostat limiter inside the unit. When the inner temperature is too hot, the unit will automatically turned off to avoid damage to the product or risk of fire.
- Page 12 USER INSTRUCTION (REMOTE CONTROL) Install / Replace Battery The remote control is provided with 2 AAA batteries. 1. Press and slide off the back cover from the remote control. 2. Insert 2 AAA betteries into the battery compartment and make sure to intall batteries in the correct polarity.
-
Page 13: Troubleshooting
TROUBLE SHOOTING Error Code Possible Cause Solution The heater is overheating Call Customer Service NTC is defective Call Customer Service Make sure the vents are not dirty or clogged. Unplug the power and wait for 5 minutes. Plug in the power again and The heat is not working turn on the heater. - Page 14 FURNITURE CARE AND MAINTENANCE Thank you for your purchase. We want your item to last as long as possible. To ensure the product gives you years of longevity, please follow the recommendations in this care and maintenance guide. CLEANING • Always turn off and unplug the unit from the power outlet before cleaning.
- Page 15 Importer Address: 19301 E Walnut Dr. N., City of Industry, CA 91745 United States Importer Tel: 1-800-682-6376 © All copyright of this document belongs to BELLEZE . This document may not be printed, translated, reproduced, or distributed in whole or in part without written permission from BELLEZE.
-
Page 16: Warranty
WARRANTY BELLEZE products come with a 1-year warranty from the date of delivery. Register your product on our website to enjoy our limited lifetime warranty! AFTER-SALE SERVICE Encounter any difficulties or missing parts? Contact us at 1-800-682-6376 or email us at support@belleze.com We will send you replacement.
