MTI300 MODULAR
UPS
20-600kW
3 Phase In-3 Phase Out
USER MANUAL
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MTI300 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Tescom MTI300

Summary of Contents for Tescom MTI300

  • Page 1 MTI300 MODULAR 20-600kW 3 Phase In-3 Phase Out USER MANUAL...

  • Page 4: Table Of Contents

    Contents Preface............................... 7 Usage............................7 Users ............................7 Note ............................7 Safety Precautions ..........................8 Safety Message Definition ......................8 Warning Label ........................... 8 Safety Instruction ........................8 Debug & Operate ........................9 Maintenance & Replacement ....................9 Battery Safety .......................... 10 Disposal and Recycling ......................
  • Page 5 2.7 Control and Communication Cables ................. 36 2.7.1 Dry Contact Interface ..................... 37 2.7.2 Communication Interface ..................44 3 UPS and Module Control Panel ....................45 LCD panel for Power Module ................. 45 3.1.1 LED Indicator ......................45 3.1.2 Control and Operation Keys ................... 46 3.1.3 LCD Display ......................
  • Page 6 işareti Declaration of Safety Conformity and CE markingHata! tanımlanmamış. 6.2 Environmental Characteristics ..................87 6.3 Mechanical Characteristics ....................88 6.4 Electrical Characteristics ....................88 6.4.1 Electrical Characteristics (Input Rectifier) ............. 88 6.4.2 Electrical Characteristics (Intermediate DC Link) ..........88 6.4.3 Electrical Characteristics (Inverter Output) ............89 6.4.4 Electrical Characteristics (Bypass Mains Input) ............

  • Page 7: Preface

    Preface Usage The manual contains information on installation, use, operation and maintenance of modular UPS. Please carefully read this manual prior to installation. Users Authorized Person Note Our company is providing a full range of technical support and service. Customers can contact our local office or customer service center for help.

  • Page 8: Safety Precautions

    Safety Precautions This manual contains information concerning the installation and operation of modular UPS. Please carefully read this manual prior to installation. The modular UPS cannot be put into operation until it is commissioned by engineers approved by the manufacturer (or its agent). Not doing so could result in personnel safety risk, equipment malfunction and invalidation of warranty.

  • Page 9: Debug & Operate

     When the system is running , do not touch the surface with this label, to avoid any hurt of scald.  ESD sensitive components inside the UPS, anti-ESD measure should be taken before handling. Move & Installation  Keep the equipment away from heat source or air outlets. ...

  • Page 10: Battery Safety

    voltages are present within the battery box. However, the risk of contact with these high voltages is minimized for non-service personnel. Since the component with dangerous voltage can only be touched by opening the protective cover with a tool, the possibility of touching high voltage component is minimized.

  • Page 11: Disposal And Recycling

     The batteries are very heavy. Please handle and lift the battery with proper method to prevent any human injury or damage to the battery terminal.  Don’t decompose, modify or damage the battery. Otherwise, battery short circuit, leakage or even human injury may be caused.

  • Page 12: Ups Structure And Introduction

    1 UPS Structure and Introduction 1.1 UPS structure 1.1.1 UPS Configuration The UPS configurations are provided in Table 1-1. Table 1-1 UPS Configuration Item Component Quantity/PCS Remark Manual Bypass Requisite, installed in the factory Bypass & Monitoring Requisite, installed in the factory module 6-slot Cabinet Dust filter...
  • Page 13 (a) The outlook of 6-slot UPS cabinet...
  • Page 14 (b) The outlook of 10-slot UPS cabinet (c) The outlook of 20-slot UPS cabinet Figure 1-1 UPS Outlook...

  • Page 15: Details Of Ups Front View

    1.1.3 Details of UPS front view The UPS front views are shown as figure 1-2. ① LCD control panel; ② SPD (optional); ③ Manual Bypass switch ④ Battery cold start; ⑤ Monitoring &static bypass module (a) Front view of 6-slot UPS...
  • Page 16 ①LCD control panel; ② SPD; ③Manual Bypass switch ④Battery cold start; ⑤ Monitoring &static bypass module (b) Front view of 10-slot UPS ① LCD control panel; ② SPD; ③ Manual Bypass switch ④ Battery cold start; ⑤ Monitoring &static bypass module; ⑥ Monitoring unit of 20-slot cabinet;...

  • Page 17: Details Of Ups Back Views

    ⑦ Static Bypass unit; ⑧ Output switch of 20-slot cabinet Q3; ⑨Input switch of 20-slot cabinet Q1 (c) Front view of 20-slot UPS Figure 1-2 Front view of UPS 1.1.4 Details of UPS back views The UPS front views are shown as figure 1-3. ①...
  • Page 18 ① PDU (b) Back View of 10-slot UPS ① PDU; ②Bypass Input switch of 20-slot cabinet Q3;...

  • Page 19: Product Introduction

    ③ Manual bypass switch of 20-slot cabinet Q3 (c) Back View of 20-slot UPS Figure 1-3 Back View of UPS 1.2 Product Introduction 1.2.1 UPS System Description The modular UPS is configured by the following parts: Power modules, Bypass & Monitoring module, and the cabinet with Bypass switch.

  • Page 20: Power Module Description

    1.2.2 Power Module Description The power module structure is shown as Figure 1-6.The power module contains a rectifier, an inverter, and one DC charger. Figure 1-6 Power Module Block Diagram 1.2.3 Operation Mode The modular UPS is an on-line, double-conversion UPS that permits operation in the following modes: ⚫...
  • Page 21 load. After restoration of the AC mains input power, UPS will transfer automatically to normal mode without users’ intervention. Figure 1-8 Battery Mode operation diagram Note: With the function of “Battery Cold Start”, the UPS could start without utility. 1.2.3.3 Bypass Mode If the inverter overload capacity is exceeded under normal mode, or if the inverter becomes unavailable for any reason, the static switch will perform a transfer of the load from the inverter to the bypass source, without interruption to critical AC load.
  • Page 22 Figure 1-10 Maintenance mode operation diagram Danger During Maintenance mode, dangerous voltages are present on the terminal of input, output and neutral, even with all the modules and the LCD turned off. 1.2.3.5 ECO Mode To improve system efficiency, UPS system works in Bypass Mode at normal time, and the inverter is standby, when the utility from the bypass fails, the UPS will transfer to Battery Mode and the inverter powers the load.

  • Page 23: Location

    2 Installation 2.1 Location As each site has itself requirements, the installation instructions in this section are as a guide for the general procedures and practices that should be observed by the installing engineer. 2.1.1 Installation Environment The UPS is intended for indoor installation and uses forced convection cooling by internal fans. Please make sure there is enough space for the UPS ventilation and cooling.
  • Page 24 cabinet, at least 1 m for the 20-slot cabinet, so as to easily maintain the power module with the front door fully open; at least 0.5m at behind of 6-slot or the 10-slot cabinet, at least 0.6 m for 20-slot cabinet for ventilation and cooling. The space reserved for the cabinet is shown in Figure 2-1.

  • Page 25: Unloading And Unpacking

    2.2 Unloading and Unpacking 2.2.1 Moving and Unpacking of the Cabinet The steps to move and unpack the cabinet are as follows: 1) Check if any damages to the packing. (If any, please contact the carrier) 2) Transport the equipment to the designated site by forklift, as shown in Figure 2-2. Figure 2-2 Transport to the designated site 3) Open the top plate of the steel-edged wooden case with the awl and the hammer, followed by side boards (see Figure 2-3).

  • Page 26: Unpacking Power Modules

    Figure 2-4 remove the protective foam 5) Check the UPS, visually examine if there are any damages to UPS during transportation. If any damages, please contact the carrier. Check the UPS with the list of the goods. If any items are not included in the list, please contact our company or the local office.

  • Page 27: Positioning

    Figure 2-7 remove the foam cover 4) Take out the UPS with plastic package and dismantle the packing materials. Attention The waste materials of unpacking should be disposed to meet the demand for environmental protection. 2.3 Positioning 2.3.1 Positioning Cabinet The UPS cabinet has two ways of supporting itself.

  • Page 28: Installing Anti-Seismic Kits (Optional)

    (b) 20-slot cabinet (Bottom view, unit: mm) ①Adjustable anchor bolt ② L-shape corner fittings ③ supporting wheels Figure 2-8 Supporting structure (Bottom View) The steps of position the cabinet are as follows: 1) Ensure the supporting structure is in good condition and the mounting floor is smooth and strong.
  • Page 29 Figure 2-9 Anti-seismic Kits and mounting holes (Top view) Figure 2-10 the effect drawing of Anti-seismic Kits 3) Use a hammer drill to drill holes in the mounting hole marks, and then install the 10 M10 expansion bolts into the holes. Figure 2-11 shows an expansion bolt. 4) Move the cabinet which has anti-seismic kits to the installation position.

  • Page 30: Installing Power Module

    (1) Bolts (2) Spring washer (3) Flat washer (4) Expansion sleeve Channel steel installation 1) According to requires mounting holes dimensions at the cabinet base, the channel steel spacing is 702mm or more, the holes spacing is 652mm. The channel steel width is 50mm or more. Determine the position for installing the cabinet on the channel steel.

  • Page 31: Battery

    2.4 Battery Three terminals (positive, neutral, negative) are drawn from the battery group and connected to UPS system. The neutral line is draw from the middle of the batteries in series (See Figure 2-13) Figure 2-13 Battery string wiring diagram Danger The battery terminal voltage is of more than 400Vdc, please follow the safety instructions to avoid electric shock hazard.
  • Page 32 Figure 2-15 Top entry for 10-slot cabinet Front view Rear view Bottom entry Top entry Figure 2-16 Cabinet entry for 20-slot cabinet...

  • Page 33: Power Cables

    2.6 Power Cables 2.6.1 Specifications The UPS power cables are recommended in Table 2-2. Table 2-2 Recommended sizes for power cables Contents 150/25 180/30 250/25 300/30 500/25 600/30 2*95 2*95 2*240 2*240 Cable 2*95 2*95 2*240 2*240 Main Input (mm²) 2*95 2*95 2*240...

  • Page 34: Circuit Breaker

    Bypass Input Cables crimped 15Nm Battery Cables crimped 15Nm OT terminal Output Cables crimped 15Nm OT terminal Cables crimped 15Nm OT terminal Main Input Cables crimped 13mm 22Nm OT terminal Bypass Input Cables crimped 13mm 22Nm OT terminal 10-slot cabinet Battery Cables crimped 13mm...
  • Page 35 battery terminal and protective earth terminal are shown in Figure 2-17, Figure 2-18 and Figure 2-19. Figure 2-17 6-slot connections terminals (separate bypass input is optional) Figure 2-18 10-slot connections terminals (separate bypass input is optional) Figure 2-19 20-slot connections terminals...

  • Page 36: Control And Communication Cables

    3) Connect the protective earth wire to protective earth terminal (PE). 4) Connect the AC input supply cables to the main input terminal and AC output supply cables to the output terminal. 5) Connect the battery cables to the battery terminal. 6) Check to ensure there is no mistake and re-install all the protective covers.

  • Page 37: Dry Contact Interface

    Figure 2-21 Dry contact &communication interface for 20-slot cabinet The UPS can accept the external dry contact signal and send out the dry contact signal, through the phoenix terminal ports. The cables connected to the dry contact terminals must be separated from power cables.
  • Page 38 Input dry contact , the function is settable , J5-2 GEN_CONNECTED Default: interface for the generator J5-3 GND_DRY Ground for +24V Output dry contact, the function is settable. J6-1 BCB Drive Default: Battery trip signal Input dry contact, the function is settable. J6-2 BCB_Status Default: BCB Status (Alarm no battery if BCB...
  • Page 39 BCB Status BCB status, closed or open Transfer Inverter UPS would transfer to the inverter mode BCB Online Enable the BCB status checking Transfer Bypass UPS would transfer to the bypass mode Fault Clear Recheck the fault or alarm information Battery Over Charge Batteries are over charged Battery Over Discharge...
  • Page 40 Table 2-8 Description of J2 and J3 Port Name Function J2-1 TEMP_BAT Detection of battery temperature J2-2 TEMP_COM common terminal J3-1 ENV_TEMP Detection of environmental temperature J3-2 TEMP_COM common terminal Note A specified temperature sensor is required for temperature detection, and it’s optional, please confirm with the manufacturer or the local agency before the order.
  • Page 41 Figure 2-24 Diagram of input port for generator input Table 2-10 Description of input port for generator input Port Name Function J5-1 +24V_DRY +24V J5-2 GEN_CONNECTED Connection status of generator J5-3 GND_DRY Power ground for +24V BCB Input Port The default functions of J6 and J7 are the ports for BCB tripping and BCB status, connect J6-1 and J7-1 to BCB tripper, the port J6-1 can provide a driver signal (+24VDC, 20mA) to trip the battery breaker when EPO is triggered or EOD (end of discharge) happen.
  • Page 42 Note In default setting, when a circuit breaker with auxiliary contacts is used, connect J6-2 and J7-1 to auxiliary contacts terminals to get the status of the BCB, this function must be enabled by shorting J7-1 and J7-2. Battery Warning Output Dry Contact Interface The default function of J8 is the output dry contact interface for battery voltage low alarm, when the battery voltage is lower than the setting value, an auxiliary dry contact signal will be activated via the relay, before UPS alarms “Battery voltage low”, J8-1 and J8-3 are connected by the relay,...
  • Page 43 Figure 2-27 General alarm dry contact interface diagram Table 2-13 General alarm dry contact interface description Port Name Function Integrated warning relay (normally closed) will be J9-1 GENERAL_ALARM_NC open during warning Integrated warning relay (normally open) will be J9-2 GENERAL_ALARM_NO closed during warning J9-3 GENERAL_ALARM_GND...

  • Page 44: Communication Interface

    2.7.2 Communication Interface RS232, RS485 and USB ports can provide series data which can be used for commissioning and maintenance by authorized engineers or can be used for networking or integrated monitoring system in the service room. SNMP is used on site for communication (Optional). Intelligent card interface is used for extension dry contact interface (Optional).

  • Page 45: Ups And Module Control Panel

    3 UPS and Module Control Panel LCD panel for Power Module The structure of LCD panel for power module is shown in Figure 3-1. 1: Status indicator 2: LCD Display 3: OFF Key 4: FUNC Key Figure 3-1 Control and display panel for power module The operator control panel is divided into three functional areas: Status indicator, control and operation keys and LCD display.

  • Page 46: Control And Operation Keys

    3.1.2 Control and Operation Keys The control and operation keys include FUNC keys and OFF key that have different functions: a) The FUNC key is used for turning the display pages; b) The OFF key is mainly for turning off the power module, as the following procedures: 1) Enable: LCD panel→Menu Operate →Enable Module “OFF”...
  • Page 47 ● highlighted: Fault and warning codes are shown in Digit Displays Area in recycle (shown with short dash when less than 3). The meanings of the codes are listed in Table3-2. ● flashing: Indicating a fault occurs. ● Energy bar of a) Flashing: Rectifier soft start;...

  • Page 48: Ups Operator Panel

    Battery maintenance fail Data CAN fail Rectifier fail Power share fail Inverter fail Inverter bridge open Rectifier over temperature Temperature difference over limit Fan fail Input current unbalanced Output overload DC bus over voltage Output overload time out Rectifier soft start fail Inverter over temperature Relay open UPS inverter Inhibited...
  • Page 49 Indicator State Description indicator Flashing Rectifier normal for at least one module, mains normal green Steady red Rectifier fault Flashing red Mains abnormal for at least one module Rectifier not operating Steady green Battery charging Flashing Battery discharging green Battery Battery abnormal (battery failure, no battery or battery reversed) indicator Steady red...

  • Page 50: Control And Operation Keys

    3.2.2 Control and Operation Keys Control and operation keys include four keys of 2, 10, 11, and 12, which are used together with LCD touch screen. The function description is shown in Table 3-5. Table 3-5 Functions of control and operation keys Function Key Description Long press，...

  • Page 51: Main Menu

    ● Warning Information Display the warning information of the cabinet. ● Information Display Users can check the information of the cabinet in this area. The bypass voltage, main input voltage, battery voltage, and output voltages are presented in the form of gauge. The loads are displayed in the form of bar chart in percentage.
  • Page 52 Figure 3-6 Cabinet menu The Cabinet menu comprises sectors of title, information display and version running status, information display and submenu. The sectors are described as follows. ● Title Display the information of the selected submenu. ● Running status The squares shown on the mimic current represent the various UPS power paths and show the current UPS operating status.
  • Page 53 (b) Interface of Output (c) Interface of Load (d) Interface of Battery Figure 3-7 Submenu interface of Cabinet...

  • Page 54: Module Menu

    The submenu of Cabinet is described in details below in Table 3-6. Table 3-6 Description of each submenu of Cabinet Submenu Name Contents Meaning Phase voltage Phase current Main Input frequency Power factor Phase voltage Phase current Bypass Bypass frequency Power factor Phase voltage Phase current...
  • Page 55 Figure 3-8 Module menu The Module comprises sectors of title, information display, power module information, version information and submenu. The sectors are described as follows. ● Title Present the title of submenu of the selected power module. ● Information display Display information of each submenu.
  • Page 56 (a) Interface of Output (b) Interface of Load (c) Interface of Information...
  • Page 57 (d) Interface of S-Code Figure 3-9 Module menu The submenus of Module are described below in details in Table 3-7. Table 3-7 Description of each submenu of Module Submenu Name Contents Meaning Input phase voltage of selected module Input phase current of selected module Input Input frequency of selected module Input power factor of selected module...

  • Page 58: Setting

    3.3.3 Setting Touch the icon (At the bottom of the screen), and the system enters the page of the Setting, as is shown in Figure 3-10. Figure 3-10 Setting menu The submenus are listed on the right side of the Setting page. Users can enter each of the setting interfaces by touching the relevant icon.
  • Page 59 3.3.3.2 Language Setting Users can select the language from the three kinds of languages, please note the group only contains 3 kinds of languages, if users need other language combinations; please inform the factory in advance. The setting interface is shown in Figure 3-12 below. Figure 3-12 the setting interface of LANGUAGE 3.3.3.3 Communication Protocol Setting The UPS provides the communication ports RS232 and RS485, and users also configure the...
  • Page 60 3.3.3.4 User Setting Users can adjust the output voltage above or below the rated voltage, the minimum scale is 1 voltage. And users also can set the range of the voltage and the frequency of the bypass. The setting interface is shown in Figure 3-14 below. Figure 3-14 the setting interface of USER 3.3.3.5 Battery Setting The setting of battery needs to be done after the first time of powering off or any changes done on...
  • Page 61 should be 80% or 85% rated capacity when it’s configured with 32 or 34 blocks of batteries. 2) Setting of battery number for LFPB For the cell of each LFPB, the cell voltage is 3.2V; each battery block consists of 1 cell. In total, if 40 blocks of Lead-Acid batteries are used, for the LFPB, the number will be 150.
  • Page 62 Figure 3-15 EOD voltage For Lead-Acid battery, the cell voltage is suggested to set to 1.65V/cell at 0.6C, and set to 1.75V/cell at 0/15C. For the LFPB battery, the cell voltage is suggested to set 2.7 V/cell at both 0.6C and 0.15C. ●...
  • Page 63 charge time has passed. The setting range can be 1-48 hours. ● Auto boost period This is for setting the auto boost period time. When the setting time is up, the system boost charges the batteries. It is suggested to boost charge the battery every three months, and set the period to 4320 hours.
  • Page 64 3.3.3.6 Service Setting Users can select the system mode. If it’s a parallel system, users can configure the parallel parameters. Users can also set the redundant module number and the delay time from battery to utility. The setting interface is shown in Figure 3-17. Figure 3-17 the setting interface of SERVICE The submenus are described in details below in Table 3-9.
  • Page 65 Submenu Name Contents Meaning Limited settable:-10%，-15%，-20%，-30%，-40% Permitted working Frequency for Bypass Bypass Frequency Limited Settable：+-1Hz，+-3Hz，+-5Hz Dust Filter Maintenance Setting Dust Filter Maintenance Period Period Battery Number Setting the number of the battery（12V） Battery Capacity Setting of the AH of the battery Setting the floating Voltage for battery cell Float Charge Voltage/Cell （2V）...

  • Page 66: Log Menu

    Warning ⚫ Ensure the number of the battery, set via the menu or the monitoring software, is completely equal to the real installed number. Otherwise it may cause serious damage to the batteries or the equipment. 3.3.4 Log menu Touch the icon , (At the bottom of the screen), and the system enters the interface of the Log, as it is shown in Figure 3-12.
  • Page 67 Table 3-9 the list for events UPS events Description Fault Clear Manually clear fault Log Clear Manually clear History log Load On UPS Inverter feeds load Load On Bypass Bypass feeds load No Load No load Battery Boost Charger is working in boost charging mode Battery Float Charger is working in float charging mode Battery Discharge...
  • Page 68 bypass fans fail. Bypass Module Over Bypass current is over the limitation. If bypass current is under Load 135% of the rated current. The UPS alarms but has no action. Bypass Over Load The bypass overload status continues and the overload times out. Tout This alarm is triggered by an inverter software routine when the frequency of bypass voltage exceeds the limit.
  • Page 69 temperature of the rectifier IGBTs is too high to keep rectifier running. This alarm is triggered by the signal from the temperature monitoring device mounted in the rectifier IGBTs. The UPS recovers automatically after the over temperature signal disappears. If over temperature exists, check: 1.
  • Page 70 Whether the power module’s capacity is big enough for load. Whether the rectifier is ready. Whether the bypass voltage is normal. Manual Transfer Byp Transfer to bypass manually Escape from “transfer to bypass manually” command. If UPS has Esc Manual Bypass been transferred to bypass manually, this command enable UPS to transfer to inverter.
  • Page 71 IO signal communication of inverter CAN bus is abnormal. Please INV IO CAN Fail check if communication cables are not connected correctly. INV DATA CAN DATA communication of inverter CAN bus is abnormal. Please Fail check if communication cables are not connected correctly. The difference of two or more power modules’...
  • Page 72 UPS works in intelligent sleep mode. In this mode, the power modules will be standby in turn. It will be more reliability and higher efficiency. It must be confirmed that remained power modules’ capacity is big enough to feed load. It must be conformed Intelligent Sleep that working modules’...

  • Page 73: Operate Menu

    If connector or signal cable is abnormal. If monitoring board is abnormal. Firmware Error Manufacturer used only. System Setting Error Manufacturer used only. Bypass module is over temperature. Please check If bypass load is overload If ambient temperature is over 40°C Bypass Over Temp.
  • Page 74 Clear/Restore Buzzing Mute or Restore buzzing of the system by touching the icon Fault Clear Clear the faults by touching the icon Transfer to and ESC Bypass Transfer to bypass mode or cancel this command by touching the icon Transfer to Inverter Transfer the bypass mode to Inverter Mode by touching the icon Enable Module”...

  • Page 75: Scope Menu

    By touching the icon , the system stops battery test or battery maintenance. 3.3.6 Scope menu Touch the icon , (at the bottom right of the screen), and the system enters the page of the Scope, as it is shown in Figure 3-14. Figure 3-14 Scope menu Users can view the waves for output voltage, output current and bypass voltage by touching the corresponding icon in the left side of the interface.

  • Page 76: Operations

    4 Operations 4.1 UPS Start-up 4.1.1 Startup in normal mode The UPS must be started up by commissioning engineer after the completeness of installation. The steps below must be followed: 1) Ensure all the external circuit breakers are open. 2) Close the input external circuit breakers, and the system starts initializing. If the system has dual inputs, please close both of the breakers.

  • Page 77: Start From Battery

    Table 4-4 Normal mode Indicator Status Indicator Status Rectifier green Inverter green Battery green Load green Bypass Status green 8) The startup has finished, users can close the external main output breaker, and then close the branch breakers one by one. Note ⚫...

  • Page 78: Procedure For Switching Between Operation Modes

    Figure 4-2 the position of the battery cold start button for 20-slot cabinet 3) After about 30 second, the “BAT” indicator turns steady green, the “INV” indicator starts green flashing, and then after 30 seconds it turns steady green and the “OUTPUT” indicator turns green from off.

  • Page 79: Switching The Ups Into Normal Mode From Bypass Mode

    Figure 4-3 enabling the switch Warning Ensure the bypass is working normally before transferring to bypass mode. Or it may cause failure. 4.2.3 Switching the UPS into normal mode from bypass mode Two ways to transfer the UPS into normal mode from bypass mode: 1) Enter the menu “Operate”, touch the icon “transfer to inverter”...

  • Page 80: Switching The Ups Into Normal Mode From Maintenance Bypass Mode

    3) Pull out the bypass module (for 6-slot and 10-slot cabinet), and dismantle monitoring, static bypass unit (for 20-slot cabinet) and the load is powered through maintenance bypass. Warning Before making this operation, please read messages on LCD display to ensure that bypass supply is regular and the inverter is synchronous with it, so as not to risk a short interruption in powering the load.
  • Page 81 Figure 4-4 Battery maintenance 2) Auto discharging. The system can be set to discharge automatically per a certain time. The setting procedures are as follows. a) Enable “battery auto discharge”. Enter the “CONFIGURE” page of the setting menu, tick “Battery Auto Discharge” and confirm (this needs to be done by factory). b) Setting the period for “battery auto discharge”.

  • Page 82: Epo

    4.4 EPO The EPO button located in the operator control and display panel (with cover to avoid the misoperation, see Figure 4-6) is designed to switch off the UPS in emergency conditions (e.g. fire, flood, etc.) To achieve this , just press the EPO button, and the system will turn off the rectifier, the inverter and stop powering the load immediately (including the inverter and the bypass), and the batteries stop charging or discharging.

  • Page 83: Maintenance

    5 Maintenance This chapter introduces UPS maintenance, including the maintenance instructions of power module and monitoring bypass module and the replacement method of dust filter. 5.1 Precautions Only maintaining engineers can maintain the power module and monitoring bypass module. 1) The power module should be disassembled from top to bottom, so as to prevent any inclination from high gravity center of the cabinet.

  • Page 84: Maintaining Static Bypass Unit For 20-Slot Cabinet

    1) Transfer the system to bypass module through the LCD control panel (refer to chapter 3.4.5). 2) Open the battery switch, close manual bypass switch; the UPS power will be supplied by manual bypass. 3) Pull out the bypass module and the load is powered through manual bypass. 4) Remove the mounting screw on the two front sides of the bypass module (see Figure 2-11) and the front signal cable connected to the bypass module.

  • Page 85: Maintenance For The Air-Drawing Fans For 20-Slot Cabinet

    5.3.3 Maintenance for the air-drawing fans for 20-slot cabinet 1) Take out the fan unit panel. 2) Push the button of the fans to turn off the fans. 3) Change the fans. 4) Push the button to turn on the fans again. 5) Install the fan panel.

  • Page 86: Replacing Dust Filter (Optional)

    Figure 5-1 the position of inner control neutral cable 5.4 Replacing dust filter (optional) As shown in Figure 5-2, there are 3-4 dust filters on the back of the front door of the UPS, ach filter is held in place by a bracket on either side of each filter. The procedure of replacing each filter is as follows: 1) Open the front door and locate the filters on the back side of the front door.

  • Page 87: Product Specifications

    6 Product Specifications This chapter provides the specifications of the product, including environment characteristics mechanical characteristics and electrical characteristics. 6.1 Applicable Standards The UPS has been designed to conform to the following European and international standards: Table 6-1 Compliance with European and International Standards Item Normative reference General safety requirements for UPS used...

  • Page 88: Mechanical Characteristics

    6.3 Mechanical Characteristics Table 6-3 Mechanical Characteristics for Cabinet Item Unit 6-slot Cabinet 10-slot Cabinet 20-slot Cabinet Mechanical Dimension 600*1100*1600 600*1100*2000 2000*1050*2000 (W*D*H) Weight Color RAL7021 Black Protection Level IP20 Table 6-4 Mechanical Characteristics for Power Module Item Unit Power Module Mechanical Dimension ，...

  • Page 89: Electrical Characteristics (Inverter Output)

    2.25V/cell(selectable from 2.2V/cell ～ 2.35V/cell) V/cell Float charge voltage （ VRLA ） Constant current and constant voltage charge mode Boost 2.3V/cell(selectable from : 2.30V/cell~2.45V/cell) V/cell （ VRLA ） charge voltage Constant current and constant voltage charge mode Temperature mV/℃/cl 3.0(selectable:0~-5.0) compensation 1.65V/cell(selectable from:...

  • Page 90: Efficiency

    6.5 Efficiency Table 6-9 Efficiency System Efficiency ％ 95 (max) Normal mode(dual conversion) Battery discharging efficiency (battery at nominal voltage 480Vdc and full-rated linear load) ％ 95 (max) battery mode 6.6 Display and Interface Table 6-10 Display and Interface Display LED + LCD +Color touch screen Standard:RS232, RS485, USB, Dry Contact Interface...

  • Page 91: Annex. A Instructions Of The Parallel System For Modular Ups

    Annex. A Instructions of the parallel system for modular UPS The UPS of 6-slot or10-slot can be paralleled; the general is 2 UPSs in parallel or 3 UPSs in parallel. The UPS of 20-slot cabinet don’t support the parallel, and the 10-cabinet can be paralleled with 3 UPSs at most;...
  • Page 92 The cable connection drawing for 2UPSs in parallel (common input) Note: IS1 and IS2 are the input switches for each UPS, OS1 and OS2 are the output switches, OS is the output main switch of the power system, MBS is the maintenance bypass switch, and all the switched mentioned above need to be provided by users, the UPS has only one manual rotation bypass switch (the manual bypass switch).
  • Page 93 MS1, MS2 and MS3 are the main input switches for each UPS, BS1, BS2 and BS3 are the bypass input switches, OS1, OS2 and OS3 are the output switches, OS is the output main switch of the power system, MBS is the maintenance bypass switch, and all the switched mentioned above need to be provided by users, the UPS has only one manual rotation bypass switch (the manual bypass switch).
  • Page 94 2) To set the parallel board as below The setting for 2 UPSs in parallel Note: J3, J5, J7, J9, J11 and J4 are short-circuited by the jumpers; J6, J8, J10, J12, J13, J14, J15 and J16 are open.
  • Page 95 The setting for 3 UPSs in parallel Note: only J3 and J4 are short-circuited by the jumpers, the other pins are open. 3) To set the parameters on the display screen As long as the display screen is lit, users can set the parallel parameters on the screen. a) To choose the system mode: Parallel.
  • Page 96 4) To check the parameters on the display screen and ensure the parameters are same for each UPS below, if no special requirement, please keep the parameters in the default setting. The setting interface for USER Setting 5) To check the nameplate of each UPS and ensure the model, the rated voltage and the rated frequency same.
  • Page 97 7) To connect the parallel signal cables. The parallel signal cable a) When 2 UPSs in parallel, please operate as below. The signal cable connection for 2 UPSs in parallel b) When 3 UPSs in parallel, please operate as below. The signal cable connection for 3 UPSs in parallel 3.
  • Page 98 Note: Before the operation, please keep all the switches off. 1) First close OS1, and then close BS1 and MS1, the first UPS will start automatically, for the details of start, please refer to the user manual. About 2 minutes later, the first UPS will complete the start and final close the battery switch used with the first UPS.
  • Page 99 The operation interface for transferring to bypass The operation interface for escaping bypass 6) Close the main output switch OS, the system is completed, users can start their equipment one by one. 4. The operations for the parallel system 1) Shut down the UPS. When UPSs in parallel, and if users want to shut down one UPS or all UPSs, there take the parallel system of 3 UPSs with dual input for example, please operate as below.
  • Page 100 First turn off the battery switch used with the first UPS, and then turn off BS1 and MS1 one by one, and finally turn off OS1, the first UPS will be off. If recover, please first turn on OS1, and then turn on BS1 and MS1 one by one and finally turn on the battery switch.
  • Page 101 c) Turn on BS1, BS2 and BS3 one by one, about 20 seconds later, confirm the static bypass of each UPS should be on. d) Turn off the maintenance bypass switch MSB e) Turn on MS1, MS2 and MS3. About 30 seconds later, the rectifiers of all modules should be on. f) Turn on all the battery switches one by one.
  • Page 103 : +90 (232) 833 36 00 pbx : +90 (232) 833 37 87 ATHENS / GREECE OFFICE ADDRESS : Tescom Hellas S.A. 7th Volou Str. 18346, Moschato ATHENS / GREECE PHONE : +30 21095 90 910 : +30 21095 90 080 www.tescom-ups.gr...
