RAM Commercial PROMASTER 2020 Owner's Manual

Hide thumbs Also See for PROMASTER 2020:
Table of Contents

Advertisement

Quick Links

RAM PROMASTER
20 2 0 OWNER' S M ANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PROMASTER 2020 and is the answer not in the manual?

Questions and answers

Related Manuals for RAM Commercial PROMASTER 2020

Summary of Contents for RAM Commercial PROMASTER 2020

  • Page 1 RAM PROMASTER 20 2 0 OWNER’ S M ANUAL...
  • Page 2 This Owner’s Manual illustrates and describes the operation of features and equipment that are either standard or optional on this vehicle. This manual may also include a description of features and equipment that are no longer available or were not ordered on this vehicle. Please disregard any features and equipment that are no longer available or were not ordered on this vehicle.

  • Page 3: Table Of Contents

    TABLE OF CONTENTS INTRODUCTION ..........................7 GETTING TO KNOW YOUR VEHICLE ................... 9 GETTING TO KNOW YOUR INSTRUMENT PANEL ............42 SAFETY ............................56 STARTING AND OPERATING ....................90 IN CASE OF EMERGENCY ...................... 119 SERVICING AND MAINTENANCE ..................149 TECHNICAL SPECIFICATIONS .....................189 MULTIMEDIA ..........................
  • Page 4 INTRODUCTION INTERIOR LIGHTS ..........26 SEATS ..............15 Manual Adjustments ........16 Courtesy Lights ..........26 HOW TO USE THIS MANUAL ......... 7 Heated Seats — If Equipped ....... 19 Illuminated Entry ......... 28 Essential Information ........7 Fold Down Tray — If Equipped..... 19 WIPERS AND WASHERS ........28 Symbols ............
  • Page 5 INSTRUMENT CLUSTER DISPLAY .......44 OCCUPANT RESTRAINT SYSTEMS ....64 AUTOMATIC TRANSMISSION ......93 Location And Controls ......... 44 Occupant Restraint Systems Features ..64 Key Ignition Park Interlock......93 Change Engine Oil........45 Important Safety Precautions..... 65 Brake/Transmission Shift Interlock Display Setup Menu ........45 Seat Belt Systems ........
  • Page 6 IN CASE OF EMERGENCY VEHICLE LOADING ..........107 TOWING A DISABLED VEHICLE......146 Vehicle Certification Label ......107 Automatic Transmission......147 HAZARD WARNING FLASHERS......119 Gross Vehicle Weight Rating (GVWR) ..107 ENHANCED ACCIDENT RESPONSE SYSTEM BULB REPLACEMENT ........119 Gross Axle Weight Rating (GAWR) ...107 (EARS) ..............
  • Page 7 TIRES ..............166 WHEEL AND TIRE TORQUE UCONNECT 3/3 NAV WITH 5-INCH Tire Safety Information......166 SPECIFICATIONS ..........189 DISPLAY.............. 207 Tires — General Information .....174 Torque Specifications........189 Introduction To The Uconnect 3/3 NAV Tire Types ...........178 FUEL REQUIREMENTS ........190 With 5-Inch Display System ...... 207 Spare Tires —...
  • Page 8 CUSTOMER ASSISTANCE SUGGESTIONS FOR OBTAINING SERVICE FOR YOUR VEHICLE ..........243 Prepare For The Appointment....243 Prepare A List..........243 Be Reasonable With Requests ....243 IF YOU NEED ASSISTANCE ......243 FCA US LLC Customer Center ....244 FCA Canada Inc. Customer Center ...244 In Mexico Contact ........244 Puerto Rico And US Virgin Islands ....244 Customer Assistance For The Hearing Or...

  • Page 9: Introduction

    INTRODUCTION Dear Customer, Congratulations on selecting your new vehicle. Be assured that it represents precision workmanship, distinctive styling, and high quality. This Owner’s Manual has been prepared with the assistance of service and engineering specialists to acquaint you with the operation and maintenance of your vehicle.

  • Page 10: Symbols

    Symbols Some vehicle components have colored labels whose symbols indicate precautions to be observed when using this component. Refer to “Warning Lights and Messages” in “Getting To Know Your Instrument Panel” for further information on the symbols used in your vehicle. WARNINGS AND CAUTIONS This Owner’s Manual contains WARNINGS against operating procedures that could result in a collision, bodily injury, and/or death.

  • Page 11: Getting To Know Your Vehicle

    GETTING TO KNOW YOUR VEHICLE KEYS Remote Keyless Entry (RKE) This system allows you to lock or unlock the Key Fob doors from distances up to approximately 66 ft (20 m) using a hand-held key fob. The key fob Your vehicle uses a key start ignition system. does not need to be pointed at the vehicle to The ignition system consists of a key fob with a activate the system.
  • Page 12 GETTING TO KNOW YOUR VEHICLE To Unlock The Doors Sound Horn With Lock Push and release the unlock button on key fob This feature will cause the horn to chirp when once to unlock only the front doors. Push and the doors are locked with the key fob.

  • Page 13: Ignition Switch

    GETTING TO KNOW YOUR VEHICLE General Information La operación de este equipo está sujeta a las siguientes dos condiciones: The following regulatory statement applies to all Radio Frequency (RF) devices equipped in this 1. es posible que este equipo o dispositivo no vehicle: cause interferencia perjudicial y This device complies with Part 15 of the FCC...

  • Page 14: Key-In-Ignition Reminder

    GETTING TO KNOW YOUR VEHICLE NOTE: CAUTION! WARNING! (Continued) A key which has not been programmed is also An unlocked vehicle is an invitation. Always considered an invalid key, even if it is cut to fit Never leave children alone in a vehicle, or ...

  • Page 15: Replacement Keys

    GETTING TO KNOW YOUR VEHICLE Replacement Keys 2. This device must accept any interference NOTE: received, including interference that may Changes or modifications not expressly NOTE: cause undesired operation. approved by the party responsible for compli- Only keys that have been programmed to the ance could void the user’s authority to operate vehicle electronics can be used to start the Le présent appareil est conforme aux CNR...

  • Page 16: To Disarm The System

    GETTING TO KNOW YOUR VEHICLE To Disarm The System Security System Manual Override The load compartment power door lock switch is located on the driver door trim panel. Use this Use the key fob to unlock the door and disarm The vehicle security alarm will not arm/disarm if switch to lock or unlock the load compartment the system.

  • Page 17: Auto Unlock Doors

    GETTING TO KNOW YOUR VEHICLE SEATS CAUTION! WARNING! (Continued) Seats are a part of the Occupant Restraint An unlocked vehicle is an invitation. Always Before exiting a vehicle, always shift the  System of the vehicle. automatic transmission into PARK or the remove the key from the ignition and lock all manual transmission into FIRST gear or of the doors when leaving the vehicle...

  • Page 18: Manual Adjustments

    GETTING TO KNOW YOUR VEHICLE Manual Adjustments To raise the front or rear of the seat, lift the  appropriate lever while none or minimal The driver and passenger seats can be adjusted weight is applied to the seat. forward/rearward and reclined. Front and rear height and lumbar can also be adjusted (if To lower the front or rear of the seat, lift the ...
  • Page 19 GETTING TO KNOW YOUR VEHICLE With Swivel Seat its normal upright position, lean forward, rotate the knob forward until the seatback is in the The height adjusting knobs are located on the upright position. center outboard side of the seat. Rotate the front knob to adjust the front of the seat up or down.
  • Page 20 GETTING TO KNOW YOUR VEHICLE Lumbar Support — If Equipped This feature allows you to increase or decrease the amount of lumbar support. The lumbar control knob is located on the rear upper outboard side of the driver's seatback. Rotate the control forward to increase and rearward to decrease the desired amount of lumbar support.

  • Page 21: Heated Seats - If Equipped

    GETTING TO KNOW YOUR VEHICLE If the driver or the passenger seats are not WARNING! (Continued) locked in the facing forward position during movement of the vehicle, a message will appear Do not place anything on the seat or seat- ...

  • Page 22: Adjustable Armrests - If Equipped

    GETTING TO KNOW YOUR VEHICLE HEAD RESTRAINTS The fold-down tray is equipped with two cup holders and a support surface with a paper Head restraints are designed to reduce the risk holder clip. of injury by restricting head movement in the event of a rear impact.

  • Page 23: Front Head Restraint Adjustment

    GETTING TO KNOW YOUR VEHICLE STEERING WHEEL Front Head Restraint Adjustment Front Head Restraint Removal To raise the head restraint, pull upward on the To remove the head restraint, raise it up as far Telescoping Steering Column head restraint. To lower the head restraint, as it can go.

  • Page 24: Mirrors

    GETTING TO KNOW YOUR VEHICLE Outside Mirrors Folding Feature WARNING! All outside mirrors are hinged and may be Do not adjust the steering column while moved either forward or rearward to resist driving. Adjusting the steering column while damage. The hinges have three detent driving or driving with the steering column positions: unlocked, could cause the driver to lose...

  • Page 25: Power Folding Mirrors - If Equipped

    GETTING TO KNOW YOUR VEHICLE To adjust a mirror, turn the control knob toward Push the switch to the right and the mirrors will NOTE: the left upper, left lower, right upper or right fold in, push the switch to the left and the The intended use of the power fold mirrors is by lower mirror positions indicated by one of the mirrors will return to the normal driving position.

  • Page 26: Heated Mirrors - If Equipped

    GETTING TO KNOW YOUR VEHICLE Daytime Running Lights (DRLs) — If CAUTION! Equipped Leaving the mirror in a non powered position, NOTE: accidental impact or manual fold, may cause When the headlights are turned on, the Daytime permanent damage to the mirror. Electrically Running Lights will be deactivated.

  • Page 27: High Beam/Low Beam Select Switch

    GETTING TO KNOW YOUR VEHICLE High Beam/Low Beam Select Switch The warning light telltale in the instrument Deactivation panel comes on. The lights stay on until the next Pull the multifunction lever toward the steering With the low beams activated, pull the ignition cycle is performed.

  • Page 28: Lane Change Assist

    GETTING TO KNOW YOUR VEHICLE Lane Change Assist Push the switch to the off/left position from  its center position and the lights are always Tap the lever up or down once, without moving off. beyond the detent, and the turn signal (right or left) will flash five times then automatically turn Leave the switch in the center position, and ...
  • Page 29 GETTING TO KNOW YOUR VEHICLE Rear Lights The Rear and Side Cargo Lamps can be set to The Ceiling Cargo Lamp can be set to three three different positions (off/right position, different positions (off/left position, center The Rear Cargo Lamp is located at the upper center position, on/left position).

  • Page 30: Illuminated Entry

    GETTING TO KNOW YOUR VEHICLE Dimmer Controls Illuminated Entry NOTE: The windshield wipers/washers will only The dimmer controls are located on the left side The courtesy lights will turn on when you use the operate with the ignition in the MAR (ACC/ON/ of the instrument panel below the instrument key fob to unlock the doors or open any door.

  • Page 31: Climate Controls

    GETTING TO KNOW YOUR VEHICLE Windshield Washer Operation Mist Feature Manual Climate Control Overview To use the washer, pull the windshield wiper/ Use the Mist feature when weather conditions The Manual Temperature Controls consist of a washer lever toward the steering wheel to make occasional usage of the wipers series of three outer rotary dials (blower speed, activate.
  • Page 32 GETTING TO KNOW YOUR VEHICLE Manual Climate Control Descriptions Icon Description A/C Button Push the A/C button to engage the Air Conditioning (A/C). The A/C indicator illuminates when A/C is on. Recirculation Button Press and release this button to change the system between recirculation mode and outside air mode. The Recirculation indicator and the A/C indicator illuminate when the Recirculation button is pressed.
  • Page 33 GETTING TO KNOW YOUR VEHICLE Icon Description Blower Control Blower Control regulates the amount of air forced through the climate system. There are seven blower speeds available. The blower speed increases as you turn the blower control knob clockwise from the lowest blower setting. The blower speed decreases as you turn the blower control knob counterclockwise.
  • Page 34 GETTING TO KNOW YOUR VEHICLE Icon Description Floor Mode Floor Mode Air comes from the floor outlets. A slight amount of air is directed through the defrost and side window demister outlets. Mix Mode Mix Mode Air is directed through the floor, defrost, and side window demister outlets. This setting works best in cold or snowy conditions that require extra heat to the windshield.

  • Page 35: Climate Control Functions

    GETTING TO KNOW YOUR VEHICLE Icon Description Rear Blower Control Push this button to turn on the rear climate controls. An indicator light will turn on when the rear climate control is on. Rear Temperature Control Rear Passenger Temperature Up Button To change the temperature in the rear of the vehicle, ...

  • Page 36: Operating Tips

    GETTING TO KNOW YOUR VEHICLE disabled automatically if this mode is selected. Vacation Storage CAUTION! Attempting to use Recirculation while in this Any time you store your vehicle or keep it out of mode causes the LED in the control button to Failure to follow these cautions can cause service (i.e., vacation) for two weeks or more, blink and then turns off.

  • Page 37: Windows

    GETTING TO KNOW YOUR VEHICLE A/C Air Filter CONTROL WEATHER The climate control system filters outside air SETTINGS containing dust, pollen and some odors. Strong Set the mode control odors cannot be totally filtered out. Refer to Cool & Humid “Dealer Service”...

  • Page 38: Window Bar Grates - If Equipped

    GETTING TO KNOW YOUR VEHICLE Auto-Up Feature — If Equipped WARNING! (Continued) The driver window may be equipped with an Do not leave the key fob in or near the  Auto-Up feature. This feature is only available vehicle or in a location accessible to chil- when the ignition is in the MAR (ACC/ON/RUN) dren.

  • Page 39: Hood

    GETTING TO KNOW YOUR VEHICLE open the front and rear windows together to 2. Move to the outside of the vehicle, reach minimize the buffeting. If the buffeting occurs into the opening beneath the center of the with the sunroof open, adjust the sunroof hood and push the safety latch lever to the right to release it, before raising the hood.

  • Page 40: Cargo Area Features

    GETTING TO KNOW YOUR VEHICLE Dash Storage CAUTION! The dash storage is located on the right side of To prevent possible damage: the instrument panel. Before closing hood, make sure the hood  prop rod is fully seated into its storage retaining clips.

  • Page 41: Cupholders

    GETTING TO KNOW YOUR VEHICLE Dashboard Clipboard Located on top of the dashboard is a clipboard and two storage bins on each side of the clipboard. Underseat Storage Tray Cupholders Cupholders Power Outlets The cupholders for the driver’s and passenger’s Passenger Compartment Power Outlet area are located near the floor just under the The power outlet is located on the instrument...
  • Page 42 GETTING TO KNOW YOUR VEHICLE Load Compartment Power Outlet — If Equipped CAUTION! The load compartment power outlet is located Many accessories that can be plugged in  in rear cargo compartment. The outlet can be is draw power from the vehicle's battery, even used for powering 12 Volt adaptive accessories when not in use (i.e., cellular phones, etc.).

  • Page 43: Auxiliary Switches - If Equipped

    GETTING TO KNOW YOUR VEHICLE Auxiliary Switches — If Equipped Your vehicle may be equipped with two auxiliary switches located on the instrument panel to the left of the steering column which can be used to power various electronic devices. Connections to the switches are found in the right central pillar fuse panel at the base of the passenger side B-pillar.

  • Page 44: Getting To Know Your Instrument Panel

    GETTING TO KNOW YOUR INSTRUMENT PANEL INSTRUMENT CLUSTER Instrument Cluster...

  • Page 45: Instrument Cluster Descriptions

    GETTING TO KNOW YOUR INSTRUMENT PANEL Instrument Cluster Descriptions jamb sticker is accurate if the odometer must or up mountain grades. It should not be be reset at zero. allowed to exceed the upper limits of the 1. Speedometer normal operating range. Gear Selector Status (PRND) ...

  • Page 46: Instrument Cluster Display

    GETTING TO KNOW YOUR INSTRUMENT PANEL 5. Fuel Gauge Location And Controls If equipped with a Uconnect system, some customer programmable features will display in The pointer shows the level of fuel in the The instrument cluster display features a driver ...

  • Page 47: Change Engine Oil

    GETTING TO KNOW YOUR INSTRUMENT PANEL main menu item. Push and hold the MODE the ON/RUN position. To turn off the message menu options. The menu items include the button for two seconds to reset displayed/ temporarily, push and release the MODE following functions: selected features that can be reset.

  • Page 48: Values Displayed

    GETTING TO KNOW YOUR INSTRUMENT PANEL Selecting An Option Of The Main Menu With Range appear on the display if the vehicle is parked Submenu with the engine running. This indicates the distance which may be traveled with the fuel remaining in the tank, 1.

  • Page 49: Trip Computer

    GETTING TO KNOW YOUR INSTRUMENT PANEL TRIP COMPUTER New Trip Trip Functions To reset: Both trip functions are resettable (reset — start The Trip Computer is located in the instrument Push and hold the TRIP button to reset the of new trip). ...

  • Page 50: Warning Lights And Messages

    GETTING TO KNOW YOUR INSTRUMENT PANEL WARNING LIGHTS AND MESSAGES continuously and a chime will sound. Refer to Door Open Warning Light “Occupant Restraints Systems” in “Safety” for This indicator will illuminate when one The warning/indicator lights will illuminate in further information.
  • Page 51 GETTING TO KNOW YOUR INSTRUMENT PANEL on when the ignition is placed in the ON/RUN or Brake Warning Light the brake fluid level in the master cylinder has MAR/ON/RUN position and remain on briefly as dropped below a specified level. This warning light monitors various a bulb check.

  • Page 52: Yellow Warning Lights

    GETTING TO KNOW YOUR INSTRUMENT PANEL Operation of the Brake Warning Light can be Vehicle Security Warning Light — If Equipped pressure loss is occurring. In these cases, checked by turning the ignition switch from the optimal tire duration and fuel consumption may This light will flash at a fast rate for OFF position to the ON/RUN position.
  • Page 53 GETTING TO KNOW YOUR INSTRUMENT PANEL pressure telltale when one or more of your tires may not be able to detect or signal low tire Electronic Stability Control (ESC) Warning is significantly under-inflated. Accordingly, when pressure as intended. TPMS malfunctions may Light the low tire pressure telltale illuminates, you occur for a variety of reasons, including the...
  • Page 54 GETTING TO KNOW YOUR INSTRUMENT PANEL The ESC system will make buzzing or clicking ignition switch from OFF to ON/RUN, have the  CAUTION! sounds when it is active. This is normal; the condition checked promptly. sounds will stop when ESC becomes inactive. Prolonged driving with the Malfunction Certain conditions, such as a loose or missing Indicator Light (MIL) on could cause damage...

  • Page 55: Yellow Indicator Lights

    GETTING TO KNOW YOUR INSTRUMENT PANEL Generic Warning Light External Light Failure Indicator Light — If Green Indicator Lights Equipped The Generic Warning Light will Turn Signal Indicator Light illuminate if any of the following The External Light Failure Indicator The turn signal arrows will flash conditions occur: Engine Oil Pressure will come on when a failure to one of...

  • Page 56: Blue Indicator Lights

    GETTING TO KNOW YOUR INSTRUMENT PANEL Cruise Control Indicator Light — If Equipped system monitors the performance of the Onboard Diagnostic System (OBD II) emissions, engine, and transmission control Cybersecurity This indicator light will illuminate systems. When these systems are operating when the cruise control is activated.

  • Page 57: Emissions Inspection And Maintenance

    GETTING TO KNOW YOUR INSTRUMENT PANEL Your vehicle has a simple ignition actuated test, The MIL will not flash at all and will  WARNING! (Continued) which you can use prior to going to the test remain fully illuminated until you place station.

  • Page 58: Safety

    SAFETY SAFETY FEATURES WARNING! WARNING! (Continued) Four-Wheel Anti-Lock Brake System (ABS) The ABS contains sophisticated electronic The ABS cannot prevent collisions,   equipment that may be susceptible to inter- including those resulting from excessive The Four-Wheel Anti-Lock Brake System (ABS) is ference caused by improperly installed or speed in turns, following another vehicle designed to aid the driver in maintaining vehicle...

  • Page 59: Electronic Brake Control (Ebc) System

    SAFETY Electronic Brake Control (EBC) System braking is no longer desired. Once the brake ESC uses sensors in the vehicle to determine pedal is released, the BAS is deactivated. the vehicle path intended by the driver and Your vehicle is equipped with an advanced compares it to the actual path of the vehicle.
  • Page 60 SAFETY ESC Operating Modes WARNING! WARNING! (Continued) The “ESC OFF” switch is located in the Electronic Stability Control (ESC) cannot Vehicle modifications, or failure to properly   center switch bank, next to the hazard prevent the natural laws of physics from maintain your vehicle, may change the flasher switch.
  • Page 61 SAFETY ESC Activation/Malfunction Indicator Light NOTE: WARNING! And ESC OFF Indicator Light The ESC Activation/Malfunction Indicator  When in “Partial Off” mode, the TCS func-  The ESC Activation/Malfunction Light and the ESC OFF Indicator Light come tionality of ESC, (except for the limited slip Indicator Light in the instrument on momentarily each time the ignition switch feature described in the TCS section), has...
  • Page 62 SAFETY vehicle will roll down the hill. The system will WARNING! WARNING! (Continued) release brake pressure in proportion to the amount of throttle applied as the vehicle starts There may be situations on minor hills with a HSA is not a parking brake. Always apply ...

  • Page 63: Auxiliary Driving Systems

    SAFETY AUXILIARY DRIVING SYSTEMS The ESC Activation/Malfunction Indicator Light attempt to stop the sway. The system may (in the instrument cluster) will start to flash as reduce engine power and apply the brake of the Tire Pressure Monitoring System (TPMS) soon as the tires lose traction and the wheels appropriate wheel(s) to counteract the sway of begin to spin.
  • Page 64 SAFETY The TPMS will warn the driver of a low tire For example, your vehicle may have a CAUTION! (Continued) pressure if the tire pressure falls below the recommended cold (parked for more than three low-pressure warning limit for any reason, hours) placard pressure of 30 psi (207 kPa).
  • Page 65 SAFETY The TPMS is not a substitute for proper tire The TPMS consists of the following Check TPMS Warnings  maintenance, and it is the driver’s responsi- components: The Tire Pressure Monitoring System Warning bility to maintain correct tire pressure using Receiver Module Light will flash on and off for 75 seconds and ...

  • Page 66: Occupant Restraint Systems

    SAFETY 1. The spare tire does not have a TPM sensor. This device complies with Part 15 of the FCC 1. es posible que este equipo o dispositivo no Therefore, the TPMS will not monitor the Rules and with Innovation, Science and cause interferencia perjudicial y pressure in the spare tire.

  • Page 67: Important Safety Precautions

    SAFETY Important Safety Precautions 4. Never allow children to slide the shoulder WARNING! belt behind them or under their arm. Please pay close attention to the information in Never place a rear-facing child restraint in  this section. It tells you how to use your restraint 5.
  • Page 68 SAFETY belts reduce the possibility of ejection and the BeltAlert is not active when an outboard front sequence will begin until the seat belts are risk of injury caused by striking the inside of the passenger seat is unoccupied. buckled again. vehicle.
  • Page 69 SAFETY Lap/Shoulder Belts WARNING! (Continued) WARNING! (Continued) All seating positions in your vehicle are It is dangerous to ride in a cargo area, Two people should never be belted into a   equipped with lap/shoulder belts. inside or outside of a vehicle. In a collision, single seat belt.
  • Page 70 SAFETY WARNING! (Continued) WARNING! (Continued) A seat belt that is buckled into the wrong A shoulder belt placed behind you will not   buckle will not protect you properly. The lap protect you from injury during a collision. portion could ride too high on your body, You are more likely to hit your head in a possibly causing internal injuries.
  • Page 71 SAFETY 4. Position the lap belt so that it is snug and 6. To release the seat belt, push the red button Adjustable Upper Shoulder Belt Anchorage lies low across your hips, below your on the buckle. The seat belt will automat- In the driver and outboard front passenger abdomen.
  • Page 72 SAFETY Seat Belts And Pregnant Women WARNING! Wearing your seat belt incorrectly could  make your injuries in a collision much worse. You might suffer internal injuries, or you could even slide out of the seat belt. Follow these instructions to wear your seat belt safely and to keep your passengers safe, too.
  • Page 73 SAFETY Seat Belt Pretensioner Energy Management Feature The front seat belt system is equipped with The front seat belt system is equipped with an pretensioning devices that are designed to Energy Management feature that may help remove slack from the seat belt in the event of further reduce the risk of injury in the event of a a collision.
  • Page 74 SAFETY occupant’s mid-section. Slide the latch plate How To Engage The Automatic Locking Mode into the buckle until you hear a "click." 1. Buckle the combination lap and shoulder In Automatic Locking Mode, the shoulder belt is belt. automatically pre-locked. The seat belt will still 2.

  • Page 75: Supplemental Restraint Systems (Srs)

    SAFETY Air Bag System Components The ORC contains a backup power supply WARNING! (Continued) system that may deploy the air bag system even Occupant Restraint Controller (ORC)  if the battery loses power or it becomes Failure to replace the seat belt assembly ...
  • Page 76 SAFETY The Air Bag Warning Light does not come on  WARNING! during the four to eight seconds when the ignition switch is first in the MAR/ACC/ON/ Ignoring the Air Bag Warning Light in your RUN position. instrument panel could mean you won’t have the air bag system to protect you in a The Air Bag Warning Light remains on after ...
  • Page 77 SAFETY Front Air Bag Operation WARNING! WARNING! (Continued) Front Air Bags are designed to provide No objects should be placed over or near Never place a rear-facing child restraint in   additional protection by supplementing the seat the air bag on the instrument panel or front of an air bag.
  • Page 78 SAFETY The steering wheel hub trim cover and the Supplemental Side Air Bag Inflatable Curtains upper passenger side of the instrument panel (SABICs) separate and fold out of the way as the air bags This vehicle is equipped with Supplemental inflate to their full size.
  • Page 79 SAFETY The SABIC deploys downward, covering the side deploys the right Side Air Bags only. Vehicle WARNING! (Continued) windows. An inflating SABIC pushes the outside damage by itself is not a good indicator of edge of the headliner out of the way and covers whether or not Side Air Bags should have In order for the SABICs to work as intended, ...
  • Page 80 SAFETY may be in progress and whether deployment is WARNING! (Continued) WARNING! (Continued) appropriate. In the event the vehicle experiences a rollover or near rollover event, Seat belts (and child restraints where Relying on the Side Air Bags alone could ...
  • Page 81 SAFETY Supplemental Side Air Bags As the air bags deflate, you may see some NOTE:   smoke-like particles. The particles are a Front and Side Impact Sensors Air bag covers may not be obvious in the inte-   normal by-product of the process that gener- rior trim, but they will open during air bag ates the non-toxic gas used for air bag infla-...
  • Page 82 SAFETY NOTE: Maintaining Your Air Bag System After an accident, remember to cycle the igni- WARNING! tion to the STOP (OFF/LOCK) position and remove the key from the ignition switch to avoid Modifications to any part of the air bag ...

  • Page 83: Child Restraints

    SAFETY or less. The EDR in this vehicle is designed to vehicle manufacturer, other parties, such as WARNING! (Continued) record such data as: law enforcement, that have the special equipment, can read the information if they Do not attempt to modify any part of your ...
  • Page 84 SAFETY There are different sizes and types of restraints Before buying any restraint system, make sure NOTE: for children from newborn size to the child that it has a label certifying that it meets all For additional information, refer to http:// ...
  • Page 85 SAFETY Infant And Child Restraints seat with a harness for as long as possible, up WARNING! to the highest weight or height allowed by the Safety experts recommend that children ride Never place a rear-facing child restraint in child seat. ...
  • Page 86 SAFETY 1. Can the child sit all the way back against WARNING! WARNING! (Continued) the back of the vehicle seat? Never allow a child to put the shoulder belt After a child restraint is installed in the  2. Do the child’s knees bend comfortably over vehicle, do not move the vehicle seat under an arm or behind their back.
  • Page 87 SAFETY The seat belts in the passenger seating WARNING! positions are equipped with a Switchable Rear-facing infant restraints must never be Automatic Locking Retractor (ALR). This seat secured in the passenger seat of a vehicle belt is designed to keep the lap portion of the with a passenger air bag.
  • Page 88 SAFETY Installing A Child Restraint With A Switchable 5. To lock the seat belt, pull down on the Automatic Locking Retractor (ALR) shoulder part of the belt until you have pulled all the seat belt webbing out of the Child restraint systems are designed to be retractor.

  • Page 89: Transporting Pets

    SAFETY Transporting Pets WARNING! (Continued) WARNING! (Continued) Air Bags deploying in the front seat could harm Do not allow people to ride in any area of If it is necessary to sit in a parked vehicle   your pet. An unrestrained pet will be thrown your vehicle that is not equipped with seats with the engine running, adjust your about and possibly injured, or injure a...

  • Page 90: Safety Checks You Should Make Inside The Vehicle

    SAFETY Safety Checks You Should Make Inside The comes on intermittently or remains on while WARNING! Vehicle driving, have an authorized dealer service the vehicle immediately. An improperly attached, damaged, folded, or Seat Belts stacked floor mat, or damaged floor mat Refer to “Occupant Restraint Systems”...

  • Page 91: Periodic Safety Checks You Should Make Outside The Vehicle

    SAFETY Lights WARNING! (Continued) WARNING! (Continued) Have someone observe the operation of brake ONLY use the driver’s side floor mat on the If the vehicle carpet has been removed and   lights and exterior lights while you work the driver’s side floor area.

  • Page 92: Starting And Operating

    STARTING AND OPERATING STARTING THE ENGINE Automatic Transmission Cold Weather Operation (Below –22°F Or −30°C) The gear selector must be in the PARK or Before starting your vehicle, adjust your seat, NEUTRAL position before you can start the To ensure reliable starting at these adjust both inside and outside mirrors, and engine.

  • Page 93: After Starting

    STARTING AND OPERATING ENGINE BLOCK HEATER — IF EQUIPPED While cruising, brief full-throttle acceleration WARNING! (Continued) within the limits of local traffic laws contributes The engine block heater warms the engine, and to a good break-in. Wide-open throttle Do not attempt to push or tow your vehicle ...

  • Page 94: Parking Brake

    STARTING AND OPERATING PARKING BRAKE When parking on a hill, it is important to turn the WARNING! (Continued) front wheels toward the curb on a downhill Before leaving the vehicle, make sure that the grade and away from the curb on an uphill Be sure the parking brake is fully disen- ...

  • Page 95: Automatic Transmission

    STARTING AND OPERATING AUTOMATIC TRANSMISSION NOTE: WARNING! (Continued) You must press and hold the brake pedal while shifting out of PARK. Never leave children alone in a vehicle, or WARNING!  with access to an unlocked vehicle. Key Ignition Park Interlock It is dangerous to shift out of PARK or ...

  • Page 96: Six-Speed Automatic Transmission

    STARTING AND OPERATING NOTE: gear. Refer to "Electronic Range Select (ERS) Swivel seats that are unlocked can also prevent Operation" in this section for further the transmission gear selector from being information. moved out of the PARK position. To shift the NOTE: transmission out of the PARK position the first If the gear selector cannot be moved to the...
  • Page 97 STARTING AND OPERATING PARK (P) WARNING! WARNING! (Continued) This range supplements the parking brake by Never use the PARK position as a substi- Unintended movement of a vehicle could   locking the transmission. The engine can be tute for the parking brake. Always apply the injure those in or near the vehicle.
  • Page 98 STARTING AND OPERATING CAUTION! WARNING! (Continued) CAUTION! (Continued) Towing the vehicle, coasting, or driving for any Do not leave the ignition key in or near the DO NOT race the engine when shifting from   vehicle (or in a location accessible to chil- PARK or NEUTRAL into another gear range, other reason with the transmission in dren).
  • Page 99 STARTING AND OPERATING Operation” in this section for further which forward gear is selected. PARK, Your authorized dealer has diagnostic equip- information) to select a lower gear range. Under REVERSE, and NEUTRAL will continue to ment to assess the condition of your transmis- these conditions, using a lower gear range will operate.
  • Page 100 STARTING AND OPERATING Overdrive if the following conditions are switch a second time restores normal WARNING! present: operation. Normal operation is always the Do not downshift for additional engine default at engine start-up. If TOW/HAUL mode is The gear selector is in the DRIVE position. ...

  • Page 101: Power Steering

    STARTING AND OPERATING demonstrate that the transmission is able to NOTE: anticipated. Coordinate inspection efforts shift into and out of Overdrive. through an authorized dealer. Increased noise levels at the end of the  If the vehicle has not been driven for several steering wheel travel are considered normal ...

  • Page 102: Speed Control - If Equipped

    STARTING AND OPERATING SPEED CONTROL — IF EQUIPPED To Activate NOTE: The vehicle should be traveling at a steady Rotate the center ring upward on the Speed When engaged, the Speed Control takes over speed and on level ground before moving the Control lever to turn the system on.

  • Page 103: To Accelerate For Passing

    STARTING AND OPERATING Metric Speed (km/h) If the lever is continually held down, the set On steep hills, a greater speed loss or gain may  speed will continue to decrease until the occur so it may be preferable to drive without Tapping the Speed Control lever up SET (+) ...

  • Page 104: Parksense Rear Park Assist - If Equipped

    STARTING AND OPERATING PARKSENSE REAR PARK ASSIST — IF ParkSense Rear Park Assist Sensors If several obstacles are detected, the ParkSense Rear Park Assist system indicates EQUIPPED The four ParkSense Rear Park Assist sensors, the nearest obstacle. located in the rear fascia/bumper, monitor the The minimum height of a detectable obstacle The ParkSense Rear Park Assist system area behind the vehicle that is within the...

  • Page 105: Parksense Rear Park Assist Failure Indications

    STARTING AND OPERATING Audible And Visual Signals Supplied By The ParkSense Rear Park Assist System SIGNAL MEANING INDICATION Audible Signal (dashboard loudspeaker) • Sound pulses emitted at a rate that increases as the distance decreases. • Emits continuous tone at 12 inches (30 cm). An obstacle is present within the sensors' field Obstacle Distance •...

  • Page 106: Cleaning The Parksense System

    STARTING AND OPERATING unavailable, without reference to the sensor in Clean the Rear Park Assist sensors regularly,  WARNING! taking care not to scratch or damage them. failure condition. If even a single sensor fails, the entire system must be disabled. The system The sensors must not be covered with ice, Drivers must be careful when backing up ...

  • Page 107: Parkview Rear Back Up Camera

    STARTING AND OPERATING opened. The image will be displayed on the Distance To The Rear CAUTION! Zone touchscreen display along with a caution note Of The Vehicle ParkSense is only a parking aid and it is to “check entire surroundings” across the top of ...

  • Page 108: Refueling The Vehicle

    STARTING AND OPERATING CAUTION! WARNING! (Continued) To avoid vehicle damage, ParkView should A fire may result if fuel is pumped into a   only be used as a parking aid. The ParkView portable container that is inside of a camera is unable to view every obstacle or vehicle.

  • Page 109: Loose Fuel Filler Cap Message

    STARTING AND OPERATING VEHICLE LOADING NOTE: Gross Vehicle Weight Rating (GVWR) The Gross Vehicle Weight Rating (GVWR) is the When the fuel nozzle “clicks” or shuts off, the  As required by National Highway Traffic Safety total allowable weight of your vehicle. This fuel tank is full.

  • Page 110: Rim Size

    STARTING AND OPERATING Rim Size The best way to figure out the total weight of NOTE: your vehicle is to weigh it when it is fully loaded Refer to the “Vehicle Certification Label” affixed This is the rim size that is appropriate for the tire and ready for operation.
  • Page 111 STARTING AND OPERATING Gross Vehicle Weight Rating (GVWR) Gross Axle Weight Rating (GAWR) Trailer Sway Control The Gross Vehicle Weight Rating (GVWR) is the The Gross Axle Weight Rating (GAWR) is the The Trailer Sway Control (TSC) can be a total allowable weight of your vehicle.

  • Page 112: Trailer Hitch Classification

    STARTING AND OPERATING Weight-Distributing Hitch Trailer Hitch Classification WARNING! A weight-distributing system works by applying The following chart provides the industry An improperly adjusted Weight Distributing  leverage through spring (load) bars. They are standard for the maximum trailer weight a given Hitch system may reduce handling, typically used for heavier loads to distribute trailer hitch class can tow and should be used to...

  • Page 113: Trailer Towing Weights (Maximum Trailer Weight Ratings)

    STARTING AND OPERATING Trailer Hitch Classification Definitions Class Max. Trailer Hitch Industry Standards Class I - Light Duty 2,000 lbs (907 kg) Class II - Medium Duty 3,500 lbs (1,587 kg) Class III - Heavy Duty 5,000 lbs (2,267 kg) Class IV - Extra Heavy Duty 10,000 lbs (4,535 kg) Refer to the “Trailer Towing Weights (Maximum Trailer Weight Ratings)”...

  • Page 114: Towing Requirements

    STARTING AND OPERATING Consider the following items when computing CAUTION! (Continued) WARNING! (Continued) the weight on the rear axle of the vehicle: Then, during the first 500 miles (805 km) When hauling cargo or towing a trailer, do The tongue weight of the trailer. ...
  • Page 115 STARTING AND OPERATING Check for signs of tire wear or visible tire requirements where the trailer is to be towed  WARNING! (Continued) damage before towing a trailer. Refer to for trailer brake requirements. “Tires” in “Servicing And Maintenance” for Total weight must be distributed between ...

  • Page 116: Towing Tips

    STARTING AND OPERATING Towing Requirements — Trailer Lights And Wiring Whenever you pull a trailer, regardless of the trailer size, stoplights and turn signals on the trailer are required for motoring safety. The Trailer Tow Package may include a four- and seven-pin wiring harness.
  • Page 117 STARTING AND OPERATING Automatic Transmission Tow/Haul Mode Cooling System The DRIVE range can be selected when towing. To reduce potential for automatic transmission To reduce potential for engine and transmission The transmission controls include a drive overheating, activate TOW/HAUL mode when overheating, take the following actions: strategy to avoid frequent shifting when towing.

  • Page 118: Recreational Towing (Behind Motorhome, Etc.)

    STARTING AND OPERATING RECREATIONAL TOWING (BEHIND MOTORHOME, ETC.) Towing This Vehicle Behind Another Vehicle Towing Condition Wheels OFF the Ground Automatic Transmission Flat Tow NONE NOT ALLOWED Front Dolly Tow Rear NOT ALLOWED On Trailer NOTE: When towing your vehicle, always follow applicable state and provincial laws. Contact state and provincial Highway Safety offices for additional details. Recreational Towing 4.

  • Page 119: Driving Tips

    STARTING AND OPERATING DRIVING TIPS complete loss of vehicle control and stopping Flowing/Rising Water ability. To reduce this possibility, the following WARNING! Driving On Slippery Surfaces precautions should be observed: Slow down during rainstorms or when the Do not drive on or across a road or path ...
  • Page 120 STARTING AND OPERATING WARNING! (Continued) CAUTION! (Continued) Driving through standing water limits your Driving through standing water may cause   vehicle’s braking capabilities, which damage to your vehicle’s drivetrain compo- increases stopping distances. Therefore, nents. Always inspect your vehicle’s fluids after driving through standing water, drive (i.e., engine oil, transmission, axle, etc.) for slowly and lightly press on the brake pedal...

  • Page 121: In Case Of Emergency

    IN CASE OF EMERGENCY HAZARD WARNING FLASHERS will flash on and off to warn oncoming traffic of When you must leave the vehicle to seek an emergency. Push the switch a second time to assistance, the Hazard Warning Flashers will The Hazard Warning Flashers switch is located turn off the Hazard Warning flashers.

  • Page 122: Replacing Exterior Bulbs

    IN CASE OF EMERGENCY Exterior Bulbs Bulb Name Bulb Number Daytime Running Lamps (If Equipped) 7440 Front Side Marker Lamps Rear Tail/Stop Lamps 7443 Rear Turn Signal Lamps 7440NA Rear Backup Lamps Rear Side Marker Lamps Front Fog Lamps License Plate Lamps Front Roof Lamps WY5W Rear Roof Lamps...
  • Page 123 IN CASE OF EMERGENCY 11. Push socket back into reflector until it locks 4. Remove two lower retaining screws from Daytime Running Lamp (DRL)/Front Side back into place. the headlamp housing. Marker Lamp 12. Install access cap. 5. Pull Headlamp forward, disconnect the 1.
  • Page 124 IN CASE OF EMERGENCY 11. Install the two lower retaining screws on the 3. Remove bulb and replace as needed. 3. Remove the two (2) 17mm tail light headlamp housing. assembly fasteners. 4. Reinstall the bulb socket and rotate 12. Carefully reinstall the lower headlamp filler clockwise to lock in place.

  • Page 125: Replacing Interior Bulbs

    IN CASE OF EMERGENCY Replacing Interior Bulbs Cargo Lamp 1. Using a suitable tool, remove either the lamp above the back door or the sliding door lamp as needed and disconnect it. Cargo Lamp Bulb Location Dome Lamp Assembly Location 1 —...

  • Page 126: Fuses

    IN CASE OF EMERGENCY FUSES 3. Remove and replace the bulbs as needed. Underhood Fuses The Front Power Distribution Center is located WARNING! on the driver’s side of the engine compartment. To access the fuses, remove the cover. When replacing a blown fuse, always use ...
  • Page 127 IN CASE OF EMERGENCY Cavity Maxi Fuse Mini Fuse Description 40 Amp Orange – Electronic Stability Control (ESC) Pump 20 Amp Yellow (3.6 Gasoline – Starter Relay 3.6L (3.6 Gasoline Engine) Engine) Secondary Power Distribution Center (PDC) (Trans 50 Amp Red (3.6 Gasoline –...
  • Page 128 IN CASE OF EMERGENCY Cavity Maxi Fuse Mini Fuse Description – 30 Amp Green Windshield Wiper – 15 Amp Blue Fuel Pump Engine Control Module (ECM), Ignition Coils – 20 Amp Yellow (3.6 Gasoline Engine) – 20 Amp Yellow Electronic Stability Control (ESC) Valves KL15 Vacuum Pump Relay Coil (3.6 Gasoline Engine) —...

  • Page 129: Interior Fuses

    IN CASE OF EMERGENCY Interior Fuses The interior fuse panel is part of the Body Control Module (BCM) and is located on the driver's side under the instrument panel. Fuse Panel Cavity Locations Fuse Panel Cavity Mini Fuse Description 5 Amp Beige INT/A 7.5 Amp Brown Clearance Lights...

  • Page 130: Right Central Pillar Fuses

    IN CASE OF EMERGENCY Cavity Mini Fuse Description 20 Amp Yellow Passenger Power Window 5 Amp Beige INT (PAM – CCS – RRM – ECM) 7.5 Amp Brown INT (ORC) 5 Amp Beige INT (REAR CAMERA-AUX) 5 Amp Beige +30 (IPC) + FTM 7.5 Amp Brown Left Fog Lamp 7.5 Amp Brown...

  • Page 131: Jacking And Tire Changing

    IN CASE OF EMERGENCY Cavity Mini Fuse Description 7.5 Amp Brown Seat Heater 20 Amp Yellow Rear Left Windows Heater 20 Amp Yellow Rear Right Windows Heater 20 Amp Yellow Auxiliary Switch (From Battery) — If Equipped 20 Amp Yellow Auxiliary Switch (From Ignition) —...

  • Page 132: Spare Tire Removal

    IN CASE OF EMERGENCY Spare Tire Removal 1. Remove the spare tire before attempting to jack up the vehicle. Attach the lug bolt adapter to the winch extension and insert it into the winch mechanism. Lock Knob Jacking Tools 1 — Unlock Position 1 —...
  • Page 133 IN CASE OF EMERGENCY 2. Rotate the wheel wrench handle counter- clockwise until the spare tire is on the ground with enough cable slack to allow you to pull it out from under the vehicle. NOTE: The winch mechanism is designed for use with the winch extension tube only.

  • Page 134: Preparations For Jacking

    IN CASE OF EMERGENCY 5. Pull the retainer through the center of the 4. Place the transmission in PARK (P) or NOTE: wheel. REVERSE (R) for manual transmission. Passengers should not remain in the vehicle when the vehicle is being lifted or raised. 5.
  • Page 135 IN CASE OF EMERGENCY CAUTION! WARNING! (Continued) Do not attempt to raise the vehicle by jacking Do not get under the vehicle when it is on a  jack. If you need to get under a raised on locations other than those indicated in the vehicle, take it to a service center where it Jacking Instructions for this vehicle.
  • Page 136 IN CASE OF EMERGENCY NOTE: NOTE: The rear jacking location is located in front of The front jacking location is located behind the the rear tire and in front of the leaf spring front tire and in front of the driver/passenger mount.
  • Page 137 IN CASE OF EMERGENCY 11. Install the winch extension and rotate the WARNING! WARNING! wrench handle clockwise until the winch Raising the vehicle higher than necessary can To avoid the risk of forcing the vehicle off the mechanism operator hears “3 clicks” from the device to indicate the wheel is properly make the vehicle less stable.

  • Page 138: Wheel Covers

    IN CASE OF EMERGENCY For vehicles with aluminum wheels: Tire Service Kit Storage Using The Mode Select Knob And Hoses The center cap must be pushed out from the Your Tire Service Kit is equipped with the The Tire Service Kit is located under the rear to install the retainer and stow the tire.

  • Page 139: Tire Service Kit Usage Precautions

    IN CASE OF EMERGENCY Using The Deflation Button these components immediately at your orig-  WARNING! inal equipment vehicle dealer. Push the Deflation Button (9) to Do not attempt to seal a tire on the side of  reduce the air pressure in the tire if When the Tire Service Kit sealant is in a liquid ...

  • Page 140: Sealing A Tire With Tire Service Kit

    IN CASE OF EMERGENCY Sealing A Tire With Tire Service Kit (B) Setting Up To Use Tire Service Kit: WARNING! (Continued) (A) Whenever You Stop To Use Tire Service 1. Push in the Mode Select Knob (2) and turn A loose Tire Service Kit thrown forward in a ...
  • Page 141 IN CASE OF EMERGENCY (C) Injecting Tire Service Kit Sealant Into The the Sealant Mode position and not Air will decrease quickly from approximately Mode. Push the Power Button (1) to turn 70 psi (4.8 Bar) to the actual tire pressure Deflated Tire: On the Tire Service Kit.
  • Page 142 IN CASE OF EMERGENCY If the tire inflates to the recommended pressure (E) After Driving: CAUTION! (Continued) or is at least 26 psi (1.8 Bar) pressure within Pull over to a safe location. Refer to “(A) 15 minutes: Failure to reinstall the cap on the fitting at ...

  • Page 143: Jump Starting

    IN CASE OF EMERGENCY If the tire pressure is 19 psi (1.3 Bar) or higher: 6. Replace the Sealant Bottle (4) and Sealant click will be heard indicating the bottle is Hose (3) assembly at an authorized dealer locked into place. Release the button. 1.

  • Page 144: Preparations For Jump Start

    IN CASE OF EMERGENCY CAUTION! WARNING! (Continued) Do not use a portable battery booster pack or Batteries contain sulfuric acid that can  any other booster source with a system burn your skin or eyes and generate voltage greater than 12 Volts or damage to hydrogen gas which is flammable and explosive.

  • Page 145: Jump Starting Procedure

    IN CASE OF EMERGENCY Jump Starting Procedure 3. Connect the negative end (-) of the jumper Disconnecting The Jumper Cables cable to the negative (-) post of the booster 1. Disconnect the negative end (-) of the WARNING! battery. jumper cable from the remote negative (-) Failure to follow this jump starting procedure 4.

  • Page 146: Battery Location

    IN CASE OF EMERGENCY NOTE: CAUTION! There are steps that you can take to slow down Accessories plugged into the vehicle power an impending overheat condition: outlets draw power from the vehicle’s battery, If your Air Conditioner (A/C) is on, turn it off. ...

  • Page 147: Gear Selector Override

    IN CASE OF EMERGENCY 6. Move the gear selector to the NEUTRAL (N) CAUTION! position. Driving with a hot cooling system could 7. The vehicle may then be started in damage your vehicle. If the temperature NEUTRAL. gauge reads HOT (H), pull over and stop the vehicle.

  • Page 148: Towing A Disabled Vehicle

    IN CASE OF EMERGENCY for further information. Once the vehicle has CAUTION! CAUTION! been freed, push the “ESC OFF” switch again to Racing the engine or spinning the wheels may restore “ESC ON” mode. When “rocking” a stuck vehicle by shifting ...

  • Page 149: Automatic Transmission

    IN CASE OF EMERGENCY Proper towing or lifting equipment is required to Automatic Transmission CAUTION! prevent damage to your vehicle. Use only tow The manufacturer recommends towing your bars and other equipment designed for this Towing faster than 25 mph (40 km/h) or ...

  • Page 150: Event Data Recorder (Edr)

    IN CASE OF EMERGENCY EVENT DATA RECORDER (EDR) This vehicle is equipped with an Event Data Recorder (EDR). The main purpose of an EDR is to record data that will assist in understanding how a vehicle’s systems performed under certain crash or near crash-like situations, such as an air bag deployment or hitting a road obstacle.

  • Page 151: Servicing And Maintenance

    SERVICING AND MAINTENANCE SCHEDULED SERVICING “Instrument Cluster Display” in “Getting To Once A Month Or Before A Long Trip: Know Your Instrument Panel” for further Check engine oil level  Your vehicle is equipped with an automatic oil information. change indicator system. The oil change Check windshield washer fluid level ...

  • Page 152: Maintenance Plan

    SERVICING AND MAINTENANCE Maintenance Plan Required Maintenance Intervals Refer to the maintenance plan on the following pages for the required maintenance intervals. More frequent maintenance may be needed in severe conditions, such as dusty areas and very short trip driving. In some extreme conditions, additional maintenance not specified in the maintenance schedule may be required.
  • Page 153 SERVICING AND MAINTENANCE Mileage or time passed (whichever comes first) Or Years: Or Kilometers: Additional Inspections Inspect the CV/Universal joints. Inspect front suspension, tie rod ends, boot seals, and replace if necessary. Inspect the brake pads, replace as necessary. Additional Maintenance Replace the engine air filter.
  • Page 154 SERVICING AND MAINTENANCE Mileage or time passed (whichever comes first) Or Years: Or Kilometers: Flush and replace the engine coolant at 10 years or 150,000 miles (240,000 km) whichever comes first. Change the automatic transmission fluid and filter. Inspect and replace the PCV valve if necessary.

  • Page 155: Heavy Duty Use Of The Vehicle

    SERVICING AND MAINTENANCE Heavy Duty Use Of The Vehicle WARNING! Change engine oil at 4,000 miles (6,500 km) or You can be badly injured working on or  350 hours of engine run time if the vehicle is around a motor vehicle. Do only service operated in a dusty or off road environment, or work for which you have the knowledge and is operated predominately at idle or only very...

  • Page 156: Engine Compartment

    SERVICING AND MAINTENANCE ENGINE COMPARTMENT 3.6L Engine 1 — Washer Fluid Reservoir 5 — Power Distribution Center (Fuses) 2 — Engine Oil Fill 6 — Coolant Reservoir 3 — Engine Oil Dipstick 7 — Power Steering Reservoir 4 — Brake Fluid Reservoir...

  • Page 157: Checking Oil Level - Gas Engine

    SERVICING AND MAINTENANCE Checking Oil Level — Gas Engine operate the system for a few seconds to flush WARNING! out any residual water. To ensure proper lubrication of your vehicle's Battery fluid is a corrosive acid solution and The washer fluid reservoir will hold a full gallon ...

  • Page 158: Pressure Washing

    SERVICING AND MAINTENANCE DEALER SERVICE Engine Oil CAUTION! Change Engine Oil An authorized dealer has the qualified service It is essential when replacing the cables on  personnel, special tools, and equipment to The oil change indicator system will remind you the battery that the positive cable is perform all service operations in an expert that it is time to take your vehicle in for...

  • Page 159: Engine Oil Filter

    SERVICING AND MAINTENANCE American Petroleum Institute (API) Engine Oil location, refer to the “Engine Compartment” Disposing Of Used Engine Oil And Oil Filters illustration in this section. Identification Symbol Care should be taken in disposing of used engine oil and oil filters from your vehicle. Used This symbol means that the oil has NOTE: been certified by the American...

  • Page 160: Engine Air Cleaner Filter

    SERVICING AND MAINTENANCE Engine Air Cleaner Filter Air Conditioner Maintenance CAUTION! Refer to the “Maintenance Plan” in this section For best possible performance, your air Do not use chemical flushes in your air for the proper maintenance intervals. conditioner should be checked and serviced by conditioning system as the chemicals can an authorized dealer at the start of each warm NOTE:...
  • Page 161 SERVICING AND MAINTENANCE Cabin Air Filter (A/C Air Filter) 1. Remove the two screws that secure the filter retainer to the fresh air inlet, and Refer to the “Maintenance Plan” for the proper remove the filter retainer. maintenance intervals. WARNING! Do not remove the cabin air filter while the vehicle is running, or while the ignition is in the ACC or ON/RUN mode.

  • Page 162: Body Lubrication

    SERVICING AND MAINTENANCE Body Lubrication Operation of the wipers on dry glass for long complete exhaust system and adjacent body periods may cause deterioration of the wiper areas for broken, damaged, deteriorated, or Locks and all body pivot points, including such blades.

  • Page 163: Cooling System

    SERVICING AND MAINTENANCE NOTE: Cooling System CAUTION! Intentional tampering with emissions control WARNING! The catalytic converter requires the use of systems can result in civil penalties being  unleaded fuel only. Leaded gasoline will assessed against you. You or others can be badly burned by hot ...
  • Page 164 SERVICING AND MAINTENANCE Coolant Checks Selection Of Coolant This vehicle has not been designed for use  with propylene glycol-based engine coolant Check the engine coolant (antifreeze) Refer to “Fluids And Lubricants” in “Technical (antifreeze). Use of propylene glycol-based protection every 12 months (before the onset of Specifications”...
  • Page 165 SERVICING AND MAINTENANCE Please review these recommendations for NOTE: WARNING! using Organic Additive Technology (OAT) engine It is the owner's responsibility to maintain the  coolant (antifreeze) that meets the Do not open hot engine cooling system.  proper level of protection against freezing Never add engine coolant (antifreeze) when requirements of FCA Material Standard according to the temperatures occurring in...

  • Page 166: Brake System

    SERVICING AND MAINTENANCE Coolant Level contents of the coolant expansion bottle Brake System must also be protected against freezing. The coolant expansion bottle provides a quick In order to ensure brake system performance, visual method for determining that the coolant all brake system components should be If frequent engine coolant (antifreeze) addi- ...

  • Page 167: Automatic Transmission (3.6L Gasoline Engine Only)

    SERVICING AND MAINTENANCE With disc brakes the fluid level can be expected Automatic Transmission (3.6L Gasoline WARNING! (Continued) to fall as the brake linings wear. However, an Engine Only) unexpected drop in fluid level may be caused by To avoid contamination from foreign matter ...

  • Page 168: Raising The Vehicle

    SERVICING AND MAINTENANCE Special Additives Fluid Level Check Fluid And Filter Changes The manufacturer strongly recommends The fluid level is preset at the factory and does Refer to the “Maintenance Plan” in this section against using any special additives in the not require adjustment under normal operating for the proper maintenance intervals.
  • Page 169 SERVICING AND MAINTENANCE Tire Markings NOTE: Temporary spare tires are designed for  temporary emergency use only. Temporary P (Passenger) — Metric tire sizing is based on  high pressure compact spare tires have the US design standards. P-Metric tires have the letter “T”...
  • Page 170 SERVICING AND MAINTENANCE Tire Sizing Chart EXAMPLE: Example Size Designation: P215/65R15XL 95H, 215/65R15 96H, LT235/85R16C, T145/80D18 103M, 31x10.5 R15 LT P = Passenger car tire size based on US design standards, or "..blank.." = Passenger car tire based on European design standards, or LT = Light truck tire based on US design standards, or T or S = Temporary spare tire or 31 = Overall diameter in inches (in)
  • Page 171 SERVICING AND MAINTENANCE EXAMPLE: H = Speed Symbol A symbol indicating the range of speeds at which a tire can carry a load corresponding to its load index under certain operating conditions  The maximum speed corresponding to the speed symbol should only be achieved under specified operating conditions (i.e., tire pressure, vehicle ...
  • Page 172 SERVICING AND MAINTENANCE EXAMPLE: ABCD = Code used by the tire manufacturer (one to four digits) 03 = Number representing the week in which the tire was manufactured (two digits) 03 means the 3rd week  01 = Number representing the year in which the tire was manufactured (two digits) 01 means the year 2001 ...
  • Page 173 SERVICING AND MAINTENANCE Term Definition Vehicle manufacturer's recommended cold tire inflation pressure as Recommended Cold Tire Inflation Pressure shown on the tire placard. A label permanently attached to the vehicle describing the vehicle’s Tire Placard loading capacity, the original equipment tire sizes and the recommended cold tire inflation pressures.
  • Page 174 SERVICING AND MAINTENANCE Tire And Loading Information Placard Loading Steps For Determining Correct Load Limit— The vehicle maximum load on the tire must not exceed the load carrying capacity of the tire on (1) Locate the statement “The combined your vehicle. You will not exceed the tire's load weight of occupants and cargo should carrying capacity if you adhere to the loading never exceed XXX kg or XXX lbs.”...
  • Page 175 SERVICING AND MAINTENANCE exceed the available cargo and luggage Metric Example For Load Limit on how to calculate total load, cargo/ luggage, and towing capacities of your load capacity calculated in Step 4. For example, if “XXX” amount equals 635 kg vehicle with varying seating configurations and there will be five 68 kg passengers in your (6) If your vehicle will be towing a trailer,...

  • Page 176: Tires - General Information

    SERVICING AND MAINTENANCE Safety Both underinflation and overinflation affect the WARNING! stability of the vehicle and can produce a feeling WARNING! Overloading of your tires is dangerous. of sluggish response or over responsiveness in Overloading can cause tire failure, affect the steering.
  • Page 177 SERVICING AND MAINTENANCE Tire Inflation Pressures maximum inflation pressure molded into the reduced vehicle loading may be required for tire sidewall. high-speed vehicle operation. Refer to an The proper cold tire inflation pressure is listed authorized tire dealer or original equipment Check tire pressures more often if subject to a on the driver's side B-Pillar or rear edge of the vehicle dealer for recommended safe operating...
  • Page 178 SERVICING AND MAINTENANCE Tire Repair Run Flat Tires — If Equipped Tire Spinning If your tire becomes damaged, it may be Run Flat tires allow you the capability to drive When stuck in mud, sand, snow, or ice repaired if it meets the following criteria: 50 miles (80 km) at 50 mph (80 km/h) after a conditions, do not spin your vehicle's wheels rapid loss of inflation pressure.
  • Page 179 SERVICING AND MAINTENANCE Tread Wear Indicators Life Of Tire NOTE: Wheel Valve Stem must be replaced as well Tread wear indicators are in the original The service life of a tire is dependent upon when installing new tires due to wear and tear equipment tires to help you in determining varying factors including, but not limited to: in existing tires.

  • Page 180: Tire Types

    SERVICING AND MAINTENANCE See the Tire Sizing Chart example found in the WARNING! CAUTION! “Tire Safety Information” section of this manual for more information relating to the Load Index Do not use a tire, wheel size, load rating, or Replacing original tires with tires of a ...

  • Page 181: Spare Tires - If Equipped

    SERVICING AND MAINTENANCE For more information, contact an authorized Snow tires generally have lower speed ratings CAUTION! dealer. than what was originally equipped with your vehicle and should not be operated at Because of the reduced ground clearance, do Summer tires do not contain the all season sustained speeds over 75 mph (120 km/h).
  • Page 182 SERVICING AND MAINTENANCE Compact Spare Tire — If Equipped Inflate collapsible tire only after the wheel is WARNING! properly installed to the vehicle. Inflate the The compact spare is for temporary emergency Compact and collapsible spares are for collapsible tire using the electric air pump use only.

  • Page 183: Wheel And Wheel Trim Care

    SERVICING AND MAINTENANCE Full Size Spare — If Equipped and reinstall on the vehicle at the first Your wheels are susceptible to deterioration opportunity. caused by salt, sodium chloride, magnesium The full size spare is for temporary emergency chloride, calcium chloride, etc., and other road use only.

  • Page 184: Tire Chains And Traction Devices

    SERVICING AND MAINTENANCE recommended or select a non-abrasive, Dark Vapor Chrome, Black Satin Chrome, or Install on front tires only.  non-acidic cleaner for aluminum or chrome Low Gloss Clear Coat Wheels For LT225/75R16 and 215/75R16C tires  wheels. use of a Quality Chain Corp Light Truck CAUTION! Highway Service (Non-Cam) tire chain or CAUTION!

  • Page 185: Tire Rotation Recommendations

    SERVICING AND MAINTENANCE DEPARTMENT OF TRANSPORTATION These effects can be reduced by timely rotation CAUTION! (Continued) of tires. The benefits of rotation are especially UNIFORM TIRE QUALITY GRADES worthwhile with aggressive tread designs such Install device as tightly as possible and ...

  • Page 186: Traction Grades

    SERVICING AND MAINTENANCE significantly from the norm due to Temperature Grades WARNING! variations in driving habits, service The Temperature grades are A (the The temperature grade for this tire is practices, and differences in road highest), B, and C, representing the tire's established for a tire that is properly inflated characteristics and climate.

  • Page 187: Bodywork

    SERVICING AND MAINTENANCE BODYWORK Insects, tree sap and tar Preserving The Bodywork  Salt in the air near seacoast localities Washing  Protection From Atmospheric Agents Wash your vehicle regularly. Always wash  Atmospheric fallout/industrial pollutants  Vehicle body care requirements vary according your vehicle in the shade using Mopar Car to geographic locations and usage.

  • Page 188: Interiors

    SERVICING AND MAINTENANCE If a lot of driving is done on gravel roads, Blot any remaining stain with a clean, damp   CAUTION! (Continued) consider mud or stone shields behind each towel. wheel. Use of power washers exceeding 1,200 psi ...

  • Page 189: Plastic And Coated Parts

    SERVICING AND MAINTENANCE Cleaning Plastic Instrument Cluster Lenses with any liquid. Please do not use polishes, oils, WARNING! cleaning fluids, solvents, detergents, or The lenses in front of the instruments in this A frayed or torn belt could rip apart in a ammonia-based cleaners to clean your leather vehicle are molded in clear plastic.

  • Page 190: Glass Surfaces

    SERVICING AND MAINTENANCE Glass Surfaces This will loosen any remaining debris. Rinse the liner thoroughly under warm running water. All glass surfaces should be cleaned on a Shake the excess water from the liner and dry regular basis with Mopar Glass Cleaner, or any the outer surfaces with a clean soft cloth.

  • Page 191: Technical Specifications

    TECHNICAL SPECIFICATIONS IDENTIFICATION DATA BRAKE SYSTEM WHEEL AND TIRE TORQUE SPECIFICATIONS Your vehicle is equipped with dual hydraulic Proper lug nut/bolt torque is very important to Vehicle Identification Number brake systems. If either of the two hydraulic ensure that the wheel is properly mounted to The Vehicle Identification Number (VIN) is found systems loses normal capability, the remaining the vehicle.

  • Page 192: Fuel Requirements

    TECHNICAL SPECIFICATIONS After 25 miles (40 km), check the lug nut/bolt However, if the engine is heard making a heavy torque to be sure that all the lug nuts/bolts are knocking sound, see your dealer immediately. properly seated against the wheel. Use of gasoline with an octane number lower than 87 can cause engine failure and may void WARNING!

  • Page 193: Materials Added To Fuel

    TECHNICAL SPECIFICATIONS Materials Added To Fuel Gasoline/Oxygenate Blends Do Not Use E-85 In Non-Flex Fuel Vehicles Besides using unleaded gasoline with the Some fuel suppliers blend unleaded gasoline Non-Flex Fuel Vehicles (FFV) are compatible proper octane rating, gasolines that contain with oxygenates such as ethanol.

  • Page 194: Cng And Lp Fuel System Modifications

    TECHNICAL SPECIFICATIONS CNG And LP Fuel System Modifications Fuel System Cautions CAUTION! (Continued) Modifications that allow the engine to run on CAUTION! The use of fuel additives, which are now  Compressed Natural Gas (CNG) or Liquid being sold as octane enhancers, is not Propane (LP) may result in damage to the Follow these guidelines to maintain your recommended.

  • Page 195: Carbon Monoxide Warnings

    TECHNICAL SPECIFICATIONS Carbon Monoxide Warnings WARNING! Carbon monoxide (CO) in exhaust gases is deadly. Follow the precautions below to prevent carbon monoxide poisoning: Do not inhale exhaust gases. They contain  carbon monoxide, a colorless and odorless gas, which can kill. Never run the engine in a closed area, such as a garage, and never sit in a parked vehicle with the engine running for an extended period.

  • Page 196: Fluid Capacities

    TECHNICAL SPECIFICATIONS FLUID CAPACITIES Metric Fuel (Approximate) 24 Gallons 90 Liters Engine Oil With Filter 3.6L Engine (SAE 5W-20, API Certified) 6 Quarts 5.6 Liters Cooling System * 3.6L Engine (Mopar Antifreeze/Engine Coolant 10 Year/150,000 Mile Formula or 10.5 Quarts 10 Liters equivalent) FLUIDS AND LUBRICANTS...
  • Page 197 TECHNICAL SPECIFICATIONS CAUTION! CAUTION! (Continued) Mixing of engine coolant (antifreeze) other This vehicle has not been designed for use   than specified Organic Additive Technology with propylene glycol-based engine coolant (OAT) engine coolant (antifreeze), may (antifreeze). Use of propylene glycol-based result in engine damage and may decrease engine coolant (antifreeze) is not recom- corrosion protection.

  • Page 198: Chassis

    TECHNICAL SPECIFICATIONS Chassis Component Fluid, Lubricant, Or Genuine Part Use Only ATF+4 Automatic Transmission Fluid. Failure to use ATF+4 fluid Automatic Transmission may affect the function or performance of your transmission. We recommend Mopar ATF+4 Fluid. We recommend you use Mopar DOT 4. Brake Master Cylinder DOT 4 brake fluid must be changed every two years regardless of mileage.

  • Page 199: Multimedia

    MULTIMEDIA CYBERSECURITY NOTE: WARNING! FCA US LLC or your dealer may contact you Your vehicle may be a connected vehicle and  It is not possible to know or to predict all of  directly regarding software updates. may be equipped with both wired and wireless the possible outcomes if your vehicle’s networks.

  • Page 200: Uconnect Settings

    MULTIMEDIA UCONNECT SETTINGS Lights, Doors & Locks, Engine off Options, Audio, Phone (if equipped), SiriusXM® Setup (if The Uconnect system uses a combination of equipped), Restore Settings, and Clear buttons on the touchscreen and buttons on the Personal Data. faceplate located on the center of the NOTE: instrument panel that allows you to access and change the customer programmable features.
  • Page 201 MULTIMEDIA Display After pressing the Display button on the touchscreen, the following settings will be available: Setting Name Selectable Options Display Mode Auto Manual Display Brightness With Headlights Up Arrow Button Down Arrow Button NOTE: This feature is only available in Manual Display Mode. Display Brightness With the Up Arrow Button Down Arrow Button...
  • Page 202 MULTIMEDIA Units — If Equipped After pressing the Units button on the touchscreen, the following settings will be available: Setting Name Selectable Options Units Metric Custom NOTE: The “Custom” option allows you to set the “Distance” (mi, or km), “Fuel Consumption” [MPG (US), MPG (UK), L/100 km, or km/L] (if equipped), and “Temperature”...
  • Page 203 MULTIMEDIA Setting Name Selectable Options Set Date Month Year NOTE: By selecting this setting, the day and month can be updated. The selectable days range from 1–31 (depending on month). The selectable months consist of Jan/Feb/March/April/May/June/July/Aug/Sept/Oct/Nov/Dec. Sync Time — If Equipped NOTE: When this setting is selected, the time will set automatically based upon GPS location.
  • Page 204 MULTIMEDIA Setting Name Selectable Options NOTE: When the “Daytime Running Lights” feature is selected, the daytime running lights can be turned On or Off. This feature is only available if allowed by law in the country of the vehicle purchase. Doors &...
  • Page 205 MULTIMEDIA Audio After pressing the Audio button on the touchscreen, the following settings will be available: Setting Name Selectable Options Equalizer – NOTE: When in this display, you may adjust the “Bass”, “Mid”, and “Treble” settings. Adjust the settings with the + and – setting buttons on the touchscreen or by selecting any point on the scale between the + and –...
  • Page 206 MULTIMEDIA Setting Name Selectable Options AUX Volume Offset – NOTE: This feature provides the ability to tune the audio level for portable devices connected through the AUX input. Auto Play NOTE: The Auto Play feature allows a media device to begin playing when the media device is plugged in. To make your selection, press the On or Off buttons to activate or deactivate Auto Play.
  • Page 207 MULTIMEDIA Setting Name Selectable Options Channel Skip List of Channels NOTE: SiriusXM® can be programmed to designate a group of channels that are the most desirable to listen to or to exclude undesirable channels while scanning. This feature allows you to select the channels you would like to skip. Subscription Information Sirius ID NOTE:...

  • Page 208: Safety And General Information

    MULTIMEDIA Clear Personal Data After pressing the Clear Personal Data button on the touchscreen, the following settings will be available: Setting Name Selectable Options Clear Personal Data NOTE: When this feature is selected, it will remove personal data including Bluetooth® devices and presets. SAFETY AND GENERAL INFORMATION Do NOT attach any object to the touchscreen.

  • Page 209: Uconnect 3/3 Nav With 5-Inch Display

    MULTIMEDIA NOTE: Do not spray any liquid or caustic chemicals  Many features of this system are speed depen- directly on the screen! Use a clean and dry microfiber lens cleaning cloth in order to dent. For your own safety, it is not possible to clean the touchscreen.
  • Page 210 MULTIMEDIA 6 — NAV or COMPASS 11 — SCREEN ON/OFF CAUTION! Push the NAV button on the faceplate to display Push the SCREEN ON/OFF button on the Do NOT attach any object to the touchscreen, the current direction of the vehicle. faceplate to turn the touchscreen on or off.

  • Page 211: Radio Mode

    MULTIMEDIA Radio Mode The radio is equipped with the following modes: Enter/Browse And Tune/Scroll Control Turn the rotary TUNE/SCROLL control knob  Operating Radio Mode clockwise to increase or counterclockwise to AM (SW/LW/MW) – If Equipped  decrease the radio station frequency. SiriusXM®...
  • Page 212 MULTIMEDIA During a Seek Down function, if the radio station or channel. Press the Tune button NFL® game, Oprah Radio, every MLB® and reaches the starting station after passing located at the bottom of the radio screen. NHL® game, every NASCAR® race, Martha through the entire band two times, the radio will Stewart and more.
  • Page 213 MULTIMEDIA This functionality is only available for radios desired numbered button for more that two 3. The Audio Menu displays the following equipped with a Satellite receiver. To receive seconds or until you hear a confirmation beep. options for you to customize your audio satellite radio, the vehicle needs to be outside settings.

  • Page 214: Media Mode

    MULTIMEDIA Loudness — If Equipped Media Mode Seek Up/Seek Down Press the Loudness button to select the Seek Up /Seek Down Operating Media Mode Loudness feature. When this feature is Press and release the Right Arrow button on Media Mode is entered by pushing the MEDIA activated it improves sound quality at lower the touchscreen for the next selection.
  • Page 215 MULTIMEDIA Repeat faceplate. Once in “Media Mode”, press the touchscreen. Press the Exit button on the Source button on the touchscreen and select touchscreen if you wish to cancel the browse Press the Repeat button on the touchscreen to “USB”. function.

  • Page 216: Phone Mode

    MULTIMEDIA AUX Mode Phone Mode The Uconnect Phone is a voice-activated, hands-free, in-vehicle communications system AUX Mode is entered by inserting a AUX device Operating Phone Mode with Voice Command Capability. Refer to using a stereo cable with a 3.5 mm audio jack “Uconnect Voice Recognition”...
  • Page 217 MULTIMEDIA Main Functions Connecting/Disconnecting A Mobile Phone 4. Press the Yes button to start the pairing procedure search for the Uconnect device Or Bluetooth® Device The buttons on the display can be used to: on the mobile phone. If No is selected the Compose phone numbers (using the graphic ...
  • Page 218 MULTIMEDIA NOTE: For further details, refer to your mobile phone The device connected is highlighted in the list  owner's handbook. The priority is determined according to the Disconnection  order of connection for mobile phones which NOTE: To disconnect a specific mobile phone or are not set as favorite.
  • Page 219 MULTIMEDIA NOTE: phone. The changes are transferred and Recent Calls updated to Uconnect Phone on the next The list of the last calls made for each of the If supported, the download and update begin  phone connection. following call types can be displayed: as soon as the Bluetooth®...
  • Page 220 MULTIMEDIA Answering An Incoming Call steering wheel to answer the call and put the Reading Messages ongoing call on hold. Call Controls The system can read the messages received by the mobile phone. The buttons on the display allow the following NOTE: phone call functions to be managed: To use this function the mobile phone must...

  • Page 221: Navigation Mode - If Equipped

    MULTIMEDIA cation option on the phone must be enabled, A Point of Interest (POI) near your current 3. Type Of Search: Press this button to change  this option is usually available on the phone, in location the type of search to any of the following: the Bluetooth®...
  • Page 222 MULTIMEDIA Near Destination: When a route has been numbers and more symbols. Select the ABC  planned, you can select this option to use button to go back to the general keyboard. your destination as the center of your Planning A Route — Searching For A City Center search.
  • Page 223 MULTIMEDIA NOTE: 1. Use the keyboard to enter the name of the The city center location is shown on the map. POI that you want to plan a route to. 4. Select Drive. NOTE: When searching, the whole map is selected. If you want to change how the search is done, select the button to the right of the search box.
  • Page 224 MULTIMEDIA 4. Select a suggestion for your destination. Planning A Route Using My Places Finding A Parking Lot 5. To plan a route to this destination, select 1. Select the Main Menu button to open the 1. Press the Parking button from the the drive button.
  • Page 225 MULTIMEDIA Finding A Gas Station The guidance view will be shown automat- Press “Let’s GO.” Guidance to your destination ically once you start driving. will automatically begin, and the guidance view 1. Select the Main Menu button to open the appears automatically as you begin driving.
  • Page 226 MULTIMEDIA Avoid Part Of Route Show Instructions You route will be recalculated to include your stop. Press the button to avoid part of the current Press the button to see a list of turn-by-turn Change Route Type route. instructions for your planned route. Press the button to change the type of route You are shown a list of the sections that make...
  • Page 227 MULTIMEDIA the Delete button. The stop will be removed Using Voice Control NOTE: from your route and your route will be recalcu- For accurate results, speak normally without WARNING! lated. trying to articulate words in an unnatural way. If there is excessive road noise, for example, you ALWAYS drive safely with your hands on the Play Route Or Track Preview may need to speak directly into the microphone.
  • Page 228 MULTIMEDIA travel, change the 2D and 3D default settings. 2 — Instruction Panel 5 — Speed Panel Refer to “Settings” within this section for more Press this button to view the following Press this button to view the following information. information: information (if available): The direction of your next turn...
  • Page 229 MULTIMEDIA Advanced Lane Guidance About Lane Guidance NOTE: Lane guidance is not available for all intersec- tions or in all countries. Your navigation system helps you prepare for highway exits and junctions by showing the correct driving lane for your planned route. Lane Guidance Map View As you approach an exit or junction, the lane you...
  • Page 230 MULTIMEDIA NOTE: 7. Main Menu Button Read Road Numbers Out Loud (if equipped):  Use this setting to control whether road For more information on how to set your home Press this button to open the Main Menu. location or add locations to My Places, refer to numbers are read out loud as part of naviga- 8.
  • Page 231 MULTIMEDIA Settings Arrival Information Show Previews Of Highway Exits In the settings menu, select “Arrival Select this setting to control the full screen About Settings Information” to change the following settings: preview when you approach highway exits. You can change the way your Show Remaining Distance: Select this setting Automatic Map View Switching navigation system looks and behaves.
  • Page 232 MULTIMEDIA Voices Setting Shortest Route warned, or warned only if you are speeding.  The following options are available: Select this setting to change how instructions You can choose whether you would like the are read out loud. Refer to “Voices” in the navigation system to chose the shortest When speeding: This warning is given ...
  • Page 233 MULTIMEDIA Points Of Interest called “Points of Interest.” You can also NOTE: select a POI category to only see POI Your navigation system will calculate a route, About Points Of Interest search results from that category. and guidance to your destination will begin. Points Of Interest (POI), are useful places on the Guidance view will begin as soon as you start map.
  • Page 234 MULTIMEDIA Using My Places 3. Press the three vertical dots to the right of the name to open the pop-up menu. You can use My Places as a way of navigating to a place without having to enter the address. To 4.
  • Page 235 MULTIMEDIA 3. Select the desired location, and then press Deleting A Location From My Places About: Press this button to view information  “Show in map”. about your Uconnect system. This informa- Deleting A Recent Destination From My Places tion includes: 4.
  • Page 236 MULTIMEDIA Use With Care TomTom® shall not be liable for technical or Data Source © 2019 TomTom® All rights editorial errors or omissions contained herein, reserved. Use of TomTom® navigation while driving still nor for incidental or consequential damages means that you need to drive with due care and The software included in this product contains resulting from the performance or use of this attention.

  • Page 237: Steering Wheel Audio Controls

    MULTIMEDIA STEERING WHEEL AUDIO CONTROLS IPOD®/USB/MP3 CONTROL — IF EQUIPPED Radio Operation Pushing the top of the right-hand switch will The remote sound system controls are located The USB Port and Auxiliary Jack is located on “Scan” up for the next listenable station, and on the surface of the steering wheel.

  • Page 238: Usb Charging Port

    MULTIMEDIA RAM TELEMATICS - IF EQUIPPED USB Charging Port Manually enter the VIN(s) or upload a CSV file  with your VINs. A vehicle name is optional The USB connector port can be used for Ram Telematics is designed to help improve and can be added later.

  • Page 239: Radio Operation And Mobile Phones

    MULTIMEDIA RADIO OPERATION AND MOBILE PHONES Interference Statement The radio manufacturer believes the internal wireless radio is safe for use by consumers. The This device complies with Part 15, 22, 24, and Under certain conditions, the mobile phone level of energy emitted is far less than the 27 of the FCC and Industry Canada being on in your vehicle can cause erratic or electromagnetic energy emitted by wireless...

  • Page 240: Uconnect Voice Recognition

    MULTIMEDIA UCONNECT VOICE RECOGNITION Le présent appareil est conforme aux CNR NOTE: d`Innovation, Science and Economic This equipment has been tested and found to  Introducing Uconnect Development applicables aux appareils radio comply with the limits for a Class B digital exempts de licence.

  • Page 241: Basic Voice Commands

    MULTIMEDIA 4. Each time you give a Voice Command, you Basic Voice Commands Radio must first push either the VR or Phone The basic Voice Commands below can be given Use your voice to quickly get to the AM, FM, or button , wait until after the beep, then at any point while using your Uconnect system.

  • Page 242: Media

    MULTIMEDIA Media Phone Voice Text Reply Uconnect offers connections via USB, Making and answering hands-free phone calls Uconnect will announce incoming text Bluetooth®, and Auxiliary ports. Voice operation is easy with Uconnect. When the Phonebook messages. Push the VR button or Phone button is only available for connected USB and iPod®...

  • Page 243: General Information

    MULTIMEDIA General Information brouillage est susceptible d'en compro- PRE-DEFINED VOICE TEXT REPLY mettre le fonctionnement. The following regulatory statement applies to all RESPONSES Radio Frequency (RF) devices equipped in this La operación de este equipo está sujeta a las I’ll call you I need See you in vehicle:...
  • Page 244 MULTIMEDIA Uconnect System Support: US residents visit DriveUconnect.com or call:  1-877-855-8400 (24 hours a day 7 days a week) Canadian residents visit DriveUconnect.ca or  call: 1-800-465-2001 (English) or 1-800-387-9983 (French) Mon. – Fri., 8:00 am – 8:00 pm, ET Sat., 9:00 am –...

  • Page 245: Customer Assistance

    CUSTOMER ASSISTANCE SUGGESTIONS FOR OBTAINING SERVICE minimal daily charge. If you need a rental, it is If for some reason you are still not satisfied,  advisable to make these arrangements when talk to the general manager or owner of the FOR YOUR VEHICLE authorized dealer.

  • Page 246: Fca Us Llc Customer Center

    CUSTOMER ASSISTANCE FCA US LLC Customer Center Customer Assistance For The Hearing Or weeks of the vehicle delivery date. If you have Speech Impaired (TDD/TTY) any questions about the service contract, call P.O. Box 21–8004 the manufacturer's Service Contract National To assist customers who have hearing Auburn Hills, MI 48321–8004 Customer Hotline at (800) 521-9922 (Canadian...

  • Page 247: Warranty Information

    CUSTOMER ASSISTANCE REPORTING SAFETY DEFECTS Avenue, SE., West Building, Washington, WARNING! D.C. 20590. You can also obtain other In The 50 United States And Engine exhaust (internal combustion engines information about motor vehicle safety only), some of its constituents, and certain Washington, D.C.

  • Page 248: Publication Order Forms

    CUSTOMER ASSISTANCE PUBLICATION ORDER FORMS Owner's Manuals These Owner's Manuals have been prepared To order the following manuals, you may use with the assistance of service and engineering either the website or the phone numbers listed specialists to acquaint you with specific FCA US below.

  • Page 249: Index

    INDEX Alarm ....162 ........13 ........... 48 Adding Engine Coolant (Antifreeze) Security Alarm Battery ........155 .........48 Adding Washing Fluid Alarm System Charging System Light ..........191 ..........13 ....10 Additives, Fuel Security Alarm Keyless Key Fob Replacement ............. 74 ............88 Air Bag Alterations/Modifications Belts, Seat ........
  • Page 250 ..........29 Climate Control Dimmer Switch ..........105 ............29 .............25 Camera, Rear Manual Headlight ..........194 .............32 Capacities, Fluid Rear Dipsticks ........90 ......166 Caps, Filler Cold Weather Operation Automatic Transmission ............106 ........180 ..........99 Fuel Compact Spare Tire Power Steering ..........154 .......... 244 .........
  • Page 251 Engine ............154 Fuel ............... 190 Air Cleaner ..........158 Filters Additives ........... 191 Block Heater ..........91 Air Cleaner ..........158 Clean Air ........... 190 Break-In Recommendations ......91 Air Conditioning ........35 Ethanol ............. 191 Compartment ..........154 Engine Oil ........157 Filler Cap (Gas Cap) ........
  • Page 252 ........22 Inside Rearview Mirror ........42 ..........26 Hazard Instrument Cluster Lane Change Assist ............44 ..........67 Driving Through Flowing, Rising, Or Shallow Display Lap/Shoulder Belts ........117 ....187 ............89 Standing Water Instrument Panel Lens Cleaning Latches ......119 ......26 ............37 Hazard Warning Flashers Interior And Instrument Lights Hood ..........
  • Page 253 Security Alarm ..........50 Modifications/Alterations Synthetic ........... 157 Service ............119 Vehicle ............8 Viscosity ........... 157 Tire Pressure Monitoring (TPMS) ....61 Monitor, Tire Pressure System ......61 Onboard Diagnostic System ......54 Traction Control ........... 59 Mopar Parts ..........245 Operating Precautions ........54 Turn Signals ........
  • Page 254 ..........105 ........145 Rear Camera Adjustable Upper Shoulder Belt Shift Lever Override ........102 ..........69 ..........67 Rear ParkSense System Anchorage Shoulder Belts ..........22 ....71 ..........53 Rearview Mirror Automatic Locking Retractor (ALR) Signals, Turn ........116 ...........81 ......182 Recreational Towing Child Restraints Snow Chains (Tire Chains) ........190 ......71...
  • Page 255 Tires ........89 Towing ..........108 Aging (Life Of Tires) ........177 Disabled Vehicle ........146 Uconnect Air Pressure ..........174 Guide ............111 Uconnect Settings ........10 Chains ............182 Recreational ..........116 Uconnect Settings Changing ......... 129 Weight ............111 Customer Programmable Features ...
  • Page 256 ......181 Wheel And Wheel Tire Care ......181 Wheel And Wheel Tire Trim ..........36 Wind Buffeting ..........34 Window Fogging ............35 Windows ............35 Power ........88 Windshield Defroster .......28 Windshield Washers ............28 Fluid .......160 Windshield Wiper Blades ...........
  • Page 259 The driver’s primary responsibility is the safe operation of the vehicle. Driving while distracted can result in loss of vehicle control, resulting in an accident and personal injury. FCA US LLC strongly recommends that the driver use extreme caution when using any device or feature that may take their attention off the road.
  • Page 260 Whether it is providing information about specific product features, taking a tour through your vehicle’s heritage, knowing what steps to take following an accident or scheduling your next appointment, we know you will find the app an important extension of your Ram vehicle. Simply download the app, select your make and model and enjoy the ride.

Table of Contents
