PLANNING AND
OPERATING INSTRUCTIONS
Steam humidifier
Condair Esco
Humidification and Evaporative Cooling

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Esco 5 and is the answer not in the manual?

Questions and answers

Related Manuals for Condair Esco 5

Summary of Contents for Condair Esco 5

  • Page 1 PLANNING AND OPERATING INSTRUCTIONS Steam humidifier Condair Esco Humidification and Evaporative Cooling...
  • Page 2 Liability Condair Group AG is not liable for any damages incurred as a result of poorly executed installation, improper operation or the use of components or equipment not approved by Condair Group AG.

  • Page 3: Table Of Contents

    Contents Introduction First things first! Information about the planning and operating instructions For your safety Product overview General notes on the Condair Esco System description 3.2.1 Condair Esco DL40 overview Esco DR73 overview Esco DR73 J overview How it works...
  • Page 4 Clearances to be maintained around the valve unit 10.2 Dimensional drawings 10.2.1 Dimensional drawings, Condair Esco 5 ductile cast iron 10.2.2 Dimensional drawings, Condair Esco 10 ductile cast iron/stainless steel 10.2.3 Dimensional drawings, Condair Esco 20 ductile cast iron/stainless steel 10.2.4...

  • Page 5: Introduction

    The Condair Esco has been built using state-of-the-art technology and in accordance with the latest safety regulations. However, improper use of the Condair Esco may put users and/or third parties at risk and/or may also cause damage to material assets.
  • Page 6 Keep this documentation in a safe place for further use. If these instructions are lost or if you are unsure whether this documentation is still up to date, please contact your Condair representative. Language versions This documentation is available in various languages. For more information, please contact your Condair representative. Introduction...

  • Page 7: For Your Safety

    Furthermore, for safety and warranty reasons, interventions may only be undertaken by specialist per- sonnel authorised by Condair. It is assumed that all persons entrusted to work on the Condair Esco are familiar with and abide by the regulations on occupational health and safety and accident prevention.
  • Page 8 Do not touch any pipes and components of the Condair Esco pressurized steam humidifier during operation. – Work must not be carried out on the Condair Esco and its components during operation and steam and condensate lines connected to the Condair Esco must not be disconnected. –...

  • Page 9: Product Overview

    Product overview General notes on the Condair Esco Condair Esco pressurized steam humidifiers are ideal for use wherever existing steam from an on-site compressed steam network is available for humidification. The Condair Esco pressurized humidifier takes the steam from an existing steam network and releases it evenly into the air stream without spraying condensate.

  • Page 10: System Description

    System description Each Condair Esco pressurized steam humidifier consists of the following individual components: – Valve unit (made of ductile cast iron or stainless steel) – Actuator (CA150A-MP electric actuator or pneumatic actuator) – Primary steam trap with a screw connection (cast iron or stainless steel) is connected directly to the valve unit.

  • Page 11: Condair Esco Dl40 Overview

    3.2.1 Condair Esco DL40 overview Esco 5 Esco 10 Esco 20 Valve units, ductile cast iron with electric actuator CA150A-MP Valve units, ductile cast iron with pneumatic actuator Valve units, stainless steel with CA150A-MP electric actuator Valve units, stainless steel...
  • Page 12 Esco 5 Esco 10 Esco 20 Collector for two DL40 steam pipes for vertical air ducts/ventilation units Collector for three DL40 steam pipes for vertical ducts/ventilation units Primary steam traps Thermostatic steam trap Ball float steam trap Inverted bucket steam trap...
  • Page 13 Example: System overview Condair Esco 10 ductile cast iron with DL40 double collector Double collector Steam connection flange Pressure gauge Steam pipes Secondary steam trap (Thermostatic steam trap, brass) Valve unit Esco 10, ductile cast iron Primary steam trap (ball float steam trap, ductile cast iron) CA150A-MP actuator Fig.
  • Page 14 (Thermostatic steam trap, brass) Valve unit Esco 10, ductile cast iron Primary steam trap (ball float steam trap, ductile cast iron) Fig. 2: Installation overview Condair Esco 10 ductile cast iron with DL40 double collector Product overview 1110513-C EN 2207...

  • Page 15: Esco Dr73 Overview

    Esco DR73 overview Esco 10 Esco 20 Esco 30 Valve units, ductile cast iron with electric actuator CA150A-MP >20 kg >20 kg Valve units, ductile cast iron with pneumatic actuator >20 kg >20 kg Valve units, stainless steel with electric actuator CA150A-MP Valve units, stainless steel with pneumatic actuator...
  • Page 16 Esco 10 Esco 20 Esco 30 DR73 collector, A type DR73 collector, B type Primary steam traps Ball float steam trap Inverted bucket steam trap Ball float steam trap, stain- less steel Inverted bucket steam trap, stainless steel Secondary steam traps Thermostatic steam trap Thermostatic steam trap, stainless steel...
  • Page 17 Example: System overview Condair Esco 10 stainless steel with DR73 A type Steam pipes Steam connection flange A type collector Pressure gauge Secondary steam trap (Thermostatic steam trap, stainless steel) Valve unit Esco 10, stainless steel Primary steam trap (Stainless steel ball float steam trap) CA150A-MP actuator Fig.
  • Page 18 Secondary steam trap (Thermostatic steam trap, stainless steel) Valve unit Esco 10, stainless steel Primary steam trap (Stainless steel ball float steam trap) Fig. 4: Installation overview Condair Esco 10 stainless steel with DR73 A type Product overview 1110513-C EN 2207...

  • Page 19: Esco Dr73 J Overview

    Esco DR73 J overview Esco 20 Esco 30 Valve units, ductile cast iron with electric actuator CA150A-MP >20 kg >20 kg Valve units, ductile cast iron with pneumatic actuator >20 kg >20 kg Valve unit, stainless steel with electric actuator CA150A-MP Valve unit, stainless steel with pneumatic actuator...
  • Page 20 Esco 20 Esco 30 DR73 JA collector, left DR73 JA collector, right DR73 J2A collector, left/right DR73 J2A collector, right/ middle Product overview 1110513-C EN 2207...
  • Page 21 Esco 20 Esco 30 DR73 J2A collector, left/ middle Primary steam traps Ball float steam trap Inverted bucket steam trap Ball float steam trap, stainless steel Inverted bucket steam trap, stainless steel Secondary steam traps Thermostatic steam trap Ball float steam trap Thermostatic steam trap, stainless steel Ball float steam trap,...
  • Page 22 Example: System overview Condair Esco 30 ductile cast iron with DR73 J2A left/right Steam pipes Steam connection flange Pressure DR73 J2A collector, left/right gauge Valve unit Esco 30, ductile cast iron Secondary steam trap (Ball float steam trap ductile cast iron)
  • Page 23 Primary steam trap (ball float steam trap ductile cast iron) Secondary steam trap (ball float steam trap ductile cast iron) CA150A-MP actuator Fig. 6: Installation overview Condair Esco 30 ductile cast iron with DR73 J2A left/right 1110513-C EN 2207 Product overview...

  • Page 24: How It Works

    The steam within the system when the ceramic rotary valve is closed is drained via the primary-side steam trap. This means that the Condair Esco is always ready for operation. However, the steam dis- tributor remains cold and does not heat the air flow.

  • Page 25: Identification (Rating Plate)

    Identification (rating plate) The rating plate is located on the right or left side of the heat deflector plate of the actuator adapter. The designation of the valve unit has also been labelled: – For ductile cast iron valves on the rear of the steam connection flange –...
  • Page 26 Field with test marks Model and version of steam distributor Permissible saturated steam temperature Protection type Fig. 8: Example: rating plate of a Condair Esco with CA150A-MP electric actuator Production (month/year) Serial number (7 digits) Manufacturer Type designation (humidifier/valve size/model) Condair Group AG, Gwattstrasse 17, 8808 Pfäffikon SZ, Switzerland...

  • Page 27: Scope Of Delivery

    Extension pipe sections for secondary steam traps for DR73 JA and J2A types Storage and transport Storage Condair Esco components must be stored in their original packaging in a protected location under the following conditions: – Room temperature: 5 to 40°C –...

  • Page 28: Components

    Components 3.9.1 Valve unit (or also steam connection unit) Steam connection The valve unit is connected to the steam supply line from above using a DIN standard flange or a 1/2" threaded connection on the Esco-5. Strainer (for ductile cast iron valve units only) The strainer is located inside the valve units and it is positioned at a 90 degree angle to the steam supply line.
  • Page 29 Strainer Fixed disk Rotary disk Steam separator Fig. 10: Ductile cast iron control valve (Fig. shows Esco 10 ductile cast iron) Fixed disk Rotary disk Steam separator Fig. 11: Stainless steel control valve (fig. shows Esco 10 stainless steel) The control valve characteristic is linear from the opening point of the valve over the entire control range, which simplifies the regulation of the steam capacity compared to equal percentage or proportional characteristic curves.
  • Page 30 Steam trap on valve unit (primary Thermostatic cap- Ball float or inverted bucket steam trap steam trap) sule steam trap Actuator Electric (Condair CA150A-MP) or pneumatic (Sauter AK41) Direction of rotation Valve opens clockwise Pressure gauge option Mounting set option Flange plate option...
  • Page 31 0.50 0.45 0.40 0.35 0.30 0.25 0.20 6 7 8 9 10 40 50 60 70 80 Steam capacity in kg/h Fig. 12: Esco 5 valve unit selection chart Valve size 4.00 3.00 2.00 1.50 1.00 0.80 0.70 0.60 0.50 0.45...
  • Page 32 Valve size 4.00 3.00 2.00 1.50 1.00 0.90 0.80 0.70 0.60 0.50 0.45 0.40 0.35 0.30 0.25 0.20 Steam capacity in kg/h Fig. 14: Esco 20 valve unit selection chart Valve size 4.00 3.00 2.00 1.50 1.00 0.90 0.80 0.70 0.60 0.50 0.45...

  • Page 33: Actuators

    3.9.2 Actuators The Condair Esco pressurized steam humidifier is equipped with an electric Condair rotary actuator. If required, a pneumatic actuator is also available ex works. Adapters for the assembly of third-party actuators are available. When using third-party actuators the responsibility for the correct functionality of the actuator/valve unit combination lies with the customer.
  • Page 34 5 to 50 °C Permissible maximum ambient humidity 80%, non-condensing Weight 2 kg Condair Esco 10 ductile cast iron with CA150A-MP Condair Esco 10 stainless steel with CA150A-MP electric actuator electric actuator Fig. 16: CA150A-MP actuator Valve characteristic, Esco valves with CA150A-MP actuator Control voltage VDC 0°...

  • Page 35: Pneumatic Actuator

    IP20 Permissible ambient temperature 5 to 50 °C Number of cylinders Esco 5 and 10: 1 cylinder Esco 20 and 30: 2 cylinders Cylinder installation position Horizontal Note: With one cylinder, the installation position can also be rotated by 90° clockwise (cylinder upwards).
  • Page 36 Condair Esco 10, ductile cast iron with Sauter AK41 pneumatic actuator and Sauter XSP31 positioner Pneumatic cylinder Positioner Condair Esco 20, stainless steel with Sauter AK41 pneumatic actuator and Sauter XSP31 positioner Pneumatic cylinder Positioner Fig. 18: Sauter AK41 pneumatic actuator and Sauter XSP31 positioner Please refer to the additional installation instructions for the pneumatic actuator.

  • Page 37: Steam Traps

    – The standard steam trap is the "ball float" model because it has proven to work best in practice. Exception: The Condair Esco-5 uses the thermostatic capsule steam trap as standard. 1110513-C EN 2207 Product overview...
  • Page 38 Please follow the following instructions when handling the steam traps: – None of the steam traps used operate below freezing point. They must therefore be protected against frost so that cooled condensate does not freeze. – Inverted bucket steam traps must not be used in systems with superheated steam, since superheated steam removes the condensate resevoir and the inverted bucket can thus blow through (continuous steam discharge at the steam trap).
  • Page 39 How the ball float steam trap works The ball float steam trap is a mechanical trap that works with the buoyancy force of the condensate. If there is air in the steam, the saturated steam temperature is not reached at the corresponding pres- sure and the thermal bleed element (1) opens (see left).
  • Page 40 The thermostatic capsule steam trap is open at temperatures below the saturated steam temperature and therefore also at ambient temperature. Thermostatic capsule steam traps used in Condair Esco open when the condensate cools down (relative to the saturated steam temperature): –...

  • Page 41: Steam Distributor

    3.9.4 Steam distributor 3.9.4.1 Esco DL40 steam distributor General information – Main applications: – Smaller ducts/ventilation units – Vertical ducts/ventilation units – Concept: Combination of standard parts (steam pipe(s) and collectors) Steam flow: – – Via the valve unit into the steam pipe with one steam pipe –...
  • Page 42 DL40 steam distributor overview Valve unit suitable for Esco DL40 Esco-5 Esco-10 Esco-10 Esco-20 Esco-20 ductile cast ductile cast stainless steel ductile cast stainless steel iron iron iron Number of steam pipes 1 to 3 1 to 3 Secondary steam trap for steam pipes Thermostatic capsule steam trap Secondary steam trap connections Rp 1/2"...
  • Page 43 Max. permissible steam capacity [mm] [kg/h] 5/023 275-424 5/038 425-524 5/048 525-624 5/058 625-724 ø41 mm for connection to: 5/068 725-924 Esco 5 ductile cast iron 5/088 925-1224 5/118 1225-1524 5/148 1525-1824 5/178 1825-2124 10/023 250-399 10/038 400-499 10/048 500-599...
  • Page 44 Single piping With single piping, the steam pipe is pushed directly from the inside of the duct/ventilation unit through the duct wall into the flange of the valve unit. Installation takes place in the centre of the duct/ventilation unit height. 1 / 2 1 / 2 Fig.
  • Page 45 Overview of collectors for DL40 Steam pipe distance 200, 250, 300, 600, 900 (see dimension "B" in Fig. Square tube cross-section Square 60 x 60 mm max. 116 kg/h (see dimension "C" in Fig. Square 80 x 80 mm max. 211 kg/h Square 100 x 100 mm max.

  • Page 46: Esco Steam Distributor Dr73

    3.9.5 Esco steam distributor DR73 General information – Main application: – Larger horizontal ducts/ventilation units (>1.5 m – Concept: – Custom-manufactured steam distribution system determined on the basis of the available space, the air volume flow rate, the steam output, the air velocity and the air temperature. –...
  • Page 47 (for collectors 100x100 mm and 80x80 mm) and 120x120 mm) Fig. 26: Collector supports The Condair Esco DR73 system is compatible with various installation types, which have been described in more detail below. Installation type/versions Type A/type JA Type B...
  • Page 48 Overview of DR73 collectors DR73 A up to 487 kg/h DR73 B up to 487 kg/h Overview of DR73 J collectors DR73 JA 488 up to 1000 kg/h Note: In order to reduce the steam velocity in the collector, the steam feed for the valve unit has been attached to the side for JA models.
  • Page 49 DR73 J2A from 1000 to 2000 kg/h In order to reduce the steam velocity in the collector, at least one steam feed is attached to the side of the J2A models. As a result, the steam flow is divided, which reduces the steam velocity. The follow- ing feed variants are possible.
  • Page 50 For special cases where the valve unit must be located inside the ventilation unit, e.g. outdoor systems, there is the option for collectors that have the valve connection on the side of the collector. These ver- sions are only possible if there is sufficient space. For more information, contact your Condair partner. DR73, inside, left...
  • Page 51 Dimensioning of the DR73 steam distributor In addition to the required steam output, the air velocity in the duct is an important parameter for dimen- sioning the DR73 steam distributors. The air velocity determines the wall distance from the outermost steam pipes and the permissible steam capacity per metre of steam pipe.

  • Page 52: Options

    3.10 Options Pressure gauge Use: For all valve units except Esco-5 Pressure gauge for installation on the valve unit in two versions: – Pressure gauge 0 to 2.5 bar for steam overpressure up to 1.5 bar – Pressure gauge 0 to 6.0 bar for steam overpressure up to 4.0 bar Accuracy class: 1.6 Material housing: Sheet steel or stainless steel Connection: G 1/4"...
  • Page 53 Strainer G 1/2" - G 1/2" Use: For installation in the steam supply line of Esco 5 ductile cast iron. Option: 90° adapter valve unit DL40 DR73 Use: For DR73 or DL40 single piping.
  • Page 54 Collector spud (DR73 wall support) Use: For DR73 steam distribution system (except B, JB and J2B type) This telescopic support to the duct/ventilation unit inner wall is used to support a DR73 steam distribution system without the need to drill holes or screw into the drain pan.
  • Page 55 Adapter for CA150A-MP Use: For all valve units If an Esco valve unit without mounted CA150A-MP actuator is required, the adapter must be ordered as an option in order to be able to attach the CA150A-MP actua- tor to the valve unit. Adapter for Siemens GCA 161.1 or Sauter ASF123 Use: For all valve units...

  • Page 56: Planning

    All steam boilers that enable flawless steam extraction from a sufficiently large steam space are suitable. The additional steam extraction for humidification with the Condair Esco must be taken into account. If the steam boiler is too small, water may be carried along with the steam extraction for humidification.

  • Page 57: Steam Types And Requirements

    Esco valve unit. This process is also known as erosion. Abrasion marks on the ceramic disc openings usually indicate steam that is too wet. Saturated steam Saturated steam has a non-evaporated water content of <2 % and is suitable for use with the Condair Esco. Superheated steam If heat is added to the saturated steam, superheated steam is produced.

  • Page 58: Steam Quality

    – Plant steam This steam is not suitable for humidification. There is also high wear on the Condair Esco system due to particles or additives in the steam. The steam lines are usually made of carbon steel or grey cast iron pipes.

  • Page 59: Ventilation Duct/Unit Requirements

    Ventilation duct/unit requirements Ventilation duct/ventilation unit design In principle, the Condair Esco pressurized steam humidifier releases the steam into the duct air without dripping. However, overfeeding the steam generator, a blocked secondary steam trap or the defect of a regulator or control valve is sufficient to supply water or a condensate/steam mixture to the steam distributor.
  • Page 60 Pan drain Pan with slope Inspection door Condair Esco pressurized steam humidifier Fig. 28: Duct/DR73 ventilation unit/distance to upstream and downstream obstacles Planning 1110513-C EN 2207...
  • Page 61 "fog zone" or "absorption distance") is the area downstream of the steam pipes in which incompletely evaporated water droplets would condense on obstacles. Your Condair partner will be happy to calculate the required humidification distance for you on request, taking into account obstacles such as filters or submicron filters.
  • Page 62 If it is necessary to install the Condair Esco pressurized steam humidifier outdoors, the entire system must be accommodated in a protective housing (provided on site) that protects the system and the lines to the system against the following environmental influences: –...

  • Page 63: Requirement For The Control Of The Actuators

    Requirement for the control of the actuators The requirements listed below for the control of the actuators only serve as a basis. In any case, contact the relevant local regulatory specialists for detailed information. WARNING! Even with external actuators, only use actuators with a return function (e.g. spring return) so that they close automatically when the high limit humidistat / air flow monitor is triggered.

  • Page 64: Pressurized Steam Network

    The responsibility for a correctly created and maintained steam network is the responsibility of the op- erator. Condair does not offer components for steam networks nor does it design steam networks. The design, construction and maintenance of steam networks must be carried out by a steam specialist.
  • Page 65 Steam supply line dimension The steam supply line connected to the Esco valve unit must be dimensioned so that the steam velocity does not exceed 25 m/s. DANGER! System damage and personal injury due to water hammer Excessive steam velocity increases the risk of water hammer. This can cause serious damage to the system or endanger persons.
  • Page 66 Note: If, due to the permissible steam velocity, a larger nominal diameter than the diameter on the flange of the valve unit must be used, the steam supply line must be extended immediately after the flange. Extension Fig. 37: Expansion of the steam supply line Insulation of steam lines To avoid condensation of the steam on the pipe wall, all steam lines within the steam system must be insulated in accordance with the applicable regulations.
  • Page 67 Drainage must be implemented using a drip leg. This must not too narrow. The drip leg must also have the same nominal diameter up to and including a DN100 steam line, be approx. 700 mm long and not protrude into the steam line. Fig.
  • Page 68 Air vent and drainage at the end of the steam line The steam line must be drained at the end of the pipe and vented at the top! Air vent Drainage (see specifi- cations in Fig. Fig. 41: Air vent and drainage at steam line end Routing the steam line •...
  • Page 69 • Ascending and descending steam lines must always be drained at the lowest point. Shut-off valve Shut-off valve Steam trap Steam trap Steam flow direction Steam flow direction Blowdown valve Blowdown valve Fig. 44: Ascending and descending steam lines • Steam lines for bypassing obstacles must always be drained at the lowest point.
  • Page 70 Condair Esco valve unit. A shut-off valve (provided on site) must be installed in the steam supply line upstream of the Condair Esco valve unit. The additional installation of a steam pressure gauge is recommended.

  • Page 71: Condensate Drain

    Condensate drain Condensate drain line requirements DANGER! Equipment and personal injury due to water and steam hammer Improperly implemented condensate drain lines can cause water and steam hammer during operation. This can lead to serious damage to the system or endanger persons. For this reason: To avoid water and steam hammer during operation, all condensate drain lines must have been correctly installed in accordance with the following specifications.
  • Page 72 Examples of correctly installed condensate drain lines Type 2: Type 1: Recirculation of primary condensate into the Primary and secondary condensate dis- steam boiler, secondary condensate discharged charged into an open drain funnel into an open drain funnel Condensate drain Condensate drain lines at lines at min.
  • Page 73 Not permitted: Condensate discharged into a shared line not permitted. Primary steam trap Secondary steam trap Fig. 49: Condensate drainage not carried out correctly Not permitted: Group drainage is not permitted. Each condensate line requires its own steam trap. Primary steam trap Secondary steam trap Fig.
  • Page 74 Flash steam (post-evaporation) When draining the pipe system with steam traps, flash steam (post-evaporation) can occur at the end of the condensate line, which is characterised by continuously escaping steam. The cause of this flash steam is the adaptation of the condensate to the external pressure and the large gradient between the condensate temperature and the room temperature.

  • Page 75: Selecting The Condair Esco System

    Selecting the Condair Esco system Required system data In order for your Condair partner to be able to determine the applicable Condair Esco system, the fol- lowing information is required: Duct dimensions Width (internal dimension) mm _________________ Height (internal dimension)

  • Page 76: Commissioning And Operation

    4.0 bar. Pressure must correspond to the designed steam pressure. 8. Actuators Check and ensure that the actuators are connected in accordance with the instructions in the Condair Esco installation manual. If the actuator has been properly connected, trigger steam output at the steam manifolds with a demand signal.

  • Page 77: Operation

    10. Spring return at actuator Disconnect the supply voltage or the supply pressure from the actuator. The drop in supply pressure must immediately mechanically close via the return spring. Note: If an external actuator without spring return is unexpectedly used, this reset must be ensured by additional components.

  • Page 78: Adjusting The Angle Of Rotation

    6.2.1.2 Adjusting the angle of rotation WARNING! During adjustment of the angle of rotation, the valve unit opens fully and, if steam pressure applies, humidification will start. If this is not desired, the steam supply to the valve unit must be shut off and depressurized.

  • Page 79: Maintenance

    Maintenance Regular maintenance The Esco pressurized steam humidifier does not feature parts that must be replaced regularly. It is therefore considered "maintenance-free". Nevertheless, it is advisable to carry out the following visual and functional checks regularly: Component When Check valve unit for leaks Once a month Check the following sealing points: –...

  • Page 80: Check The Strainer And Replace It, If Necessary (For Ductile Cast Iron Valve Unit Only)

    Check the strainer and replace it, if necessary (for ductile cast iron valve unit only) Important: The strainer may only be removed by a Condair service technician. 1. Shut off the steam supply to the valve unit and secure it against unintentional opening.
  • Page 81 – Pneumatic actuator: • Loosen the screw and remove cover plate "A". • Mark attachment point "C" and the protrusion of the spring strut "D" well using a pen. Remove screw "E" and remove spring "B". • Loosen 4 screws "F" and remove cover "G". •...
  • Page 82 7. Fit the strainer cover with a new seal. 8. Turn shaft counterclockwise up to the stop. Important: There is no stop on the Esco 5. In this case, the Allen screw on the coupling piece must be in a vertical position before the actuator is mounted.

  • Page 83: Troubleshooting

    Troubleshooting WARNING! The following inspection and corrective measures for troubleshooting may only be carried out by a Condair service technician or a service technician authorised by Condair. Fault Possible causes/errors Test/remedy No steam escap- High limit humidistat permanently • Reduce moisture on high limit...
  • Page 84 Fault Possible causes/errors Test/remedy Condensate sprays out Steam boiler dimension too small • Correct steam dimensioning. of the steam nozzles (water is carried along). Thermostatic secondary steam trap • Install the thermostatic second- installed incorrectly (direction of flow). ary steam trap according to the installation instructions (observe flow direction).
  • Page 85 Fault Possible causes/errors Test/remedy No steam pressure at On-site shut-off valve in the steam • Open shut-off valve valve unit supply line closed • Check actuation to shut-off valve and correct, if necessary. Obstruction in the steam supply line • Check that there is no obstruc- (e.g.

  • Page 86: Technical Data

    Technical data Esco DL40 Esco DL40 / DR73 Esco DR73 Range Technical data Unit Esco 5 Esco 10 DL 10 stainless Esco 20 DL 20 stainless Esco 30 Ductile cast iron Ductile cast iron steel Ductile cast iron steel Ductile cast iron...
  • Page 87 Esco DL40 Esco DL40 / DR73 Esco DR73 Range Technical data Unit Esco 5 Esco 10 DL 10 stainless Esco 20 DL 20 stainless Esco 30 Ductile cast iron Ductile cast iron steel Ductile cast iron steel Ductile cast iron...

  • Page 88: Appendix

    Appendix 10.1 Clearances to be maintained around the valve unit Dimensions in mm in mm Fig. 56: Clearances to be maintained around the valve unit Appendix 1110513-C EN 2207...

  • Page 89: Dimensional Drawings

    10.2 Dimensional drawings Note on dimensional drawings: In practice, all dimensions marked with "≈" may differ slightly due to conically threaded connections or deviating hose routing. 10.2.1 Dimensional drawings, Condair Esco 5 ductile cast iron SIDE VIEW SIDE VIEW 276.5 144.5...

  • Page 90: Dimensional Drawings, Condair Esco 10 Ductile Cast Iron/Stainless Steel

    10.2.2 Dimensional drawings, Condair Esco 10 ductile cast iron/stainless steel SIDE VIEW SIDE VIEW 295.5 295.5 Rp 1/2" Rp 1/2" TOP VIEW TOP VIEW DN32/PN16 DN32/PN16 Dimensions in mm Fig. 59: Dimensional drawing, Esco 10 ductile Fig. 60: Dimensional drawing, Esco 10 ductile...
  • Page 91 SIDE VIEW SIDE VIEW ø 140 ø 140 Rp 1/2" Rp 1/2" TOP VIEW TOP VIEW DN32/PN16 DN32/PN16 Dimensions in mm Fig. 61: Dimensional drawing, Esco 10 stain- Fig. 62: Dimensional drawing, Esco 10 stainless less steel with ball float steam trap with steel with inverted bucket steam trap CA150A-MP electric actuator with CA150A-MP electric actuator...
  • Page 92 SIDE VIEW SIDE VIEW 424.5 295.5 295.5 Rp 1/2" Rp 1/2" TOP VIEW TOP VIEW 385.5 385.5 DN32/PN16 DN32/PN16 Dimensions in mm Fig. 63: Dimensional drawing, Esco 10 ductile Fig. 64: Dimensional drawing, Esco 10 ductile cast iron with ball float steam trap with cast iron with inverted bucket steam Sauter AK41 pneumatic actuator trap with Sauter AK41 pneumatic actua-...
  • Page 93 SIDE VIEW SIDE VIEW 409.5 409.5 144.5 144.5 ø 140 ø 140 Rp 1/2" Rp 1/2" TOP VIEW TOP VIEW 370.5 370.5 DN32/PN16 DN32/PN16 Dimensions in mm Fig. 65: Dimensional drawing, Esco 10 stain- Fig. 66: Dimensional drawing, Esco 10 stainless less steel with ball float steam trap with steel with inverted bucket steam trap Sauter AK41 pneumatic actuator...

  • Page 94: Dimensional Drawings, Condair Esco 20 Ductile Cast Iron/Stainless Steel

    10.2.3 Dimensional drawings, Condair Esco 20 ductile cast iron/stainless steel SIDE VIEW SIDE VIEW Rp 1/2" Rp 1/2" TOP VIEW TOP VIEW DN50/PN16 DN50/PN16 Dimensions in mm Fig. 67: Dimensional drawing Esco 20 ductile cast Fig. 68: Dimensional drawing Esco 20 ductile...
  • Page 95 SIDE VIEW SIDE VIEW 502.5 502.5 354.5 354.5 ø 165 ø 165 Rp 1/2" Rp 1/2" TOP VIEW TOP VIEW DN50/PN16 DN50/PN16 Dimensions in mm Fig. 69: Dimensional drawing Esco 20 stainless steel Fig. 70: Dimensional drawing Esco 20 stainless steel with ball float steam trap with electric actua- with inverted bucket steam trap with electric tor CA150A-MP...
  • Page 96 SIDE VIEW SIDE VIEW 514.5 514.5 Rp 1/2" Rp 1/2" TOP VIEW TOP VIEW 475.5 475.5 DN50/PN16 DN50/PN16 Dimensions in mm Fig. 71: Dimensional drawing Esco 20 ductile cast Fig. 72: Dimensional drawing Esco 20 ductile cast iron with ball float steam trap with pneumatic iron with inverted bucket steam trap with actuator Sauter AK41 pneumatic actuator Sauter AK41...
  • Page 97 SIDE VIEW SIDE VIEW 154.5 354.5 154.5 354.5 ø 165 ø 165 Rp 1/2" Rp 1/2" TOP VIEW TOP VIEW DN50/PN16 DN50/PN16 Dimensions in mm Fig. 73: Dimensional drawing Esco 20 stainless steel Fig. 74: Dimensional drawing Esco 20 stainless steel with ball float steam trap with Sauter AK41 with inverted bucket steam trap with pneu- pneumatic actuator...

  • Page 98: Dimensional Drawings Condair Esco 30 Ductile Cast Iron

    10.2.4 Dimensional drawings Condair Esco 30 ductile cast iron SIDE VIEW 491.5 Rp 1/2" TOP VIEW DN80/PN16 Dimensions in mm Fig. 75: Dimensional drawing Esco 30 ductile cast iron with ball float steam trap with electric actua- tor CA150A-MP Appendix...
  • Page 99 SIDE VIEW 491.5 Rp 1/2" TOP VIEW DN80/PN16 Dimensions in mm Fig. 76: Dimensional drawing Esco 30 ductile cast iron with inverted bucket steam trap with electric actuator CA150A-MP 1110513-C EN 2207 Appendix...
  • Page 100 SIDE VIEW 621.5 491.5 Rp 1/2" TOP VIEW 582.5 DN80/PN16 Dimensions in mm Fig. 77: Dimensional drawing Esco 30 ductile cast iron with ball float steam trap with pneumatic actuator Sauter AK41 Appendix 1110513-C EN 2207...
  • Page 101 SIDE VIEW 621.5 491.5 Rp 1/2" TOP VIEW 582.5 DN80/PN16 Dimensions in mm Fig. 78: Dimensional drawing Esco 30 ductile cast iron with inverted bucket steam trap with pneu- matic actuator Sauter AK41 1110513-C EN 2207 Appendix...

  • Page 102: Dimensional Drawings, Condair Dl40 Double And Triple Collector

    10.2.5 Dimensional drawings, Condair DL40 double and triple collector Dimensional drawings of valve units, Section 10.2.1 Section 10.2.4 SIDE VIEW SIDE VIEW TOP VIEW TOP VIEW Esco 10 Esco 10 Esco 20 Esco 20 ductile cast iron stainless steel ductile cast iron...
  • Page 103 Dimensional drawings of valve units, Section 10.2.1 Section 10.2.4 SIDE VIEW SIDE VIEW TOP VIEW TOP VIEW Esco 10, ductile cast iron Esco 20, ductile cast iron Actuator CA150A-MP electric actuator ø45 mm 200 mm / 250 mm / 300 mm / 600 mm / 900 mm 60 mm / 80 mm / 100 mm 80 mm / 100 mm / 120 mm 75 mm...
  • Page 104 Dimensional drawings of valve units, see to Section 10.2.1 Section 10.2.4 SIDE VIEW SIDE VIEW TOP VIEW TOP VIEW Esco 10 Esco 10 Esco 20 Esco 20 ductile cast iron stainless steel ductile cast iron stainless steel CA150A-MP electric actuator CA150A-MP electric actuator Actuator Sauter AK41 pneumatic actuator...
  • Page 105 Dimensional drawings of valve units, Section 10.2.1 see to Section 10.2.4 SIDE VIEW SIDE VIEW TOP VIEW TOP VIEW Esco 10 Esco 10 Esco 20 Esco 20 ductile cast iron stainless steel ductile cast iron stainless steel Actuator CA150A-MP electric actuatoror Sauter AK41 pneumatic actuator ø45 mm ø65 mm 200 mm / 250 mm / 300 mm / 600 mm / 900 mm...
  • Page 106 Notes...
  • Page 108 CONSULTING, SALES AND SERVICE: CH94/0002.00 Condair Group AG Gwattstrasse 17, 8808 Pfäffikon SZ, Switzerland Phone +41 55 416 61 11, Fax +41 55 588 00 07 info@condair.com, www.condairgroup.com...
