4−05 Litho in U.S.A. (ebk)
JAR ASSEMBLY PARTS
For Models: KCB348PGR0
1
Illus.
Part
No.
No.
DESCRIPTION
1
Literature Parts
8204583 Use & Care Guide
8204597 Repair Parts List
8204596 Label, Warning
2
4176896 Ingredient Cap
3
4176895 Lid, Plastic
4
8211661 Jar, Plastic
5
8211454 Blade Assembly
7
4176894 O Ring (2)
8
4176886 Nut, Retainer
Part No. 8204597
Commercial
Bar Blender

Advertisement

loading

  Summary of Contents for KitchenAid KCB348PGR - Pro Line

  • Page 1 JAR ASSEMBLY PARTS Commercial Bar Blender For Models: KCB348PGR0 Illus. Part DESCRIPTION Literature Parts 8204583 Use & Care Guide 8204597 Repair Parts List 8204596 Label, Warning 4176896 Ingredient Cap 4176895 Lid, Plastic 8211661 Jar, Plastic 8211454 Blade Assembly 4176894 O Ring (2) 4176886 Nut, Retainer Part No.
  • Page 2 DESCRIPTION 4176868 Coupler, Lower 8211662 Housing 8211461 Power Cord 4176873 Seal, Motor 4176874 Motor 4176875 Screw, 10 x 16 4176876 Base 4176877 Screw, 10 x 16 4176878 Screw, 8 x 3/8 4176879 Pedestal Foot 4176880 Cover, Base 8211663 Sensor, Hall...
  • Page 3 4176861 Seal, Escutcheon 4176860 Escutcheon 4176859 Switch, On/Off 4176858 Bezel, Switch 4176883 Mount, Main PCB 4176882 Main PCB 4176897 Nut, Plastic 4176881 Screw, Plastic 4176875 Screw, PCB Mount 4176877 Screw 10 x 16 4176871 EMC Mount 4176872 EMC−PC Board 8204597...
