  • Page 2 promaster 2015 User Guide If you are the first registered retail owner of your vehicle, you may obtain a complimentary printed copy of the Owner’s Manual, Navigation/Uconnect ® Manuals or Warranty Booklet by calling 1-866-726-4636 (U.S.) or 1-800-387-1143 (Canada) or by contacting your dealer. IMPORTANT This User Guide is intended to familiarize you with the important features of your vehicle.

  • Page 3: Table Of Contents

    T A B L E O F C O N T E N T S INTRODUCTION/WELCOME ADDING FUEL ....68 DIESEL EXHAUST FLUID ..69 WELCOME FROM CHRYSLER GROUP LLC .

  • Page 4: Introduction/Welcome

    I N T R O D U C T I O N / W E L C O M E WELCOME FROM CHRYSLER GROUP LLC Congratulations on selecting your new Chrysler Group LLC vehicle. Be assured that it represents precision workmanship, distinctive styling, and high quality - all essen- tials that are traditional to our vehicles.
  • Page 5 I N T R O D U C T I O N / W E L C O M E VEHICLES SOLD IN CANADA With respect to any vehicles sold in Canada, the name Chrysler Group LLC shall be deemed to be deleted and the name Chrysler Canada Inc. used in substitution (excluding legal lines).

  • Page 6: Controls At A Glance

    C O N T R O L S A T A G L A N C E DRIVER COCKPIT 1. Power Mirrors 2. Headlight Switch pg. 24 3. Instrument Cluster/Electronic Vehicle Information Center (EVIC) Display pg. 6 4. Wiper/Washer pg. 27 5.
  • Page 7 C O N T R O L S A T A G L A N C E 12. Power Outlet pg. 55 13. USB Port (Charging Only) 14. Switch Panel • Front Fog Lights • Electronic Stability Control (ESC) OFF pg. 77 •...

  • Page 8: Instrument Cluster

    C O N T R O L S A T A G L A N C E INSTRUMENT CLUSTER 1. Speedometer 2. Turn Signal Lights 3. Electronic Vehicle Information Center (EVIC) 4. Fuel Gauge (See page 72 for Instrument Cluster Indicator Lights.)
  • Page 9 C O N T R O L S A T A G L A N C E 5. Turn Signal Lights 6. Tachometer 7. Temperature Gauge (See page 76 for Instrument Cluster Indicator Lights.)

  • Page 10: Getting Started

    G E T T I N G S T A R T E D KEY FOB Locking And Unlocking The Doors • Push the LOCK button once to lock all the doors. • Push the UNLOCK button once to un- lock the driver’s door only and twice within five seconds to unlock the pas- senger door.

  • Page 11: Supplemental Restraint System (Srs) - Air Bags

    G E T T I N G S T A R T E D Seat Belt Pretensioner • The front seat belt system is equipped with pretensioning devices that are designed to remove slack from the seat belt in the event of a collision. •...
  • Page 12 G E T T I N G S T A R T E D Advanced Front Air Bags • This vehicle has Advanced Front Air Bags for both the driver and front passenger as a supplement to the seat belt restraint systems. The Advanced Front Air Bags will not deploy in every type of collision.
  • Page 13 G E T T I N G S T A R T E D NOTE: If the speedometer, tachometer, or any engine related gauges are not working, the Occupant Restraint Controller (ORC) may also be disabled. In this condition the air bags may not be ready to inflate for your protection.

  • Page 14: Child Restraints

    G E T T I N G S T A R T E D WARNING! • Side Air Bags need room to inflate. Do not lean against the door or window. Sit upright in the center of the seat. • Being too close to the Side Air Bags during deployment could cause you to be severely injured or killed.
  • Page 15 G E T T I N G S T A R T E D Installing Child Restraints In Commercial Vehicles This commercial vehicle is not designed for use as a family vehicle and is not intended for carrying children in the front passenger seat(s). Never install rearward- facing child restraints in this vehicle.

  • Page 16: Head Restraints

    G E T T I N G S T A R T E D WARNING! • In a collision, an unrestrained child, even a tiny baby, can become a projectile inside the vehicle. The force required to hold even an infant on your lap could become so great that you could not hold the child, no matter how strong you are.

  • Page 17: Front Seats

    G E T T I N G S T A R T E D FRONT SEATS Forward/Rearward The forward/rearward adjusting bar is lo- cated at the front of the seat near the floor. • Lift up on the adjusting bar and re- lease it when the seat is at the desired position.
  • Page 18 G E T T I N G S T A R T E D Height Adjustment — Without Swivel Seat The height adjusting levers are located on the center outboard side of the seat. • Lift up on the front lever to adjust the front of the seat up or down.
  • Page 19 G E T T I N G S T A R T E D Recliner — Without Swivel Seat The recliner knob is located on the rear outboard side of the seat. • To recline the seatback, lean back, rotate the recliner knob rearward to position the seatback as desired.
  • Page 20 G E T T I N G S T A R T E D Air Seat Adjustment The seat is equipped with a mechanical spring system and hydraulic shock ab- sorber to ensure maximum comfort and safety. The system of springs also effec- tively absorbs impact from uneven road surfaces.
  • Page 21 G E T T I N G S T A R T E D Armrest Height Adjustment The height adjusting rotating knob is lo- cated underneath the front of the drivers and passengers armrest. • Rotate the knob to adjust the armrest up or down.

  • Page 22: Heated Seats

    G E T T I N G S T A R T E D HEATED SEATS Front Heated Seats The controls for the front heated seats are located on the lower outboard side of the seat. • Press the switch once to turn on the heated seats.

  • Page 23: Telescoping Steering Column

    G E T T I N G S T A R T E D TELESCOPING STEERING COLUMN The telescoping control handle is located below the steering wheel at the end of the steering column. • To unlock the steering column, pull the control handle up.

  • Page 24: Operating Your Vehicle

    O P E R A T I N G Y O U R V E H I C L E ENGINE BREAK-IN RECOMMENDATIONS A long break-in period is not required for the engine and drivetrain (transmission and axle) in your vehicle. Drive moderately during the first 300 miles (500 km).

  • Page 25: Manual Climate Controls

    O P E R A T I N G Y O U R V E H I C L E MANUAL CLIMATE CONTROLS Manual Climate Controls 1 — Rotate Blower Control 4 — Push A/C Button 2 — Push Air Recirculation Button 5 —...

  • Page 26: Turn Signals/Headlights/High Beams Lever

    O P E R A T I N G Y O U R V E H I C L E TURN SIGNALS/HEADLIGHTS/HIGH BEAMS LEVER Turn Signal Headlight Lever 1 — High Beams 2 — Headlights 3 — Turn Signals Turn Signals/Lane Change Assist •...

  • Page 27: Interior Lights

    O P E R A T I N G Y O U R V E H I C L E INTERIOR LIGHTS Map/Dome Lights These lights are mounted between the sun visors on the overhead console. Each light is turned on by pressing the corre- sponding switch.
  • Page 28 O P E R A T I N G Y O U R V E H I C L E Dimmer Controls The dimmer controls are located on the left side of the instrument panel below the instrument cluster. • Press and release the UP button to increase the brightness of the instru- ment panel lights.

  • Page 29: Wiper/Washer Lever

    O P E R A T I N G Y O U R V E H I C L E WIPER/WASHER LEVER Wiper Washer Lever 1 — Mist 2 — Intermittent, Low And High 3 — Washer The Wiper/Washer Lever is located on the right side of the steering column. Front Wipers Intermittent, Low And High Operation •...

  • Page 30: Electronic Speed Control

    O P E R A T I N G Y O U R V E H I C L E ELECTRONIC SPEED CONTROL Electronic Speed Control Lever 1 — Set/Accel 2 — On/Off 3 — Resume 4 — Decel The Electronic Speed Control lever is located on the left side of the steering column. Cruise ON/OFF •...
  • Page 31 O P E R A T I N G Y O U R V E H I C L E The speed increment shown is dependant on the speed of U.S. (mph) or Metric (km/h) units: U.S. Speed (mph) • Tapping the Speed Control lever up (+) once will result in a 1 mph increase in set speed.

  • Page 32: Parksense® Rear Park Assist

    O P E R A T I N G Y O U R V E H I C L E Cancel • A soft tap on the brake pedal, pushing the RES button, or normal brake pressure while slowing the vehicle will deactivate the Speed Control without erasing the set speed memory.

  • Page 33: Parkview® Rear Back-Up Camera

    O P E R A T I N G Y O U R V E H I C L E PARKVIEW® REAR BACK-UP CAMERA You can see an on-screen image of the rear of your vehicle whenever the shift lever is put into REVERSE.

  • Page 34: Electronics

    E L E C T R O N I C S YOUR VEHICLE'S SOUND SYSTEM 1. Steering Wheel Audio Controls (Left) pg. 53 2. Uconnect ® Phone Mute Button 3. Uconnect Phone Button pg. 43 ® 4. Steering Wheel Audio Controls (Right) pg. 53 5.
  • Page 35 E L E C T R O N I C S 9. Eject Button pg. 38 10. CD Slot pg. 41 11. Uconnect ® Radio pg. 38 12. SETTINGS Button 13. Tune/Scroll Knob/Browse/Enter Button 14. Front Power Outlet/Cigar Lighter pg. 55 15.

  • Page 36: Identifying Your Radio

    E L E C T R O N I C S IDENTIFYING YOUR RADIO Uconnect® RH3 • Single Din Mono-Chromatic • Manual Three-Knob Climate Control Uconnect® RH3 Uconnect® 5.0 • 5.0” Full Color Touchscreen Display • Single Disc CD Player •...

  • Page 37: Uconnect® Rh3

    E L E C T R O N I C S Uconnect® RH3 Uconnect® RH3 1 — On/Off Volume Knob 8 — RND Button 2 — Display 9 — Display Button 3 — SEEK Down Button 10 — Band/As Button 4 —...
  • Page 38 E L E C T R O N I C S Equalizer, Balance And Fade • Adjust Equalizer of bass and treble • Balance left/right (BALANCE) and front/rear (FADER) • Strengthen sound (loudness) Equalization • Push the AUDIO button for more than two seconds to access equalization: ROCK, CLASSIC, POP, VOCAL, JAZZ, USER or FLAT.
  • Page 39 E L E C T R O N I C S USB/MP3 Audio Jack USB/iPod Mode is entered by inserting a USB Jump Drive or an iPod cable into the ® ® USB port. CAUTION! To remove devices connected to the USB port, first select the other audio source. Failure to follow this procedure can cause damage to the connected device.

  • Page 40: Uconnect ® 5.0

    E L E C T R O N I C S Uconnect® 5.0 Uconnect® 5.0 1 — Disc Eject Button 8 — Compass/NAV — If Equipped 2 — Disc Slot 9 — Media Button 3 — Settings Button 10 — Radio Button 4 —...
  • Page 41 E L E C T R O N I C S NOTE: Once the time has been set on the radio, the time will also appear in the Electronic Vehicle Information Center (EVIC). Equalizer, Balance And Fade 1. Push the SETTINGS button on the right side of the display. 2.
  • Page 42 E L E C T R O N I C S Radio Operation Uconnect® 5.0 Radio 1 — Radio Station Presets 5 — Station Info 2 — Show All Presets 6 — Direct Tune 3 — Seek Up 7 — Radio Band 4 —...
  • Page 43 E L E C T R O N I C S SiriusXM Premier Over 160 Channels Get every channel available on your satellite radio, and enjoy all you want, all in one place. Hear commercial-free music plus sports, news, talk and entertainment. Get all the premium programming, including Howard Stern, every NFL game, Oprah Radio ®...
  • Page 44 E L E C T R O N I C S USB/Audio Jack (AUX)/Bluetooth® Operation USB/iPod® The USB Input and Auxiliary Jack is lo- cated on the instrument panel left of the radio (driver’s lower right). • USB/iPod ® Mode is entered by either inserting a USB Jump Drive or an iPod cable into the USB port or by...
  • Page 45 E L E C T R O N I C S Uconnect® 5.0 Available Media Hubs Media Hub (USB, AUX Ports) Uconnect ® S = Standard Equipment Navigation If your vehicle is equipped with Navigation, there will be a NAV button on the faceplate in place of the COMPASS button on the faceplate.
  • Page 46 E L E C T R O N I C S Complete The Pairing Procedure • When prompted on the phone, verify with radio password shown on the Uconnect ® Screen. • If your phone asks you to accept a connection request from Uconnect , select ®...
  • Page 47 E L E C T R O N I C S Phonebook Uconnect ® radios automatically downloads your phonebook from your paired phone, if this feature is supported by your phone. Entries are updated each time that the phone is connected. If your phone book entries do not appear, check the settings on your phone.
  • Page 48 E L E C T R O N I C S WARNING! • Any voice commanded system should be used only in safe driving conditions following applicable laws regarding phone use. Your attention should be focused on safely operating the vehicle. Failure to do so may result in a collision causing you and others to be severely injured or killed.
  • Page 49 E L E C T R O N I C S Get Started 1. Visit UconnectPhone.com to check mobile device and feature compatibility and to find phone pairing instructions. 2. Reduce background noise. Wind and passenger conversations are examples of noise that may impact recognition.
  • Page 50 E L E C T R O N I C S Basic Voice Commands The basic Voice Commands below can be given at any point while using your Uconnect ® system. Push the VR button . After the beep, say: •...
  • Page 51 E L E C T R O N I C S Radio Use your voice to quickly get to the AM, FM or SiriusXM™ Satellite Radio stations ® you would like to hear. (Subscription or included SiriusXM™ Satellite Radio trial required.) Push the VR button .
  • Page 52 E L E C T R O N I C S Media Uconnect offers connections via USB, SD, Bluetooth and auxiliary ports (If Equipped). ® ® Voice operation is only available for connected USB and iPod ® devices. (Remote CD player optional and not available on all vehicles.) Push the VR button .
  • Page 53 E L E C T R O N I C S Phone Making and answering hands-free phone calls is easy with Uconnect . When the ® Phonebook button is illuminated on your touchscreen, your system is ready. U.S. residents can visit UconnectPhone.com to check mobile device and feature compatibility and to find phone pairing instructions.
  • Page 54 E L E C T R O N I C S Voice Text Reply Uconnect ® will announce incoming text messages. Push the Phone button say Listen. (Must have compatible mobile phone paired to Uconnect system.) ® 1. Once an incoming text message is read to you, push the Phone button .

  • Page 55: Steering Wheel Audio Controls

    E L E C T R O N I C S STEERING WHEEL AUDIO CONTROLS The steering wheel audio controls are located on the front surface of the steering wheel. Right Switch • Push the switch up or down to search for the next listenable station.

  • Page 56: Programmable Features

    E L E C T R O N I C S PROGRAMMABLE FEATURES Programmable Features The EVIC can be used to view or change the following settings: • Push the MODE button to access the menu items then push the UP or DOWN button to view the menu items listed below.

  • Page 57: Power Outlets

    E L E C T R O N I C S POWER OUTLETS The front power outlet is located in the center console. It only operates with the ignition key at MAR/ON. The power outlets are labeled with either a “key” or a “battery” symbol to indicate how the outlet is powered.
  • Page 58 E L E C T R O N I C S • Power outlets are designed for accessory plugs only. Do not insert any other object in the power outlet as this will damage the outlet and blow the fuse. Improper use of the power outlet can cause damage not covered by your new vehicle warranty.

  • Page 59: Utility

    U T I L I T Y TRAILER TOWING WEIGHTS (MAXIMUM TRAILER WEIGHT RATINGS) NOTE: For additional trailer towing information (maximum trailer weight ratings) refer to the following website addresses: • ramtrucks.com/en/towing_guide/ • ramtruck.ca (Canada) • rambodybuilder.com RECREATIONAL TOWING (BEHIND MOTORHOME, ETC.) Towing This Vehicle Behind Another Vehicle Wheels OFF the Gasoline Engine...
  • Page 60 U T I L I T Y Recreational Towing — Gasoline Engine All Models Recreational towing is allowed ONLY if the front wheels are OFF the ground. This may be accomplished using a tow dolly or vehicle trailer. If using a tow dolly, follow this procedure: 1.

  • Page 61: Diesel

    D I E S E L DIESEL ENGINE BREAK-IN RECOMMENDATIONS The diesel engine does not require a break-in period due to its construction. Normal operation is allowed, providing the following recommendations are followed: • Warm up the engine before placing it under load. •...
  • Page 62 D I E S E L CAUTION! If the “Generic Warning Light” remains on and a “Service Fuel Filter” message displays, DO NOT START engine before you drain the water from the fuel filter housing to avoid engine damage. Please see your authorized dealer for draining the fuel filter/water separator and fuel filter replacement.

  • Page 63: Automated Manual Transmission - Diesel Only

    D I E S E L In the case of LOW temperature after Starting, the Automated Manual Transmission may not be able to engage first gear. In this case a message "Shift not allowed" appears. In this situation use the engine block heater. Water In Fuel Message If a Generic Warning Light appears in the cluster and a “Service Fuel Filter”...
  • Page 64 D I E S E L • During extremely cold temperatures, the transmission will not operate if the oil temperature is -22°F (-30°C) or below. Allow the engine to idle briefly to warm the fluid. Normal operation will resume once the transmission temperature has risen to a suitable level.
  • Page 65 D I E S E L Instrument Cluster Messages Messages will be displayed in the instrument cluster to alert the driver when certain unusual conditions occur. These messages are described below: MESSAGE DESCRIPTION Transmission/Gearbox Fault (Red) When the ignition key is turned to ON/RUN/MAR, the Transmission Fault Indicator light turns on and should go off after a few seconds.
  • Page 66 D I E S E L MESSAGE DESCRIPTION Press Brake Pedal Delayed Startup This messages appears when the key is first turned ON, if the brake is fault and/or the shift lever is not in NEUTRAL (N). The shift lever must be in the NEU- TRAL (N) position, and the brake pedal must be pressed, to allow engine crank- ing.
  • Page 67 D I E S E L MESSAGE DESCRIPTION Shift To Neutral This message appears, together with a warning buzzer, when the shift lever must be moved to the NEUTRAL (N) position. When the shift lever is moved to NEUTRAL (N) the message on the display should go off.

  • Page 68: Exhaust Regeneration

    D I E S E L EXHAUST REGENERATION This engine meets all required EPA diesel engine emissions standards. To achieve these emissions standards, your vehicle is equipped with a state-of-the-art engine and exhaust system. These systems are seamlessly integrated into your vehicle and managed by the Powertrain Control Module (PCM).

  • Page 69: Cool-Down Idle Chart

    D I E S E L Exhaust Filter Full — Power Reduced See Dealer The PCM derates the engine in order to limit the likelihood of permanent damage to the after-treatment system. If this condition is not corrected and a dealer service is not performed, extensive exhaust after-treatment damage can occur.

  • Page 70: Adding Fuel

    D I E S E L ADDING FUEL The fuel cap is located behind the fuel filler door on the left side of the vehicle. When the fuel nozzle “clicks” or shuts off, the fuel tank is full. Tighten the fuel filler cap until you hear a “clicking”...

  • Page 71: Diesel Exhaust Fluid

    D I E S E L DIESEL EXHAUST FLUID Diesel Exhaust Fluid (DEF) sometimes known simply by the name of its active component, UREA – is a key component of selective catalytic reduction (SCR) systems, which help diesel vehicles meet stringent emission regulations. DEF is a liquid reducing agent that reacts with engine exhaust in the presence of a catalyst to convert smog-forming nitrogen oxides (NOx) into harmless nitrogen and water vapor.
  • Page 72 D I E S E L Adding Diesel Exhaust Fluid The DEF low level message (located in the EVIC) will display when the DEF level is low. Completely fill the DEF tank through the diesel exhaust fluid fill location (located behind the fuel door) at every maintenance interval or before if prompted by the Electronic Vehicle Information Center (EVIC).
  • Page 73 D I E S E L CAUTION! • To avoid DEF spillage and overfilling, do not “top off” the DEF tank after filling. • When DEF is spilled, clean the area immediately with water or a mild solvent. • DO NOT OVERFILL. DEF will freeze below 12 degrees F (-11 degrees C). The DEF system is designed to work in temperatures below the DEF freezing point, however, if the tank is overfilled and freezes, the system could be damaged.

  • Page 74: What To Do In Emergencies

    W H A T T O D O I N E M E R G E N C I E S ROADSIDE ASSISTANCE Dial toll-free 1-800-521-2779 for U.S. Residents or 1-800-363-4869 for Canadian Residents. • Provide your name, vehicle identification number, license plate number, and your location, including the telephone number from which you are calling.
  • Page 75 W H A T T O D O I N E M E R G E N C I E S WARNING! A hot engine cooling system is dangerous. You or others could be badly burned by steam or boiling coolant. - Anti-Lock Brake (ABS) Light This light monitors the Anti-Lock Brake System (ABS).
  • Page 76 W H A T T O D O I N E M E R G E N C I E S IF THE LIGHT STARTS FLASHING INDICATING A LOW TIRE PRESSURE, ADJUST THE AIR PRESSURE IN THE LOW TIRE TO THE AIR PRESSURE SHOWN ON THE VEHICLE PLACARD OR TIRE INFLATION PRESSURE LABEL LOCATED ON THE DRIVER'S DOOR.
  • Page 77 W H A T T O D O I N E M E R G E N C I E S - Seat Belt Reminder Light When the ignition switch is first turned to the ON/RUN position, this light will turn on for four to eight seconds as a bulb check.

  • Page 78: Instrument Cluster Indicator Lights

    W H A T T O D O I N E M E R G E N C I E S WARNING! Driving a vehicle with the red brake light on is dangerous. Part of the brake system may have failed. It will take longer to stop the vehicle. You could have a collision. Have the vehicle checked immediately.
  • Page 79 W H A T T O D O I N E M E R G E N C I E S - Vehicle Security Light This light will flash rapidly for approximately 15 seconds when the vehicle security alarm is arming. The light will flash at a slower speed continuously after the alarm is set.

  • Page 80: If Your Engine Overheats

    W H A T T O D O I N E M E R G E N C I E S IF YOUR ENGINE OVERHEATS In any of the following situations, you can reduce the potential for overheating by taking the appropriate action: •...

  • Page 81: Jacking And Tire Changing

    W H A T T O D O I N E M E R G E N C I E S JACKING AND TIRE CHANGING Jack Location The jack and jack tools are stored under the front passenger seat. Removing The Spare Tire Remove the spare tire before attempting to jack up the vehicle.
  • Page 82 W H A T T O D O I N E M E R G E N C I E S Preparations 1. Park the vehicle on a firm, level surface as far from the edge of the roadway as possible.
  • Page 83 W H A T T O D O I N E M E R G E N C I E S Instructions 1. Remove the spare tire, jack and tools from storage. 2. Using the wheel wrench, loosen, but do not remove, the wheel bolts by turning them counterclockwise one turn while the wheel is still on the ground.
  • Page 84 W H A T T O D O I N E M E R G E N C I E S 4. There are two jack engagement points on the vehicle for the front and rear tires. The front tire jacking location is located behind the front tire and in front of the driver/passenger door.
  • Page 85 W H A T T O D O I N E M E R G E N C I E S Wheel Bolts • All wheel bolts should be tightened occasionally to eliminate the possibility of the bolts loosening unintentionally. •...
  • Page 86 W H A T T O D O I N E M E R G E N C I E S WARNING! • Do not attempt to change a tire on the side of the vehicle close to moving traffic. Pull far enough off the road to avoid the danger of being hit when operating the jack or changing the wheel.

  • Page 87: Jump-Starting

    W H A T T O D O I N E M E R G E N C I E S JUMP-STARTING Preparations For Jump-Starting NOTE: Only use the recommended jump starting location. The vehicle’s jump starting locations are located under the hood in the engine compartment on the driver’s side.
  • Page 88 W H A T T O D O I N E M E R G E N C I E S Once the engine is started, disconnect the jumper cables in the reverse sequence: Disconnecting The Jumper Cables 1. Disconnect the negative end (-) of the jumper cable from the remote negative (-) post of the vehicle with the discharged battery.
  • Page 89 W H A T T O D O I N E M E R G E N C I E S WARNING! • When temperatures are below the freezing point, electrolyte in a discharged battery may freeze. Do not attempt jump-starting because the battery could rupture or explode and cause personal injury.

  • Page 90: Shift Lever Override

    W H A T T O D O I N E M E R G E N C I E S SHIFT LEVER OVERRIDE If a malfunction occurs and the shift lever cannot be moved out of the PARK position, you can use the following procedure to temporarily move the shift lever: 1.

  • Page 91: Freeing A Stuck Vehicle

    W H A T T O D O I N E M E R G E N C I E S FREEING A STUCK VEHICLE • If your vehicle becomes stuck in mud, sand or snow, it can often be moved by a rocking motion.

  • Page 92: Event Data Recorder (Edr)

    W H A T T O D O I N E M E R G E N C I E S EVENT DATA RECORDER (EDR) This vehicle is equipped with an Event Data Recorder (EDR). The main purpose of an EDR is to record, in certain crash or near crash-like situations, such as an air bag deployment or hitting a road obstacle, data that will assist in understanding how a vehicle’s systems performed.

  • Page 93: Maintaining Your Vehicle

    M A I N T A I N I N G Y O U R V E H I C L E OPENING THE HOOD 1. Open the drivers door to gain access to the hood release lever. Pull the hood release lever located on the side of the instrument panel.

  • Page 94: Engine Compartment

    M A I N T A I N I N G Y O U R V E H I C L E ENGINE COMPARTMENT 3.6L Engine 1. Power Steering Reservoir 2. Washer Fluid Reservoir 3. Engine Coolant Reservoir 4. Brake Fluid Reservoir...
  • Page 95 M A I N T A I N I N G Y O U R V E H I C L E 5. Power Distribution Center (Fuses) 6. Remote Jump Starting Points 7. Engine Oil Dipstick 8. Engine Oil Fill...
  • Page 96 M A I N T A I N I N G Y O U R V E H I C L E 3.0L Diesel Engine 1. Power Steering Reservoir 2. Washer Fluid Reservoir 3. Brake Fluid Reservoir 4. Remote Jump Starting Positive...
  • Page 97 M A I N T A I N I N G Y O U R V E H I C L E 5. Power Distribution Center (Fuses) 6. Engine Oil Dipstick 7. Engine Oil Fill 8. Engine Coolant Reservoir...

  • Page 98: Fluid Capacities - Gasoline Engine

    M A I N T A I N I N G Y O U R V E H I C L E FLUID CAPACITIES — GASOLINE ENGINE U.S. Metric Fuel (Approximate) 24 Gallons 90 Liters Engine Oil with Filter 3.6L Engine (SAE 5W-20, 6 Quarts 5.6 Liters API Certified)
  • Page 99 M A I N T A I N I N G Y O U R V E H I C L E CAUTION! • Mixing of engine coolant (antifreeze) other than specified Organic Additive Technology (OAT) engine coolant (antifreeze), may result in engine damage and may decrease corrosion protection.

  • Page 100: Fluid Capacities - Diesel Engine

    M A I N T A I N I N G Y O U R V E H I C L E FLUID CAPACITIES — DIESEL ENGINE U.S. Metric Fuel (Approximate) 3.0L Diesel Engine 24 Gallons 90 Liters Diesel Exhaust Fluid Tank 5 Gallons 18.9 Liters Engine Oil with Filter...
  • Page 101 M A I N T A I N I N G Y O U R V E H I C L E Component Fluid, Lubricant, or Genuine Part Fuel Selection Use good quality diesel fuel from a reputable sup- plier in your vehicle. Federal law requires that you must fuel this vehicle with Ultra Low Sulfur Highway Diesel fuel (15 ppm Sulfur maximum) and prohibits the use of Low Sulfur Highway Diesel fuel (500 ppm...

  • Page 102: Maintenance Procedures

    M A I N T A I N I N G Y O U R V E H I C L E Chassis Component Fluid, Lubricant, or Genuine Part • Gearbox: Full synthetic 75W-85 manual Automated Manual Transmission transmission fluid meeting the API GL4 specification.
  • Page 103 M A I N T A I N I N G Y O U R V E H I C L E Your authorized dealer will reset the oil change indicator message after completing the scheduled oil change. If a scheduled oil change is performed by someone other than your authorized dealer, the message can be reset by referring to the steps described under “Electronic Vehicle Information Center (EVIC)”...
  • Page 104 M A I N T A I N I N G Y O U R V E H I C L E...
  • Page 105 M A I N T A I N I N G Y O U R V E H I C L E...
  • Page 106 M A I N T A I N I N G Y O U R V E H I C L E...

  • Page 107: Maintenance Schedule - Diesel Engine

    M A I N T A I N I N G Y O U R V E H I C L E MAINTENANCE SCHEDULE — DIESEL ENGINE Your vehicle is equipped with an automatic oil change indicator system. The oil change indicator system will remind you that it is time to take your vehicle in for scheduled maintenance.
  • Page 108 M A I N T A I N I N G Y O U R V E H I C L E...
  • Page 109 M A I N T A I N I N G Y O U R V E H I C L E...
  • Page 110 M A I N T A I N I N G Y O U R V E H I C L E...
  • Page 111 M A I N T A I N I N G Y O U R V E H I C L E...

  • Page 112: Fuses

    M A I N T A I N I N G Y O U R V E H I C L E FUSES Underhood Fuses The Power Distribution Center (fuses) is located on the right side of the engine compartment. This center contains maxi-fuses, mini-fuses and relays. Cavity Maxi Fuse Mini Fuse...
  • Page 113 M A I N T A I N I N G Y O U R V E H I C L E Cavity Maxi Fuse Mini Fuse Description Secondary Loads, ECM 20 Amp Yellow (3.0 Diesel Engine) KL30 ECM, KL30 Main Relay 7.5 Amp Brown Coil (3.6 Gasoline Engine) KL30 MTA, KL30 ECM, KL30...
  • Page 114 M A I N T A I N I N G Y O U R V E H I C L E Interior Fuses The interior fuse panel is part of the Body Control Module (BCM) and is located on the driver's side under the instrument panel.

  • Page 115: Tire Pressures

    M A I N T A I N I N G Y O U R V E H I C L E TIRE PRESSURES Check the inflation pressure of each tire, including the spare tire, at least monthly and inflate to the recommended pressure for your vehicle. The tire pressures recommended for your vehicle are found on the “Tire and Loading Information”...

  • Page 116: Spare Tires - If Equipped

    M A I N T A I N I N G Y O U R V E H I C L E SPARE TIRES — IF EQUIPPED NOTE: For vehicles equipped with Tire Service Kit instead of a spare tire, please refer to “Tire Service Kit”...

  • Page 117: Wheel And Wheel Trim Care

    M A I N T A I N I N G Y O U R V E H I C L E Full Size Spare — If Equipped The full size spare is for temporary emergency use only. This tire may look like the originally equipped tire on the front or rear axle of your vehicle, but it is not.

  • Page 118: Bulbs

    M A I N T A I N I N G Y O U R V E H I C L E BULBS Interior Bulbs Bulb Number Overhead Lamp Sun Visors Courtesy Lamp FF500 Glove Compartment Rear Courtesy Lamp Exterior Bulbs Bulb Number Front Low and High Beam Headlamp H7LL...

  • Page 119: Customer Assistance

    C U S T O M E R A S S I S T A N C E CHRYSLER GROUP LLC CUSTOMER CENTER P.O. Box 21–8004 Auburn Hills, MI 48321–8004 Phone: 1–866–726–4636 CHRYSLER CANADA INC. CUSTOMER CENTER P.O. Box 1621 Windsor, Ontario N9A 4H6 Phone: 1–800–465–2001 (English) Phone: 1–800–387–9983 (French) ASSISTANCE FOR THE HEARING IMPAIRED To assist customers who have hearing difficulties, the manufacturer has installed...

  • Page 120: Reporting Safety Defects In The United States

    C U S T O M E R A S S I S T A N C E NOTE: • A street address is required when ordering manuals (no P.O. Boxes). • The Owner's Manual and User Guide electronic files are also available on the Chrysler, Jeep, Ram Truck, Dodge and SRT websites.

  • Page 121: Mopar® Accessories

    M O P A R ® A C C E S S O R I E S AUTHENTIC ACCESSORIES BY MOPAR® In choosing Authentic Accessories you gain far more than expressive style, premium protection, or extreme entertainment, you also benefit from enhancing your vehicle with accessories that have been thoroughly tested and factory-approved.

  • Page 122: Faq's

    F A Q ’ s Frequently Asked Questions GETTING STARTED Where are the controls for the Front Heated Seats? pg. 20 How to adjust your seat? pg. 15 ELECTRONICS Which radio is in my vehicle? pg. 38 How do I activate the Audio Jack? pg. 42 How do I set the clock on my radio? pg.

  • Page 123: Index

    I N D E X Adding Diesel Exhaust Fluid ..68 Caps, Filler Adding Engine Coolant Fuel ....68 (Antifreeze)... . .100 Oil (Engine) .
  • Page 124 I N D E X Corrosion Protection ..100 FAQ....120 Cruise Control (Speed Control) ..28 Filters Cruise Light .
  • Page 125 I N D E X Jack Location ....79 Outlet Jack Operation ... . .79 Power ....55 Jump Starting.
  • Page 126 I N D E X Shift Lever Override ..88 Washer Signals, Turn ... .24, 76 Adding Fluid ...100 Sirius Satellite Radio .
  • Page 127 N O T E S...
  • Page 128 N O T E S...
  • Page 129 N O T E S...
  • Page 130 N O T E S...
  • Page 131 promaster 2015 User Guide This guide has been prepared to help you get quickly acquainted with your new RAM and to provide a convenient reference source for common questions. However, it is not a substitute for your Owner’s Manual. For complete operational instructions, maintenance procedures and important safety messages, please consult your Owner’s Manual, Navigation/Uconnect ®...
  • Page 132 DOWNLOAD A FREE ELECTRONIC COPY OF THE OWNER’S MANUAL AND WARRANTY BOOKLET BY VISITING: WWW.RAMTRUCKS.COM/EN/OWNERS/MANUALS OR WWW.RAMTRUCKS.COM/EN/WARRANTY (U.S.); WWW.OWNERS.MOPAR.CA/EN (CANADA). 15VF-926-AA . RAM ProMaster . First Edition . User Guide...

Table of Contents
